XAG B13860S User manual

B13860S Smart Battery
User Manual
EN
Australia Version 2.0

To Users
Dear user, thank you for choosing XAG products.
For safety reasons and the best experience possible, XAG recommends that you read through the User
Manual and Disclaimer in this document before attempting to use the Smart Battery 2019.
Contact Us
If you have any questions about this document, please contact our Technical Support via email: info@
xa.com

1
Product Prole
The B13860S Smart Battery 2020 is compatible with all XAG P-Series Plant Protection UAV Modules. The Smart
Battery contains 13 large-capacity lithium polymer batteries, and is integrated with the BMS module. It enables
real-time monitoring of voltage, current, and temperature, and also features charging protection. During use, the
battery can transmit feedback information to the device in real time. In the case of low power or battery failure, the
BMS system will send an emergency stop command to ensure the safety of the device.
Overview
Handle
Control Panel
Clip
Plug Slot
ON: Normal
Flashes slowly: Low
Temperature
Flashes quickly:
High Temperature
Flashes twice:
Battery Malfunction
Battery Level Indicators Status Indicator Power Button
Maximum water Level
ON/OFF
1. When the Battery is turned o, press the Power button once to check the current battery level,
indicated by the Battery level LED. If the battery is too low, recharge before use
2. Connect the battery to an device, then press the Power button once for at least 1 second until all the
indicator lights ashes, then press and hold the power button again for at least 1 second until you hear
a beep from the battery.
3. Repeat Step 2 to turn o the Battery
Battery ON/OFF
Max
Min
Max
Min
4Air Outlet
Minimal water Level
Air Inlet
1
2
3
5
6
7
8
1
2
3
4
5
6
7
8

2
Checking Battery Level
When the battery is OFF, press the power button once to display the battery level.
When the battery is ON, check the battery level indicators to see the battery level.
RED LIGHT ON Normal Normal
RED QUICK FLASH Overheated Temporarily locked. Prohibited
from charging and usage.
RED SLOW FLASH Low Temperature Battery requires preheating.
RED DOUBLE FLASH Battery Malfunction Stop using immediately.
Battery Level LED Status Battery Level
Checking Battery Status
• During the battery charging, the fan on the charger will be turned on to dissipate heat. The battery
management system will automatically suspend the charging if the temperature is over 50° C, and
resume after the temperature drops below 50° C. The ideal ambient charging temperature (20° - 35° C)
for charging helps maintain the normal service life of the battery.
• The battery level indicators corresponding to the current battery level will be solid green, and the
remain will be flashing in series indicating the battery is currently charging. Once the charging is
completed, the buzzer will beep for 30secs and all the battery level indicators will ashes for 2 minutes,
then the battery will turn o automatically
Battery Preheating
Press and hold the power button for 5 seconds when the battery is OFF until a beep is heard from the
battery and the status indicator is on. The pre-heating of the battery will start and the battery will turn o
automatically after heating.
[1] Device: Device as UAV or Charger
[2] Preheating: Preheating can be conducted when the battery is not connected to a device
Battery Charging
Battery Level LED
1 GREEN FLASH
1 GREEN
2 GREEN
3 GREEN
4 GREEN
5 GREEN
2 LIGHTS
DOUBLE FLASH Self-locked
Remotely locked
3 GREEN
DOUBLE FLASH
Battery is locked due to low power level. Please contact
customer support to unlock the device.
Battery is locked remotely. Please contact customer
support to unlock device.
Status Battery Level
0% - 10%
10% - 30%
30% - 50%
50% - 70%
70% - 90%
90% - 100%
Anti-tamper lock
4 GREEN
DOUBLE FLASH
Battery is locked remotely. Please contact customer
support to unlock device.

3
Charging by Intelligent Super Charger
Charging by Auto Super Charge Station

4
Technical Specications
IP Code: IP67
Operating temperature: 10 - 45°C
Charging temperature: 10 - 40 °C
Storage temperature: 10 - 30 °C
Weight: Approx. 6.0kg
Dimensions: 189*137*312mm
Model: B13860S
Type: Lithium polymer battery
Capacity: 18000mAh/865.8Wh
Rated output: 48.1V/120A
Charging voltage: 56.55 V
• When charging with the Super Charger, please use 15A/16A sockets in compliance with national/
industry standards only. Losses incurred by the use of non-standard or unqualied sockets to connect
the SuperCharger to the battery for charging shall be borne by the user.
• Where water cooling is needed, please use clean and non-corrosive water, and make sure the
water level is no higher than the maximum level marked on the battery case. To ensure optimal heat
dissipation, it is recommended to maintain a water level between the Max and Min water levels. Each
period of cooling should not exceed 60 minutes. Do not completely immerse the battery in water.
• Please rst remove the battery before pouring water out of the container.
• Before charging, please keep all battery terminals clean and dry, and ensure that no metal objects or
liquids are trapped in the charging socket.
• To prevent power failture or damage to the Super Charge Station and battery, avoid splashing water
onto either the charger or Super Charge Station when charging with a cooling water container.
Charging by Auto Super Charge Station & Cooling Water Container

