Xiaomi Smart Home Hub 2 User manual

Smart Home Hub 2 User Manual

Product Overview
The Xiaomi Smart Home Hub 2 is a smart home control center that can
connect with Wi-Fi, Zigbee, and Bluetooth devices. The hub and other
smart devices can be freely combined into various flexible systems that
enable mobile phone-based remote control of smart home devices and
linkage of automation scenes to control smart home life at will.
CAUTION: This product is intended for indoor use only.
Type-C Power PortIndicator
Ethernet Port
Read this manual carefully before use, and retain it for future reference.
01

Connecting with the Mi Home/Xiaomi Home App
This product works with the Mi Home/Xiaomi Home app*. Control your
device with Mi Home/Xiaomi Home app.
Scan the QR code to download and install the app. You will be directed
to the connection setup page if the app is installed already. Or search for
"Mi Home/Xiaomi Home" in the app store to download and install it.
Open the Mi Home/Xiaomi Home app, tap "+" on the upper right, and
then follow the instructions to add your device.
* The app is referred to as Xiaomi Home app in Europe (except for Russia).
The name of the app displayed on your device should be taken as the
default.
Note:
The version of the app might have been updated, please follow the
instructions based on the current app version.
02

3Please select a suitable hub placement for networking with a network
cable. Connect the hub to the router's LAN portwith a network cable.
Adding the Hub
1Select the installation location of the hub, and avoid metal obstacles
around the hub which will aect the wireless signal.
2For Wi-Fi networking, it is recommended to place the hub 2–6 meters
away from the router to which the hub will be connected, and there
should be no metal obstacles between the hub and the router. If
using wired networking, please skip this step.
2-6 Meters
2.4 GHz/5 GHz
03

Note: If the QR code of the hub cannot be scanned, search for its name
to add it.
Note: Bluetooth function of the phone needs to be enabled for network
access.
6Open the Mi Home/Xiaomi Home app, log into your account, and
enter the homepage of the app.
7Tap "+" in the upper right corner on the homepage of the app, select
"Add a device" or scan the QR code of the hub to enter the device
adding page, and operate according to on-screen instructions.
8Select a network access method and complete adding the hub
according to on-screen instructions.
4Please use the provided Type-C charging cable and power adapter
(purchase it separately) to power the hub.
5
and the indicator to blink orange, which indicates that the hub enters
the awaiting connection mode.
04

Wi-Fi name or password containing unsupported special characters
will result in failure to connect to the router, and please change them
to commonly used characters and try again.
If the router enables the AP isolation function, the phone will not be
able to search for the hub in the LAN.
The hub does not support WPA/WPA2 enterprise Wi-Fi networks.
It is recommended not to connect to a bridged network.
Note: If the hub cannot be added or the network cannot be connected
restarting it.
If using wireless network access, make sure your phone is connected to
a Wi-Fi network and placed as close to the hub as possible before
adding the hub.
If using wired network access, make sure that both the phone and the
hub are connected to the same router or the same LAN and the phone
is placed as close to the router as possible when adding the hub.
9
and wait for the indicator to blink orange. Add the hub again on the
Mi Home/Xiaomi Home app.
10
smart devices accessible through the Mi Home/Xiaomi Home app,
and add corresponding child devices.
05

Using the Hub
Adding a Child Device
smart devices accessible through the Mi Home/Xiaomi Home app, and
add corresponding child devices.
indicating that the reset of the hub's network is completed. Repeat the
"Add a device" steps to add the device.
network data) in the hub and related data of the child devices. Repeat
the "Add a device" steps to add the device.
Note: The version of the app might have been updated, please follow
the instructions based on the current app version.
11 You can perform automation and scene configuration on the scene
page of the Mi Home/Xiaomi Home app, to enable a variety of
automatic controls.
06

Indicator Status Descriptions
Indicator status Device status
Not connected to Wi-Fi/Ethernet network and not
paired to the account
30 minutes
Connecting/Reconnecting to the network, waiting to
add a child device, or updating the firmware manually
via the Mi Home/Xiaomi Home app
Successfully connected to the network and paired to
the account
Blinking orange
White
Blinking blue
Blue
07

Specifications
Name: Xiaomi Smart Home Hub 2
Model: ZNDMWG04LM
Item Dimensions: 95 × 95 × 26 mm
Input: 5 V 1 A
Network Port: 10/100 Mbps Ethernet
Wireless Connectivity: Wi-Fi IEEE 802.11 a/b/g/n 2.4 GHz/5 GHz, Zigbee
3.0 IEEE 802.15.4, Bluetooth 5.0
Operating Temperature: -10°C to 50°C
Operating Humidity: 0–95% RH, non-condensing
Wi-Fi Operation Frequency: 2412–2472 MHz
Wi-Fi Operation Frequency: 5150–5250 MHz
Wi-Fi Operation Frequency: 5725–5850 MHz
Wi-Fi Maximum Output Power < 20 dBm (2412–2472 MHz)
Wi-Fi Maximum Output Power < 23 dBm (5150–5250 MHz)
Wi-Fi Maximum Output Power < 13.98 dBm (5725–5850 MHz)
Bluetooth Operation Frequency: 2402–2480 MHz
Bluetooth Maximum Output Power < 13 dBm
Zigbee Operation Frequency: 2405–2480 MHz
Zigbee Maximum Output Power < 13 dBm
5150–5350 MHz are restricted to indoor use only.
08

The Bluetooth® word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc. and any
use of such marks by Xiaomi Inc. is under license.
Other trademarks and trade names are those of
their respective owners.
Hereby, [Lumi United Technology Co., Ltd.] declares that the radio
equipment type [Xiaomi Smart Home Hub 2, ZNDMWG04LM] is in
compliance with Directive 2014/53/EU. The full text of the EU declaration
of conformity is available at the following internet address:
https://www.mi.com/global/ service/support, declaration.html.
All products bearing this symbol are waste electrical and
electronic equipment (WEEE as in directive 2012/19/EU) which
should not be mixed with unsorted household waste. Instead,
WEEE Disposal and Recycling Information
09

Under normal use of condition,this equipment should be kept a separation
distance of at least 20 cm between the antenna and the body of the user.
Manufactured for: Xiaomi Communications Co., Ltd.
Manufactured by: Lumi United Technology Co., Ltd.
(a Mi Ecosystem company)
Address:Room 801-804, Building 1, Chongwen Park, Nanshan iPark, No. 3370,
Liuxian Avenue, Fuguang Community, Taoyuan Residential District, Nanshan
District, Shenzhen, China
For further information, please go to www.mi.com
Importer:
Beryko s.r.o.
Pod Vinicemi 931/2, 301 00 Plzeň
www.beryko.cz
you should protect human health and the environment by handing over
your waste equipment to a designated collection point for the recycling
of waste electrical and electronic equipment, appointed by the
government or local authorities. Correct disposal and recycling will help
prevent potential negative consequences to the environment and
human health. Please contact the installer or local authorities for more
information about the location as well as terms and conditions of such
collection points.
10
