Yamaha A-670 User manual

© 2015 Yamaha Corporation Printed in China ZS21860
Integrated Amplifier / Amplificateur Intégré
OWNER’S MANUAL
MODE D’EMPLOI
MANUAL DE INSTRUCCIONES
ULV
English Français Español

IMPORTANT SAFETY INSTRUCTIONS
i En
• Explanation of Graphical Symbols
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert you to the presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral triangle is intended to alert you to the
presence of important operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with dry cloth.
7 Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8 Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9 Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding type plug has two blades and a third grounding
prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit
into your outlet, consult an electrician for replacement of the obsolete outlet.
10 Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11 Only use attachments/accessories specified by the manufacturer.
12 Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or
sold with the apparatus. When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
13 Unplug this apparatus during lightning storms or when unused for long periods of
time.
14 Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
IMPORTANT SAFETY INSTRUCTIONS
CAUTION
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
We Want You Listening For A Lifetime
Yamaha and the Electronic Industries Association’s Consumer Electronics Group
want you to get the most out of your equipment by playing it at a safe level. One
that lets the sound come through loud and clear without annoying
blaring or distortion – and, most importantly, without affecting your sensitive
hearing.
Since hearing damage from loud sounds is often undetectable until it is too late, Yamaha and the
Electronic Industries Association’s Consumer Electronics Group recommend you to avoid
prolonged exposure from excessive volume levels.

IMPORTANT SAFETY INSTRUCTIONS
ii En
English
FCC INFORMATION (for US customers)
1 IMPORTANT NOTICE: DO NOT MODIFY THIS UNIT!
This product, when installed as indicated in the instructions contained in this manual, meets FCC
requirements. Modifications not expressly approved by Yamaha may void your authority, granted
by the FCC, to use the product.
2 IMPORTANT: When connecting this product to accessories and/or another product use only high
quality shielded cables. Cable/s supplied with this product MUST be used. Follow all installation
instructions. Failure to follow instructions could void your FCC authorization to use this product in
the USA.
3 NOTE: This product has been tested and found to comply with the requirements listed in FCC
Regulations, Part 15 for Class “B” digital devices. Compliance with these requirements provides a
reasonable level of assurance that your use of this product in a residential environment will not
result in harmful interference with other electronic devices.
This equipment generates/uses radio frequencies and, if not installed and used according to the
instructions found in the users manual, may cause interference harmful to the operation of other
electronic devices.
Compliance with FCC regulations does not guarantee that interference will not occur in all
installations. If this product is found to be the source of interference, which can be determined by
turning the unit “OFF” and “ON”, please try to eliminate the problem by using one of the following
measures:
Relocate either this product or the device that is being affected by the interference.
Utilize power outlets that are on different branch (circuit breaker or fuse) circuits or install AC line
filter/s.
In the case of radio or TV interference, relocate/reorient the antenna. If the antenna lead-in is 300 ohm
ribbon lead, change the lead-in to coaxial type cable.
If these corrective measures do not produce satisfactory results, please contact the local retailer
authorized to distribute this type of product. If you can not locate the appropriate retailer, please contact
Yamaha Corporation of America A/V Division, 6600 Orangethorpe Avenue, Buena Park, CA 90620.
The above statements apply ONLY to those products distributed by Yamaha Corporation of America or
its subsidiaries.
FCC CAUTION
Change or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
FOR CANADIAN CUSTOMERS
To prevent electric shock, match wide blade of plug to wide slot and fully insert.
CAN ICES-3 (B)/NMB-3(B)
IMPORTANT
Please record the serial number of this unit in the space below.
MODEL:
Serial No.:
The serial number is located on the rear of the unit. Retain the Owner’s Manual in a safe place for
future reference.
COMPLIANCE INFORMATION STATEMENT
Responsible Party: Yamaha Corporation of America A/V Division
Address: 6600 Orangethorpe Avenue, Buena Park, CA 90620
Telephone: 714-522-9011
Type of Equipment: Integrated Amplifier
Model Name: A-670/A-U670
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received including interference that
may cause undesired operation.

