Yaesu FP-29 User manual

YAESU FP-29
AC POWER SUPPLY
for the FT-1000MP MARK-V HF Transceiver
The FP-29 is an external AC power supply for use with the FT-1000MP MARK-V HF Transceiver, providing 30
Volts DC at up to 15 amperes for extended periods.
Excellent regulation and conservative design assure the owner of many years of trouble-free operation. A ther-
mally-switched cooling fan automatically activates during long periods of high current demand, to maintain a
safe operating temperature in the power supply.
Specifications
DC Output Voltage:+30 V , +13.8 V
DC Output Current:+30 V: 15A; +13.8 V: 3A
Input Voltage:AC 100-120V, 50 - 60 Hz
AC 200-240 V, 50 - 60 Hz
Current Consumption (Approx.): AC 100-120 V: 9 A, AC 200-240 V: 5 A
Operating Temperature Range:–10 °C ~ +50 °C
Case Size (W x H x D): 106 x 135.5 x 331 mm (4.2 x 5.3 x 13 inch)
Weight (Approx.): 3.2 kg (7 lbs)
Specifications are subject to change without notice or obligation.
Supplied Accessory
DC Power Cable: T9022299 (length: 2 meters) ............................................................................................1
AC Power Cable..........................................................................................................................................1
Operating Manual (this sheet) .....................................................................................................................1
Warranty Card ............................................................................................................................................1
YAESU MUSEN CO., LTD.
4-8-8 Nakameguro, Meguro-Ku, Tokyo 153-8644, Japan
YAESU U.S.A.
17210 Edwards Rd., Cerritos, CA 90703, U.S.A.
YAESU EUROPE B.V.
P.O. Box 75525 1118 ZN, Schiphol, The Netherlands
YAESU UK LTD.
Unit 12, Sun Valley Business Park, Winnall Close
Winchester, Hampshire, SO23 0LB, U.K.
YAESU GERMANY GmbH
Am Kronberger Hang 2, D-65824 Schwalbach, Germany
YAESU HK LTD.
11th Floor Tsim Sha Tsui Centre, 66 Mody Rd.,
Tsim Sha Tsui East, Kowloon, Hong Kong
EAA9 7 X100
Visit http://www.fotango.org

INSTALLATION
Before connecting the FP-29 to any power source, be absolutely certain that the voltage specification on the rear
panel matches your local supply voltage. The FP-29 is manufactured for use around the world, from a variety of
power sources, and the wiring must be connected properly to prevent damage to the internal circuit.
Connect the supplied AC Power Cable between the FP-29 AC jack and AC line outlet, then connect the supplied
DC Power Cable between the FP-29 OUTPUT jack and FT-1000MP MARK-V DC IN jack.
Warning: Our Warranty does not cover damage caused by improper supply voltage nor use of an im-
proper fuse.
Operation
rTurn on the FP-29 MAIN switch on the front panel to activate the power supply. Always turn the FP-29 MAIN
switch on before turning on the FT-1000MP MARK-V POWER switch.
rTo turn off the FP-29, always turn the FT-1000MP MARK-V POWER switch off before turning off the FP-29
MAIN switch.
Changing AC Mains Jumper Wiring
rBefore change the AC Main Jumper, disconnect the AC Power Cable from the AC line outlet, then wait
10 minute for discharge the capacitor to prevent the electorical shock.
rRemove the 10 screws (right side: 6 screws; left side: 4 screws) affixing the top cover of the FP-29,
and remove the top cover.
rPerform the correct wiring on the Switching Regulator Unit
for the AC Mains voltage used in your area (AC 100-120 V
or AC 200-240 V) as shown below. There are three screw
terminalsinvolved,anda jumpermust beconnected across
two of them, per the drawing at the right.
rChange the fuse in the fuse holder on the rear panel, as
indicated below. Do not use slow-blow type fuses.
AC Mains Voltage AC Fuse Rating
100 ~ 120 V 10 A
200 ~ 240 V 6 A
Also, change the voltage marking on the label on the rear
panel to match the new voltage setting.
rReplace the top cover and its 10 screws. This completes the wiring change.
Warning: Our Warranty does not cover damage caused by improper supply voltage nor use of an
improper fuse.

