Wyrestorm EXP-CON-AUD-H2 User manual

Digital & Analog Audio Extractor
with 18Gbps HDMI Passthrough
EXP-CON-AUD-H2 Quickstart Guide
Copyright © 2020 WyreStorm Technologies | wyrestorm.com
EXP-CON-AUD-H2 Quickstart Guide | 200317
UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)
[email protected]
1 of 4
WyreStorm recommends reading through this document in its entirety to become familiar with the product’s features prior to starting the
installation process.
Basic Wiring Diagram
IMPORTANT! Installation Requirements
• Visit the product page to download the latest documentation.
• Read through the Wiring and Connections section for important wiring
guidelines before creating or choosing premade cables.
In the Box
1x EXP-CON-AUD-H2 Audio Converter
1x 5V DC 1A Power Supply with Wall Adapters
2x Mounting Brackets
Key
Digital Audio
HDMI
Analog Audio
HDMI Source
AVR
Multiroom Amplifier
5V DC
Power Supply
4K/UHD HDMI Display
Front Panel Rear Panel
Power In
2.1mm DC Jack Input
Connect to the included 5V DC 1A power
supply.
Power LED Solid: The unit is powered On
Off: The unit is powered Off
HDMI In 19-pin type A HDMI female
Supports HDMI and DVI/D with adapter
EDID Switch Switch between Passthrough, 2ch and 5ch
Audio Modes
HDMI Output 19-pin type A HDMI female
Supports HDMI and DVI/D with adapter
Optical Output
Toslink optical port
Connect to digital audio input of pre-amplier,
AVR or audio system
Analog Audio
Output
2 x RCA (L/R Phono) Ports
Connect to analogue audio input of pre-
amplier, AVR or audio system
Copyright © 2020 WyreStorm Technologies | wyrestorm.com
EXP-CON-AUD-H2 Quickstart Guide | 200317
UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)
[email protected]
2 of 4
ABC D ABC
Troubleshooting
No or Poor Quality Picture (snow or noisy image)
• Verify that power is being supplied to the device
• Verify that all HDMI connections are not loose and are functioning properly
Troubleshooting Tips:
• WyreStorm recommends using a cable tester or connecting the cable to
other devices to verify functionality.
Audio Connections
Analog Audio Out
Tip: Audio Postive (+)
Shield: Audio Negative (-)
Copyright © 2020 WyreStorm Technologies | wyrestorm.com
EXP-CON-AUD-H2 Quickstart Guide | 200317
UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)
[email protected]
3 of 4
Setup and Conguration
EDID Switch Settings
Pass Through
(Default)
Allows EDID pass-through from the display to the
source for optimum video and audio outputs to the
display.
IR TX
Pass 2.0CH 5.1CH
EDID
2.0CH
Transfers 2.0CH EDID of EXP-CON-AUD-H2 to the
source for optimum video and 2.0CH audio outputs
to the display.
IR TX
Pass 2.0CH 5.1CH
EDID
5.1CH
Transfers 5.1CH EDID of EXP-CON-AUD-H2 to the
source for optimum video and 5.1CH audio outputs
to the display.
IR TX
Pass 2.0CH 5.1CH
EDID
Note:
• If EDID Copy fails, a xed 1920x1080p @60Hz 2.0CH would be provided to source device.
• In order to achieve a better user experience, please refer to the following audio support descriptions and examples for EDID setting during installation.
1. Slide the EDID to Pass Through (default) - Copy EDID from HDMI out.
Display Audio HDMI Output Audio S/PDIF Output Audio L/R Output Audio
Dolby /DTS 7.1 Dolby/DTS 7.1 - -
Dolby/DTS 5.1 Dolby/DTS 5.1 Dolby/DTS 5.1 -
PCM 7.1 PCM 7.1 PCM 2.0 PCM 2.0
PCM 5.1 PCM 5.1 PCM 2.0 PCM 2.0
PCM 2.0 PCM 2.0 PCM 2.0 PCM 2.0
By default (position “Pass Through”), when connected to a 1080p, PCM5.1 TV, the extractor will transmit the 1080p, PCM5.1 signal to it, S/PDIF Output audio is
PCM2.0, and L/R Output Audio is PCM2.0.
