X10 PowerFlash PF284 User manual

X10 Wireless Technology, Inc. 90 Day Limited Warranty
X10.com, a division of X10 Wireless Technology, Inc. (X10) warrants X10 products to be
free from defective material and workmanship for a period of 90 days from the original date
of purchase at retail. X10 agrees to repair or replace, at it’s sole discretion, a defective X10
product if returned to X10 within the warranty period and with proof of purchase.
If service is required under this warranty:
1. Visit www.x10.com/support/return_policy.htm, or e-mail [email protected] to obtain a
Return Merchandise Authorization (RMA) number.
2. Return the defective unit postage prepaid to X10 (see address on back).
3. Enclose a check for $4.00 to cover postage and handling.
4. Enclose a dated proof of purchase.
5. X10 is not responsible for shipping damage. Units to be returned should be packed
carefully.
Please visit www.x10.com/support for help.
PF284-6/13
Check Out our Web site at:
http://www.x10.com
For more information on X10 products and
special promotional offers.
InstallationandoperatinginstructionsfortheX10PowerFlash
Universal Interface, Model PF284
1
9
513

A
I
EM

AB 1 23
INPUT MODE
POWERFLASH INTERFACE
TEST ALL UNITS OFF
The Powerflash Universal Interface provides a way to
interface to conventional security systems, and other contact
closure or voltage output devices, to control X10 powerline
controlled products, to turn on lights, flash lights, activate
plug-in alarm sirens, etc.
The Powerflash Interface has terminals for two types of
inputs, determined by the INPUT slide switch:
Position A: 6-18 VDC
Position B: Dry contact closure
Setting up the Powerflash Interface
• Use a small screwdriver to set the desired House Code and Unit Code A-P and 1-16.
• Adjust the MODE slide switch to select the desired mode of operation as follows:
1. Turns on all Lamp Modules and Wall Switch Modules set to the same Housecode
as the Powerflash Interface. Also turns on Appliance Modules set to the same
Housecode and Unit Code as the Powerflash Interface. When the alarm is reset,
only the Modules set to the same Housecode and Unit Code as the Powerflash
Interface are turned off.
2. Flashes all Lamp Modules and Wall Switch Modules set to the same Housecode
as the Powerflash Interface. When reset all lights stay on.
3. Turns on Lamp Modules and Appliance Modules set to the same Housecode and
Unit Code as the Powerflash Interface. When reset, turns the same Module off.
• Connect the terminals on the Powerflash Interface to the burglar alarm or output
device such as a driveway sensor or similar contact closure.
Note: Observe the polarity shown on the unit if the alarm output is DC voltage.
• Plug the Powerflash Interface into a 120VAC wall outlet.
Testing the Interface
• Press TEST to activate the Powerflash Interface according to the selected mode.
• Press ALL UNITS OFF to turn off Modules left on after activating the Interface.
Do not connect 120V
to the terminals!
TM

Mini Timer MT13A
AController, Timer and Alarm Clock all in
one! Programs up to eight X10 Modules to
go on and off at specific times, up to a total
of64 timed events. Controls eight modules
instantly. Dims lights too.
Maxi Controller SC503
Lets you control up to 16 X10 Modules at
the touch of a button from anywhere in the
house. Dims lights too!
Mini Controller MC10A
Lets you control up to eight X10 Modules
at the touch of a button from anywhere in
the house. Dims lights too!
2-Way Home Control Interface CM15A
Set up from a PC to control up to 256
X10 Modules. ActiveHome Pro software
download & USB cable included.
Thermostat Set-Back TH2807
Automatically sets-back your central
heating/airconditioning.Mountsonthewall
under your existing thermostat and plugs
into an Appliance Module.
WirelessRemoteControlSystemRC5000
Letsyoucontrol16X10modulesfrominside
or outside your home. Can also dim and
brighten Lamp Modules and Wall Switch
Modules. Works with the HR12APalmPad
RemoteandX10RFWallSwitches(SS13A,
SS15A).
Lamp Module LM465
Can be Dimmed and Brightened from any
X10Controller.Respondsto“Alllightson”.
Rated for 300 W. Incandescent only.
2-Way version LM14A.
SocketRocket LM15A
Screwsintoanexistinglightfixture.Controls
up to 150W, incandescent only.
Appliance Module - AM486/AM466
Two pin polarized (AM486) or 3 pin
grounded (AM466). For controlling an air
conditioner,TV, stereo,etc.anywhereinthe
home. Rated 15A for heaters, coffee pots
etc.; 1/3 H.P. for motors; 400W for TVs;
500W for lamps. 2-Way versions available
AM14A (2 pin), AM15A (3 pin).
Wall Switch Module WS467
Forcontrollingimportantindoorandoutdoor
security lights. Replaces your existing
wall switch and installs like a regular
dimmer.Dimmed/brightenedfromanyX10
Controller. Rated 500W incandescent only.
3 - Way Wall Switch Module WS4777
For controlling a light which is controlled
by two switches. Same features as WS467.
Split Receptacle Module SR227
Replacesexisting walloutlet.Thetopoutlet
functions like an Appliance Module, the
bottom one is a regular outlet. Rated 15A.
Universal Module UM506
Isolated contact relay and beeper. Can be
set for momentary or continuous operation.
Not compatible with X10 security systems.
Trim Trim
X10 Wireless Technology, Inc.
400 Forge Way, Suite 409-412,
Rockaway, NJ 07866
RMA#
Tear off and keep the portion to the right (setup instructions are
on the other side of it) and keep for future use.
visit www.x10.com/support/return_policy.htm
or e-mail [email protected] to obtain a Return Merchandise
Authorization (RMA) number.
Write your RMA number above. Tear off and tape this label to
the outside of the package and mail it (postage prepaid).
