xtpower XT-750Wh User manual

User Manual
Portable Power Supply
P
o
w
e
r
y
o
u
r
l
i
f
e
!

What's inside the box1
1
Dear Customer,
Thank you for choosing our portable power supply.
Our product adopts the advanced lithium-ion battery technology
and is an ideal portable power supply solution for your activities.
It makes your camping, shing and other activities more comfort-
able and easier. Furthermore, it can also be used
as critical backup power in emergency.
Please carefully read and follow the instructions before using this
product. If there is any question, please contact our team.
Hope you enjoy using our product.
* Before using, please use the provided charger to fully charge our product and
ensure it can work normally.
* Please read this manual before using our product and keep it for future reference.
* The design and specications are subject to change without prior notice.
Portable Power Supply Charger Manual
Packing List
Solar Panel
Optional Accessories

Get to know our product2
1. ON/OFF power switch
2. LCD screen
3. AC Adaptor input
4. Solar charging input
5. USB outputs
6. 12V DC outputs
7. Cigar lighter output
8. AC output button
9. AC output indicator
10. AC outputs
2
11. Cooling fan
12. Light
13. Light button
14. Handle
11
12
1413
EUROPE, SOUTH
AMERICA & ASIA
USA, MEX,
CAN & JPN
GBR, IRL, MLT,
MAS & SIN
AUS, NZL,
ARG & CHN
2
1
34
5
67
9
8
10
Please refer to below respective outlet types
30-36V

Use our product
3
*When battery capacity is below 20%, AC outputs will be automatically disabled.
* When battery capacity is below 5%, DC (USB & 12V) outputs will be automatically
disabled.
* When DC is in use or AC is on, the discharging indicator on the right side of LCD
screen remains rotating ( ).
·
3
Switch on our product, it will start initial self-checking.
During the process, all the icons on the LCD screen will be activated.
The LCD screen will turn to normal display if all functions are normal.
Press AC output button, LED indicator is on and the AC output icon ( ) on
the LCD screen will be activated, then you can charge your devices.
When you finish using, press AC output button to turn off the AC output.
The interval time between pressing AC output button on/off should not be
less than 5 seconds.
Power On
Using AC Output
·

USB outputs can be used directly to charge your devices. When our product
detects the load, the USB icon ( ) on the LCD screen will be activated.
Our product has 3 separate USB ports, with different output currents of each
one (see the technical specification for more details). You can use different USB
port according to your power request, while the 3 USB ports are not allowed
to charge in parallel the same device by connection or modification.
12V DC outputs can be used directly to charge your devices. When our product
detects the load, the DC icon ( ) on the LCD screen will be activated.
Our product has two separate 12V DC outputs, with the same output power.
4
Using 5V Output
Using 12V DC Output

12V DC cigar lighter outputs can be used directly to charge your devices.
When our product detects the load, the 12V DC cigar lighter icon ( ) on
the LCD screen will be activated. The max output power is 60W.
There are 5 lighting modes:
High bright (100% power), Normal (50% power), Energy saving (25% power),
Emergency flash and SOS.
Press the light button hard to turn on/off the light, and press gently to shift
between different modes.
SOS
When finish using, please power off our product by following steps:
①Remove all the connected cables and loads;
② Press to turn off the AC output, and the LED indicator will be off;
③ Switch off the power, and well keep it for next using.
Using 12V DC Cigar Lighter Output
Lighting
Power Off
5

• 40W Input = 20-25 hours
• 60W Input = 12-15 hours
• 80W Input = 10-12 hours
• 100W Input = 8-10 hours
• 120W Input = 6-7 hours
• 200W Input = 4-5 hours
Charging time based on the best performance.
Wall Charging
Solar Charging
6
In case of using the optional solar panel, please not: A solar panel generate
electricity from direct sunlight. Keeping solar panels away from curtains or
behind windosw and exposing them toward the sun at a proper angle can
significantly improve efficiency.
Important: Please do not use our product while charging!
Recharging
approx. 5 Hours
approx. 10 Hours

USB
12V DC 12V Cigar Lighter
AC
AC Adaptor Charging
Solar
Charging
Charging
Indicator Discharging
Indicator
Warning
LCD Screen Guide4
No. Alarm LCD Screen Display Causes
Every 1 sec.
Every 2 sec.
Every 3 sec.
Every 4 sec.
Low Battery Icon keeps flashing
until battery is charged above10%
Warning Icon keeps flashing until
fault is resolved.
Battery capacity below 10%
Charging fault
DC output fault
AC output fault
Over temperature
1
2
3
4
5
Input
Being charged by solar
Being charged by AC adaptor
Remain rotating when being charged
Battery
Battery Volume Indicator
USB in use
12V DC in use
12V Cigar Lighter in use
AC power is on
Remain rotating when DC in use or AC is on
Output
7
Warning

