Xantech D5RHK Instruction Manual

1
Xantech Corporation | 13100 Telfair Avenue, Sylmar CA 91342-3573 | 800.843.5465 | FAX [phone] | www.xantech.com
CONTENTS
02 ... D5RHK - Complete 4x4 Rack Kit
03 ... D5RHK4 - Complete 4x4 Structured Wiring Kit
03 ... D5SHK - Complete 1x4 Structured Wiring Kit
04 ... D5RH - 4X4 Equipment Rack Hub
04 ... D5XH - Expansion Equipment Rack Hub
05 ... D5SH4 - 4X4 Wall Mount Hub
05 ... D5SH - 1X4 Wall Mount Hub
06 ... D5PS - Efficient Wall Mount Power Supply
06 ... D5IP - Local Source Input Wall Plate
07 ... D5KP4 - Four Source Keypad
07 ... D5KP - Single Source Keypad
08 ... D5MR - Mini Remote
08 ... D5LR - Advanced Learning Remote
08 ... Accessories
2009
Multi-room audio distribution offers a lifestyle usually associated with luxury. Bulky
electronics and big box speakers are gone and the freedom of listening to what you want
where you want it takes on a new level. Xantech now introduces an opportunity for
versatile multi-room audio distribution to our faithful customers.
Xantech is proud to present DIGI-5, a Linear Home Technology Group technology. Xantech
DIGI-5 is a complete line of products that are simple to install, CAT5 based system that
provides a full featured, fully distributed digital music system at the price of analog.
Systems are configurable for single or multi-zone concurrent listening in four locations and
are expandable to up to 16 locations. The new platform comes in multiple form factors
such as a structure wiring module and an equipment rack model. Additional features
include room EQ and local and shared source switching in each room. Whole house audio
was never so good or so easy to install.

DIGITAL DELIVERY SYSTEM
2Xantech Corporation | 13100 Telfair Avenue, Sylmar CA 91342-3573 | 800.843.5465 | FAX [phone] | www.xantech.com
4 - SOURCE 4 -ZONE KIT - EQUIPMENT RACK
FEATURES:
• Digital Delivery System (DDS)
• Complete multi-room audio package
• Controls up to four sources
• Distributes audio up to four zones
• 30 Watts Digital Amp
• Super Bright OLED Display
• Studio Slim Design
• Fits in Decora Plate
Order: D5RHK
General Info:
• (1) Equipment Rack 4x4 Hub
• (1) Advanced Learning Remote
• (4) DIGI-5 Keypads
• (1) 110 Punch-Down Tool
International Version Available
Order: D5RHKE

DIGITAL DELIVERY SYSTEM
3
Xantech Corporation | 13100 Telfair Avenue, Sylmar CA 91342-3573 | 800.843.5465 | FAX [phone] | www.xantech.com
4 - SOURCE 4 -ZONE KIT - WALL MOUNT KIT
FEATURES:
•Digital Delivery System (DDS)
• Complete multi-room audio package
• Controls up to four sources
• Distributes audio up to four zones
• Sources can be remotely located
• Based on Wall Mount hub
• Fits most structured wiring systems
• 30 Watts Digital Amp
• Super Bright OLED Display
• Studio Slim Design
• Fits in Decora Plate
Order: D5SHK4
General Info:
• (1) Wall Mount 4x4 Hub
• (1) Wall Mount Power Supply
• (1) Advanced Learning Remote
• (4) 283D Emitters
• (4) DIGI-5 Keypads
• (4) Local Source Input Plates
• (1) 110 Punch-Down Tool
International Version Available
Order: D5SHK4E
SINGLE SOURCE 4 -ZONE KIT - WALL MOUNT
FEATURES:
• Digital Delivery System (DDS)
• Complete multi-room audio package
• Controls a single source
• Distributes audio up to four zones
• Source can be remotely located
• Based on Wall Mount hub
• Fits most structured wiring systems
• 30 Watt Digital Amp
• Super Bright OLED Display
• Studio Slim Design
• Fits in Decora Plate
Order: D5SHK4
General Info:
• (1) Wall Mount 1x4 Hub
• (1) Wall Mount Power Supply
• (1) Advanced Learning Remote
• (4) 283D Emitters
• (4) DIGI-5 Keypads
• (1) Local Source Input Plates
• (1) 110 Punch-Down Tool
International Version Available
Order: D5SHKE

