Yale PWLCL630SS Installation guide

1
Use, Care, and Installation Guide
Guide d’utilisation, d’entretien et d’installation
Guía de instalación, uso y mantenimiento
READ AND SAVE THESE INSTRUCTIONS
LISEZ CES INSTRUCTIONS ET CONSERVEZ-LES
LEA Y GUARDE ESTAS INSTRUCCIONES
LIB0184513
05/22
Models: PWLCL630SS
PWLCL136SS
PWLCL148SS

2
APPROVED FOR RESIDENTIAL APPLIANCES
FOR RESIDENTIAL USE ONLY
READ AND SAVE THESE INSTRUCTIONS
PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING.
INSTALLATION MUST COMPLY WITH ALL LOCAL CODES.
IMPORTANT: Save these Instructions for the Local Electrical Inspector’s use.
INSTALLER: Please leave these Instructions with this unit for the owner.
OWNER: Please retain these instructions for future reference.
Safety Warning: Turn off power circuit at service panel and lock out panel, before wiring this appliance.
Requirement: 120 V AC, 60 Hz. 15 or 20 A Branch Circuit
Important Safety Notice ............................................................................................................................................................................ 3
Electrical & Installation requirements ..................................................................................................................................................... 4
Product dimentions................................................................................................................................................................................... 5
List of materials......................................................................................................................................................................................... 6
Ducting Options......................................................................................................................................................................................... 7
Installation ................................................................................................................................................................................................. 8
Venting Methods........................................................................................................................................................................................ 8
Wall Installation ......................................................................................................................................................................................... 9
Electrical connection .............................................................................................................................................................................. 12
Complete installation .............................................................................................................................................................................. 12
Description of the hood .......................................................................................................................................................................... 12
Control ..................................................................................................................................................................................................... 12
Maintenance............................................................................................................................................................................................. 13
English

3
Important Safety Notice
CAUTION
FOR GENERAL VENTILATING USE ONLY. DO NOT USE
TO EXHAUST HAZARDOUS OR EXPLOSIVE
MATERIALS OR VAPOURS.
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR
INJURY TO PERSONS, OBSERVE THE FOLLOWING:
A. Use this unit only in the manner intended by the
manufacturer. If you have questions, contact the
manufacturer.
B. Before servicing or cleaning the unit, switch power off
at service panel and lock service panel disconnecting
means to prevent power from being switched on
accidentally. When the service disconnecting means
cannot be locked, securely fasten a prominent warning
device, such as a tag, to the service panel.
C. Installation Work and Electrical Wiring Must Be Done By
 QualiedPerson(s)InAccordanceWithAllApplicable
Codes & Standards, Including Fire-rated Construction.
D. Sufcientairisneededforpropercombustionand 
 exhaustingofgasesthroughtheue(Chimney)offuel
burning equipment to prevent back- drafting.
Follow the heating equipment manufacturers guideline
and safety standards such as those published by the
 NationalFireProtectionAssociation(NFPA), 
 theAmericanSocietyforHeating,  
 RefrigerationandAirConditioningEngineers(ASHRAE),
and the local code authorities.
E. When cutting or drilling into wall or ceiling, do not
damage electrical wiring and other hidden utilities.
F. Ducted fans must always be vented to the outdoors.
CAUTION
Toreduceriskofreandtoproperlyexhaustair,be
sure to duct air outside - do not vent exhaust air into
spaces within walls, ceilings, attics, crawl spaces, or
garages.
WARNING
TO REDUCE THE RISK OF FIRE, USE ONLY METAL
DUCT WORK.
Install this hood in accordance with all requirements
specied.
WARNING
To Reduce The Risk Of Fire Or Electric Shock, Do Not
UseThisHoodWithAnyExternalSolidStateSpeed
Control Device.
WARNING
TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE.
a) Never leave surface units unattended at high settings.
Boilovers cause smoking and greasy spillovers that may
 ignite.Heatoilsslowlyonlowormediumsettings.
b) AlwaysturnhoodONwhencookingathighheator 
 whenambeingfood(I.e.CrepesSuzette,Cherries 
 Jubilee,PeppercornBeefFlambe’).
c) Clean ventilating fans frequently. Grease should not be
 allowedtoaccumulateonfanorlter.
d) Useproperpansize.Alwaysusecookwareappropriate
 forthesizeofthesurfaceelement.
WARNING
TO REDUCE THE RISK OF INJURY TO PERSONS, IN
THE EVENT OF A RANGE TOP GREASE FIRE,
OBSERVE THE FOLLOWING:a
a) SMOTHERFLAMESwithaclose-ttinglid,cookie 
sheet, or other metal tray, then turn off the gas burner or
 theelectricelement.BECAREFULTOPREVENT 
 BURNS.Iftheamesdonotgooutimmediately, 
 EVACUATEANDCALLTHEFIREDEPARTMENT.
b) NEVERPICKUPAFLAMINGPAN-youmaybe 
burned.
c) DONOTUSEWATER,includingwetdishclothsor 
towels - a violent steam explosion will result.
d) Use an extinguisher ONLY if:
1) YouknowyouhaveaclassABCextinguisher,and
you already know how to operate it.
2) Thereissmallandcontainedintheareawhereit
started.
3) Theredepartmentisbeingcalled.
4) Youcanghttherewithyourbacktoanexit.
aBasedon“KitchenFireSafetyTips”publishedbyNFPA.
OPERATION
a.Alwaysleavesafetygrillsandltersinplace.Without
these components, operating blowers could catch onto hair,
ngersandlooseclothing.
The manufacturer declines all responsibility in the event of
failure to observe the instructions given here for installation,
maintenance and suitable use of the product. The
manufacturer further declines all responsibility for injury due
to negligence and the warranty of the unit automatically
expires due to improper maintenance.
CAUTION
For model PWLCL630SS use this hood only in conjunction with
rangesorrangetopsratedatmaximum78KBTU's.
For models PWLCL136SS and PWLCL148SS use this hood only
in conjunction with ranges or range tops rated at maximum 108
KBTU's.
READ AND SAVE THESE INSTRUCTIONS
Internal Blower
(alreadyincludedwiththehood)
HeatLampsKit
(Seeaccessoriestableforreference)
HOODMODEL A WAW
PWLCL630SS 4.1 490 6.8 583
PWLCL136SS 7.6 913 10.5 1033
PWLCL148SS 7.7 920 10.6 1040