IMPORTANT SAFETY INSTRUCTIONS
iii En
1 To assure the finest performance, please read this manual carefully. Keep it in a safe place for future
reference.
2 Install this sound system in a well ventilated, cool, dry, clean place - away from direct sunlight, heat
sources, vibration, dust, moisture, and/or cold. For proper ventilation, allow the following minimum
clearances.
Top: 10 cm (4 in.)*, Rear: 10 cm (4 in.), Sides: 10 cm (4 in.)
*Except for CD-NT670
3 Locate this unit away from other electrical appliances, motors, or transformers to avoid humming sounds.
4 Do not expose this unit to sudden temperature changes from cold to hot, and do not locate this unit in an
environment with high humidity (i.e. a room with a humidifier) to prevent condensation inside this unit,
which may cause an electrical shock, fire, damage to this unit, and/or personal injury.
5 Avoid installing this unit where foreign object may fall onto this unit and/or this unit may be exposed to
liquid dripping or splashing. On the top of this unit, do not place:
– Other components, as they may cause damage and/or discoloration on the surface of this unit.
– Burning objects (i.e. candles), as they may cause fire, damage to this unit, and/or personal injury.
– Containers with liquid in them, as they may fall and liquid may cause electrical shock to the user
and/or damage to this unit.
6 Do not cover this unit with a newspaper, tablecloth, curtain, etc. in order not to obstruct heat radiation.
If the temperature inside this unit rises, it may cause fire, damage to this unit, and/or personal injury.
7 Do not plug in this unit to a wall outlet until all connections are complete.
8 Do not operate this unit upside-down. It may overheat, possibly causing damage.
9 Do not use force on switches, knobs and/or cords.
10 When disconnecting the power cable from the wall outlet, grasp the plug; do not pull the cable.
11 Do not clean this unit with chemical solvents; this might damage the finish. Use a clean, dry cloth.
12 Only voltage specified on this unit must be used. Using this unit with a higher voltage than specified is
dangerous and may cause fire, damage to this unit, and/or personal injury. Yamaha will not be held
responsible for any damage resulting from use of this unit with a voltage other than specified.
13 To prevent damage by lightning, keep the power cable and outdoor antennas disconnected from a wall
outlet or this unit during a lightning storm.
14 Do not attempt to modify or fix this unit. Contact qualified Yamaha service personnel when any service
is needed. The cabinet should never be opened for any reasons.
15 When not planning to use this unit for long periods of time (i.e. vacation), disconnect the AC power
plug from the wall outlet.
16 Be sure to refer to the “Troubleshooting” section for common operating errors before concluding that
this unit is faulty.
17 Before moving this unit, press Ato set it to standby mode and disconnect the AC power plug from the
wall outlet.
18 Condensation will form when the surrounding temperature changes suddenly. Disconnect the power
cable from the outlet, then leave this unit alone.
19 When using this unit for a long time, this unit may become warm. Turn the power off, then leave this
unit alone for cooling.
20 Install this unit near the AC outlet and where the AC power plug can be reached easily.
21 Excessive sound pressure from earphones and headphones can cause hearing loss.
CAUTION: READ THIS BEFORE OPERATING YOUR UNIT.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS UNIT
TO RAIN OR MOISTURE.
This unit is not disconnected from the AC power source as long as it is connected to the wall
outlet, even if this unit itself is turned off by A. This state is called the standby mode. In this
state, this unit is designed to consume a very small quantity of power.
The user shall not reverse engineer, decompile, alter, translate or disassemble the software used in
this unit, whether in part or in whole. For corporate users, employees of the corporation itself as
well as its business partners shall observe the contractual bans stipulated within this clause. If the
stipulations of this clause and this contract cannot be observed, the user shall immediately
discontinue using the software.

INTRODUCTION
2 En
INTRODUCTION ................................................................... 2
What the unit can do ......................................................................................2
Supplied accessories......................................................................................2
NAMES AND FUNCTIONS OF THE PARTS ..................................... 3
Front panel .....................................................................................................3
Rear panel......................................................................................................4
CONNECTIONS .................................................................... 5
Connecting a network CD player ....................................................................5
Connecting speakers......................................................................................5
Connecting a subwoofer.................................................................................6
Connecting to power source ..........................................................................6
PLAYBACK ......................................................................... 7
Playing a source.............................................................................................7
PLAYING BACK MUSIC STORED ON A PC
(USB DAC FUNCTION) (A-U670 only)........................................ 8
ADJUSTING TO THE DESIRED SOUND (A-U670 only) ......................10
INTERLOCKING WITH A NETWORK CD PLAYER.............................10
Operating the power with the remote control...............................................10
Adjusting the sound volume with the remote control...................................10
Operating mute with the remote control.......................................................10
Selecting input (A-U670 only)......................................................................10
TROUBLESHOOTING.............................................................11
SPECIFICATIONS.................................................................13
uThe unit is an integrated amplifier that plays back analog stereo signals with high
quality sound. Combined with speakers, the unit can play back music with high audio
quality.
uTREBLE (high-frequency range), BASS (low-frequency range), and BALANCE (right
and left balance) can be desirably adjusted with the controls on the front panel.
uThe USB DAC function allows you to play back music stored on a PC (+page 8).(A-
U670 only)
uEnjoy pure, high fidelity sound by using the PURE DIRECT function (+page 10).(A-
U670 only)
uBoost bass sounds by connecting a subwoofer (+page 6).
Please check that you received all of the following parts.
CONTENTS INTRODUCTION
What the unit can do
Supplied accessories
System connection cable