FP-29 PARTS LIST
REF DESCRIPTION VALUE W/V TOL MFR'S DESIG VXSTD P/N VERS. LOT. LAY ADR QTY
B 0001 BEADS INDUCTOR B-01-A L1190386 1 1
B 0011 FERRITE BEADS B-20L-48B L9190120 1 1
B 0012 FERRITE BEADS B-20L-48B L9190120 1 1
B 0013 FERRITE BEADS B-20L-48B L9190120 1 1
B 0014 FERRITE BEADS B-20L-48B L9190120 1 1
C 0001 FILM CAP. 0.47uF 250V ECQU2A-474MV K52240010 1 1
C 0002 FILM CAP. 0.22uF 250V ECQU2A-224MV K52240009 1 1
C 0003 CERAMIC CAP. 2200pF 250V DE1007E222M-KH K10249002 1 1
C 0004 CERAMIC CAP. 2200pF 250V DE1007E222M-KH K10249002 1 1
C 0005 FILM CAP. 0.22uF 250V ECQU2A-224MV K52240009 1 1
C 0008 AL. ELECTRO. CAP. 330uF 100V LXV100VB330ML30 K40209001 1 1
C 0009 AL. ELECTRO. CAP. 390uF 400V EC0S2GB391EB 1 1
C 0010 AL. ELECTRO. CAP. 390uF 400V EC0S2GB391EB 1 1
C 0011 FILM CAP. 0.022uF 630V MMC630K223-0100 S8100928 1 1
C 0012 CERAMIC CAP. 0.1uF 50V RPE132F104Z50 K23170054 1 1
C 0013 CERAMIC CAP. 470pF 1kV DE0705R471K1K K10309002 1 1
C 0014 CERAMIC CAP. 470pF 1kV DE0705R471K1K K10309002 1 1
C 0015 FILM CAP. 0.033uF 1250V ECWH12333JV K55310001 1 1
C 0016 CERAMIC CAP. 1000pF 1kV DE0705R102K1K K10309003 1 1
C 0017 FILM CAP. 0.56uF 1250V ECWH12563JV K55310002 1 1
C 0018 AL. ELECTRO. CAP. 100uF 35V EEUFC1V101 K40169040 1 1
C 0019 CERAMIC CAP. 0.1uF 50V RPE132F104Z50 K23170054 1 1
C 0020 AL. ELECTRO. CAP. 82uF 35V EEUFC1V820-E K40169041 1 1
C 0031 CERAMIC CAP. 2200pF 250V DE1007E222M-KH K10249002 1 1
C 0032 CERAMIC CAP. 2200pF 250V DE1007E222M-KH K10249002 1 1
C 0041 AL. ELECTRO. CAP. 220uF 50V EEUFC1H221 K40179077 1 1
C 0042 AL. ELECTRO. CAP. 470uF 25V EEUFC1E471 K40149067 1 1
C 0043 AL. ELECTRO. CAP. 470uF 25V EEUFC1E471 K40149067 1 1
C 0044 CERAMIC CAP. 0.1uF 50V RPE132F104Z50 K23170054 1 1
C 0045 CERAMIC CAP. 0.1uF 50V RPE132F104Z50 K23170054 1 1
C 0045 AL. ELECTRO. CAP. 1200uF 50V EEUFC1H122 K40179078 1 1
C 0046 AL. ELECTRO. CAP. 1200uF 50V EEUFC1H122 K40179078 1 1
C 0047 AL. ELECTRO. CAP. 1200uF 50V EEUFC1H122 K40179078 1 1
C 0049 AL. ELECTRO. CAP. 220uF 50V EEUFC1H221 K40179077 1 1
C 0050 FILM CAP. 0.022uF 630V MMC630K223-0100 S8100928 1 1
C 0051 FILM CAP. 0.022uF 630V MMC630K223-0100 S8100928 1 1
C 0052 AL. ELECTRO. CAP. 100uF 35V EEUFC1V101 K40169040 1 1
C 0053 FILM CAP. 0.1uF 50V ECQB1H104KFW K50170107 1 1
C 0054 FILM CAP. 1000pF 50V ECQB1H102KFW K50170106 1 1
C 0056 FILM CAP. 0.033uF 50V ECQB1H333KFW K50170108 1 1