4
Electrical & Installation requirements
IMPORTANT
Observe all governing codes and ordinances.
It is the customer’s responsibility:
• Tocontactaqualiedelectricalinstaller.
• To assure that the electrical installation is adequate and in
conformancewithNationalElectricalCode,ANSI/NFPA70—
latestedition*,orCSAStandardsC22.1-94,CanadianElectrical
Code, Part 1 and C22.2 No.0-M91-latest edition** and all local
codes and ordinances.
• If codes permit and a separate ground wire is used, it is
recommendedthataqualiedelectriciandeterminethatthe
ground path is adequate.
• Do not ground to a gas pipe.
• Checkwithaqualiedelectricianifyouarenotsurerangehood
is properly grounded.
• Do not have a fuse in the neutral or ground circuit.
IMPORTANT
• Save Installation Instructions for electrical inspector’s use.
• The range hood must be connected with copper wire only.
• The range hood should be connected directly to the fused
disconnect(Orcircuitbreaker)boxthroughmetalelectrical
conduit.
• WiresizesmustconformtotherequirementsoftheNational
ElectricalCodeANSI/NFPA70—latestedition*,orCSA
Standards C22.1-94, Canadian Electrical Code Part 1 and
C22.2 No. 0-M91 - latest edition** and all local codes and
ordinances.
• AU.L.-orC.S.A.-listedconduitconnectormustbeprovidedat
eachendofthepowersupplyconduit(attherangehoodandat
thejunctionbox).
Copies of the standards listed may be obtained from:
*NationalFireProtectionAssociationBatterymarchParkQuincy,Massachusetts02269
**CSAInternational8501EastPleasantValleyRoadCleveland,Ohio44131-5575
BEFORE INSTALLING THE HOOD
1 Forthemostefcientairowexhaust,useastraightrunoras
few elbows as possible.
CAUTION:Ventunittooutsideofbuilding,only.
2 Atleasttwopeoplearenecessaryforinstallation.
3 Fittings material is provided to secure the hood to most types
ofwalls/ceilings,consultaQualiedInstaller,checkifthey
perfectlytwithyourcabinet/wall.
4 Donotuseexducting.
5 COLDWEATHERinstallationsshouldhaveanadditional
backdraftdamperinstalledtominimizebackwardcoldairow
andanonmetallicthermalbreaktominimizeconductionof
outside temperatures as part of the ductwork. The damper
should be on the cold air side of the thermal break. The break
should be as close as possible to where the ducting enters the
heated portion of the house.
6 Make up air: Local building codes may require the use of
Make-UpAirSystemswhenusingDuctedVentilationSystems
greaterthanspeciedCFMofairmovement.Thespecied
CFMvariesfromlocaletolocale.ConsultyourHVAC
professionalforspecicrequirementsinyourarea.

5
Product dimentions
J
K
H
I
E
F
A
B
D
C
G
Models
PWLCL630SS PWLCL136SS PWLCL148SS
A30”(76cm) 36”(91.1cm) 48”(121.7cm)
B25”(63.5cm)
C18”(45.7cm)
D12”(30.3cm)
E15⁄8”(5.7cm)
F291⁄8”(74cm) 351⁄8”(89.2cm) 471⁄8”(119.7cm)
G71⁄2”(19cm)
H29⁄16”(6.5cm)
I3⁄8”(1cm)
Duct
CoverKit JK
ACC02159 30"
(76.2cm)
6"
(15.2cm)
ACC02158 36"
(91.54cm)
ACC02164 48"
(121.7cm)
ACC02160 30"
(76.2cm)
12"
(30.5cm)
ACC02161 36"
(91.54cm)
ACC02165 48"
(121.7cm)
Optional accessories and consumable parts
KIT # Part
PWLCL630SS
30" (76.2 cm)
PWLCL136SS
36" (91.54 cm)
PWLCL148SS
48" (121.7 cm)
Long Chimney Extension Kit 6" ACC02159 ACC02158 ACC02164
Long Chimney Extension Kit 12" ACC02160 ACC02161 ACC02165
Heat Lamp w/ 2 - 175W Bulbs Kit ACC0155106 ACC0155107 ACC0155111
Stainless Back Splash and Warm Racks Kit ACC0142864 ACC0142867 ACC0142870
CFM Reduction Kit ACC0185752** ACC0185099***
10" to 8" Transition Kit* ACC0185271
Kit No Blower External ACC0179547 ACC0179547
Kit No Blower In Line ACC0179549 ACC0179549
*TherearenoHVIcertiedratingsavailableforthe8"transitionKitconguration,pleasecheckwithlocalbuildingcodesinorderto
verifycompliancewithoutHVIcertication.
**CAUTION:WhenusingthisCFMreductionkit,themaximumBTUuseforthishoodis65KBTU’s.
***CAUTION:WhenusingthisCFMreductionkit,themaximumBTUuseforthishoodis78KBTU’s.

6
List of materials
Removing the packaging.
ICAUTION
Remove carton carefully, wear gloves to protect against sharp edges.
IWARNING
Removetheprotectivelmcoveringtheproductbeforeputtingintooperation.
Supplied Part Pieces Supplied Part Pieces
Hoodassemblyand
LED lamps already installed
1
10”roundairtransition
1
Single blower motor assembly
30”:2
Dual blower motor assembly
36”,48”:1
6x80 mm 4
Ø 6.4x11 mm washers
5
6x16 mm
5
Ø 5.3x20 mm washers
2
3.5x9.5 mm 4 10x50 mm wall anchors 2
4.2x19 mm 6
Torx 20 adapter 1
Drip tray screws
4
Drip tray bracket
30”,36”:1
48”:2
Greaselters
30”,36”:2
48”:3
Drip tray
30”,36”:2
48”:3
Parts not supplied
Tools/Materials required
• Level
• Drill with 1 1⁄4”(3.0cm),1⁄8”(3.0mm),1⁄16”(4.8mm)drillbits
• Pencil
• Wire stripper or utility knife
• Tape measure or ruler
• Pliers
• Caulking gun and weatherproof caulking compound
• Ventclamps
• Saber or keyhole saw
• Metal snips
• Screwdrivers:
• Phillips
• Flat-blade
Parts needed
• Homepowersupplycable
• ½”(12.7mm)ULlistedorCSAapprovedstrainrelief
• 3 UL listed wire connectors
• 1 wall or roof cap
• Metal vent system

