XLine Sound ALIVE RB83 User manual

ALIVE ARRAY
·2 x ALIVE RB83
·4 x ALIVE PRO SUB 15
·
·Mobile Djs
·Rental
·Fixed Installation
Live Bands
Anwendung Application
portable digital active P.A.systems for:
·
Its design offers you a high acoustic
output and low extended frequencies,
ideal for voice or music.Use it at any place.
Part number:ALIVE ARRAY
User’s Manual

Before using your speaker box,please read this instruction
manual to prevent any damage.Put it away in a safe place for
future references
★ Avoid exposing the loudspeakers to moisture.If they are set up.
★ outdoors,be sure they are under cover.
★ Warranty is void if you open the case.
★ If you open the case,you may cause malfunctions to it.
★ In case you require a revision of the equipment,please contact
an authorized dealer.
★ Do not use or store the equipment near wet places .May cause.
★ malfunction or shock hazard.
★ Avoid exposure to extreme cold. If you must operate the
loudspeakers in a cold environment,warm up the voice coils
slowly by sending a low-level signal through them for about 15
minutes.
★ Clean inly with a soft,dry cloth.
★ If the power cord is broken,it must be replaced by the manufacturer
or service agent or qualified personnel to avoid risks.
★ Used wisely,your new sound equipment will provide a lifetime
of fun and enjoyment.Since hearing damage from loud noise is
often undetectable until it is too late.Steren recommend you avoid
prolonged exposure to excessive noise.This list of sound levels is
included for your protection.
IMPORTANT
- 1 -
ALIVE PRO SUB 15
User Instructions
Professional Speaker System
The ALIVE PRO SUB 15 active bass system works with
a 600W RMS / 1200W power max.digital power amplifier.
- 2 -

BOX SPEAKER CONTROLS
2
1
3
4
5
6
7
8
9
10
11
12
13
1.
2.Lift channel line input cannon jack.
Allows you to connect an external audio device (CD / radio / etc),with a cannon
connector.
3.Left high pass.
Use this in cannon, only allowed 120 Hz ac above through.
4.On / Off power switch .
Press to power on / off the speaker box.
5.Full range output right
Output signal right.
6.Right channel line input cannon jack.
Allows you to connect an external audio device (CD / radio / etc),with a cannon
connector.
7.Subwoofer volume control.
Set the general volume level.
8.Phase .
In single operation use position “normal”. If use a second active cabinet it’s
adviseable depending on positioning of bass cabinets to turn the phase to
180°.Try in which position the low frequencies sounds best.
9.Right high pass.
Use this in cannon, only allowed 120 Hz ac above through.
10.Power indicator
11.Overload indicator
12.AC power .
Use it to connect the AC power cord.
13.Voltage switch to adjust
Select the voltage you want.
Full range output left
Output signal XLR left for to connect an additional ALIVE 12A.
- 3 - - 4 -
2
3
1
2
3
1

- 6 -
LINE
IN
LINE
OUT
POWE R CLI P
POWER
ON
OFF
AC 115V-2 30 V
115V 2 30 V
A pro du ct of X Li ne acou st ic
250W / 5 00 W CLASS D
RUSS IA
Digital powered
VOLUM E
MIN M AX
2
3
1
2
1
3
4
5
6
7
8
BOX SPEAKER CONTROLS
1.
Set the general volume level.
2.Line out
Output signal .
3.
4.Overload indicator
5.Power indicator
6.AC power .
Use it to connect the AC power cord.
7.On / Off power switch .
Press to power on / off the speaker box.
8.Voltage switch to adjust
Select the voltage you want.
Master volume control
Cannon line-In
RCA Line-in Allows you to connect an external audio device(CD,radio,DVD,
etc.),with a Cannon connector.
- 5 -
ALIVE RB83
User Instructions
Professional Speaker System
The ALIVE RB83 active speaker system works with
a 250W RMS / 500W power max.digital power amplifier.
The ALIVE RB83 use three groups ribbon driver and 3 pcs
8" speaker,with nice frequency response curve, Have
better sound
ALIVE RB83
Ribbo n dri ver

THE WIRING DIAGRAM
- 8 -- 7 -
Amplifier
Connenctors
Input: 1 multi-function Cannon
Output: 1 Cannon
THD: 0.1%
Power(RMS): 250W
Woofer
Diameter: 3x8”
Impedance: 8 Ohms
Coil diameteter: 2”
Magnet: 39 Oz
Tweeter
Impedance: 6 Ohms
Magnet: Neodymium iron N40
Frequency response: 40Hz to 20kHz
Sensitivity: 101dB(1m/1w)
AC options: 230V/50HZ 115V / 60HZ
Diameter: 420mm(L) x 300mm(W) x 690mm(H)
ALIVE RB83 SPECIFICATONS
Product design and specifications are subject to change without
previous notice.
ALIVE PRO SUB 15 SPECIFICATONS
Amplifier
Connenctors
Input: 2 multi-function Cannon
Output: 4 Cannon
THD: 0.1%
Power(RMS): 600W
Woofer
Diameter: 15”
Impedance: 8ohms
Coil diameteter: 4”
Magnet: 100 Oz
Frequency response: 30Hz to 120Hz
Sensitivity: 102dB(1m/1w)
AC options: 230V/50HZ 115V / 60HZ
Diameter: 680mm(L) x 420mm(W) x 510mm(H)
Mixer
2
3
1
2
3
1
2
3
1
2
3
1
LINE
IN
LINE
OUT
POWER CLIP
POWER
ON
OFF
AC 115V-23 0V
115V 230V
A produc t of XLin e acous tic
250W / 50 0W CLASS D
RUSSI A
Digi tal pow ered
VOLUME
MIN MAX
2
3
1
ALI VE RB 83
Ribbo n drive r
2
3
1
2
3
1
2
3
1
2
3
1
LINE
IN
LINE
OUT
POWER CLIP
POWER
ON
OFF
AC 115V-23 0V
115V 230V
A produc t of XLin e acous tic
250W / 50 0W CLAS S D
RUSSI A
Digi tal pow ered
VOLUME
MIN MAX
2
3
1
ALI VE RB 83
Ribbo n drive r
To line in To line in
Full out
Full out
Full out Full out
To line in To line in
ALIVE PRO SUB 15
ALIVE PRO SUB 15
ALIVE PRO SUB 15
ALIVE PRO SUB 15
ALIVE RB83ALIVE RB83