Trouble Shooting5
8
No. Faults Causes Solutions
Under-voltage Protection
Abnormal Load Protection
Product Damage
Unmatched Charger
Charger Damage
Abnormal Power Supply
or Connection
Over-Current
Weak Sunlight
Abnormal Wiring-harness
Connection
Battery Under-voltage
Protection
Discharge Over-current
Protection
Over-temperature
Protection
Product Damage
Hardware Fault
LCD Screen Damage
Failure to
Power-up
Charger Fault
Solar Panel
Charging Fault
DC / AC
Output Fault
Abnormal Icon
Display
LCD Screen Fault
Abnormal Loads
Please charge our product.
Please remove the loads and recharge
our product. If the problem can not be
solved, please ask for repair.
Please send back to the dealer/
shop for repair or replacement.
Please only use the authorized
charger.
Please contact your local dealer to
replace the charger.
Please re-connect the charger. If the
problem cannot be solved, please
contact your local dealer to replace
the charger.
Please use only PV panel within the
technical specification.
Please charge in sunny place.
Please contact your local dealer to
replace the PV panel.
Please re-connect the wiring-harness.
If the problem can not be solved,
please contact your local dealer to
replace the PV panel.
Please charge our product.
Please check and ensure the power
of loads are within the allowed range.
(Total loads ≤500W).
Please turn off our product and restart
after cooling down.
Please send back to the dealer/shop
for repair or replacement.
Please remove the loads.
Please send back to the dealer/shop
for repair or replacement.
Solar Panel Damage
LCD Screen Damage
Please send back to the dealer/shop
for repair or replacement.
Please send back to the dealer/shop
for repair or replacement.
1
2
3
4
5
6

Loading time:
32
TV
7+ hours
Laptop
8+ times
Tablet
17+ times
Smart phone
70+ times
PSP
175+ times
Mini Bar
15+ hours
60W Fan
12+ hours
12V 3W
Lighting
230+ hours
Camera
85+ times
Stereo
15+ hours
*All technical features are tested and achieved under the environment of 25℃
Specifications6
9
756Wh (25.2V, 30Ah)
7.6kg (16.7lbs)
349 × 160 × 285 mm (13.7 × 6.3 × 11.2 in)
Working : -10 ~ 45℃(14 ~ 113℉)
Storage : 0 ~ 45℃(32 to 113℉)
2 x 230V/50Hz 500W (1200W short peak)
30 - 36V / Max. Power up to 200W
150W AC Wall Charger / 29.4V5A
2 x 12V 2.5A
1 x 5V 1A + 1 x 5V 2A + 1 x 5V 2.4A
1W High Brightness LED with SOS mode
1 x 12V 5A/60W
Capacity
Weight
Dimensions
Adaptor Input
Solar Input
USB Output
Lighting
Temperature
AC Output
Cigar Lighter
DC Output

Attentions7
10
Please use our product to charge your devices under the environ-
ment of 0℃to 45℃, and do not use it if the environment tempera-
ture is excessively low or high.
Please recharge our product under the environment of 0℃-45℃.
Recharging our product above 45℃ may cause overheating or fire.
Please use the original or authorized cable or charger.
Please use our product between 20%-90% battery volume to achieve
longer service life and better performance.
Please keep it away from heat source, fire, inflammable gas or liquid,
and please do not expose to the blazing sun for long time.
Please recharge or use it at least once every four months for a longer
product life.
Please keep it away from children or pets.
Please do not carry this product aboard planes.
Unauthorized disassembly is forbidden. Violation may cause electric
shock or product damage, even fire or explosion in serious situations.
Please avoid dropping our product.
Please avoid metal objects ingress.
0 -45
°C

Warranty8
Disposal Information10
Warranty Exclusions:
• Warranty period exceeded.
• No valid purchase voucher (like invoice, etc.) can be provided, or the
voucher was modified without authorization, or the writing on the voucher
cannot be recognized.
• Repaired or modified by unauthorized agency or individual.
• Provided accessories e.g. charger missed.
• Damage caused by using the unauthorized accessories, like unauthorized
charger.
• Damage caused by improper transportation, usage, operation, or storage.
• Damage caused by force majeure, like lightning, abnormal voltage, flood,
fire, natural disaster, or accidental breakage, etc.
• Damage caused if our product is used in territories where it is not intended
to design and produce for.
11
Do not throw batteries or rechargeable batteries into the household waste.
The Battery Directive requires consumers to return these to the manufac-
turer, retailer or a public collection site at the end of their life.
This is indicated by the crossed out trash can icon on the product, in the
instructions for use and/or the packaging. This type of material separation,
recovery and recycling of used batteries and storage batteries is
significantly contributes to protecting the environment.
Subject to Battery Directive: 2006/66/E
CE Declaration of Conformity9
CE Declaration of Conformity
This product bears the required CE marking according to Directive
2004/108/EC. The product meets the essential requirements of the
European directives and regulations.
Batteries and Power Solutions GmbH
Veit-Hirschmann-Str. 6
73479 Ellwangen
Germany
www.xtpower.de
