Xtant 2200ix Assembly instructions

INPUT SENSITIVITY ADJUSTMENT
The 2200ix offers five (5) input gain settings. The adjust-
ment runs in 10 dB steps from -20 dB to + 20 dB. This wide
range of adjustment allows the 2200ix to accept input volt-
ages from 100 mV to 17 V. Adjustment is made by
installing a jumper across the associated input voltage/pin
location. Refer to the illustration on the reverse side of this
document prior to setting the input sensitivity.
CROSSOVER MODES OF OPERATION
The 2200ix is equiped with two (2) crossover mode
jumpers. The four (4) position header jumper controls the
crossover function as it applies to the 2200ix’s amplifier.
The modes of operation are: Position 1 = Bypass (Full
Range), Position 2 = High Pass, Position 3 = Low Pass, and
Position 4 = Band Pass. (See illustration)
The three (3) position jumper controls the crossover
function as it applies to the RCA Line Outputs. The modes
of operation are: Position 1 = Bypass (Full Range), Position
2 = High Pass, and Position 3 = Low Pass.(See illustration )
The High and Low Pass frequenies are determined by the
Frequency Modules (SIPs) installed in the two (2) SIP sock-
ets pictured on the reverse side of this document.
CROSSOVER FREQUENCY MODULES
The following is a chart of Xtant’s available frequency
modules. The frequency module (SIP) “ID Code” printed on
the SIP and the associated frequency value is detailed below.
SIP Number Frequency
224 50 Hz
134 70 Hz
114 80 Hz
104 90 Hz
683 120 Hz
563 150 Hz
273 300 Hz
153 500 Hz
103 700 Hz
752 1 kHz
242 3 kHz
182 4 kHz
152 5 kHz
The 2200ix amplifier is shipped from the factory with 90
Hz High Pass and Low Pass frequency modules (SIP)
installed. To change a frequency module, simply remove the
resistor SIP and replace it with the appropriate SIP value to
achieve the desired frequency.
The Low and High Pass frequencies are independent. Any
combination of the available frequency modules (SIPs) may
be used (ie. 80 Hz Low Pass and 120 Hz High Pass).
•••••••••
installer’s reference
xtant technologies
THIS DOCUMENT HAS BEEN CRAFTED TO MAKE INSTALLA-
TION, SYSTEM DESIGN AND TROUBLE-SHOOTING, A QUICK
AND EASY PROCESS. THE CHARTS PROVIDED, OFFER A SIM-
PLE METHOD OF DOCUMENTATION.
IT IS IMPORTANT THAT YOU RETAIN THIS LOG
FOR YOUR RECORDS. ON PAGE 12 OF THE OWNER’S
MANUAL, YOU WILL FIND THE OWNER’SREFERENCE LOG.
ONCE YOU HAVE NOTATED THE FINAL SETTINGS FOR THIS
2200IX, TRANSFER THOSE SETTINGS TO THE OWNER’S
REFERENCE LOG. IN THE FUTURE, ANY SYSTEM EXPANSION
AND
/OR PROBLEMS MAY BE REFERENCED TO THIS LOG.
INSTALLATION SEQUENCE
REMOVE AMPLIFIER COVER:
Loosen allen head screws and lift-off cover. Do not remove
protective covering on stainless steel lid until installa-
tion is complete.
TEMPORARILY MOUNT AMPLIFIER:
The amplifier is designed to be anchored through the four
(4) holes located on the circuit board/base assembly.
MARK WIRES FOR TERMINATION AND REMOVE 2200IX:
Determine wire lengths for Power, Ground, Remote, &
speaker cables. Mark for cutting/termination. Remove the
2200ix before cutting and terminating all wires. CAU-
TION: stripping wires over the circuit board may cause
product failure.
CROSSOVER SET-UP:
Adjust crossover mode jumpers at your work bench. Also,
change crossover frequency SIP’s if desired.
INPUT SENSITIVITY:
Make initial adjustment to input gain at your work bench.
To increase input gain, place jumper in the +20 dB posi-
tion. To decrease input gain, place jumper in the 0, -10,
or -20 dB position.
MOUNT THE AMPLIFIER AND MAKE ALL CONNECTIONS:
Re- install the amplifier and make all wire connections.
i.e:.Speaker, Power, Remote, Ground, and RCA input.
DOUBLE CHECK ALL CONNECTIONS! TURN ON AMPLIFIER.
Check red LED, it should be on.
ADJUST LEFT, RIGHT AMPLIFIER GAINS.
ADJUST NOISE GATE THRESHOLD (IF USED):
Turn noise gate on and adjust the threshold by turning
clockwise to increase sensitivity (gate will open with less
input signal). The green LED will illuminate when the
gate passes signal.
AFTER FINE TUNING THE SYSTEM:
Remove protective covering from amplifier and clean per
the maintanence section on page 9 of the Owner’s
Manual. Attach cover to base.