7
Ducting Options
Closely follow the instructions set out in this manual.
Allresponsability,foranyeventualinconveniences,damagesorrescausedbynotcomplyingwiththeinstructionsinthismanual, is
declined.
HorizontalDischarge VerticalDischarge
Usea10”(25.4cm)roundventsystemanda10”(25.4cm)
round transition for discharge of fumes to the outside.
A
B
D
C
A
B
Usea10”(25.4cm)roundventsystemanda10”(25.4cm)
round transition for discharge of fumes to the outside.
A
B
C
A.10”(25.4cm)roundtransition
B.10”(25.4cm)or8"(20.3cm)duct
C. Cabinet
D. 90° elbow
A.10”(25.4cm)roundtransition
B.10”(25.4cm)or8"(20.3cm)duct
C. Cabinet
Preparation
Do not cut a joist or stud unless absolutely necessary. If a joist or
stud must be cut, then a supporting frame must be constructed.
Fittings material is provided to secure the hood to most types of
walls/ceilings.
However,aqualiedtechnicianmustverifysuitabilityofthe
materials in accordance with the type of wall/ceiling.
Before making cutouts, make sure there is proper clearance
within the ceiling or wall for exhaust vent.
ICAUTION
For gas cooktop & range installations: Mount the hood so the
bottomisatleast30”(76.2cm)abovethecookingsurface.
For electric/induction cooktop & range installations: Mount the
hoodsothebottomisatleast24”(61cm)abovethecooking
surface.
There is no maximum mounting height, however, we recommend
mountingthehoodnogreaterthan36”(91.4cm)abovethe
cookingsurface.Foreveryinch(2.54cm)above36”(91.4cm),
fumeandmoisturecaptureefciencydiminishesatanincrea-
sing rate and may not deliver an acceptable level of ventilating
performance.
This hood is intended for household use.
PLEASEREADTHEINSTALLATIONMANUALFORSPECIFIC
APPLICATION.Checkyourceilingheightandhoodheight
before selecting your hood.

8
Installation
• It is recommended that the vent system be installed before
hood is installed.
• If you are installing the optional backsplash with shelves for
heat lamps, follow the instructions included with that product.
• If possible, disconnect and move freestanding or slide-in
range from cabinet opening to provide easier access to rear
wall.
• Before making cutouts, make sure there is proper clearance
within the ceiling or wall for exhaust vent.
• Check that all installation parts have been removed from the
shipping carton.
1 Disconnect power.
2 Determine which venting method to use: roof or wall exhaust.
NOTE: This hood is factory set to vent through the top air exit.
If you decide to use the rear vent exit, you have to remove the
rear vent cover and relocate it to the top vent exit.
3 Selectaatsurfaceforassemblingtherangehood.Place
covering over that surface.
Venting Methods
Outside Top exhaust
VerticalductØ10”(25.4cm)
Use the diagram or the hood as a template and mark the
locations on the cabinet’s bottom or roof for ductwork, electrical
wiring and keyhole screw slots.
WALL
FRONT OF THE HOOD
A
CL
C
D
EB
F
G
H
Ø1”
(25.4 mm)
3⁄4” (19 mm)
51⁄4”
(133mm)
51⁄4”
(133mm)
101⁄2”
(266 mm)
PWLCL630SS PWLCL136SS PWLCL148SS
A30”(760mm) 36”(912mm) 48”(1217mm)
B12”(305mm)
C1”(25.4mm)
D2 5⁄8”(65mm)
E7 1⁄2”(190mm)
F3 9⁄16”(90mm) 6 7⁄16”(164mm)
G2”(50mm)
H3 1⁄2”(89mm)
Outside rear exhaust
HorizontalductØ10”(25.4cm)
Use the diagram or the hood as a template and mark the
locations on the wall for ductwork, electrical wiring and keyhole
screw slots.
TOP OF
THE HOOD
CL
EE D
B
4”
(102 mm)
F
G
H
I
J
Ø1”
(25.4 mm)
51⁄4”
(133mm) 51⁄4” (133mm)
101⁄2”
(266 mm)
A
D
B
C C
PWLCL630SS PWLCL136SS PWLCL148SS
A30”(760mm) 36”(912mm) 48”(1217mm)
B97⁄8”(250mm)
C4”(100mm)
D7 9⁄16”(192.6mm)
E3 7⁄16”(87mm) 5”(127mm) 6 9⁄16”(167mm)
F2 15⁄16”(75mm) 5 7
8”(149mm)
G7 1⁄2”(192mm)
H2”(50mm)
I6 2⁄8”(157mm)
J311⁄16”(94mm)
1 Removethegreaselters.
2 Remove the blower mounting screws. Put the screws in a
safe place in order to use them again.
3 Set free the two blower springs from the top of the range
hood housing.

9
4 Flip the blower base to the rear face of the range hood.
5 Insert the two blower springs to the top of the range hood
housing, Secure it with the four mounting screws previously
released.
Wall Installation
IWARNING
USETWOORMOREPEOPLETOMOVEANDINSTALLRANGE
HOOD.FAILURETODOSOCANRESULTINBACKOROTHER
INJURY.
IMPORTANT: Framing must be capable of supporting up to
150 lbs.
The hood is attached to the wall with the wood support that is
attached to the back of the hood.
• Determine and mark the centerline on the wall where the
canopy hood will be installed.
• Selectamountingheight“X”.
For gas cooktop & range installations: Mount the hood so the
bottomisatleast30”(76.2cm)abovethecookingsurface.
For electric/induction cooktop & range installations: Mount the
hoodsothebottomisatleast24”(61cm)abovethecooking
surface.
• Markahorizontalreferencelineonthewall.
• Remove the wood support from the back of the range hood by
loosening the 2 screws from the inside. Locate and level the
topofthewoodsupport15³⁄8”(39.1cm)abovethemarked
horizontallineandcenteredontheverticalcenterline.Using2
of the 4 of the 6 x 80 mm screws, install wood support so that it
is screwed into at least 2 vertical studs.
• Leave a 1⁄4”(6.4mm)gapbetweenthewallandthebackofthe
screw head to slide range hood into place.
1⁄4”
(6,4 mm)
C
A
“x”
153⁄8”
(39 cm)
D
B
A.Woodsupport
B. Bottom of range hood
C. Centerline
D.Dimension“X”=rangehoodmountingheight
NOTE: The screws provided for mounting this range hood must
be fastened into solid wood; do not fasten into sheetrock only.
Complete Preparation
1 Determine and make all necessary cuts in the wall or roof for
the vent system. Install the vent system before installing the
rangehood.Seethe“VentingMethods”section.
2 Determine the location where the power supply cable will be
run through the wall or the roof.
3 Drill a 1 1⁄4”(3.2cm)holeatthislocation.
4 Pull enough power supply cable through the wall to allow for
easy connection to the terminal box.
5 Remove terminal box cover and set aside.
6 Remove knockout from the back of the range hood and install
aULlistedorCSAapproved¹⁄2”(1.3cm)strainrelief.
7 Place the range hood near its mounting position and run the
power supply cable through the strain relief into terminal box
(enoughtomakeconnection).
8 Tighten the strain relief screws.