NAMES AND FUNCTIONS OF THE PARTS
3 En
English
1A(Power) button
Turns this unit on, or sets it to standby mode.
In standby mode, the unit consumes a small amount of power.
2Power indicator
Lights up when the unit is turned on.
3PHONES jack
Connect your headphones.
When headphones are connected, no sound comes from the speakers or subwoofer.
4BASS control
Increases or decreases the low frequency response.
Control range: –10 dB to +10 dB
5TREBLE control
Increases or decreases the high frequency response.
Control range: –10 dB to +10 dB
6BALANCE control
Adjusts the sound output balance of the left and right speakers to compensate for
sound imbalances.
7VOLUME control
Adjusts the volume.
8USB DAC indicators (A-U670 only)
Lights up when audio signals are input to the USB DAC jack of this unit (+page 9).
9PURE DIRECT button and indicator (A-U670 only)
Reproduces any input source in the purest sound possible (+page 10).
The indicator lights up when the PURE DIRECT function is turned on.
NAMES AND FUNCTIONS OF THE PARTS
Front panel
(A-U670)
Notes
Notes

NAMES AND FUNCTIONS OF THE PARTS
4 En
1USB DAC (Type B) jack (A-U670 only)
Used to connect a PC (+page 5).
2ANALOG IN jacks
Used to connect a network CD player (+page 5).
3SYSTEM jack
Used to connect a network CD player (+page 5).
4SUBWOOFER jack
Used to connect a subwoofer with built-in amplifier (+page 5).
5SPEAKERS terminals
Used to connect speakers (+page 5).
6Power cable
Rear panel
(A-U670)

CONNECTIONS
5 En
English
Make sure to connect L (left) to L, R (right) to R, “+” to “+” and “–” to “–.” If the connections are faulty, no sound may be heard from the speakers, and if the polarity of the speaker
connections is incorrect, the sound may be unnatural and lack bass. Refer to the owner’s manual for each of your components. Make sure to use RCA type cables, the supplied system
connection cable, or a commercially available USB cables (A-U670 only) to connect audio components.
Do not connect this unit or other components to the main power until all connections between components are complete.
As shown in the figure, connect the ANALOG OUT jacks of the network CD player (CD-
NT670) to the ANALOG IN jacks of the unit by using the RCA stereo cable supplied with
the network CD player, and connect the SYSTEM jacks of the both equipment to each
other by using the supplied system connection cable.
When the SYSTEM jacks of the unit and the network CD player are connected to each
other, you can use the remote control of the network CD player to operate the unit
(+page 10).
Connect the SPEAKERS terminals of the unit and the terminals of the speakers as shown
in the figure.
CONNECTIONS
CAUTION
Connecting a network CD player Connecting speakers

CONNECTIONS
6 En
nConnecting speaker cables
1Remove approximately 10 mm (3/8”) of insulation from the end of each speaker cable.
2Twist the bare wires of the cable firmly together.
3Unscrew the knob.
4Insert one bare wire into the hole in the side of each terminal.
5Tighten the knob to secure the wire.
•Use speakers with the impedance of 6 Ωor higher.
•Do not let bare speaker wires touch each other or any metal part of this unit. This could
damage this unit and/or the speakers.
nUsing a banana plug (North America, China, Taiwan and
Australia models only)
1Tighten the knob.
2Insert the banana plug into the end of the corresponding terminal.
To use a subwoofer, connect the jack of the subwoofer to the SUBWOOFER jack of the
unit as shown in the figure.
After all the connections are complete, plug in the power cable to the AC outlet.
CAUTION
10 mm
(3/8”)
Red: positive (+)
Black: negative (–)
Banana plug
Connecting a subwoofer
Connecting to power source
Subwoofer

PLAYBACK
7 En
English
1Press the A(power) button on the front panel to turn on the unit.
You can also turn on the unit by pressing the A(power) button on the remote control
of the connected network CD player if the SYSTEM jacks of the network CD player
and of the unit are connected to each other.
The unit is turned on by interlocking with the network CD player (+page 10).
2Select the input source on the network CD player and play the source.
3Rotate the VOLUME control on the front panel to adjust the volume.
You can also adjust the volume by pressing VOLUME +/– buttons on the remote
control of the connected network CD player if the SYSTEM jacks of the network CD
player and of the unit are connected to each other.
4When finished listening, press A(power) button on the front panel to
set the unit to standby mode.
PLAYBACK
Playing a source
VOLUME
Auto power standby function
•The auto power standby function will be activated as follows (default setting).
- The unit turn off automatically if no operation has been performed for more than 8 hours.
Activating/deactivating the auto power standby function
1 While pressing and holding A(power) on the unit, plug in the power cable to the
AC outlet.
2 Keep pressing A(power).
•The auto power standby function switches and the power indicator blink as follows:
- Auto power standby function is activated: blink twice
- Auto power standby function is deactivated: blink once
•If the SYSTEM jacks of the network CD player and the unit are connected to each other, and the
network CD player is turned on, the unit operates interlocking with auto power standby function
of the network CD player.
Notes