•••••••••
INSTALLER’S REFERENCE LOG
DATE INSTALLED:
OWNERS NAME: PHONE:
ADDRESS:
CITY/STATE: ZIP:
VEHICLE: YEAR:
XTANT AMPLIFIER:MODEL SERIAL#
CROSSOVER SETTINGS: JUMPER SETTINGS:
SIP HIGH PASS AMPLIFIER:(CIRCLE SETTING)
VALUE CODE: ALL HIGH LOW BAND PASS
SIP LOW PASS RCA OUTPUTS (CIRCLE SETTING)
VALUE CODE: ALL HIGH LOW
INPUT SENSITIVITY JUMPER (CIRCLE SETTING)
–20 dB –10 dB 0 dB +10 dB +20 dB
OUTPUT GAIN ADJUSTMENT ( DRAW ARROW POSITION ) NOISE GATE ADJUSTMENT
THRESHOLD POSITION
SWITCH: IN DEFEAT
(CIRCLE SETTING)
Accessory modules (CIRCLE YES OR NO)
CM24X YES N O PQM 1 YES
NO
CHIP FREQUENCY
system components
SOURCE SERIAL #
PROCESSOR(S)SERIAL #
SERIAL #
AMPLIFIER(S)SERIAL #
SERIAL #
SERIAL #
SPECIAL COMPONENTS
SERIAL #
SERIAL #
LEFT RIGHT
xtant technologies •••••••••
7676 SOUTH 46TH STREET PHOENIX, ARIZONA 85040 USA
••••••••602.431.8686
All manuals and user guides at all-guides.com
all-guides.com

MAXI
FUSE
50 AMP
REMOTE
GROUND
12 V
GREEN LED
NOISE GATE YELLOW LED
LOW IMPEDANCE ORANGE LED
THERMAL PROTECT RED LED POWER ON
SPEAKER OUTPUTS
LEFT RIGHT
LEFT RIGHT
INPUTS LEFT RIGHT OUTPUTS
–20
–10
0
+10
+20
+
+POSITIVE
+ –
–NEGATIVE
–
BALANCED LINE
FAN
CROSSOVER
MODE JUMPERS:
CROSSOVER SIP SOCKETS
2 HP
3 LP
1 BYP
1 BYP
RCAOUTPUT AMPLIFIER
2 HP
3 LP
4BNP
REMOTE SWITCHED 12 VOLTS
16 GAUGE OR LARGER
NOTE: ADD 50 AMP FUSE
AT POSITIVE TERMINAL OF
THE BATTERY.
NOISE GATE THRESHOLD ADJUST:TURN CLOCKWISE TO INCREASE SENSITIVITY (GATE WILL OPEN WITH LESS INPUT SIGNAL)
NOISE GATE SWITCH:LEFT POSITION = ON; RIGHT POSITION = OFF
GROUND – 8 GAUGE OR LARGER
SPEAKER WIRE – 14 GAUGE OR LARGER
POWER – 8 GAUGE OR LARGER
BRIDGED OUTPUT CONNECTION
ACCESSORY MODULE PORT:REMOVE JUMPERS (2) PRIOR TO INSTALLATION OF ACCESSORY MODULE.
JUMPERS MUST BE IN-PLACE WHEN MODULE IS NOT INSTALLED.
INPUT SENSITIVITY:TO ADJUST INPUT GAIN, MOVE JUMPER (IF NEEDED) – AND INSTALL IT IN THE LOCATION WHICH
MATCHES YOUR INPUT SIGNAL LEVEL. REFER TO THE ILLUSTRATION BELOW FOR PROPER JUMPER LOCATION / LEVEL SETTING.
NOTE: –20 dB = 10V – 17V IS ONLY TO BE USED WITH BALANCED INPUT FROM A BALANCED SOURCE.
–20 dB = 10V–17V –10 dB = 3V – 8V 0 dB = 1V – 3V +10 dB = 300mV–1V +20dB=100–300mV
CROSSOVER
FREQUENCY SELECTION:
TO CHANGE THE FREQUENCY
OF EITHER THE HIGH AND/OR
LOW PASS FILTERS, REMOVE
AND REPLACE THE FRE-
QUENCY MODULE (SIP)
LOCATED ON THE CIRCUIT
BOARD NEXT TO THE
CROSSOVER MODE JUMPERS.
NOTE THAT THE IDENTITY OF
THE HIGH & LOW PASS
SOCKETS ARE NOT MARKED
ON THE BOARD. REFER TO
THIS DRAWING FOR LOCA-
TION & THE CHART ON THE
BACK FOR THE AVAILABLE
SELECTION OF SIP / FRE-
QUENCY VALUES.
RCA OUTPUTS:
3 – LOW PASS
2 – HIGH PASS
1 – BYPASS
AMPLIFIER:
4 – BAND PASS
3 – LOW PASS
2 – HIGH PASS
1 – BYPASS
LOWPASSSIP
INDEPENDENT LEFT AND RIGHT AMPLIFIER GAIN
CONTROLS – ROTATE CLOCKWISE TO INCREASE SENSITIVITY.
XTANT TECHNOLOGIES 7676 SOUTH 46TH STREET PHOENIX, ARIZONA 85040 PHONE: [phone] FAX [phone]
HIGH PASS SIP
BONDED FIN
HEATSINK
INSTALLER’S
REFERENCE
..............
XTANT2200IX
..............
Caution:SHARPEDGES
be careful when
handling top and
bottom metal.
Left
right
Balanced line: Disable (off) jumper position
Enable (on)
SERVICE JUMPER: REMOVING JUMPER WILL TURN-OFF AMPLIFIER WHEN
