XPOtool SK-22B User manual

Operation Manual
3-Phase Pressure Switch for House Water Systems,
Pumps, and Compressors SK-22B
50621
Illustration similar, may vary depending on model
Read and follow the operating instructions and safety information before using for the first time.
Technical changes reserved!
Due to further developments, illustrations, functioning steps, and technical data can differ insignificantly.
Updating the documentation
If you have suggestions for improvement or have found any irregularities, please contact us.

https://www.XPOtool.com Item 50621 Page 2
The Tool Experts
08 2022-1
The information contained in this document may alter at any time without previous notice. It is prohibited
to copy or spread any parts of this document in any way without prior written allowance. All rights re-
served.
The WilTec Wildanger Technik GmbH cannot be held accountable for any possible mistakes in this
operating manual, nor in the diagrams and figures shown.
Even though, the WilTec Wildanger Technik GmbH has undergone biggest possible efforts to ensure
that the operating manual is complete, faultless, and up to date, mistakes cannot be entirely avoided.
If you should find a mistake or wish to make a suggestion for improvement, we look forward to hearing
from you.
Send an e-mail to:
[email protected]
or use our contact form:
https://www.wiltec.de/contacts/
The most recent version of this manual in various languages can be found in our online shop via:
https://www.wiltec.de/docsearch
Our postal address is:
WilTec Wildanger Technik GmbH
Königsbenden 12
52249 Eschweiler
Germany
To return orders for exchange, repair, or other purposes, please use the following address. Attention!
To allow for a smooth execution of your complaint or return, it is important to contact our customer
service team before returning the goods.
Returns Department
WilTec Wildanger Technik GmbH
Königsbenden 28
52249 Eschweiler
E-mail: [e-mail]
Tel: [phone]
Fax: [phone]

https://www.XPOtool.com Item 50621 Page 3
The Tool Experts
08 2022-1
Introduction
Thank you for purchasing this quality product. To minimise the risk of injury we urge that our clients
take some basic safety precautions when using this device. Please read the operation instruc-
tions carefully and make sure you have understood its content.
Keep these operation instructions safe.
Usage
The SK-22B is suitable as a replacement part for many common compressors, such as those used in
workshops for mobile compressors. The switch-on and switch-off pressure can be continuously ad-
justed. You can also use the SK-22B to switch three phases, i.e., phase and neutral at the same time.
Technical data
Voltage (single-phase) (V)
380
Permissible voltage fluctuation (%)
±10
Max. current (A)
16
Phases
3
Max. operating pressure (㍴)
13
Pressure setting range (㍴)
3–12 (continuously adjustable)
Starting pressure setting range (㍴)
5.5–8 (continuously adjustable)
Connections (㎜)
20.67 (½″)
Operation temperature (℃)
0–55
Material
Plastic/Metal
Colour
Black
Protection class
IP20
Setting
1. Loosen the differential pressure nut (2).
2. Set the switch-on pressure (1).
3. Screw in the differential pressure nut (2) up to the switch-off pressure.

https://www.XPOtool.com Item 50621 Page 4
The Tool Experts
08 2022-1
Dimensions and parts
Switch-on pressure (1)
Differential pressure (2)
Motor
Phase 1
Phase 2
Phase 3
Earth

https://www.XPOtool.com Item 50621 Page 5
The Tool Experts
08 2022-1