PLAYING BACK MUSIC STORED ON A PC (USB DAC FUNCTION) (A-U670 ONLY)
8 En
When a PC is connected to the USB DAC jack of the unit, the unit works as a USB DAC
and can play back songs stored on the PC.
nSupported operating systems
The USB connection is available for PCs with the following operating systems:
For Windows: Windows 7 (32/64bit) / Windows 8 (32/64bit) /Windows 8.1 (32/64bit)
For Mac: OS X 10.6.4 or later
•Operations with other operating systems are not guaranteed.
•Operations may be disabled even with the above-mentioned operating systems, depending on the
configuration or environment of the PC.
nInstalling the dedicated driver
Before connecting a PC to this unit, install the dedicated driver on the PC. The dedicated
driver is available only for Windows. For Mac, the standard driver of Mac OS is available
for setting.
1Access the following URL to download the dedicated “Yamaha HiFi USB
Driver,” and unzip and execute the file.
2Install the downloaded “Yamaha HiFi USB Driver” to your PC.
For details, refer to the Installation Guide supplied with the downloaded driver.
3When installation is complete, quit all running applications.
•Operations may not be executed correctly if the PC is connected to this unit before the driver is
installed.
•The “Yamaha HiFi USB Driver” is subject to change without prior notice. For details and the latest
information, refer to the download page for the driver.
PLAYING BACK MUSIC STORED ON A PC (USB DAC FUNCTION) (A-U670 ONLY)
Notes
PC
USB cable (Type B)
Rear panel
Website for downloading the dedicated driver
URL: http://download.yamaha.com/
Notes

PLAYING BACK MUSIC STORED ON A PC (USB DAC FUNCTION) (A-U670 ONLY)
9 En
English
nPlaying back music stored on a PC
Check if the SYSTEM jacks of the network CD player and of the unit are connected to
each other. If not connected, operation is unavailable with the network CD player and its
remote control.
1Connect the PC to the unit with a USB cable.
2Turn on the PC.
3Press the A(power) button on the front panel to turn on the unit.
You can also turn on the unit by pressing the A(power) button on the remote control
of the connected network CD player.
The unit is turned on by interlocking with the network CD player (+page 10).
4Press the USB button on the remote control of the connected network
CD player (or rotate the INPUT knob of the connected network CD
player) to select [USB DAC].
5Set the audio output destination of the PC to “Yamaha A-U670/A-U671.”
With Windows OS:
Control Panel -> Hardware and Sound -> Sound -> [Playback] tab
With Mac OS:
System Preferences -> Sound -> [Output] tab
The setting may vary, depending on the operating systems. For details, consult the
manufacturer of your PC.
6Operate the PC to start playback of music files.
When the music signal is input from the PC to the unit, the USB DAC indicator on
the front panel lights up in accordance with the sampling frequency of the music
being played. Sampling frequencies available for the unit are as follows:
nAdjusting the sound volume
To obtain higher sound quality, set the sound volume at the PC to the maximum, and
gradually increase the volume at this unit from the minimum to your desired level.
•Do not disconnect the USB cable, turn off the unit, or change the input while playback on a PC
connected via the USB cable is in progress. Doing so may cause a malfunction.
•To mute operation sounds of the PC during music playback, change the setting on the PC.
•
If music files cannot be played correctly, restart the computer and perform the mentioned procedure again.
•The music files stored on a PC cannot be controlled from this unit. Operate them on the PC.
•When the unit is not connected with a network CD player, or when a network CD player is turned
off even if the SYSTEM jacks of the unit and of the network CD player are connected, the input
source automatically switches to USB when the unit detects the PC connected to it. When the unit
cannot recognize the connection, the input source automatically switches to ANALOG IN.
USB DAC
indicator
A
Indicator Frequency
PCM
×1 44.1/48 kHz
×2 88.2/96 kHz
×4 176.4/192 kHz
×8 352.8/384 kHz
DSD ×1 2.8224 MHz
×2 5.6448 MHz
Notes

