Tools You Will Need:
YAMAHA TOUGH-TERRAIN FRAME
ASSEMBLY INSTRUCTIONS FOR T-335, T-2700, T-2400
• Phillips (+) screwdriver • Plyers • Hex/allen wrench (included) • 5⁄32" Hex/allen wrench (included)
1Carefully unpack
• Unpack the box and make sure you have all of the parts
Do not throw away the box until you have
complete the assembly of the frame an
the instrument.
(vibe only)
4a Vibe Pedal
• emove pedal assembly from round tube
3Upper wheel/frame assembly
• Attach the upper wheel/frame assembly
– Part A to the ends of the wheel assembly
– Part D, secure the allen bolts at the bottom of part A.
– Include part E for vibraphone frame.
A
A
BB
C
D
D
E
D
E
4b Vibe Pedal
• Attach vibe pedal assembly to square lower crossbar
of Tough Terrain Frame
B
D
E
™
F
2a Lower frame assembly 2b Lower frame assembly
• Attach the lower frame assembly
– Slide part B on to the vertical posts of part D (wheel assembly)
– Tighten the allen bolts on part B to secure the low end frame assembly to the vibe wheel assembly.
Vibraphone Only
– Slide part E on to the post of part D – tighten allen bolt on part E
E
Vibraphone Only

For more information, check out the “Tips From the Pros” at www.YamahaPercussion.com
If you nee further assistance, e-mail us at [email protected]
©2010 Yamaha Corporation of America. Yamaha is a registered trademark of Yamaha Corporation. All rights reserved. www.yamaha.com/band
YAMAHA TOUGH-TERRAIN FRAME -ASSEMBLY INSTRUCTIONS PAGE 2
Assembled TTF
Connect with Yamaha
Finishe assembly can now be a juste
for height an accessories can be a e
to the accessory bar.
9Attach bolts
• Attach the provided allen bolts in to the bottom of the
wood frame assembly, securing the wood end pieces to
the top of the metal frame. The bolts should be insert-
ed with care and not fully tightened until all 4 bolts are
finger tight.
FOR SAFETY CHECK BOLTS FREQUENTLY TO
MAKE SURE THEY ARE SECURE.
E
• Attach the Knob (part F) to secure the accessory bar to
the frame. Ensure the longer end is inserted in to the
lower end the shorter end is inserted into the higher
end of the frame.
8Attach wood end pieces
• Attach the upper and lower wood end pieces and
wood rails to the top of the metal frame assembly.
MAKE SURE THE WOOD FRAME OF THE
INSTRUMENT IS CENTERED ON THE METAL
FRAME TO PREVENT INSTRUMENT DAMAGE.
– Add resonators after moving wood frame to Tough
Terrain Frame
– For Marimba – attach wood end pieces first, then
attach horizontal rails
A
B
F
Xylophone
6Secure the accessory bar
• Pull height adjustment tubes out of lower frame assembly.
• Unscrew tube from bottom of wood frame.
• Mount wood frame end piece on TTF and use screws
(step 9) to loosely secure the wood end frame.
7emove Tubes
Search for Yamaha Percussion Instruments,
Yamaha Wind Instruments and Yamaha Drums
on www.facebook.com
Search for @yamahawinds, @yamahaperc,
@yamahadrums and @theyamahahub
on www.twitter.com
The new online multimedia experience from Yamaha that includes
exclusive performances, clinics, tutorials and backstage artist interviews.
www.yamaha.com/signaturesoun s
™
5Accessory bar
• Attach the Accessory bar
– Slide part C to the front of the upper and lower frame
assembly. (parts A and B)
A
B
C
short
long
Vibraphone
Marimba
Marimba Only
