Owner’s Manual – RLC
Remote Level Connector
7676 South 46th Street • Phoenix, Z 85040
888.449.8268 • Xtant.com
# NDM152

TThhee RRLLCC iiss ddeessiiggnneedd ttoo bbee aaddjjuusstteedd wwiitthh tthhee uussee ooff aa
ccoonnttrrooll kknnoobb
 Remove the RLC from the package
 Turnoff amplifier
 Plug the supplied cord into the RLC’s socket on the
amplifier
 Rotate the amplifier’s gain control clockwise to the
loudest desired listening level
 Run the supplied cord to the location in the vehicle
where you want to mount the gain knob
INSTALLING THE RLC
STEP 1: Installing on Amplifier
INSTALLING THE RLC
STEP 2: Rear & Surfa e Mount
FFOORR RREEAARR MMOOUUNNTT
 Gently pull the black gain knob off the shaft to remove it
 Plug the cord into the RLC control box
 Use a /” size drill bit to make a hole in the surface you wish
to mount the knob to
 Place the control box behind the panel and insert the knob
through the hole
 Replace the nut located in the parts bag on the shaft by turn
ing it clockwise and then gently push the knob back onto the
shaft
 The RLC knob is now controlling the gain of your amplifier
FFOORR SSUURRFFAACCEEMMOOUUNNTT
 Plug supplied cord into RLC control box
 Secure control box to surface where you wish to mount it
with supplied screws
 The RLC knob is now controlling the gain of your amplifier
