X10 SC23A User manual

1. Attach thecameratoa wallin thelocation youwant to
monitor. Mount it with the cable coming out of the
bottom.If youare installingthecameraoutdoors,pass
the60ft.cablefromthecamerathroughasmallholein
yourexteriorwall.
2. Plug thecamera’splug intothe adaptercable.
3. Plugthevideoplugontheadaptercableintotheyellow
VideoIn socketon yourTV/monitor.
4. Plugtheaudiojackintoeitheraudiosocket(redorwhite)
onyourTV/monitor.
5. Plug thepower supply’s jackintothe powersocket on
theadaptercable.
6. Plug thepower supplyintoany120VAC outlet.
X10Wireless Technology,Inc.
LIMITED1-YEARWARRANTY
X10.com, a division of X10 Wireless Technology, Inc.
(X10) warrants X10 products to be free from defective
materialandworkmanshipforaperiodofone(1)yearfrom
theoriginaldateofpurchaseatretail.X10agreestorepair
orreplace,atit’ssolediscretion,adefectiveX10product
ifreturnedtoX10withinthewarrantyperiodandwithproof
ofpurchase.
Ifserviceisrequiredunderthiswarranty:
Call1-800-442-5065,visitwww.x10.com,ore-mail
[email protected].
X10.com, a division of
X10 Wireless Technology, Inc.
Visit www.x10.com/support for more help.
●Extremely small size.
●Plugs into RCA type inputs on any TV or monitor.
●Can be turned on and off from X10 controllers.
●Remote controlled power supply (included).
●Very sensitive so it can be used in low light conditions.
●Use it outdoors to monitor your front door, back yard, etc. (60 ft. cable included).
Model SC23A
TheSC23A includesa verysmallandcompactB/Wvideocamera(WC12A)that plugsinto theRCA audio/videojacks
onanyTVormonitor.Youcanplaceit anywhereyouwanttomonitor(indoorsoroutdoors). Italsoincludesamicrophone
soyoucanhearaswellassee what’s goingon.It ispoweredfromaremotecontrolledpowersupply(XM17A)soyou can
turnit onand offby remotecontrol usingX10 controllersand remotes(sold separately).
NightWatch 2 Indoor/Outdoor Black &White Camera
WC12A
™
(with microphone)
Video/Audio
monitor of
your choice
Video Audio
In In
60 ft.
SettheHousecodedialto
matchthesettingontheX10
ControllerorRemoteControl
thatyouwanttocontrolthe
cameraconnectedtothe
XM17Afrom.
SettheUnitCodedialtoany
unusednumberbetween1
and16.
Plugvideo
adapterin
here.
Plugpower
supplyinhere.
Plugcamerainhere.
Adapter Cable.
Plugaudioin here.
SC23A-9/02
Plugintoany
ACoutlet