10
Mounting the Hood
The range hood attaches to the wall by the 2 mounting screws in
the wood support mounted to the wall.
1 Using 2 or more people, hang the range hood on the wall by
placing the slotted holes in the range hood back over the 2
screws mounted to the wood support mounted to the wall.
NOTE: If your installation uses the optional duct cover, the vent
system needs to be connected to the range hood and the duct
cover mounted to the top of the range hood before tightening
the mounting screws.
2 Push the range hood up into the narrow slots, align the bottom
ofthehoodtothehorizontalline,levelthehood,andtighten
the 2 mounting screws.
3 Mark2lowermountingholecenterpointlocations.Drill¹⁄8”
(0.32cm)pilotholesiftheholesarelocatedintowood.Ifholes
arenotlocatedintowood,drilltwo³⁄8”(0.95cm)pilotholesand
insert 10 x 50 mm wall anchors. Install 2 - 6 x 80 mm screws
with 5.3 x 20 mm washers into the lower mounting anchors and
tighten.
A
B
B
C
D
A.Mountingscrews
B. 4 screws - 4.2 x 19 mm
C. 2 5.3 x 20 mm washers
D. 2 screws - 6 x 80 mm
4 Install 4 - 4.2 x 19 mm screws through the back of the hood
into the wood support and tighten.
5 Connect vent system to hood. Seal all joints with clamps.
Install Transition
• Installthe10”(25.4cm)squarex10”(25.4cm)roundvent
transition with damper to top or rear side of the range hood
(dependingonyourinstallation),using4-3.5x9.5mmscrews.
NOTE: The exhaust adaptor/damper can be installed up to 1
inch on either side of the hood center to accommodate offcenter
ductwork. In extreme offcenter installations, one end of the duct
connector may need to be trimmed to clear the electrical cable
clamp.
Install Range Hood Internal Blower Motor
1 Removegreaseltersfromrangehood.Seethe“Maintenance”
section in the Use and Care Guide.
2 Install the range hood blower motor assembly inside the range
hood canopy with the wiring connection to the left for the single
motor system and to the front or top for the dual motor system.
Single blower motor assembly
A
A.Wiringconnection
Dual blower motor assembly
A
A.Wiringconnection

11
3 Slidetheleftmountingplateangeunderthemotormounting
bracket.
ABA.Motormountingbracket
B. Mounting plate left flange
4 Run the power supply wires and connector from the range
hood through the hole in the right end of the motor mounting
plate.
B
A
A.Motormountingplatehole
B. Power supply wires and connector
5 Push the right end of the motor mounting plate up and snap it
into the spring tab.
NOTE: The spring tab should be outside the slot in the
mounting plate.
A
B
A.Motormountingplate
B. Spring clip
6 Alignmountingholesandinstall6x16mmscrewsand6.4mm
lock washers
B
A
A.Screwwithlockwasher
B. Mounting hole
7 Attachpowersupplyconnectorfromtherangehoodtothe
connector on the blower motor assembly wiring box.
A
B
A.4-4x8mmmountingscrews
B. Security screws

12
Electrical connection
IWARNING
ELECTRICALSHOCKHAZARD.
DISCONNECTPOWERBEFORESERVICING.REPLACEALL
PARTSANDPANELSBEFOREOPERATING.FAILURETODO
SOCANRESULTINDEATHORELECTRICALSHOCK.
• Remove the knockout and the Junction box cover and install
theconduitconnector(cULuslisted)injunctionbox.
A
E
B
F
C
D
A.Whitewires
B. Black wires
C. UL listed wire connector
D.Green(orbare)andyellow-greengroundwire
E.Homepowersupplycable
F.ULlistedorCSAapproved½”strainrelief
• Run 3 wires; black, white and green ,according to the National
ElectricalCodeandlocalcodesandordinances,in1⁄2”conduit
from service panel to junction box.
IWARNING
ELECTRICALLYGROUNDBLOWER.CONNECTGROUND
WIRETOGREENANDYELLOWGROUNDWIREINTERMINAL
BOX.FAILURETODOSOCANRESULTINDEATHOR
ELECTRICALSHOCK.
• Connect black wire from service panel to black or red in
junction box, white to white and green to green-yellow.
• Close and secure junction box cover.
Complete installation
Replaceltersandcheckoperationofthehood.
If range hood does not operate:
• Check that the circuit breaker is not tripped or the house fuse
blown.
• Disconnect power supply. Check that wiring is correct.
Togetthemostefcientusefromyournewrangehood,readthe
“Maintenance”section.
KeepyourInstallationInstructionsandUseandCareGuideclose
to range hood for easy reference.
Description of the hood
2
4
3
13
1. Blower and light controls
2. LED lamps
3. Grease filter handle
4. Grease filter
Control
The range hood is designed to remove smoke, cooking vapors
and odors from the cooktop area. For best results, start the hood
before cooking and allow it to operate several minutes after the
cooking is complete to clear all smoke and odors from the kitchen.
The hood controls are located on the center side of the hood.
Recessing Knobs
• Youcanhidecontrolknobsbydepressingthemuntilushwith
the hood body.
• Pressing the knobs again will lower the knobs, and enable the
user to operate the lights and blower.

