Xm Xmc050 User manual

Welcome

WelcomeWelcome

Welcome

Thank you for purchasing a Heads Up Technologies XMC050

Satellite Radio luetooth System. Your XMC050 gives you access to

over 150 XM Satellite Radio channels of music, news, sports, traffic

& weather, talk, comedy and more coast to coast.

WARNING: When using this product it is always important to

maintain safe aircraft operation. Changes or modifications to

this device not expressly approved by the manufacturer could

void the user’s authority to operate the equipment.

About XMC050

XMC050 is the latest in the acclaimed line of electronics from Heads

Up Technologies and XM Satellite Radio which represents the best in

aviation satellite radio technology. XMC050 uses two new

technologies – OLED and luetooth. OLED – Organic Light Emitting

Diode uses less power than similar devices while providing superior

illumination and graphics clarity. luetooth wireless communication

provides the latest in industry RF transmission. Unlike traditional

infrared systems requiring line of sight transmission, luetooth

operates through low-density walls and other obstructions.

FCC ID # TGVXMSC43. This device complies with Part 15 of the

FCC rules subject to the following two conditions:

1) This device may not cause harmful interference.

2) This device must accept all interference received, including

interference that may cause undesired operation.

About Heads Up Technologies

Heads Up Technologies designs, manufactures and markets

electronic solutions for the aviation industry. At Heads Up, we’ve

provided integrated digital voice and data systems to more than

2,500 customers across the world. Our users include OEM/airframe

manufacturers, major/regional airlines and corporate and private

fixed-wing and helicopter operators. We also provide Design and

Manufacturing Services to clients in other industries, including

entertainment and government. A turnkey solutions provider, Heads

Up is based in Dallas, Texas – but serves the world.

About XM

One big idea can change everything. And XM Satellite Radio is one

big idea: Radio to the Power of X®. America’s most popular satellite

radio service offers over 150 digital channels of sheer variety: music,

sports, talk, comedy, drama, news, traffic and weather, kids

programming, and more. All XM music channels are 100 percent

commercial-free, and XM’s instant traffic and weather channels

provide the most comprehensive, in-depth information on traffic

incidents, delays, and road conditions available on radio. These

services are available for a low monthly subscription, and additional

devices may qualify for a reduced subscription fee through the XM

Family Plan.

Table of Contents

Table of ContentsTable of Contents

Table of Contents

GETTING STARTED: ACTIVATING XMC050.............................10

XMC050 CASE.......................................................................13

TAKING CARE OF YOUR XMC050...........................................14

ATTERY INSTALLATION .......................................................15

XMC050 CONTROLS..............................................................16

XMC050 DISPLAY SCREEN .....................................................17

XMC050 FUNCTION UTTONS...............................................19

ASIC OPERATIONS ...............................................................24

TROU LESHOOTING ..............................................................34

XM SATELLITE RADIO LIMITED CONSUMER WARRANTY..........35

Getting Started: Activating the receiver

To quickly begin enjoying XM Satellite Radio, follow these simple

steps:

- Locate the identification label on the receiver. On the label is the

two-digit receiver identification number. Write the number Here (Do

NOT skip this step!!!):



- Activate your receiver with XM Satellite Radio by using the

installation instructions that came with your receiver.

- Press the power button to turn your XMC050 on and verify that it

is playing channel 1, the XM Preview Channel.

Now you can contact XM Satellite Radio to activate. Make sure you

have a major credit card and your XM Satellite Radio ID number

handy and contact XM at http://activate.xmradio.com. You may also

activate your service by calling 1-800-985-9200.

Note: You will need to keep your receiver on for at least one hour

after activation to receive the full channel lineup. It is not necessary

to keep your remote on during this time.

XMC050 Case

XMC050 is made from a high strength, painted polymer. It includes

two attachment points.

-One for a lanyard that is supplied for those operators who desire

to secure the XMC050 to provisions in the seatback (fabric loop

inside the seat pocket) or other suitable location.

-A clip that can be used to attach the XMC050 to fabric, vinyl or

leather pouches, pockets and belts.

Taking Care of Your XMC050

Important:

Important:Important:

Important:

Use only a soft, dry cloth to clean the outside of your XMC050.