ADJUSTING TO THE DESIRED SOUND (A-U670 ONLY)
10 En
nReproducing pure, high fidelity sound (PURE DIRECT)
With the PURE DIRECT function on, the BASS, TREBLE, and BALANCE circuits are
bypassed to reduce noises. Therefore, in all input sources, you can enjoy music playback
in straight and high quality sound.
Press the PURE DIRECT button on the front panel to switch the PURE DIRECT function
on or off.
The PURE DIRECT indicator lights up when this function is turned on.
The BASS, TREBLE, and BALANCE controls do not function while the PURE DIRECT function is
turned on.
Operation is available with the remote control of the network CD player (CD-NT670).
Check if the SYSTEM jacks of the unit and the network CD player are connected to each
other.
Pressing the A(power) button of the remote control causes the unit to turn on or enter the
standby mode by interlocking with the network CD player.
y
Even if the A(power) button on the unit is pressed, interlocking does not work. The unit and the
network CD player are independently turned on or enter the standby mode.
With either the unit or the network CD player on, if you press the A(power) of the remote control,
the unit will be turned on or enter the standby mode according to the status of the network CD player.
You can adjust the sound volume by pressing the VOLUME +/– buttons of the remote
control.
You can turn on or off mute by pressing the MUTE button on the remote control.
You can select USB as the input source of the unit by pressing the USB button of the
remote control (or rotate the INPUT knob of the connected network CD player).
ADJUSTING TO THE DESIRED SOUND (A-U670
ONLY)
Notes
PURE DIRECT
INTERLOCKING WITH A NETWORK CD PLAYER
Operating the power with the remote control
Adjusting the sound volume with the remote control
Operating mute with the remote control
Selecting input (A-U670 only)

TROUBLESHOOTING
11 En
English
Refer to the chart below if this unit does not function properly. If the problem you are experiencing is not listed below or if the instructions below do not help, turn off this unit,
disconnect the power cable, and then contact the nearest authorized Yamaha dealer or service center.
TROUBLESHOOTING
Problem Cause Solution See page
This unit fails to turn on. The power cable is not connected or the plug is not completely
inserted.
Connect the power cable firmly. 6
The protection circuitry has been activated because of a short
circuit, etc.
Check that the speaker wires are not touching each other and then turn the
power of this unit back on. 6
There is a problem with the internal circuitries of this unit. Disconnect the power cable and contact the nearest authorized Yamaha
dealer or service center. -
A speaker with a low impedance is connected. Use speaker(s) with proper speaker impedance (6 Ωor higher). 6
This unit turns off suddenly and the power
indicator turns off.
The speaker wires are touching each other or shorting out against
the rear panel.
Connect the speaker cables properly and turn the power on again. Confirm
normal sound output from speakers after the unit is turned on. 6
The speaker is malfunctioning. Replace the speaker set and turn the power on again. Confirm normal
sound output from speakers after the unit is turned on. -
This unit has been exposed to a strong external electric shock (such
as lightning or strong static electricity).
Turn off this unit, disconnect the power cable, plug it back in after 30
seconds, then use the unit normally. -
There is a problem with the internal circuitries of this unit. Disconnect the power cable and contact the nearest authorized Yamaha
dealer or service center. -
No sound. Headphones are connected.
(When headphones are connected, no sound comes from the
speakers or subwoofer.)
Disconnect headphones when you use the speakers or subwoofer.
-
Incorrect cable connections. Connect the stereo cable for audio units and the speaker wires properly. If
the problem persists, the cables may be defective. 5
Playback has been stopped on the connected component. Turn the component on and start playback. 7
(A-U670 only) The driver is not installed in the PC connected with
the unit via USB.
Before connecting a PC to this unit, install the driver on the PC. 8
The volume of the unit is set to the minimum. Turn up the volume with the VOLUME control so that you can hear
sound. -
The unit cannot be turned off. The internal microprocessor is frozen due to an external electronic
shock (lightning, excessive static electricity, etc.) or decrease in the
power supply voltage.
Press the power button on the front panel of the unit for 10 seconds or
more to restart the unit (If the problem persists, unplug the power cable
and after about 30 seconds, then plug it back in again).
-

TROUBLESHOOTING
12 En
Only the speaker on one side can be
heard.
Incorrect cable connections. Connect the cables properly. If the problem persists, the cables may be
defective. 5
Incorrect setting for the BALANCE control. Set the BALANCE control to the appropriate position. 3
There is a lack of bass and no ambience. (When a subwoofer is connected.)
The subwoofer is not properly connected.
Connect the cables properly. If the problem persists, the setting for the
subwoofer may be incorrect. 6
The + and – wires are connected in reverse at the amplifier or the
speakers.
Connect the speaker wires to the correct + and – phase. 6
Incorrect setting for the BASS control. Set the BASS control to the appropriate position. 3
A “humming” sound can be heard. Incorrect cable connections. Connect the audio plugs firmly. If the problem persists, the cables may be
defective. 5
The sound level is low. The volume of the unit is set to a low level. Turn up the volume with the VOLUME control so that you can hear
sound. 7
(A-U670 only) The volume of the PC connected with the unit via
USB is set to a low level.
Turn up the volume of the PC. -
(A-U670 only) The BASS, TREBLE, and
BALANCE controls does not work.
The PURE DIRECT function is turned on. Turn off the PURE DIRECT function. 10
(A-U670 only) The connected PC does not
recognize this unit.
The operating system of the PC is not supported. Use a PC with an operation-guaranteed operating system. 8
Improper USB cable connection. Connect the USB cable properly. 8
The output of the PC or application is muted. Cancel the sound muting of the PC or application. -
(A-U670 only) Noisy playback. Another application is launched on the PC while a music file is
being played.
(If another application is launched while a music file is being
played, sound may be momentarily lost or noise may be generated.)
Do not launch other applications during playback.
-
(A-U670 only) The sound is interrupted. Another application is launched on the PC while a music file is
being played.
(If another application is launched while a music file is being
played, sound may be momentarily lost or noise may be generated.)
Do not launch other applications during playback.
-
(A-U670 only) Music files cannot be
played.
The music data are not properly reproduced, because this unit is
connected to the PC or the input of this unit is switched to USB
while the music application is running on the PC.
Connect this unit to the PC and set the input of the unit to USB in
advance. Then launch the music application and start playback. 8
The dedicated “Yamaha HiFi USB Driver” has not been installed
correctly.
Install the “Yamaha HiFi USB Driver” again by following the correct
procedure. 8
The audio output destination of the computer is not set to “Yamaha
A-U670/A-U671.”
Set the audio output destination of the computer to “Yamaha A-U670/A-
U671.” 9
Problem Cause Solution See page