5
• Do not plug or unplug the battery when it is turned on, otherwise the power connector may be
damaged.
• Check the battery rmware before ight operation. If there is a new version, please update rst. The
ight loss caused by the user’s failure to update the battery rmware in time will be borne by the user.
• The battery should be used between 10° and 50° C (ambient temperature). Overheating (above 50°
C) may cause the ignition or even explosion of the battery. Low temperature (below 0° C) may greatly
degrade the battery performance, resulting in failure to meet the requirements of use.
• To avoid short circuiting, do not connect the positive and negative poles of the battery with a wire or
other metal objects.
• Prevent the battery from coming into contact with any liquid. Please remember that it is strictly
forbidden to soak the battery in water or expose the battery to water, otherwise it may lead the battery
to decompose, and then spontaneous combustion or even explosion.
• If there is liquid or foreign matter on the battery terminal, wipe in a timely fashion and keep it clean.
Otherwise it may cause poor contact, resulting in loss of energy or charging failure.
• Please handle with care during use. Do not disassemble it, puncture its case, or manually press the
battery, including but not limited to the following: Sitting on the battery, placing heavy objects on the
battery, or otherwise putting pressure on the battery.
• Regularly check the battery terminal, plug, and other components before use. Do not use alcohol or
other ammable agents to clean charging devices. Do not use a damaged charging device.
• When charging, place the battery and charging devices on flat ground that is free of flammable or
combustible materials. Battery charging shall be watched over to prevent accidents. For safety, when
charging, a distance of more than 30cm shall be kept between two batteries, or between a battery and
a charger, to avoid the malfunction of the charger or the battery, and even serious consequences such
as re due to overheating.
• Before each ight, make sure the battery has completed charging. Never operate with a full load when
the battery is not fully charged.
• It is strictly forbidden to use batteries other than those provided by XAG. For replacement, please
contact the after sales or designated dealers of XAG. The user shall bear the responsibility for battery
accidents, ight failures or other accidents caused by the use of batteries not provided by XAG.
• In case of ONE GREEN LIGHT FLASH after ight, please charge the battery to a level of 40%-60%before
storage. Failure to charge in time may cause damage to the battery. The battery should be recharged
and discharged every 90 days to maintain its activity.
• The battery should be stored in a dry environment at a temperature of -10-30° C. Do not place the
battery where leakage may occur.
• When the battery is found swollen, leaking, or damaged, stop using the battery immediately and
contact XAG or your dealer timely.
• The liquid inside the battery is highly corrosive. If it inadvertently comes into contact with your skin
or eyes, rinse with clean water and seek medical advice immediately.
• When disposing the battery, please follow local laws and regulations. Protect the natural environment,
and do not discard the battery at random.
󱩓IMPORTANT:

6
Disclaimer
1. Please read this document carefully before using this product. This Disclaimer has an important
impact on the safe use of the product and your legitimate rights and interests. The use of the product
shall be deemed as you have known, understood, acknowledged, and accepted all terms and
contents of this document.
2. This product is not a toy, and is not suitable for people under the age of 18. Please keep this product
away from the reach of children, and be very careful when operating in the presence of children.
3. This product must be charged with the charging devices provided by XAG. For product malfunction or
damage caused by the use of other devices for charging, XAG does not bear the corresponding legal
responsibility.
4. Please install and use this product as guided by the “Product Manual/Operation Manual”. Do not
modify or disassemble the product without authorization. All losses caused by the user’s unauthorized
modication or disassembly of this product shall be borne by the user, while XAG does not assume any
corresponding legal responsibility.
5. To the maximum extent permitted by law, XAG shall not be liable for all losses caused by users' failure
to use the product in accordance with this document and the “Product Manual/Operation Manual”.
6. To the maximum extent permitted by law, XAG’s liability or amount under any circumstances to you for
all damages, losses, and litigation arising therefrom will not exceed the amount paid to XAG by you for
the purchase of the product.
7. In any case, the purchaser or user shall comply with relevant laws and regulations of the country and
region where the product is used. XAG does not assume any liability arising from violation of relevant
laws and regulations by the purchaser or user.
8. As laws in some countries may prohibit exemptions from liability clauses, your rights in dierent
countries may vary. This does not mean that the contents of this Disclaimer are necessarily invalid.
9. To the extent permitted by law, XAG has the nal right to interpret and modify the above terms. XAG
has the right to update, modify, or terminate these terms through its ocial website, the “Product
Manual/Operation Manual”, online APP and other means without prior notice.
˙Users are required to read the complete “Product Manual” and be familiar with the product operations
before using the product. Otherwise, it may cause serious injury to yourself or others, or cause product
damage and property loss. Strong safety awareness is required to operate this product. Do not use the
parts that are not provided or suggested by XAG. Please strictly follow the instructions of XAG to install
and use the product.
WARNING:
