XingKeChuang XKC-Y27B-D3-PUB User manual

深圳市星科创科技有限公司
Shenzhen XingKeChuang Technology Co., Ltd.
Phone: [phone] FAX: [phone] URL: http://www.sz-xkc.com
Address: 11th Floor, No. 48, Xinyu Road, Xinqiao Community, Xinqiao Street, Baoan District, Shenzhen
1/10
Non-contact liquid level sensor instruction manual
(Special series products for small tube liquid level sensor)
XKC-Y27B-PUB
content
1st. Overview .................................................................................................................................................................................... 2
2nd. Scope of application .................................................................................................................................................................2
3rd. Technical Parameters .............................................................................................................................................................. 2
4th. Wiring diagram .......................................................................................................................................................................3
4. 1 Wiring diagram of XKC-Y27B-Dx-V ........................................................................................................................ 3
4.2 Wiring diagram of XKC-Y27B-Dx-NPN ......................................................................................................................4
5th. Product selection .......................................................................................................................................................................5
6th. Structure description ................................................................................................................................................................5
7th. Installation method ...................................................................................................................................................................6
8th. Instructions method ................................................................................................................................................................. 6
9th.Sensitivity setting steps ............................................................................................................................................................. 6
10th. Physical shape map ................................................................................................................................................................ 7
11th. Installation diagram ............................................................................................................................................................... 7
12th. Dimensions related to each model product ..........................................................................................................................7
13th.Precautions ............................................................................................................................................................................... 8
14th.Product warranty terms and instructions .............................................................................................................................9
15th. Manual version ..................................................................................................................................................................... 10
XKC-Y27B-V12

深圳市星科创科技有限公司
Shenzhen XingKeChuang Technology Co., Ltd.
Phone: [phone] FAX: [phone] URL: http://www.sz-xkc.com
Address: 11th Floor, No. 48, Xinyu Road, Xinqiao Community, Xinqiao Street, Baoan District, Shenzhen
2/10
1st. Overview
The intelligent non-contact small tube liquid level sensor (hereinafter referred to as the small tube sensor) adopts
advanced signal processing technology and high-speed signal processing chip, which is specially designed for the liquid
level detection needs of infusion tubes and industrial small tubes. The intelligent non-contact small tube liquid level
sensor can output high and low level signals at the same time, which can meet the needs of various occasions.
The intelligent non-contact small tube liquid level sensor uses the sensing capacitance of water to detect whether there is
liquid. When there is no liquid approaching the sensor, the sensor has a certain static capacitance to the ground due to the
existence of distributed capacitance. , when the liquid level slowly rises and approaches the sensor, the parasitic
capacitance of the liquid will be coupled to this static capacitance, making the capacitance value of the sensor larger, and
the changed capacitance signal is then input to the control IC for signal conversion, which will change the The
capacitance is converted into the change of a certain electrical signal, and then a certain algorithm is used to detect and
judge the degree of this change. When the change exceeds a certain threshold, it is considered that the liquid level reaches
the sensing point.
2nd. Scope of application
It is specialized in small tube application industries, such as medical equipment, medical infusion, biological liquid
detection, scientific research and teaching equipment, intelligent coffee machine, intelligent water dispenser, intelligent
electrical appliances, industrial small tube liquid level detection, etc.
3rd. Technical Parameters
Project name
Parameter
Product number
XKC-Y27B-D3(D4 D6 D8 D10)-PUB
Current consumption
3.5mA
Input voltage (Vin)
5~24(V)
Output method
High and low level，NPN
Output current
≤100mA
Response time
500mS
Working temperature
-20~85℃
Conduit Dimensions (Outer diameter)
D3=3mm
D4=4mm
D6=6mm
D8=8mm
D10=10mm
Humidity
5%~80%(no frosting)
Material
PC V0 fireproof material
Safety standard certification
CE
Environmental certification
ROHS-2.0

深圳市星科创科技有限公司
Shenzhen XingKeChuang Technology Co., Ltd.
Phone: [phone] FAX: [phone] URL: http://www.sz-xkc.com
Address: 11th Floor, No. 48, Xinyu Road, Xinqiao Community, Xinqiao Street, Baoan District, Shenzhen
3/10
4th. Wiring diagram of various models
4. 1 Wiring diagram of XKC-Y27B-Dx-V
High and low level output drive small relay (coil current ≤100mA) working principle:
When the liquid is sensed, the transistor will cut off and output a high level, and the relay will not pull in when it is
powered off;
When no liquid is sensed, the transistor is turned on and outputs a low level, and the relay is energized and pulled
inSimplified schematic diagram of NPN output wiring principle.

深圳市星科创科技有限公司
Shenzhen XingKeChuang Technology Co., Ltd.
Phone: [phone] FAX: [phone] URL: http://www.sz-xkc.com
Address: 11th Floor, No. 48, Xinyu Road, Xinqiao Community, Xinqiao Street, Baoan District, Shenzhen
4/10
4.2 Wiring diagram of XKC-Y27B-Dx-NPN
NPN output drives small relays (coil current≤100mA) working principle:
When the liquid is sensed, the transistor is turned on and closed, and the relay is energized and closed;
When no liquid is sensed, the transistor is cut off and disconnected, and the relay does not pull in when it is cut off.

深圳市星科创科技有限公司
Shenzhen XingKeChuang Technology Co., Ltd.
Phone: [phone] FAX: [phone] URL: http://www.sz-xkc.com
Address: 11th Floor, No. 48, Xinyu Road, Xinqiao Community, Xinqiao Street, Baoan District, Shenzhen
5/10
5th. product selection
serial
number
Product number
output method
Outer diameter of clampable water pipe
1
XKC-Y27B-D3-V
High and low level
The outer diameter of the clampable water pipe is 3mm
2
XKC-Y27B-D3-NPN
NPN
3
XKC-Y27B-D4-V
High and low level
The outer diameter of the clampable water pipe is4mm
4
XKC-Y27B-D4-NPN
NPN
5
XKC-Y27B-D6-V
High and low level
The outer diameter of the clampable water pipe is6mm
6
XKC-Y27B-D6-NPN
NPN
7
XKC-Y27B-D8-V
High and low level
The outer diameter of the clampable water pipe is 8mm
8
XKC-Y27B-D8-NPN
NPN
9
XKC-Y27B-D10-V
High and low level
The outer diameter of the clampable water pipe is 10mm
10
XKC-Y27B-D10-NPN
NPN
6th. Structure description

深圳市星科创科技有限公司
Shenzhen XingKeChuang Technology Co., Ltd.
Phone: [phone] FAX: [phone] URL: http://www.sz-xkc.com
Address: 11th Floor, No. 48, Xinyu Road, Xinqiao Community, Xinqiao Street, Baoan District, Shenzhen
6/10
7th. Installation method
Open installation holes on the panel where the sensor needs to be installed, and place the nuts in the upper and lower
fixing holes of the sensor or in the front and rear fixing holes to tighten to achieve up and down or front and rear fixing.
8th. Instructions method
When the sensor is working normally, put the liquid pipe into the pipe clamp wire groove. The instruction light is on
and the output is high, indicating that there is liquid passing through the current position of the tube. The indicator light is
off and the output is low, indicating that no liquid is passing through the current position of the tube .
9th. Sensitivity setting steps
The sensitivity of the product shall be calibrated in strict accordance with the standard before delivery; However, in the
actual use process, it may be necessary to fine tune the accuracy of sensitivity according to the on-site environment to achieve a
better experience effect.
1. Connect the sensor circuit as required.
2. Align the liquid level in the liquid pipe with the center of the sensor.
3. Turn on the power supply to power up the sensor.
4. After the mark line of the sensor (sensitivity calibration line) and the sensor gnd wire are shorted for about 1 second, the
mark line is converted from high level to low level, and the LED lamp of the sensor flashes to indicate that the sensor enters the
calibration state. After entering the calibration state, the mark line and the gnd wire are separated, and the calibration is
completed successfully when the LED lamp is always on.
Precautions: In normal use, the mark wire of the sensor(sensitivity calibration line) can only be suspended in the air and cannot
be connected to the positive or negative pole of the power supply.（It is recommended that the sensitivity calibration line be
connected to the negative pole (GND) through a switch. When setting the sensitivity, the switch should be closed, and it should
be disconnected in normal use.）
In the picture above, there is no liquid in the
water pipe at the detection level, and the
indicator light does not light up
In the picture above, there is liquid in the water
pipe at the detection level, and the indicator
light is on

深圳市星科创科技有限公司
Shenzhen XingKeChuang Technology Co., Ltd.
Phone: [phone] FAX: [phone] URL: http://www.sz-xkc.com
Address: 11th Floor, No. 48, Xinyu Road, Xinqiao Community, Xinqiao Street, Baoan District, Shenzhen
7/10
10th. Physical shape map
XKC-Y27B-D3 XKC-Y27B-D4 XKC-Y27B-D6 XKC-Y27B-D8 XKC-Y27B-D10
11th. Installation diagram
12th. Dimensions related to each model product

深圳市星科创科技有限公司
Shenzhen XingKeChuang Technology Co., Ltd.
Phone: [phone] FAX: [phone] URL: http://www.sz-xkc.com
Address: 11th Floor, No. 48, Xinyu Road, Xinqiao Community, Xinqiao Street, Baoan District, Shenzhen
8/10
XKC-Y27B-D3 XKC-Y27B-D4
XKC-Y27B-D6 XKC-Y27B-D8 XKC-Y27B-D10
13th.Precautions
1. The viscosity of the liquid medium to be measured
Normal measurement when dynamic viscosity <10mPaS. 10mPaS < dynamic viscosity < 30mPaS may affect the
detection. When the dynamic viscosity is more than 30mPaS, it cannot be measured because a large amount of liquid
adheres to the wall of the container.
2. Note: As the temperature increases, the viscosity decreases, and most high-viscosity liquids are more affected by
temperature, so pay attention to the effect of liquid temperature when measuring viscous liquids.
3. Pay attention to keep the level gauge clean, try to prevent corrosion and avoid violent collisions and blows from other
objects.
4. When installing outdoors, avoid direct sunlight on the main body of the level gauge, keep away from heat sources and
pay attention to ventilation. If the ambient temperature exceeds the rated temperature, corresponding cooling protection