13
Controls
AB
A.Lampsknob
B. Blower knob
Operating the lamps
1 Turnthelightswitchtothe“ON”positiontoturntherangehood
lights On.
2 Turnthelightswitchtothe“OFF”positiontoturntherange
hood lights Off.
Operating the blower
1 Turntheblowerswitchat“1”toturntherangehoodon.
2 Turn the blower switch to the desired speed position.
3 Turntheblowerswitchtothe“MAX”positiontoturntherange
hoodonHigh.
4 Turntheblowerswitchtothe“OFF”positiontoturntherange
hood blower Off.
Auto On blower
The range hood is equipped with a sensor to automatically turn
on the blower when excessive heat is detected in the control area.
Whentheblowerswitchisinthe“Off”position,thissensorwill
turn the blower to high speed when necessary. When the heat
decreases, the blower will turn off. When the blower switch is in
the On position, the heat sensor is not active and the range hood
functions normally.
Maintenance
Cleaning
Exterior surfaces:
To avoid damage to the exterior surface, do not use steel wool or
soap-lledscouringpads.Donotusechlorinebasecleaners.Rub
in direction of the grain line to avoid scratching the surface.
Alwayswipedrytoavoidwatermarks.
• Stainless Steel Cleaner and Polish.
• Mild liquid detergent and water.
• Wipe with damp soft cloth or nonabrasive sponge, then rinse
with clean water and wipe dry.
Metal lters and drip trays:
1 Use2handstoremovelters.
2 Grasplterhandles,pulltowardthefrontofrangehoodand
pulldownontherearhandletoremove.Repeatforeachlter.
A
A.Greasefilter
3 Remove grease drip tray.
AA.Driptray
4 Place the drip tray bracket using the screws included.
A
C
B
A.Driptray
B. Drip tray bracket
C.Driptraybracketscrews(2)
5 Washmetalltersandgreasetraysasneededindishwasher
or hot detergent solution to clean.
6 Replace grease drip tray.
7 Reinstalllters,grasplterhandlesandplacefrontedgeof
lterintothehood.
8 Pushuponthebackhandleandsetrearoflterintothedrip
traytosecure.Repeatforeachlter.
A
A.Greasefilter
Replacing a LED Lamp
Turn off the range hood and allow the LED lamp to cool.
To avoid damage or decreasing the life of the new lamp, do
nottouchlampwithbarengers.Replacelamp,usingtissueor
wearing cotton gloves to handle lamp.
If new lamps do not operate, make sure the lamps are inserted
correctly before calling service.
1 Disconnect power.
2 Push up on the lens and turn it counterclockwise.
3 Remove the lamp and replace it with a 120-volt, 7.5 W watt
maximum halogen lamp with a GU10 base. Turn it clockwise to
lock it into place.
4 Repeat steps 2-3 for the other lamps if needed.
5 Reconnect power.

14
TWO-YEAR LIMITED WARRANTY
TO OBTAIN SERVICE UNDER WARRANTY
Ownermustpresentproofoforiginalpurchasedate.Pleasekeepacopyofyourdatedproofofpurchase(salesslip)inordertoobtain
service under warranty.
PARTS AND SERVICE WARRANTY
Fortheperiodoftwo(2)yearsfromthedateoftheoriginalpurchase,thesupplierwillprovidefreeofcharge,nonconsumablepartsor
componentsthatfailedduetomanufacturingdefects.Duringthesetwo(2)yearslimitedwarranty,thesupplierwillalsoprovidefreeof
charge, all labor and in-home service to replace any defective parts.
WHAT IS NOT COVERED
• DamageorfailuretotheproductcausedbyaccidentoractofGod,suchas,ood,reorearthquake.
• Damageorfailurecausedbymodicationoftheproductoruseofnon-genuineparts.
• Damage or failure to the product caused during delivery, handling or installation.
• Damage or failure to the product caused by operator abuse.
• Damage or failure to the product caused by dwelling fuse replacement or resetting of circuit breakers.
• Damage or failure caused by use of product in a commercial application.
• Service trips to dwelling to provide use or installation guidance.
• Lightbulbs,metalorcarbonltersandanyotherconsumablepart.
• Normalwearofnish.
• Weartonishduetooperatorabuse,impropermaintenance,useofcorrosiveorabrasivecleaningproducts/padsandovencleaner
products.
• When the product has not been operated in accordance with the accompanying instructions for use.
WHO IS COVERED
ThiswarrantyisextendedtotheoriginalpurchaserforproductspurchasedforordinaryresidentialuseinNorthAmerica(Includingthe
UnitedStates,Guam,PuertoRico,USVirginIslands&Canada).
This warranty is non-transferable and applies only to the original purchaser and does not extend to subsequent owners of the product.
This warranty is made expressly in lieu of all other warranties, expressed or implied, including, but not limited to any implied warranty
ofmerchantabilityortnessforaparticularpurposeandallotherobligationsonthepartofthesupplier,provided,however,thatifthe
disclaimer of implied warranties is ineffective under applicable law, the duration of any implied warranty arising by operation of law shall
belimitedtotwo(2)yearsfromthedateoforiginalpurchaseatretailorsuchlongerperiodasmayberequiredbyapplicablelaw.
Thiswarrantydoesnotcoveranyspecial,incidentaland/orconsequentialdamages,norlossofprots,sufferedbytheoriginal
purchaser, its customers and/or the users of the Products.
WHO TO CONTACT
To obtain service under warranty or for any service related question:
Contact this number:
888 732 8018
To ensure prompt after-sales service, when you call we will kindly ask you to provide the following information indicated on the
nameplate inside the hood: hood model, 12 NC and date of purchase on original invoice.To access the nameplate, all you have to
doisremovethegreaselters.
12NC:___________________________________________________________________________
Hood model:_____________________________________________________________________
Serial No.:_______________________________________________________________________
Date of purchase on original invoice:________________________________________________

15
APPROUVÉ POUR LES APPAREILS DE TYPE RÉSIDENTIEL
POUR UNE UTILISATION RÉSIDENTIELLE SEULEMENT
LISEZ CES INSTRUCTIONS ET CONSERVEZ-LES
VEUILLEZ LIRE CES INSTRUCTIONS AU COMPLET AVANT DE COMMENCER.
L’INSTALLATION DE L’APPAREIL DOIT RESPECTER TOUS LES CODES EN VIGUEUR.
IMPORTANT : Conservezcesinstructionsandepouvoirlesremettreàl’inspecteur-électriciendevotrerégion.
INSTALLATEUR : Veuillezlaissercesinstructionsavecl’appareilpourlepropriétaire.
PROPRIÉTAIRE : Veuillezconservercesinstructionspourpouvoirvousyréférerplustard.
Avertissement de sécurité : Coupezl’alimentationducircuitdanslepanneauélectriqueetverrouillezle
panneauavantderaccorderleslsdecetappareil.
Exigence : 120Vc.a.,60Hzcircuitdedérivationde15Vc.a.,20Hz,de15ou20A.
Avis de sécurité important ..................................................................................................................................................................... 16
Exigences electriques et d’Installation ................................................................................................................................................. 17
Dimensions du produit ........................................................................................................................................................................... 18
Liste des pièces....................................................................................................................................................................................... 19
Options de ventilation............................................................................................................................................................................. 20
Options de ventilation............................................................................................................................................................................. 20
Methodes d’evacuation........................................................................................................................................................................... 21
Installation sur le mur ............................................................................................................................................................................ 22
Connexion Électrique.............................................................................................................................................................................. 24
Achever l’installation .............................................................................................................................................................................. 25
Description de la hotte............................................................................................................................................................................ 25
Commandes............................................................................................................................................................................................. 25
Entretien................................................................................................................................................................................................... 26
Français
Moteur interne
(inclusaveclehotte)
KitLampe chauffante
(Voirletableaudesaccessoirespour
plusderéférences)
MODÈLEDEHOTTE A WAW
PWLCL630SS 3.9 463 6.8 583
PWLCL136SS 7.6 913 10.5 1033
PWLCL148SS 7.7 920 10.6 1040