C 0057 FILM CAP. 0.033uF 50V ECQB1H333KFW K50170108 1 1
C 0058 FILM CAP. 0.033uF 50V ECQB1H333KFW K50170108 1 1
C 0059 FILM CAP. 0.033uF 50V ECQB1H333KFW K50170108 1 1
CN0001 CONNECTOR B2P3-VH P0090866 1 1
CN0002 CONNECTOR B2B-EH 1 1
CN0011 CONNECTOR B2P3-VH P0090866 1 1
CN0012 CONNECTOR B170267-1 Q8000164 1 1
CN0013 CONNECTOR B170267-1 Q8000164 1 1
CN0014 CONNECTOR B170267-1 Q8000164 1 1
CN0015 CONNECTOR B170267-1 Q8000164 1 1
CN0016 CONNECTOR B3B-EH P0090667 1 1
D 0001 DIODE RBV606 1 1
D 0002 DIODE FSF05A20 G2090771 1 1
D 0003 DIODE FML-24S 1 1
D 0004 DIODE 1SS270A G2090754 1 1
D 0005 DIODE 1SS270A G2090754 1 1
D 0006 DIODE HZ15-2 G2090406 1 1
D 0007 DIODE 1SS270A G2090754 1 1
D 0008 DIODE HZ2B1 G2090755 1 1
D 0009 DIODE 1SS270A G2090754 1 1
D 0010 DIODE 1SS270A G2090754 1 1
D 0011 DIODE ERA15-06 G2090769 1 1
D 0012 DIODE 1SS270A G2090754 1 1
D 0021 DIODE ESAD85-009 G2090732 1 1
D 0022 DIODE ESAD85-009 G2090732 1 1
D 0023 DIODE RK46 G2090776 1 1
D 0024 DIODE ERA92-02 G2090770 1 1
D 0025 DIODE 1SS270A G2090754 1 1
D 0026 DIODE HZ5C1 G2090188 1 1
D 0027 DIODE HZ7A3L 1 1
D 0028 DIODE HZ33-2 G2090772 1 1
D 0029 DIODE HZ15-2 G2090406 1 1
F 0001 FUSE 215 06.3 Q0000099 1 1
HIC0001 MODULE MB2013A S8100824 1 1
IC0001 IC S-80745AN G1092610 1 1
IC0011 IC LM2576T-ADJ G1092803 1 1
IC0012 IC NJM2904D G1090539 1 1
L 0001 RFC MS10-200 1 1
L 0002 RFC MS10-200 1 1
L 0011 RFC FL1719A S8100204 1 1
L 0012 RFC HP-034SZ S8100925 1 1
L 0013 RFC FL1719A S8100204 1 1
L 0014 RFC FL1783A S8100206 1 1
L 0015 RFC FL1783A S8100206 1 1

FP-29 PARTS LIST
REF DESCRIPTION VALUE W/V TOL MFR'S DESIG VXSTD P/N VERS. LOT. LAY ADR QTY
LF0001 LINE FILTER SC-10-10J S8100923 1 1
LF0002 LINE FILTER SC-10-10J S8100923 1 1
PC0001 PHOTO COUPLER PC123FY2 G0090036 1 1
PC0002 PHOTO COUPLER PC123FY2 G0090036 1 1
Q 0001 TRAIACK TF1661S-L G3090138 1 1
Q 0002 POWER MOS FET FS222M-10 G3090137 1 1
Q 0003 POWER MOS FET FS222M-10 G3090137 1 1
Q 0004 TRANSISTOR 2SC4002E G3340010E 1 1
Q 0005 TRANSISTOR DTC114ESA G3090130 1 1
Q 0006 TRANSISTOR 2SC945AP G3309451P 1 1
Q 0011 TRANSISTOR 2SA733 G3107330K 1 1
Q 0012 TRANSISTOR 2SC945AP G3309451P 1 1
Q 0013 TRANSISTOR 2SA733 G3107330K 1 1
R 0001 CARBON FILM RES. 470k 1/2W RD50SS-470K OHM J S8100947 1 1
R 0002 FUSE RES. 5.1 1.6W A53K-5R1J S8100920 1 1
R 0003 FUSE RES. 5.1 1.6W A53K-5R1J S8100920 1 1