深圳市星科创科技有限公司
Shenzhen XingKeChuang Technology Co., Ltd.
Phone: [phone] FAX: [phone] URL: http://www.sz-xkc.com
Address: 11th Floor, No. 48, Xinyu Road, Xinqiao Community, Xinqiao Street, Baoan District, Shenzhen
9/10
measures should be taken.
5. When the ambient temperature is too low, the instrument protection box or other protective devices can be used for
antifreeze protection, and pay attention to keep the level gauge dry.
6. The sensor should be regularly inspected for maintenance. (The detection time interval is determined by the use unit
according to the specific situation).
14th.Product warranty terms and instructions
(A) .Warranty service
1. Warranty period maintenance: from the date of purchase, the product host has a one-year free warranty. The company
has the right to decide to repair or replace the faulty part. If it is replaced, the replacement part may be a new device or a
repair product of the same category, function, and quality. The replaced faulty part belongs to the company; the product
Resale and repair do not affect the warranty period. Products that have been repaired or replaced continue to enjoy the
original remaining warranty period service. If the warranty period is less than three months after the repair, the repaired or
replaced part shall be shipped from the date of delivery Warranty for three months; all products of the company are
guaranteed for repair.
2. Loss upon arrival (DOA) replacement: From the day of purchase, you can enjoy a free replacement service within 7
days. Products with the following problems are defined as DOA equipment: the packing and packing list do not match
after the first unpacking of the product; some or all of the components cannot be used normally after the first unpacking
of the product (surface scratches or other things that do not affect the function of the device) Defects are not included);
other hardware failures identified by our company’s engineers remotely or locally.
(B). Applicable limitations of warranty
For the following situations, the company does not assume warranty responsibility:
1. The product is out of warranty; the surface of the product is fragile and damaged; the appearance of the product is
seriously damaged, installation/use in abnormal environment, unauthorized disassembly and repair/modification, external
power supply damage and other abnormal damage;
2. Damage caused by incorrect installation and use of the product by the user not following the requirements of the
manual;
3. Damage caused by natural disasters and human negligence (fire, lightning, flooding, impact, etc.).
(C) .Accessories and consumables are not covered by the warranty.
(D) .Non-free warranty service
Within two years of product purchase, for non-warranty product (including components) failures and damages, you can
choose paid maintenance services (free labor costs), and we will charge the transportation cost of repairing parts and
accessories according to the actual situation.
(E). Ways to obtain warranty service
It is recommended that you contact the dealer who purchased this product to obtain the warranty service. For the
warranty, please present a valid warranty card (the dealer’s stamp is required to take effect) or the purchase
invoice/receipt: if you can’t show it, the product’s free warranty period 12 months from the product shipment date, and
the latest DOA application deadline is 7 days from the product shipment date.

深圳市星科创科技有限公司
Shenzhen XingKeChuang Technology Co., Ltd.
Phone: [phone] FAX: [phone] URL: http://www.sz-xkc.com
Address: 11th Floor, No. 48, Xinyu Road, Xinqiao Community, Xinqiao Street, Baoan District, Shenzhen
10 /10
(F). Statement
1. The copyright of this manual belongs to Shenzhen Xingkechuang Technology Co., Ltd. (Xingkechuang) and its
authorized licensors. Shenzhen Xingkechuang Technology Co., Ltd. (Xingkechuang) reserves all rights.
2. Without the written permission of the company, no unit or individual may excerpt or copy part or all of the contents of
this manual, and shall not spread it in any form.
3. The customer recognizes that the purpose of the design and production of the company's products does not involve use
in products related to life support or other systems or products used in other dangerous activities or environments.
Personal injury or death, property or environmental damage due to product failure (collectively referred to as high-risk
activities). The company's products are artificially used in high-risk activities, and the company does not guarantee it and
is not liable to customers or third parties.
4. Due to product version upgrades or other reasons, the contents of this manual may change. Xingkechuang reserves the
right to modify the contents of this manual without any notice or prompt. This manual is only used as a guide.
Xingkechuang makes every effort to provide accurate information in this manual. However, Xingkechuang does not
guarantee that the contents of the manual are completely free of errors. All statements, information and suggestions in this
manual do not constitute any express or Implied guarantee.
5. Not all models are available in all countries/regions
Please keep this manual properly. Before using the product, please read this manual carefully. When using the product,
please be sure to operate in accordance with this manual. The company is not responsible for injuries and accidents
caused by operations that do not follow this manual.
(G).Environmental protection This product meets the design requirements for environmental protection.The storage, use
anddisposal should comply with relevant national laws and regulations.Seek to proceed.
15th. Manual version
Version
Release date
V12
Oct 26, 2022