16
Avis de sécurité important
IATTENTION
UTILISER CET APPAREIL À DES FINS DE VENTILATION
GÉNÉRALE SEULEMENT. NE PAS UTILISER CET
APPAREIL POUR ÉVACUER DES MATÉRIAUX OU DES
VAPEURS DANGEREUX OU EXPLOSIFS.
AVERTISSEMENT
POUR RÉDUIRE LES RISQUES D’INCENDIE, DE CHOC
ÉLECTRIQUE ET DE BLESSURE, RESPECTER LES
DIRECTIVES SUIVANTES :
A. Utilisercetappareiluniquementauxnsprévuesparle
 fabricant.Sivousavezdesquestionsàproposde 
 l’appareil,communiquezaveclefabricant.
B. Avantdefairel’entretiendel’appareiloudelenettoyer,
 coupezl’alimentationdanslepanneauélectriqueet 
 verrouillezlepanneauenbloquantledispositif 
permettant d’empêcher d’activer l’alimentation
accidentellement. S’il n’est pas possible de verrouiller
 l’accèsaupanneau,xezuneétiquettetrèsvoyanteau
 panneauélectrique.
C. Unepersonnequaliéedoiteffectuerl’installationetle
 câblagedeslsélectriquesenconformitéavectousles
codes et toutes les normes, y compris la cote de
 résistanceaufeu.
D. Ilestimportantdeprévoirsufsammentd’airpour 
 assurerunebonnecombustiondel’équipementde 
 chauffeetl’évacuationadéquatesdesgazparleconduit
 decheminéandeprévenirlesrefoulementsd’air. 
 Respectezlesdirectivesetlesnormesdesécuritédes
 fabricantsdel’équipementdechauffage,commecelles
 publiéesparlaNationalFireProtectionAssociation 
 (NFPA),laAmericanSocietyforHeating,Refrigeration
 andAirConditioningEngineers(ASHRAE)etlecode
 desautoritésdevotrerégion. 
E. Aumomentdecouperoudepercerunmurouun 
 plafond,assurez-vousdenepasendommagerlalerie
 électriqueoutoutautreaccèsàunservicepublique.
F. Ilfauttoujoursévacueràl’extérieurlessystèmesà
conduit.
IATTENTION
Pourréduirelesrisquesd’incendieetévacuerl’aircorrectement,
assurez-vousqueleconduitmèneàl’extérieur;ilnefautpas
évacuerl’airdansl’espaceentrelesmurs,danslesplafonds,
dans les greniers, les vides sanitaires ou les garages.
AVERTISSEMENT
POURRÉDUIREDESRISQUESD’INCENDIE,UTILISEZ
UNIQUEMENTDESCONDUITSENMÉTAL.
Installezcettehotteenrespectanttouteslesexigences
mentionnées.
AVERTISSEMENT
Pourréduirelesrisquesd’incendieetdechocélectrique,n’utilisez
pascettehotteavecuncontrôleurdevitesseàsemi-conducteurs.
IATTENTION
PourlemodèlePWLCL630SS,utilisezcettehotteuniquement
avecdescuisinièresoudesdessusdecuisinièred'unecapacité
maximalede78KBTU.
PourlesmodèlesPWLCL136SSetPWLCL148SS,utilisez
cette hotte uniquement avec des cuisinières ou des dessus de
cuisinièred'unecapacitémaximalede108KBTU.
AVERTISSEMENT
POUR RÉDUIRE LES RISQUES D’INCENDIE DE GRAISSE
SUR LES CUISINIÈRES.
a) Nelaissezjamaislacuisinièresanssurveillance 
 lorsqu’elleestrégléeàunehautetempérature.Les 
 débordementsparbouillonnementcausentdelafumée
 etdesdébordementsdegrasquipeuvents’enammer.
 Faiteschaufferl’huilelentement,àunetempérature 
basse ou moyenne.
b) Faitestoujoursfonctionnerlahottelorsquevousutilisez
 lacuisinièreàunehautetempératureouquevousfaites
 amberdesaliments(P.ex.:crêpesSuzette,cerises
 jubilées,boeufaupoivreambé).  
c) Nettoyezleshélicesdeventilationfréquemment.Ilne
 fautpasquelagraisses’accumulesurleslresoules
 hélices.
d) Utilisezlebonformatdecasserole.Utiliseztoujoursun
chaudrondetailleappropriéàl’élémentdelacuisinière.
AVERTISSEMENT
POURÉVITERDEBLESSERQUELQU’UNLORSD’UN
INCENDIEDEGRAISSESURLACUISINIÈRE,SUIVRE
LESCONSEILSSUIVANTS:a
a) ÉTOUFFERLESFLAMMESavecuncouvercleaux 
 dimensionsdelataquedecuisson,unetôleàbiscuitou
 toutautreplateaumétallique,puiscouperlegazou 
 l’alimentationélectriquedelacuisinière.FAIRE 
 ATTENTIONANEPASSEBRÛLER.Silesammesne
 s’éteignentpasimmédiatement,QUITTERLAPIÈCEET
 APPELERLESPOMPIERS.
b) NEJAMAISPRENDREENMAINUNECASSEROLE
 ENFEU,vouspourriezvousblesser.
c) NEPASUTILISERD’EAU,ycomprislesessuiesde 
vaisselle ou les serviettes humides – une violente
 explosiondueàlavapeurforméepourraitsurvenir.
d) Utiliser un extincteur SEULEMENT si:
1) Vousêtessûrd’avoirunextincteurdeclasseABCque
 voussavezutiliser.
2) Lefeuestpetitetconnéàlazoneoùils’estformé.
3) Lespompiersontétéappelés.
4) Vouspouvezluttercontrelefeuavecunesortie 
derrière vous.
aRecommandationstiréesdesconseilsdesécuritéencas
d’incendiedecuisinepubliésparlaNFPA.
MODE OPÉRATOIRE
a) Toujourslaisserlesgrillesdesécuritéetlesltresàleur
 place.Sanslaprésencedecesderniers,lesparties 
aspirantes pourraient attirer les cheveux, les doigts ou
les vêtements.
Lefabricantdéclinetouteresponsabilitésilesinformations
détailléesdanscemanuelpourl’installation,l’entretienet
l’utilisationadéquateduproduitnesontpasobservées.Le
fabriquantdéclineenoutretouteresponsabilitépour
d’éventuellesblessuresduesàdesnégligences;enoutre,la
garantiedel’appareilseraannuléesuiteàdesconditions
d’entretieninappropriées.Cetappareilestfabriquépourun
usageinterne.Nepasutilisercetappareilàl’extérieur.
LISEZ CES INSTRUCTIONS ET CONSERVEZ-LES