R 0004 CARBON FILM RES. 10k 1/4W RD16S-10K OHM J S8100933 1 1
R 0005 CARBON FILM RES. 100 1/2W RD50SS-100 OHM J S8100946 1 1
R 0006 CARBON FILM RES. 100k 1/4W RD16S-100K OHM J S8100932 1 1
R 0007 CARBON FILM RES. 220k 1/2W RD50SS-470K OHM J S8100947 1 1
R 0009 CARBON FILM RES. 10 1/4W RD16S-10 OHM J S8100930 1 1
R 0010 CARBON FILM RES. 100k 1/4W RD16S-100K OHM J S8100932 1 1
R 0011 CARBON FILM RES. 10 1/4W RD16S-10 OHM J S8100930 1 1
R 0012 CARBON FILM RES. 100k 1/4W RD16S-100K OHM J S8100932 1 1
R 0013 CARBON FILM RES. 22 1/4W RD16S-22 OHM J S8100938 1 1
R 0014 CARBON FILM RES. 47k 1/4W RD16S-47K OHM J S8100944 1 1
R 0015 CARBON FILM RES. 1.5k 1/4W RD16S-1.5K OHM J S8100929 1 1
R 0016 CARBON FILM RES. 47k 1/4W RD16S-47K OHM J S8100944 1 1
R 0017 CARBON FILM RES. 27k 1/4W RD16S-27K OHM J S8100941 1 1
R 0018 CARBON FILM RES. 220k 1/4W RD16S-220K OHM J S8100940 1 1
R 0019 CARBON FILM RES. 4.7k 1/4W RD16S-4.7K OHM J S8100943 1 1
R 0020 METAL FILM RES. 33k 1W ERG1SJ-333 J22305333 1 1
R 0021 CARBON FILM RES. 3.3k 1/4W RD16S-3.3K OHM J S8100942 1 1
R 0022 CARBON FILM RES. 220k 1/4W RD16S-220K OHM J S8100940 1 1
R 0023 CARBON FILM RES. 220k 1/4W RD16S-220K OHM J S8100940 1 1
R 0024 CARBON FILM RES. 100 1/4W RD16S-100 OHM J S8100931 1 1
R 0031 CARBON FILM RES. 1.5k 1/4W RD16S-1.5K OHM J S8100929 1 1
R 0032 CARBON FILM RES. 150 1/4W RD16S-150 OHM J S8100934 1 1
R 0033 RES. 0.01 2W MPC76-0.01 OHM K 1 1
R 0034 RES. 0.01 2W MPC76-0.01 OHM K 1 1
R 0035 CARBON FILM RES. 2.2 1/4W RD16S-2.2 OHM J S8100937 1 1
R 0036 CARBON FILM RES. 150 1/4W RD16S-150 OHM J S8100934 1 1
R 0037 CARBON FILM RES. 1k 1/4W RD16S-1K OHM J S8100936 1 1
R 0038 CARBON FILM RES. 1k 1/4W RD16S-1K OHM J S8100936 1 1
R 0039 CARBON FILM RES. 10k 1/4W RD16S-10K OHM J S8100933 1 1
R 0040 CARBON FILM RES. 150 1/4W RD16S-150 OHM J S8100934 1 1
R 0041 CARBON FILM RES. 4.7k 1/4W RD16S-4.7K OHM J S8100943 1 1
R 0042 CARBON FILM RES. 10k 1/4W RD16S-10K OHM J S8100933 1 1
R 0043 CARBON FILM RES. 4.7k 1/4W RD16S-4.7K OHM J S8100943 1 1
R 0044 CARBON FILM RES. 47k 1/4W RD16S-47K OHM J S8100944 1 1
R 0045 CARBON FILM RES. 220 1/4W RD16S-220 OHM J S8100939 1 1
R 0046 CARBON FILM RES. 15k 1/4W RD16S-15K OHM J S8100935 1 1
R 0047 CARBON FILM RES. 4.7k 1/4W RD16S-4.7K OHM J S8100943 1 1
R 0048 CARBON FILM RES. 220 1/4W RD16S-220 OHM J S8100939 1 1
R 0049 CARBON FILM RES. 220 1/4W RD16S-220 OHM J S8100939 1 1
