XICOY V10 User manual
Serial adapter 1.0
V10 Fadec to serial comunications
Users Guide.
Torrent d’en Puig, 31. 08358, Arenys de Munt, Barcelona,Catalonia,Spain
Xicoy WEEE register number: ES004749
© Copyright 2014, Xicoy Electronica SL. All Rights Reserved
Manual contents & design: Gaspar Espiell. V1.0
Welcome!
Congratulations on the purchase of your new adapter. Xicoy are dedicated to the design
and production of electronic controllers to the highest standards of quality and reliability to
bring you the customer the very latest next generation designs.
Features:
The Xicoy serial adapter provides the protocol translation between the data from the
engine collected by the different Xicoy Fadec turbine controllers (from model 1 7K) and
JetsMunt specific controllers which use different proprietary protocols to a standard
asynchronous protocol to allow the data to be collected and used in other systems like test
bench setups on universities.
Electrical connections:
The adapter connects to the ecu trough the supplied 3 wire patch lead, and it is powered
by the ecu.
On the other side of the adapter there is a RJ12 connector of which 3 pins are used, TX,
RX and ground. Ground is the same as the ecu and engine ground; take this fact in to
account on industrial installations to avoid ground loops. Signal levels are of 3,3V TTL.
Under request Xicoy Electronica can supply a 3 wire lead installed in place of the RJ12
connector, or a RS232 compliant lead.
The adapter has 2 small LED lights to show its working status, one green and one red.
The green led blinks to confirm that there is traffic from ecu to adapter, and the red led
blinks to signal the traffic from the adapter to the external device.
BASIC SETUP:
The list of measures and commands available in the current software release are
described in the protocol section.
If the adaptor is going to be used in a flight vehicle and on this application is necessary to
have the information of fuel flow and remaining tank capacity, due that several fadec
models don’t support these measures, the adapter itself can calculate these values from
the data retrieved from the fadec, plus a couple of parameters to be programmed on the
adapter. This programming is only necessary if you plan to use the fuel flow and tank
capacity information.
The programming procedure is:
Connect the data terminal to the fadec port on the telemetry adapter trough a “Y” servo
lead. Connect a battery (4 to 8V) on the other port of the lead to power both devices.
Connect the battery last, after both devices are already connected.
The RED led on the adapter will lit, and the data terminal will display
Tank capacity: using +/- buttons set the tank capacity on your model in
milliliters. (1Oz=29,6ml)
Pump factor: The unit calculates the fuel used from the pump power supplied the
fadec. Different pump models move different amounts of fuel at same voltage, so this
factor should be set to suit your particular engine+pump+installation.
At moment of writing we don’t have a table of values for the different engines on
the market. The recommended calibration process is:
1) Enter the fuel capacity of your plane in the “tank capacity” menu. Leave the
pump factor at the default 4 unit, unless you know a more accurate figure
for your engine model.
2) Do a normal flight; use your usual timer to determine the length of the flight.
Ignore on this flight the % of fuel in the tank displayed by the telemetry on
landing.
3) After landing, before to shut down the receiver, check the % of remaining fuel
displayed on the telemetry screen.
4) Measure the real quantity of fuel left. If you use a regular shape tank
(cylindrical, square, etc) them you can measure the height of the remain fuel in
respect to total capacity of the tank.
5) Once you know the % displayed on the radio and the real % of fuel in the
tank, you can calculate the correct pump factor in your plane.
Example: You have set a pump factor of 4 . After the flight you see that telemetry show
a remaining fuel quantity of 18%. Then you measure the tank, and you have a tank of
2 cm long of a regular shape and the fuel that remain arrive to 5cm height of the total of
2 cm.
Your remaining fuel is 5/2 *1 = 25%
The indicated fuel as per telemetry is 18%
The error is 18/25= ,72. Then, the new pump factor should be 4 x ,72= 288
Serial interface protocol and electrical connections:
Electrical:
Pin 1 is the TX pin, pin 6 is the RX pin, and pin 5 is ground.
Do not connect anything else on other pins, these pins are
connected directly to CPU and can damage it.
Nominal electrical levels are of 3,3V. Rx input is tolerant to 5V
inputs. TX output always will output a 3,3V signal.
Serial interface settings:
baud rate: 96
data bits: 8
parity: none
stop bits: 1
Protocol description:
Data is retrieved from the adapter trough different commands. See table.
Note that the adapter is continuously retrieving the data from the fadec, but due at the
nature of the fadec protocols and speed data speed used on different fadec models, there
are 3 types of informations available that differ in the refresh rate.
igh speed: Updated 1 times/second, like RPM, EGT, Pump power
Medium speed: Updated each 2 seconds.
Slow speed: Updated once each 6 seconds
Command structure:
SYNC , COMMAND, CR
Where:
SYNC: First byte. Always C7h value (Decimal 199)
COMMAND: 3 byte command in ASCII. See table.
CR: Last byte. Dh value (Decimal 13)
After sending a command, the adapter will return the answer for this particular command,
see the table.
Example:
To retrieve the data displayed on the LCD screen of the fadec. The command is “RSD”.
Then the command would be:
C7h 2Ch 52h 53h 44h 2Ch Dh
C7h -> Sync
2Ch -> “,” Separator
52h -> “R”
53h -> “S”
44h -> “D”
2Ch -> “,” Separator
Dh -> CR, last byte.
The ecu will return two strings.
First, a copy of the command received, followed by the data requested
In the above example, it will return:
The command received: C7h, RSD, Dh
C7h->Sync byte
2Ch -> “,” Separator
Payload in ASCII “TrimLow EGT 2 CRpm 5 . Pw=124”
2Ch -> “,” Separator
Dh -> CR, last byte.
Command
Meaning
Answer
(Payload)
Update
rate
Adapter
version
Fadec
models
RSD
Read Screen
D
ata
ASCII text 32 byte
F
All
All
RCV
Read Current
V
alues
RPM, EGT in ºC,
Pump Power, Voltage
of Battery,
Throttle
%
F
All
All
W
DU
Data Up Command
OK.
-
> Send to the
fadec a keypress on the “+” button
-
All
All
W
D
D
Data Down Command
OK.
-
> Send to the fadec a keypress on the “
-
” button
-
All
All
WMU
Menu Up Command
OK.
-
> Send to the fadec a keypress on the “^” button
-
All
All
W
MD
Menu Down
Command
OK.
-
> Send to the fadec a keypress on the “.” button
-
All
All
RAV
Read Adapter version
ASCII version number (ex: 1. )
F
All
All
REL
Read Engine Limits
Full Power RPM, Idle RPM, Max EGT, Pump Limit
, Tank Size ml
S
All
All
Disposal