Do not use any solvents, chemicals, or cleaning solutions containing

alcohol, ammonia, or abrasives. Do not allow liquids to spill on the

unit. Do not use sprays near your XMC050. It is best to keep the

XMC050 out of direct sunlight or other sources of extreme heat.

attery Installation

The XMC050 requires three AAA batteries to operate. Please note

proper battery orientation. attery life is affected by usage.

XMC050 Controls

XMC050 Display Screen

While tuned to an XM channel, the XMC050 default display contains

information about that channel and the XMC050 settings.

XMC050 Function uttons

Controller power. Turns the XMC050 on or off.

Receiver Select. Searches for and sets the receiver

ID. FOR MAINTAINENCE USE ONLY! Password is

FOR MAINTAINENCE USE ONLY! Password isFOR MAINTAINENCE USE ONLY! Password is

FOR MAINTAINENCE USE ONLY! Password is

required for use. Password is 4881. If you access

required for use. Password is 4881. If you accessrequired for use. Password is 4881. If you access

required for use. Password is 4881. If you access

and change your receiver ID you will not be able

and change your receiver ID you will not be ableand change your receiver ID you will not be able

and change your receiver ID you will not be able

to control the receiver with your remote. To

to control the receiver with your remote. Toto control the receiver with your remote. To

to control the receiver with your remote. To

resolve this, you will need to enter the correct

resolve this, you will need to enter the correctresolve this, you will need to enter the correct

resolve this, you will need to enter the correct

receiver ID that you wrote down on page 8.

receiver ID that you wrote down on page 8.receiver ID that you wrote down on page 8.

receiver ID that you wrote down on page 8.

Channel List Up and Down. Used to move up or

down through channel lists.

Previous and Next channel.

Channel List Enter. Used to select highlighted

channel.

Previous and Next Category. Provides category

search and displays channels grouped by

category. Continued presses step through

available categories. Use the ‘Channel List Up and

Down’ buttons to scroll through channels within a

category. Press ‘Channel List Enter’ button to

select channel.

Audio Mute. This button mutes and unmutes the

audio output.

Channel Mode Key – Provides selection between

“Direct” (Direct Channel Entry), Preset “A” and

Preset “ ” options.

Volume Up and Down.

Number keys (0-9). Number keys are used to

select a channel directly (when in Direct Entry

mode), and to select or set presets when in a

Preset mode.

Display Format Select. The display button toggles

between two display options:

- Channel name, channel number, artist name,

song title.

- Channel name, and a big channel number.

Memory. Press Memory to save artist name and

song title information. Press and hold the memory

key to recall information.

asic Operations

Turning the XMC050 On and Off

Turning the XMC050 On and OffTurning the XMC050 On and Off

Turning the XMC050 On and Off

Press the button on the XMC050. When first turned on, the

receiver will power up in mute mode, and remain muted until a

connection is established with the remote. After the connection is

established the volume level and channel are changed to previous

settings.

Direct Channel Selection

Direct Channel SelectionDirect Channel Selection

Direct Channel Selection

The system should be in Direct Entry mode. “Direct” will appear in

the upper right corner of the display. If A, appears, press ‘Channel

Mode Key’ until the display says “Direct.” Then, enter your desired

channel number using the number keys,

e.g., 5 then 0 for Channel

50.

Channel presets

Channel presetsChannel presets

Channel presets

Your XMC050 can store up to 20 preset channels. They are

organized into two different groups (Preset A and Preset ), each

with 10 channels corresponding to the 10 number keys. For the

tenth preset in each group, press the “0” key.

Setting channel presets

Setting channel presetsSetting channel presets

Setting channel presets

1. Tune in the channel you want to register as a preset, making sure

it is playing.

2. Select either Preset A, or Preset by pressing until an A or

appears in the upper right corner of the display.

3. Press and hold the number key corresponding to the preset you

would like to set. The upper right corner of the display will change

to indicate the preset channel “A-1”.

4. When you first get your XMC050, all presets go to Channel 1.

Selecting channel presets

Selecting channel presetsSelecting channel presets

Selecting channel presets

Press the button until an A or appears in the upper right

corner of the display. Press the number key corresponding to the

desired preset.

Select a channel by category

Select a channel by categorySelect a channel by category

Select a channel by category

Press either of the category keys to enter category search.