R 0050 CARBON FILM RES. 4.7k 1/4W RD16S-4.7K OHM J S8100943 1 1
R 0051 POSISTOR PTH9M04BD222TS2F333 G9090083 1 1
R 0052 CARBON FILM RES. 47k 1/4W RD16S-47K OHM J S8100944 1 1
R 0053 METAL FILM RES. 68 1W ERG1SJ-680 J22305680 1 1
S 0001 THERMOSTAT 67F080 1 1
T 0001 CONVERTER TRANSE FP2083A-501 FP2083A-501 S8100921 1 1
T 0002 CONVERTER TRANSE FP2083A-502 FP2083A-502 S8100922 1 1
VR0011 TRIMER 100 FT-6P-100 S8100926 1 1
VR0012 TRIMER 100 FT-6P-100 S8100926 1 1
VR0013 TRIMER 500 FT-6P-500 S8100927 1 1
Z 0001 SURGE ABSORBER ERZV14D621 Q9000599 1 1
- CW-ASSY FP2084A-801 1 1
- FUSE CLIP F220P P2000064 1 2
- FITTING FR309A S8000030 1 1
- THERMAL CONDUCTOR FB419 S8001781 1 1
- FITTING FR336A S8001784 1 1
- HEAT SHINK 20PB31/20PC31 S8001888 1 1
- THERMAL CONDUCTOR FB428A S8001889 1 1
- HEAT SHINK FP2083A-601 S8001890 1 1
- HEAT SHINK FP2083A-602 S8001891 1 1
- FITTING FR315A S8001892 1 1
- FITTING FR333-3019 S8001893 1 1
- THERMAL CONDUCTOR TC-30A(T0-3P) S8001894 1 1
- THERMAL CONDUCTOR TC-30A(T0-3P) S8001894 1 1

LLNN
CN1CN1
B2P3-VHB2P3-VH
F1F1
6.3AT6.3AT
250V250V
C1C1
0.47u0.47u
AC250VAC250V
LF1LF1
SC-05-20JSC-05-20J
C2C2
0.22u0.22u
AC250VAC250V
C3C3
2200p2200p
AC250VAC250V
C4C4
2200p2200p
AC250VAC250V
C6C6
AC250VAC250V
0.22u0.22u
C5C5
SC-05-20JSC-05-20J
LF2LF2
C7C7
R1R1
470K470K
0.5W0.5W
R3R3
5.15.1
1.6W1.6W
R2R2
5.15.1
1.6W1.6W
Q1Q1
TF861STF861S
R4R4
10K10K
R5R5
100100
0.5W0.5W
D1D1
RBV606RBV606
C9C9
390u390u
400V400V
C10C10
390u390u
400V400V
C8C8
330u330u
100V100V
R6R6
100K100K
R7R7
470K470K
0.5W0.5W
D2D2
FSFFSF
05A2005A20
C11C11
0.022u0.022u
630V630V
C12C12
0.1u0.1u
50V50V
PC1PC1
(1/2)(1/2)
PC123PC123
1212
1111
1010
55669988
22
11
33
44
77
HIC1HIC1
MB2013AMB2013A
VCCVCC
0.V0.V
ON/ON/
OFFOFF
OUT HOUT H
VSVS
NCNC
OUT LOUT L
STST
PGPG GNDGND FB2FB2 FB1FB1
R15R15
1.5K1.5K R14R14 47K47K
PC2PC2
(1/2)(1/2)
PC123PC123
D4D4 D5D5
1SS270A1SS270A
x2x2
R13R13
2222
Q2Q2
FS22SM-10FS22SM-10
R9R9
1010 R10R10 100K100K
R11R11
1010
Q3Q3
FS22SM-10FS22SM-10
R12R12
100K100K
C13C13
470p470p
1KV1KV
C14C14
470p470p
1KV1KV
C15C15
0.033u0.033u
1250V1250V
C16C16
1000p1000p
1KV1KV
C17C17
0.056u0.056u
1250V1250V
D3D3
FML-24SFML-24S
T1T1
FP2083A-501FP2083A-501
T2(1/2)T2(1/2)
FP2083A-502FP2083A-502
C31C31 C32C32
2200p2200p
AC250VAC250V
x2x2
T2(2/2)T2(2/2)
FP2083A-502FP2083A-502
R22R22
220K220K
R23R23
220K220K
R20R20
33K33K
Q4Q4
2SC4002E2SC4002E
