Xiaomi S26 User manual

Xiaomi Soundbar 3.1ch
User Manual

Packing list
Product Overview
HDMI Connection
Input
NFC
Power on/o Volume – Volume +
ARC
TV
External Device
Boom of the Soundbar
Boom of the Soundbar
TV
“ARC” Mode
Subwoofer
Remote
Plastic tubes ×2
HDMI Cable
Bar
Wall Bracket ×2
Screw ×2
(M4,L10mm)(7.5x30mm)
Screw ×2
(T4, L30mm),

For DTS patents, see hp://patents.dts.com. Manufactured under licence fron DTS Licensing Limited. DTS, Digital Surround, Virtual:X and the
DTS logo are registered trademarks or trademarks of DTS, Inc. in the United States and other countries. 2021 DTS, Inc. ALL RIGHTS RESERVED.
Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio and the double-D symbol are trademarks of Dolby Laboratories
Licensing Corporation.
Hanger Mount Installation
Drill holes into the wall at a distance of 600mm.
Push the plastic expansion tube into the hole, and then screw the wall-hanging screws in. (T4, L30mm).
Fix the mounts onto the unit with screws (M4, L10mm).
Hang the unit onto the wall screws.
2. No naked flame sources, such as lighted candles, should be placed on the apparatus.
1. The USB port of Soundbar is used for update soware and signal input only.
6. Risk of fire or explosion if the baery is replaced by an incorrect type.
3. The apparatus is intended to be used in moderate climates.
4. WARNING: The mains plug/appliance coupler is used as disconnect device, the disconnect device shall remain readily operable
5. Correct Disposal of this product. This marking indicates that this product should not be disposed with other household wastes
throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of material resources. To return your used device, please use the return and collection
systems or contact the retailer where the product was purchased. They can take this product for environmental safe recycling.
CAUTION:

Remote function
Other function
Specifications
Power on/o
Input
Up
Down
Mute
Night mode
Bass +
Volume +
Volume -
Right
Play/Pause
Le
Sound mode
Bluetooth
AI Sound
Bass -
Short press to switch between HDMI, ARC,BT, OPTICAL,
COAXIAL and USB.
Long Press Sound mode to enter Advanced Sound
Seing. Then press up/down to switch in Treble/System
Bass/Audio Sync. Press OK to start adjustment.
When playing music, short press this to switch to former
one or next one. Long press to fast forward or rewind.
Press to switch between Standard, Cinema, Music, Game
and News.
Press to switch AI Sound on/o. When AI Sound on,
Soundbar will adjust sound mode automatically to fit the
current play.
Press to switch Night mode on/o
Press to change Subwoofer volume
Press to change Bar volume
Input:
Up/Down:
Le/Right:
Sound mode:
Bluetooth:
AI Sound:
Night mode:
Bass +/- :
Volume +/- :
NFC
Switch Soundbar to BT input, tap the phone in NFC section, the phone will connect with Soundbar automatically.
Bar and Subwoofer Connection
Connect power supply, the Bar and Subwoofer will connect with each other automatically.
If auto pairing didn’t work, please follow these instructions.
1. Long press “Power buon” and “Volume ” on the Bar at the same time, until the screen shows “ID SET”.
2. Long press pairing button of Subwoofer until the indicator in the back of it quickly flashes.
3. Wait for bar and subwoofer pairing. When it’s done, the indicator will light stably.
Model Name: S26
Channel: 3.1
Max Power output (Speaker): 430W (Bar-180W, Subwoofer-250W)
Supported play formats: Dolby Audio, DTS Digital Surround, DTS Virtual: X
Dimension(L×W×H): Bar-860×115×60 mm
3
, Subwoofer-297×210×371 mm
3
Operating Temperature Range: 0°C~40°C
Operating Humidity Range: 20%~80%
Storage Temperature Range: -15°C~45°C
Storage Humidity Range: < 80%
Short press to check BT status. Long press to start
BT pairing.

The terms HDMI and HDMI High-Definition Multimedia Interface,
and the HDMI Logo are trademarks or registered trademarks of
HDMI Licensing Administrator, Inc. in the United States and
other countries.
Importer:
Beryko s.r.o.
Na Roudné 1162/76, 301 00 Plzeň
www.beryko.cz
Important Safety Instructions
Read these operating instructions carefully before using the
unit. Follow all the safety instructions listed below. Keep these
operating instructions handy for future reference.
1. Read these instructions.
2. Keep these Instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
groundingtype plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11. Only use aachments/accessories specified by the
manufacturer.
12. Use only with the cart, stand, tripod, bracket,
or table specified by the manufacturer, or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms
or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
SAFETY INFORMATION
The following also applies to the Wireless Subwoofer
SAFETY WARNINGS
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
THE COVER (OR BACK).
NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
This symbol indicates that high voltage is present
inside. It is dangerous to make any kind of
contact with any internal part of this product.
This symbol indicates that this product comes
with important literature concerning
operation and maintenance.
Caution. Consult Instructions for use : This
symbol instructs the user to consult the user
manual for further safety related information.
AC voltage : Rated voltage marked with this
symbol is AC voltage.
DC voltage : Rated voltage marked with this
symbol is DC voltage.
Class II product : This symbol indicates that a safety
connection to electrical earth (ground) is not
required.
If this symbol is not present on a product with a
power cord, the product MUST have a reliable
connection to protective earth (ground).
WARNING
• To reduce the risk of fire or electric shock, do not expose this
appliance to rain or moisture.
• To prevent injury, this apparatus must be securely aached
to the floor/wall in accordance with the installation
instructions.
• This product contains chemicals known to the State of
California to cause cancer and birth defects or other
reproductive harm.
CAUTION
• Do not expose this apparatus to dripping or splashing. Do not
put objects filled with liquids, such as vases, on the
apparatus.
• To turn this apparatus o completely, you must pull the
power plug out of the wall socket. Consequently, the power
plug must be easily and readily accessible at all times.