DIGITAL DELIVERY SYSTEM
4Xantech Corporation | 13100 Telfair Avenue, Sylmar CA 91342-3573 | 800.843.5465 | FAX [phone] | www.xantech.com
4 - SOURCE 4 - ZONE EQUIPMENT RACK HUB
FEATURES:
• Digital Delivery System (DDS)
• Digital coax audio inputs
• Analog Left & Right audio inputs
• Audio input level control
• Audio clipping indicators
• Serial RS-232 control port
• Paging & Doorbell compatible
• IR emitter outputs
• Zone pairing for combining keypads in a zone
• Zone power output for longer distances
• Expansion capability
Order: D5RH
General Info:
• ~120V 50/60Hz Power Supply: 240W max.
• Dimensions: 17"W x 14.25"D x 2.41"H
• Optional RM1UKIT rack ears available
International Version Available
Order: D5RHE
6 -ZONE EQUIPMENT RACK EXPANSION HUB
FEATURES:
• Digital Delivery System (DDS)
• Audio Loop-Thru connection from master hub
• Audio input level control
• Serial RS-232 control port
• IR emitter outputs
• Zone pairing for combining keypads in a zone
• Zone power output for longer distances
Order: D5XH
General Info:
• ~120V 50/60Hz Power Supply: 240W max.
• Dimensions: 17"W x 14.25"D x 2.41"H
• Optional RM1UKIT rack ears available
International Version Available
Order: D5XHE

DIGITAL DELIVERY SYSTEM
5
Xantech Corporation | 13100 Telfair Avenue, Sylmar CA 91342-3573 | 800.843.5465 | FAX [phone] | www.xantech.com
4 - SOURCE 4 - ZONE WALL MOUNT HUB
FEATURES:
• Digital Delivery System (DDS)
• 4 Source 110 punch-down inputs
• 4 Zone 110 punch-down outputs
• 4 Source Loop-Thru, expansive capable
• Zone power output for longer distances
• Serial RS-232 control port
Order: D5SH4
General Info:
• Requires D5PS Power Supply
• Requires D5IP Source Input Plate
• Mounting Holes: 6" Width, 4" Height
(structured wiring enclosed compatible)
• Dimensions: 6.50"W x 1.89"D x 6.80"H
SINGLE - SOURCE 4 - ZONE WALL MOUNT HUB
FEATURES:
• DIGI-5 Technology
• Single Source 110 punch-down inputs
• 4 Zone 110 punch-down outputs
• Single Source Loop-Thru, expansive capable
• Zone power output for longer distances
• Serial RS-232 control port
Order: D5SH
General Info:
• ~120V 50/60Hz Power Supply: 240W max.
• Dimensions: 17"W x 14.25"D x 2.41"H
• Optional RM1UKIT rack ears available

DIGITAL DELIVERY SYSTEM
6Xantech Corporation | 13100 Telfair Avenue, Sylmar CA 91342-3573 | 800.843.5465 | FAX [phone] | www.xantech.com
WALL MOUNT POWER SUPPLY
FEATURES:
• Universal input 90 to 264VAC, 47 to 63Hz
• Incredible efficiency (up to 89%)
• Standard IEC power cord compatible
• Over voltage protection
• Over temperature protection
• Standard IEC power cord compatible
• Use additional D5ERGPS1 to increase
keypad distances over 300 feet
Order: D5PS
General Info:
• 24VAC, 8.3A rated
• Intended for Wall Mount hubs
• Mounting Holes: 6” Width, 3” Height
(structured wiring enclosure compatible)
• Dimensions: 6.55"W x 1.74"D x 4.50"H
Shipped with International power cords
Order: D5PSE
LOCAL SOURCE INPUT PLATE
FEATURES:
• Digital coax audio inputs
• Analog Left & Right audio inputs
• Audio input level control
• IR emitter output
• 110 punch-down output
Order: D5IP
General Info:
• Decora style, fits into a single-gang box