17
Exigences electriques et d’Installation
IMPORTANT
Respecteztouslescodesetlesordennancesenvigueur.
Leclientalaresponsabilitéde:
• Contacterunélectricien-installateur.
• Vérierquel’installationélectriqueestadéquateetconfor-
 meavecleCodenationaldel’électricité,ANSI/NFPA
 70(laplusrécenteédition*),oulesnormesC22.1-94,Code
 canadiendel’électricité,Partie1etC22.2No.0-M91
 (Laplusrécenteédition**)delaCSA,ainsiquetousles
 codesetlesordonnancesdevotrerégion.
• Silecodelepermetetquevousutilisezunldemise
 àlaterredistinct,ilestrecommandédefairevérierle
 chemindulparunélectricien.
• Nepasmettrel’appareilàlaterresuruneconduitedegaz.
• Consultezunélectricienqualiésivousn’êtespas
 certainquelahotteestmiseàlaterrecorrectement.
• N’installezpasunfusibledanslecircuitneutreoule
 circuitdemiseàlaterre.
IMPORTANT
• Conservezcesinstructionsandepouvoirlesremettreà
 l’inspecteur-électricien.
• Lahottedoitêtrecâbléeuniquementàl’aidedelsde
cuivre.
• Ilfautraccorderlahottedirectementàuneboîteà
 fusibleouàundisjoncteurparl’entremised’une
 canalisationélectriqueenmétal.
• Lecalibredeldoitêtreconformeauxexigencesdu
 Codenationaldel’électricité,ANSI/NFPA70(Laplus
 récenteédition*),oulesnormesC22.1-94,Code
 canadiendel’électricité,Partie1etC22.20-M91(La
 plusrécenteédition**)delaCSA,ainsiquetousles
 codesetlesordonnancesdevotrerégion.
• Ilfautprévoirunconnecteurdecanalisationapprouvé
 parl’ULoulaCSAàchaqueextrémitédelacanalisation
 d’alimentation(Àlahotteetàlaboîtedejonction).
Vouspouvezobtenirunexemplairedesnormesindiquéesenvousadressantà:
*LaNationalFireProtectionAssociation,BatterymarchParkQuincy,Massachusetts,02269
**LaCSAInternational,8501EastPleasantValleyRoad,Cleveland,Ohio,44131-5575
AVANT D’INSTALLER LA HOTTE
1 Pourassurerlaventilationlaplusefcacepossible,installezla
conduite en ligne droite ou avec le moins decoudes possibles.
1 I ATTENTION La sortie de la conduite de ventilation
doitdonnersurl’extérieur.  
2 Deuxpersonnessontnécessairespoureffectuerl’installation.
3 Laquincailleriefourniepermetdexerlahotteàlaplupartdes
mursetdesplafonds;consultezuninstallateurqualiépour
vousassurerquelaquincailleriefournieestadaptéeàvotre
type de mur ou d’armoire.
4 N’utilisezpasdeconduitexible. 
5 DanslecasdesendroitssujetsauxTEMPÉRATURES
FROIDES, il faut installer un clapet de contre-tirage
supplémentaireandeminimiserleretourd’airfroidet
unisolantthermiquenonmétalliqueandeminimiserla
conductiondelatempératureextérieurdansleconduit.Ilfaut
placerleclapetducôtédel’airfroiddel’isolantthermique.
L’isolantdoitêtreplacéleplusprèspossibledel’endroitoùle
conduitentredanslapartiechaufféedelamaison.
6 Aird’appoint:Lecodedubâtimentdevotrerégionpeut
exigerl’utilisationd’unsystèmed’aird’appointsivousutilisez
unsystèmedeventilationàconduitdontlemouvementd’air
dépasseuncertainnombredeCFM.Lenombredepi3/min
varied’unerégionàl’autre.Consultezunprofessionnelde
CVCpourconnaîtrelesexigencesprécisesdevotrerégion.

18
Dimensions du produit
J
K
H
I
E
F
A
B
D
C
G
Modèles
PWLCL630SS PWLCL136SS PWLCL148SS
A30”(76cm) 36”(91.1cm) 48”(121.7cm)
B25”(63.5cm)
C18”(45.7cm)
D12”(30.3cm)
E15⁄8”(5.7cm)
F291⁄8”(74cm) 351⁄8”(89.2cm) 471⁄8”(119.7cm)
G71⁄2”(19cm)
H29⁄16”(6.5cm)
I3⁄8”(1cm)
Cache
ConduitKit JK
ACC02159 30"
(76.2cm)
6"
(15.2cm)
ACC02158 36"
(91.54cm)
ACC02164 48"
(121.7cm)
ACC02160 30"
(76.2cm)
12"
(30.5cm)
ACC02161 36"
(91.54cm)
ACC02165 48"
(121.7cm)
Accessoires optionnel
Accesoire # Part
PWLCL630SS
30" (76.2 cm)
PWLCL136SS
36" (91.54 cm)
PWLCL148SS
48" (121.7 cm)
Caché Conduit Extension Kit 6” ACC02159 ACC02158 ACC02164
Caché Conduit Extension Kit 12” ACC02160 ACC02161 ACC02165
Lampe chauffante w/ 2 - kit ampoules 175W ACC0155106 ACC0155107 ACC0155111
Kit de dosseret et de supports chauds en
acier inoxydable ACC0142864 ACC0142867 ACC0142870
Kit de réduction CFM ACC0185752** ACC0185099***
Kit de transition de 10 à 8 pouces ACC0185271
Kit sans ventilateur externe ACC0179547 ACC0179547
Kit sans ventilateur en ligne ACC0179549 ACC0179549
*Iln'yapasdevaleursnominalescertiéesHVIdisponiblespourlacongurationdukitdetransition8",veuillezvérierlescodesde
constructionlocauxandevérierlaconformitésanscerticationHVI.
**ATTENTION:EnutilisantcekitderéductiondeCFM,l'utilisationmaximaledeBTUpourcettehotteestde65KBTU.
***ATTENTION:EnutilisantcekitderéductiondeCFM,l'utilisationmaximaledeBTUpourcettehotteestde78KBTU.