D6D6
HZ15-2HZ15-2
R21R21
3.3K3.3K
D7D7
1SS270A1SS270A
R19R19
4.7K4.7K
Q5Q5
DTC114EDTC114E
C20C20
82u82u
35V35V
R24R24
100100
R18R18
220K220K
IC1IC1
S80745ANS80745AN
C19C19
0.1u0.1u
50V50V
R16R16
47K47K
R17R17
27K27K
C18C18
100u100u
35V35V
Q6Q6
2SC945A2SC945A
D8D8
HZ2B1HZ2B1
D9D9
1SS270A1SS270A
D10D10
1SS270A1SS270A
B1B1
B-01-AB-01-A
R35R35
2.22.2
D24D24
ERA92-02ERA92-02
C52C52
100u100u
35V35V
D21D21
ESAD85M-009ESAD85M-009
D22D22
ESAD85M-009ESAD85M-009
C45C45
1200u1200u
50V50V
C46C46
1200u1200u
50V50V
C47C47
1200u1200u
50V50V
C48C48
+V+V
L14L14
FL1783AFL1783A
L15L15
FL1783AFL1783A
R33R33
0.010.01
2W2W
R34R34
0.010.01
2W2W
C49C49
220u220u
50V50V
C50C50
0.022u0.022u
630V630V
C51C51
0.022u0.022u
630V630V
L11L11
FL1719AFL1719A C41C41
220u220u
50V50V J1J1
11
553344
22
IC11IC11
LM2576T-ADJLM2576T-ADJ
VinVin
S.SS.S GNDGND VosVos
SWoutSWout
L12L12
HP-034SZHP-034SZ L13L13 FL1719AFL1719A
D23D23
RK46RK46
R31R31
1.5K1.5K
VR11VR11
100100
R32R32
150150
C42C42
470u470u
25V25V
C44C44
0.1u0.1u
50V50V
C43C43
470u470u
25V25V
CN11CN11
B2P3-VHB2P3-VH
+13.8V+13.8V
GNDGND
CN13CN13
170267-1170267-1
CN14CN14
170267-1170267-1
+VOUT+VOUT
GNDGND
PC2(2/2)PC2(2/2)
PC123PC123
D25D25
1SS270A1SS270A
R37R37
1K1K
IC12(1/2)IC12(1/2)
29042904
R36R36
150150
VR12VR12
100100
R38R38
1K1K C53C53
0.1u0.1u
50V50V
R39R39
10K10K
C54C54
1000p1000p
50V50V
R40R40
150150 D26D26 HZ5C1HZ5C1
R41R41
4.7K4.7K
C55C55
0.1u0.1u
50V50V
IC12(2/2)IC12(2/2)
29042904
R43R43
4.7K4.7K
R44R44
47K47K
C57C57
0.033u0.033u
50V50V
Q11Q11
2SA7332SA733
R42R42
10K10K
C56C56
0.033u0.033u
50V50V
Q12Q12
2SC2SC
945A945A
D27D27
HZ7A3LHZ7A3L
R45R45
220220
C58C58
0.033u0.033u
50V50V
+V+V
R46R46
15K15K C59C59
50V50V
0.033u0.033u
VR13VR13
500500
R47R47
4.7K4.7K
D28D28
HZ33-2HZ33-2
R48R48
220220
D29D29
HZ15-2HZ15-2
PC1PC1
(2/2)(2/2)
PC123PC123
R50R50
4.7K4.7K
Q13Q13
2SA2SA
733733
R49R49
220220 R52R52 47K47K
R51R51
330 ˆÈ‰º330 ˆÈ‰º
at 25 •Žat 25 •Ž
R53R53
CN16CN16
B3B-EHB3B-EH
+12V+12V
GNDGND
88
99
1010
1111
11
33
66
88
1111
1313
1515
1717
CN12CN12
170267-1170267-1
+VOUT+VOUT
CN15CN15
170267-1170267-1
99
1212
44
55
11
22
11
33
22
8866
55
44
6868
1W1W
GNDGND
B11,B12B11,B12
B-20L-48BB-20L-48B
B13,B14B13,B14
B-20L-48BB-20L-48B
L1L1
MS10-200MS10-200
L2L2
MS10-200MS10-200
AA
KKAA
GG
D11D11
ERA15-06ERA15-06
1W1W
Z1Z1
14D62114D621
D12D12
1SS270A1SS270A
S1S1
67F08067F080
CN2CN2
B2B-EHB2B-EH
R54R54
CN17CN17
