X10 XCam Anywhere SC15A User manual

Refer to the setup and operating instructions that came
with the 2.4 GHz Video Sender Kit, Model VK30A (sold
separately). Make sure that the Video Sender (VT30A)
and Video Receiver (VR30A) are set up and functioning
properly.
1. Plug the video plug on the adapter cable into the yellow
Video In jack on the Video Sender (transmitter).
2. Plug the camera’s plug into the video adapter.
3. Plug the audio jack into either audio socket (red or
white) on the Video Sender (transmitter).
4. Plug the adapter cable’s power plug into the power
jack on the Video Sender.
5. Plug the Video Sender’s power supply jack into the
adapter cable’s power socket.
6. Plug the power supply into any 120V AC outlet.
7. Attach the camera to a wall in the location you want to
monitor using the mounting bracket (supplied). Mount
it with the cable coming out of the bottom.
8. Adjust the antenna on the Video Sender if necessary
to aim it in the direction of the receiver you have
connected to your TV or monitor.
X10WirelessTechnology,Inc.
LIMITED1-YEARWARRANTY
X10.com,adivisionofX10WirelessTechnology,Inc.
(X10)warrantsX10productstobefreefromdefective
materialandworkmanship foraperiodofone(1)year
fromtheoriginaldateofpurchaseatretail.X10agreesto
repairorreplace,atit’ssolediscretion,adefectiveX10
productifreturnedtoX10withinthewarrantyperiodand
withproofofpurchase.
Ifserviceisrequiredunderthiswarranty:
Call1-800-442-5065,visitwww.x10.com,ore-mail
[email protected].
X10.com, a division of
X10 Wireless Technology, Inc.
Visit www.x10.com/support for more help.
●Extremely small size.
●Plugs into X10’s 2.4 GHz Video Sender.
●Powered from theVideo Sender’s plug-in power supply.
●Use it indoors or outdoors to monitor your front door, back yard, etc.
●Monitor a child’s bedroom, etc.
Models SC15A
and SC16A
SC15-16A-12/02
The SC15A (white) and SC16A (Gray) are very small and compact color video cameras that plug into X10’s 2.4 GHz Video
Sender (sold separately). The camera is powered from the Video Sender’s plug-in power supply. The Video Sender transmits
the video picture to the 2.4 GHz receiver connected to your TV located somewhere else in your home (up to 100 ft. away).
It also includes a microphone so you can hear as well as see what’s going on.
XCam Anywhere Indoor/Outdoor Color Video Camera
The Video Sender Kit Model VK30A (sold
separately) includes the VT30A Video
Sender (shown below) and the VR30A
Video Receiver.
Pluginto
anyAC
outlet
Plug video
adapter in
here.
Plugpower
jackinhere.
Adjustantenna.
Plugpower
supplyin here.
VT30A
Important:
always unplug
the power
supply before
unplugging the
power jacks.
™
Adapter Cable
Plug camera in here.
(with microphone)
Audio