2. Slide the EDID to 2.0CH - The option with 2.0CH.
HDMI Output Audio S/PDIF Output Audio L/R Output Audio
PCM 2.0 PCM 2.0 PCM 2.0
Slide to position “2.0CH”, when connected to a 1080p/5.1ch TV, the extractor will transmit the 1080p/2.0ch signal to it, S/PDIF Output audio is PCM2.0, and L/R
Output Audio is PCM2.0.
3. Slide the EDID to 5.1CH - The option with 5.1CH
Display Audio HDMI Output Audio S/PDIF Output Audio L/R Output Audio
Dolby /DTS 7.1 Dolby/DTS 7.1 - -
Dolby/DTS 5.1 Dolby/DTS 5.1 Dolby/DTS 5.1 -
PCM 7.1 PCM 7.1 PCM 2.0 PCM 2.0
PCM 5.1 PCM 5.1 PCM 2.0 PCM 2.0
PCM 2.0 PCM 2.0 PCM 2.0 PCM 2.0
Slide to position “5.1CH”, when connected to a 1080p, PCM7.1 TV, the extractor will transmit the 1080p, PCM5.1 signal to it, S/PDIF Output audio is PCM2.0, and
L/R Output Audio is PCM2.0.
Copyright © 2020 WyreStorm Technologies | wyrestorm.com
EXP-CON-AUD-H2 Quickstart Guide | 200317
UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)
[email protected]
4 of 4
Specications
Audio and Video
Inputs 1x HDMI In: 19-pin type A
Outputs 1x HDMI Out: 19-pin type A | 1x RCA Female Stereo (L/R) | 1x S/PDIF Toslink
Audio Formats
HDMI: 2ch PCM | Multichannel: LPCM and up to DTS-X and Dolby Atmos
Analog: 2ch LPCM
Toslink: 5.1ch surround sound
Video Resolutions (Max)
Resolution HDMI
1920x1080p @60Hz 12bit
1920x1080p @60Hz 16bit
3840x2160p @24Hz 10bit 4:2:0 HDR
3840x2160p @30Hz 8bit 4:4:4
3840x2160p @60Hz 10bit 4:2:0 HDR
4096x2160p @60Hz 8bit 4:2:0
4096x2160p @60Hz 8bit 4:4:4
15m/49ft
7m/23ft
7m/23ft
5m/16ft
5m/16ft
5m/16ft
3m/10ft
Supported Standards DCI | RGB | HDR | HDR10 | Dolby Vision up to 30Hz | HLG | BT.2020 | BT.2100
Maximum Pixel Clock 600MHz
Communication and Control
HDMI HDCP 2.2 | DVI-D supported with adapter (not included)
Power
Power Supply 5V DC 1A
Max Power Consumption 2.88W
Environmental
Operating Temperature 0 to + 45°C (32 to + 113 °F), 10% to 90%, non-condensing
Storage Temperature -20 to +70°C (-4 to + 158 °F), 10% to 90%, non-condensing
Maximum BTU 9.83 BTU/hr
Dimensions and Weight
Rack Units/Wall Box <1U
Height 22mm/0.87in
Width 80mm/3.15in
Depth 90mm/3.54in
Weight 0.23kg/0.51lbs
Regulatory
Safety and Emission CE | FCC | RoHS
Warranty Information
WyreStorm Technologies LLC warrants that its products to be free from defects in material and workmanship under normal use for a
period of ve (5) years from the date of purchase. Refer to the Product Warranty page on wyrestorm.com for more details on our limited
product warranty.
Note: WyreStorm reserves the right to change product specication, appearance or dimensions of this product at any time without prior notice.