DIGITAL DELIVERY SYSTEM
7
Xantech Corporation | 13100 Telfair Avenue, Sylmar CA 91342-3573 | 800.843.5465 | FAX [phone] | www.xantech.com
DIGITAL DISTRIBUTION SYSTEM KEYPAD AND DIGITAL AMPLIFIER
FEATURES:
• Digital Distribution System (DDS)
• Built-in digital amplifier
• Source selection control
• Volume level control
• Bass, treble, balance control
• Back-lit buttons with timeout control
• 110 punch-down input
• 30 Watt Digital Amp
DDS Keypad
Order: D5KP
General Info:
• Decora style, fits into a single-gang box
• Includes a decora gasket for a flush fit
DIGITAL DELIVERY SYSTEM KEYPAD AND DIGITAL AMPLIFIER UK/EU VERSION
FEATURES:
• Digital Distribution System (DDS)
• Built-in digital amplifier
• Source selection control
• Volume level control
• Bass, treble, balance control
• Back-lit buttons with timeout control
• 110 punch-down input
• 30 Watt Digital Amp
UK / EU Version
Order: D5KPE
General Info:
• Decora style, fits into a single-gang box
• Includes a decora gasket for a flush fit

DIGITAL DELIVERY SYSTEM
8Xantech Corporation | 13100 Telfair Avenue, Sylmar CA 91342-3573 | 800.843.5465 | FAX [phone] | www.xantech.com
MINI REMOTE
FEATURES:
• Palm-sized remote control
• Source selection functions
• Volume control functions
• MUTE and POWER functions
Order: D5MR
General Info:
• Includes battery
ADVANCED LEARNING REMOTE
FEATURES:
• Hand-held remote control
• Programmable four source
• Compatible with all major components
• Pre-programmed with DIGI-5 controls
• Compatible with all major components
• Dedicated DIGI-5 volume and source controls
• 3 IR macro function buttons
Order: D5LR
General Info:
• Includes batteries
• Built-in IR code library
1U RACK EAR KIT
FEATURES:
• For use with 19" Equipment Rack hubs
• Easy to install
Order: RMIUKIT
General Info:
• Includes left and right ears and hardware

DIGITAL DELIVERY SYSTEM
9
Xantech Corporation | 13100 Telfair Avenue, Sylmar CA 91342-3573 | 800.843.5465 | FAX [phone] | www.xantech.com
NEW HOME AUDIO DISTRIBUTION
Distribute beautiful audio to 4 locations. The master hub is centrally located whereas the source material can be conveniently
placed in the entertainment center. Digi-5 technology delivers high-power amplification negating the need for special high-
efficiency speakers.
Product Shown: D5SHK4

10 Xantech Corporation | 13100 Telfair Avenue, Sylmar CA 91342-3573 | 800.843.5465 | FAX [phone] | www.xantech.com
Contact Us:
Xantech Corporation
13100 Telfair Avenue
Sylmar, CA 91342
800.843.5465
www.xantech.com
© 2009 Xantech Corporation. All rights reserved.
This document is copyright protected. No part of this document may be copied or reproduced in any form without prior written consent
from Xantech Corporation.
Xantech Corporation shall not be liable for operational, technical, or editorial errors/omissions made in this document.
Due to constant product improvements, all specifications and prices subject to change without notice.
iPod is a registered trademark of Apple Computer, Inc, All other marks are redistered trademarks and trademarks of Xantech
Corporation. All rights reserved.