SPECIFICATIONS
13 En
English
AUDIO SECTION
nANALOG IN
• Input jack ............................................................................RCA jack
nUSB DAC (A-U670 only)
• Input jack ..................................... USB (Type B), supported USB2.0
• Supported sampling frequencies
........................................ 384/352.8/192/176.4/96/88.2/48/44.1 kHz
• PCM word depths ..........................................................32/24/16 bits
• DSD ................................................................... 2.8224/5.6448 MHz
nSPEAKERS
• Maximum output power (6 Ω, 1 kHz, 10% THD)
[A-670] ........................................................................ 65 W + 65 W
[A-U670].......................................................................70 W + 70 W
• Frequency response (10 Hz to 40 kHz) .................................0±3 dB
• Total harmonic distortion (30 W/6 Ω, 1 kHz) ..............0.05% or less
nPHONES
• Output level/Output impedance
(Input 1 kHz, 230 mV, 32 Ωterminated)
..................................................................................... 500 mV/24 Ω
nSUBWOOFER
• Output level/Output impedance (Input 1 kHz, 230 mV)
..........................................................................................2.0 V/1 kΩ
GENERAL
•Powersupply
[U.S.A., Canada and Taiwan models] ....AC 100 to 120 V, 50/60 Hz
[Asia model] ...........................................AC 220 to 240 V, 50/60 Hz
• Power consumption
[A-670] ......................................................................................28 W
[A-U670] ................................................................................... 30 W
• Standby power consumption
(with system connection/without system connection)..............0.5 W
• Dimensions (W × H × D)
..............................314 × 70 × 342 mm (12-3/8" × 2-3/4" × 13-1/2")
• Weight....................................................................... 3.3 kg (7.3 lbs.)
Specifications are subject to change without notice.
SPECIFICATIONS