1. Continue pressing one of the category keys until a category you

are interested in appears.

2. Press the to move between the channels within the

category.

3. Press to tune to the selected channel.

4. If you do not select a channel, category search will time out after

several seconds.

5. Pressing the key changes from channel names to artist names

to song names back to channel names.

6. Holding the up/down-arrow key auto-repeats them.

Select a channel by channel name

Select a channel by channel nameSelect a channel by channel name

Select a channel by channel name

Press either of the to enter channel search.

1. Press the up-arrow or down-arrow to move between the

channels.

2. Press to tune to the selected channel.

4. If you do not select a channel, channel search will time out after

several seconds.

5. Pressing the key changes from channel names to artist names

to song names back to channel names.

6. Holding the up/down-arrow key auto-repeats them.

Changing the Display

Changing the DisplayChanging the Display

Changing the Display

Pressing lets you change what is shown on your three-line

XMC050 display during normal listening from among options:

• Display mode 1 (factory default): Shows the channel name and

channel number on the first line, the artist name on the second line

and song title on the third line.

• Display mode 2: Shows the channel name on the first line, and a

big channel number on the second line.

Save and Recall Artist Name and Song Title Information

Save and Recall Artist Name and Song Title InformationSave and Recall Artist Name and Song Title Information

Save and Recall Artist Name and Song Title Information

You can save the artist name and song title on the current channel

for future reference.

1. Press and release to save the current screen information. Up

to 10 different artist and song titles can be saved, after which any

new information that is saved will replace the oldest information in

memory.

2. To recall saved information, press and hold for 3 seconds.

Next, use the Channel List buttons to display each saved artist

name/song title.

Audio Level

Use to adjust the XMC050 audio-output level if it is too high,

causing distortion, or if too low. Most users will not need to change

this level from the factory setting. You should set the volume using

the audio system connected to your XMC050. Holding the +/- keys

auto-repeats them.

Power Conservation

The XMC050 uses two methods to extend battery life:

1.) After 30 seconds of inactivity (no key presses) the display will

shut off. y pressing any key the screen will turn on.

2.) After 3 minutes of inactivity the remote will shut off. The remote

can be turned back on by pressing the button

Troubleshooting

Your XMC050 has been designed and built to provide you with

trouble-free performance. If it does not appear to be functioning

correctly, please follow these troubleshooting steps:

1. Make sure the batteries are charged and properly installed.

2. Make sure all connectors are properly attached.

If this happens:

If this happens:If this happens:

If this happens: You should:

You should:You should:

You should:

You do not receive all

subscribed XM

Channels. Cause: Your

receiver is not activated.

Contact XM Satellite Radio

The audio sounds distorted Reduce audio-output level

The audio level is too low Increase audio-output level

You cannot tune to a channel Verify that you are authorized

to receive that channel as part

of your subscription with XM

and that you have not asked

XM to block that channel.

No song title or artist name Nothing is wrong with your

receiver. This is normal on

many talk and news channels.

Also, this information may

not yet be in the channel

lineup for some selections.

The audio on the XM instant

traffic and weather channels

Nothing is wrong with your

receiver. These channels use

does not sound the same as

the other XM channels.

a different audio technology

than the main XM channels in

order to provide many

different dedicated city

channels.

Contacting Product Technical Support and Customer Service

Contacting Product Technical Support and Customer ServiceContacting Product Technical Support and Customer Service

Contacting Product Technical Support and Customer Service

For additional information in solving problems, contact:

Heads Up Technologies at 1.972.980.4890 Monday—Friday,

8:00am—5:00pm Central Standard Time.

XM Satellite Radio Limited Consumer Warranty

Heads Up Technologies

Heads Up TechnologiesHeads Up Technologies

Heads Up Technologies

Limited Warranty - Satellite Radio Products

Limited Warranty - Satellite Radio ProductsLimited Warranty - Satellite Radio Products

Limited Warranty - Satellite Radio Products

Heads Up Technologies, Inc., hereby warrants that it will repair or replace, at its

Heads Up Technologies, Inc., hereby warrants that it will repair or replace, at itsHeads Up Technologies, Inc., hereby warrants that it will repair or replace, at its