19
Liste des pièces
Retirer les pièces de leur emballage.
IATTENTION
Enleverdélicatementlecarton,porterdesgantspourseprotégerdesbordscoupants.
IAVERTISSEMENT
Enleverlelmdeprotectionrecouvrantleproduitavantdecommencerl’opération.
Pièces Fournies Quantité Pièces Fournies Quantité
AssemblagehotteaveclampesDEL
1
Transitionrondede10”
1
Ensembleàunseulmoteur-ventilateur
30”:2
Ensembleàdeuxmoteurs-ventilateurs
36”,48”:1
6x80 mm 4
Rondelles Ø 6,4x11 mm
5
6x16 mm
5
Rondelles Ø 5,3x20 mm
2
3,5x9,5 mm 4 10x50 mm 2
4.2x19 mm 6
AdaptateurTorx20 1
Visdeplateaud’égouttement
4
Supportduplateaud’égouttement
30”,36”:1
48”:2
Filtresàgraisse
30”,36”:2
48”:3
Plateaud’égouttement
30”,36”:2
48”:3
Pièces non fournies
Outils nécessaires
• Perceuse
• Foret de 1 1⁄4”(3,0cm)
• Foret de 1⁄16”(4,8mm)
• Foret de 1⁄8”(3,0mm)pouravant-trous
• Crayon
• Pinceàdénuderoucouteauutilitaire
• Ruban á mesurer ou règle
• Pistoletàcalfeutrageetcomposédecalfeutragerésistant
 auxintempéries
• Tournevisàlameplate
• Tournevis Philips
• Sciesauteuseouscieàguichet
• Cisaille de ferblantier
Pièces nécessaires
• Câbled'alimentationdomestique
• Serre-câble de 1⁄2"(12,7mm)(homologationULouCSA)
• 3connecteursdelshomologuésUL
• Bouchededéchargemuraleouàtraversletoitcorrespondant
ausystèmed’évacuation
• Systèmedeconduitd’évacuationmétallique

20
Options de ventilation
Suivezàlalettrelesdirectivesprésentéesdanscemanuel.
Lefabricantrefusetouteresponsabilitéencequiatraitàtoutpréjudice,dommageouincendiecauséparlanonobservationdesdirec-
tivescontenuesdansleprésentmanuel.
Évacuationhorizontale Évacuation verticale
Utilisezunsystèmedeventilationrondde25,4cm(10")etune
transitionrondede25,4cm(10")pourévacuerlesfuméesvers
l'extérieur.
A
B
D
C
A
B
Utilisezunsystèmedeventilationrondde25,4cm(10")etune
transitionrondede25,4cm(10")pourévacuerlesfuméesvers
l'extérieur.
A
B
C
A.Transitionrondede10"(25,4cm)
B.Conduitde10"(25,4cm)ou8"(20,3cm)
C. Placard
D. 90° coude
A.Transitionrondede10"(25,4cm)
B.Conduitde10"(25,4cm)ou8"(20,3cm)
C. Placard
Préparation
Necoupezpasunesoliveouunmontantàmoinsqu’ilsoit
absolumentnécessairedelefaire.Sivousdevezcouperune
soliveouunmontant,vousdevezconstruireuncadredesoutien.
Laquincailleriefourniepermetdexerlahotteàlaplupartdes
murs et des plafonds.
Vousdevezcependantdemanderàuntechnicienqualiéde
vérierlasoliditédesmatériauxselonletypedemuroude
plafond.
Avantdecouper,assurez-vousqu’ilyaundégagementsufsant
dans le plafond ou le mur pour passer la conduite de sortie.
IATTENTION
Pourl’installationdescuisinieresàgaz:Installercettehottede
sortequelerebordinférieurestà30”(76,2cm)au-dessusdela
surface de cuisson.
Pourl’installationdescuisinieresélectriques/induction:Installer
cettehottedesortequelerebordinférieurestpasmoinsde24”
(61cm)surlasurfacedecuisson.
Ilestrecommandéd’installercettehotteplusde36”(91,4cm)
au-dessusdelasurfacedecuisson.Parpouce(2,54cm)
supérieureà36(91,4cm)diminueral’efcacitédelacapturedela
fuméeetdel’humidité,etlaperformancedeventilation.
S’ILVOUSPLAÎTLIREL’INSTALLATIONPOURUNE
INSTALLATIONSPÉCIFIQUE.Avantdechoisirlahotte,vériezla
hauteur du plafond et la hauteur maximale de la hotte.
Options de ventilation
• Ilestrecommandéd’installerlesystèmed’évacuationavantde
procéderàl’installationdelahotte.
• Si l’on installe un dosseret avec des tablettes pour les lampes
àrayonsinfrarouges,suivrelesinstructionsfourniesavecce
produit-là.
• Avantd’exécuterlesdécoupages,vérierladisponibilitéd’un
dégagementsufsantdansleplafondoulemurpourleconduit
d’évacuation.
• Vérierquelespiècesd’installationontétéretiréesducarton
d’expédition.
1 Déconnecterlasourcedecourantélectrique.
2 Déterminerlaméthoded’évacuationàutiliser:parletoitoule
mur.
REMARQUE:Cettehotteestconguréepourexpulserl’airpar
lasortiesupérieure.Sivousdécidezd’utiliserlasortiearrière,
vousdevezretirerlecouverclearrièreetleplacersurlasortie
supérieure.
3 Sélectionnerunesurfaceplanepourl’assemblagedelahotte.
Placerlematériaudeprotectionsurcettesurface.