PRÉCAUTIONS CONCERNANT LA SÉCURITÉ
i Fr
• Explication des symboles
L’éclair avec une flèche à l’intérieur d’un triangle équilatéral est destiné à attirer
l’attention de l’utilisateur sur la présence d’une « tension dangereuse » non isolée à
l’intérieur de l’appareil, pouvant être suffisamment élevée pour constituer un risque
d’électrocution.
Le point d’exclamation à l’intérieur d’un triangle équilatéral est destiné à attirer
l’attention de l’utilisateur sur la présence d’instructions importantes sur l’emploi ou
la maintenance (réparation) de l’appareil dans la documentation fournie.
1 Lire ces instructions.
2 Conserver ces instructions.
3 Tenir compte de tous les avertissements.
4 Suivre toutes les instructions.
5 Ne pas utiliser ce produit à proximité d’eau.
6 Nettoyer uniquement avec un chiffon propre et sec.
7 Ne pas bloquer les orifices de ventilation. Installer l’appareil conformément aux instructions du
fabricant.
8 Ne pas installer l’appareil à proximité d’une source de chaleur comme un radiateur, une bouche de
chaleur, un poêle ou tout autre appareil (y compris un amplificateur) produisant de la chaleur.
9 Ne pas modifier le système de sécurité de la fiche polarisée ou de la fiche de terre. Une fiche polarisée
dispose de deux broches dont une est plus large que l’autre. Une fiche de terre dispose de deux broches
et d’une troisième pour le raccordement à la terre. Cette broche plus large ou cette troisième broche est
destinée à assurer la sécurité de l’utilisateur. Si la fiche équipant l’appareil n’est pas compatible avec
les prises de courant disponibles, faire remplacer les prises par un électricien.
10 Acheminer les cordons d’alimentation de sorte qu’ils ne soient pas piétinés ni coincés, en faisant tout
spécialement attention aux fiches, prises de courant et au point de sortie de l’appareil.
11 Utiliser exclusivement les fixations et accessoires spécifiés par le fabricant.
12 Utiliser exclusivement le chariot, le stand, le trépied, le support ou la table
recommandés par le fabricant ou vendus avec cet appareil. Si l’appareil est posé sur un
chariot, déplacer le chariot avec précaution pour éviter tout risque de chute et de
blessure.
13 Débrancher l’appareil en cas d’orage ou lorsqu’il doit rester hors service pendant une
période prolongée.
14 Confier toute réparation à un personnel qualifié. Faire réparer l’appareil s’il a subi tout dommage, par
exemple si la fiche ou le cordon d’alimentation est endommagé, si du liquide a coulé ou des objets sont
tombés à l’intérieur de l’appareil, si l’appareil a été exposé à la pluie ou à de l’humidité, si l’appareil ne
fonctionne pas normalement ou est tombé.
PRÉCAUTIONS CONCERNANT LA SÉCURITÉ
ATTENTION
ATTENTION: POUR RÉDUIRE LES RISQUES D’INCENDIE ET DE
DÉCHARGE ELECTRIQUE, NE PAS RETIRER LE COUVERCLE
(OU LE PANNEAU ARRIÈRE). NE CONTIENT AUCUNE PIÈCE
INTERNE RÉPARABLE PAR L’UTILISATEUR. POUR
L’ENTRETIEN, S’ADRESSER À UN PERSONNEL QUALIFIÉ.
RISQUE DE CHOC ÉLECTRIQUE:
NE PAS OUVRIR
Nous vous souhaitons un plaisir musical durable
Yamaha et le Groupe des Entreprises Électroniques Grand Public de l’Association
des Industries Électroniques désirent que vous tiriez le meilleur parti de votre
équipement tout en écoutant à un niveau non dommageable pour l’ouïe. Un niveau
qui vous permet d’obtenir un son fort et clair, sans hurlement ni distorsion, –mais
sans aucun danger pour l’ouïe.
Comme les sons trop forts causent des lésions auditives qui ne peuvent être détectées qu’à long
terme, lorsqu’il est trop tard, Yamaha et le Groupe des Entreprises Électroniques Grand Public de
l’Association des Industries Électroniques vous déconseillent l’écoute prolongée à des volumes
excessifs.

PRÉCAUTIONS CONCERNANT LA SÉCURITÉ
ii Fr
Français
INFORMATION DE LA FCC (pour les clients résidant aux États-Unis)
1 AVIS IMPORTANT : NE PAS APPORTER DE MODIFICATIONS À CET APPAREIL !
Cet appareil est conforme aux exigences de la FCC s’il est installé selon les instructions du mode
d’emploi. Toute modification non approuvée expressément par Yamaha peut invalider
l’autorisation de la FCC d’utiliser cet appareil.
2 IMPORTANT : N’utiliser que des câbles blindés de haute qualité pour le raccordement de cet
appareil à des accessoires et/ou à un autre appareil. Seuls le ou les câbles fournis avec le produit
DOIVENT être utilisés. Suivre les instructions concernant l’installation. Le non respect des
instructions peut invalider l’autorisation, accordée par la FCC, d’utiliser ce produit aux États-Unis.
3 REMARQUE : Cet appareil a été testé et déclaré conforme aux normes relatives aux appareils
numériques de Classe
«
B
»
,
telles que fixées dans l’Article 15 de la Réglementation FCC. Ces
normes sont destinées à assurer une protection suffisante contre les interférences nuisibles avec
d’autres appareils électroniques dans une installation résidentielle.
Cet équipement génère et utilise des fréquences radio qui, en cas d’installation et d’utilisation non
conformes aux instructions du mode d’emploi, peuvent être à l’origine d’interférences empêchant
d’autres appareils de fonctionner.
Cependant, la conformité à la Réglementation FCC ne garantit pas l’absence d’interférences dans une
installation particulière. Si cet appareil devait produire des interférences, ce qui peut être déterminé en
« ÉTEIGNANT », puis en « RALLUMANT » l’appareil, l’utilisateur est invité à essayer de corriger le
problème d’une des manières suivantes :
Réorienter cet appareil ou le dispositif affecté par les interférences.
Utiliser des prises d’alimentation branchées sur différents circuits (avec interrupteur de circuit ou
fusible) ou installer un ou des filtres pour ligne secteur.
Dans le cas d’interférences radio ou TV, changer de place l’antenne et la réorienter. Si l’antenne est un
conducteur plat de 300 ohms, remplacer ce câble par un câble de type coaxial.
Si ces mesures ne donnent pas les résultats escomptés, prière de contacter le détaillant local autorisé à
commercialiser ce type d’appareil. Si ce n’est pas possible, prière de contacter Yamaha Corporation of
America A/V Division, États-Unis, 6600 Orangethorpe Ave., Buena Park, CA 90620.
Les déclarations précédentes concernent EXCLUSIVEMENT les appareils commercialisés par
Yamaha Corporation of America ou ses filiales.
PRÉCAUTION FCC
Tout changement ou toute modification non approuvé expressément par le tiers responsable peut
aboutir à l’interdiction de faire fonctionner cet appareil.
POUR LES CONSOMMATEURS CANADIENS
Pour prévenir tout choc électrique, faites correspondre la broche large de la fiche à la fente large et
insérez complètement.
CAN ICES-3 (B)/NMB-3(B)
IMPORTANT
Veuillez noter le numéro de série de cet appareil dans l’espace réservé à cet effet, ci-dessous.
MODÈLE:
No. de série:
Le numéro de série se trouve à l’arrière de l’appareil. Prière de conserver le mode d’emploi en lieu sûr
pour toute référence future.
DÉCLARATION SUR LES INFORMATIONS DE CONFORMITÉ
Partie responsable: Yamaha Corporation of America A/V Division
Addresse: 6600 Orangethorpe Avenue Buena Park, CA 90620
Téléphone: 714-522-9011
Type d’équipement: Amplificateur intégré
Nom de modèle: A-670/A-U670
Cet appareil est conforme à l’article 15 de la réglementation FCC.
Le fonctionnement de cet appareil est soumis aux deux conditions suivantes : (1) cet appareil ne
doit pas provoquer d’interférences nuisibles, et (2) cet appareil doit accepter les interférences
reçues, notamment celles pouvant entraîner un dysfonctionnement.