Heads Up Technologies, Inc., hereby warrants that it will repair or replace, at its

option, any part of the Heads Up product with which this warranty is enclosed which

option, any part of the Heads Up product with which this warranty is enclosed whichoption, any part of the Heads Up product with which this warranty is enclosed which

option, any part of the Heads Up product with which this warranty is enclosed which

proves defective by reason of improper workmanship and/or material, without charge

proves defective by reason of improper workmanship and/or material, without chargeproves defective by reason of improper workmanship and/or material, without charge

proves defective by reason of improper workmanship and/or material, without charge

for parts or labor. The XM radio/weather receiver is covered for a period of 2 years

for parts or labor. The XM radio/weather receiver is covered for a period of 2 yearsfor parts or labor. The XM radio/weather receiver is covered for a period of 2 years

for parts or labor. The XM radio/weather receiver is covered for a period of 2 years

and the XM remote is covered for a period of 1 year. This warranty period commences

and the XM remote is covered for a period of 1 year. This warranty period commencesand the XM remote is covered for a period of 1 year. This warranty period commences

and the XM remote is covered for a period of 1 year. This warranty period commences

upon the in-service date, or six months from Heads Up invoice to buyer, whichever is

upon the in-service date, or six months from Heads Up invoice to buyer, whichever isupon the in-service date, or six months from Heads Up invoice to buyer, whichever is

upon the in-service date, or six months from Heads Up invoice to buyer, whichever is

later, and only if such original purchase by the buyer was made in the United States.

later, and only if such original purchase by the buyer was made in the United States.later, and only if such original purchase by the buyer was made in the United States.

later, and only if such original purchase by the buyer was made in the United States.

Products supplied by and not manufactured by Heads Up shall be covered by the

Products supplied by and not manufactured by Heads Up shall be covered by theProducts supplied by and not manufactured by Heads Up shall be covered by the

Products supplied by and not manufactured by Heads Up shall be covered by the

original manufacturer’s warranty.

original manufacturer’s warranty.original manufacturer’s warranty.

original manufacturer’s warranty.

To obtain service under this warranty you must return your Heads Up product or

To obtain service under this warranty you must return your Heads Up product orTo obtain service under this warranty you must return your Heads Up product or

To obtain service under this warranty you must return your Heads Up product or

component as instructed in the maintenance manual, packaged in the original

component as instructed in the maintenance manual, packaged in the originalcomponent as instructed in the maintenance manual, packaged in the original

component as instructed in the maintenance manual, packaged in the original

shipping container or an equivalent, to the nearest authorized service center or the

shipping container or an equivalent, to the nearest authorized service center or theshipping container or an equivalent, to the nearest authorized service center or the

shipping container or an equivalent, to the nearest authorized service center or the

dealer from whom the product was purchased. Any postage, insurance, shipping,

dealer from whom the product was purchased. Any postage, insurance, shipping,dealer from whom the product was purchased. Any postage, insurance, shipping,

dealer from whom the product was purchased. Any postage, insurance, shipping,

and installation costs incurred in presenting your Heads Up product for service are

and installation costs incurred in presenting your Heads Up product for service areand installation costs incurred in presenting your Heads Up product for service are

and installation costs incurred in presenting your Heads Up product for service are

your responsibility. The original bill of sale or other satisfactory proof of the date of

your responsibility. The original bill of sale or other satisfactory proof of the date ofyour responsibility. The original bill of sale or other satisfactory proof of the date of

your responsibility. The original bill of sale or other satisfactory proof of the date of

the original purchase of your HEADS UP product must be made available to obtain

the original purchase of your HEADS UP product must be made available to obtainthe original purchase of your HEADS UP product must be made available to obtain

the original purchase of your HEADS UP product must be made available to obtain

service under this warranty.

service under this warranty.service under this warranty.

service under this warranty.

This warranty applies only if your Heads Up product fails to function under normal

This warranty applies only if your Heads Up product fails to function under normalThis warranty applies only if your Heads Up product fails to function under normal

This warranty applies only if your Heads Up product fails to function under normal

use and within the manufacturer's specifications.

use and within the manufacturer's specifications. use and within the manufacturer's specifications.

use and within the manufacturer's specifications. This warranty does not apply if the

This warranty does not apply if theThis warranty does not apply if the

This warranty does not apply if the

Table of contents