ATTENTION : VEUILLEZ LIRE CE QUI SUIT AVANT D’UTILISER L’APPAREIL.
iii Fr
1 Pour utiliser l’appareil au mieux de ses possibilités, lisez attentivement ce mode d’emploi.
Conservez-le soigneusement pour référence.
2 Installez cet ensemble audio dans un endroit bien aéré, frais, sec et propre - veillez à ce qu’il soit à
l’abri de la lumière directe du soleil, des sources de chaleur, des vibrations, des poussières, de
l’humidité et/ou du froid. Pour une ventilation correcte, ménagez l’espace minimum suivant.
Au-dessus : 10 cm*, À l’arrière : 10 cm, Sur les côtés : 10 cm
* À l’exception du modèle CD-NT670
3 Placez l’appareil loin des équipements, moteurs et transformateurs électriques, pour éviter les ronflements parasites.
4 N’exposez pas l’appareil à des variations brutales de température, ne le placez pas dans un
environnement très humide (par exemple dans une pièce contenant un humidificateur) car cela peut
entraîner la condensation d’humidité à l’intérieur de l’appareil qui elle-même peut être responsable de
décharge électrique, d’incendie, de dommage à l’appareil ou de blessure corporelle.
5 Evitez d’installer l’appareil dans un endroit où des objets peuvent tomber, ainsi que là où l’appareil
pourrait être exposé à des éclaboussures ou des gouttes d’eau. Sur le dessus de l’appareil, ne placez pas :
– d’autres appareils qui peuvent endommager la surface de l’appareil ou provoquer sa décoloration.
– des objets se consumant (par exemple, une bougie) qui peuvent être responsables d’incendie, de
dommage à l’appareil ou de blessure corporelle.
– des récipients contenant des liquides qui peuvent être à l’origine de décharge électrique ou de
dommage à l’appareil.
6 Ne couvrez pas l’appareil d’un journal, d’une nappe, d’un rideau, etc. car cela empêcherait l’évacuation
de la chaleur. Toute augmentation de la température intérieure de l’appareil peut être responsable
d’incendie, de dommage à l’appareil ou de blessure corporelle.
7 Ne branchez pas la fiche du câble d’alimentation de l’appareil sur une prise secteur aussi longtemps que
tous les raccordements n’ont pas été effectués.
8 Ne pas faire fonctionner l’appareil à l’envers. Il risquerait de chauffer et d’être endommagé.
9 N’exercez aucune force excessive sur les commutateurs, les boutons et les cordons.
10 Pour débrancher la fiche du cordon d’alimentation au niveau de la prise secteur, saisissez la fiche et ne
tirez pas sur le cordon.
11 Ne nettoyez pas l’appareil au moyen d’un solvant chimique, ce qui pourrait endommager la finition.
Utilisez un chiffon sec et propre.
12 N’alimentez l’appareil qu’à partir de la tension prescrite. Alimenter l’appareil sous une tension plus
élevée est dangereux et peut être responsable d’incendie, de dommage à l’appareil ou de blessure
corporelle. Yamaha ne saurait être tenue responsable des dommages résultant de l’alimentation de
l’appareil sous une tension autre que celle prescrite.
13 Pour empêcher tout dommage causé par les éclairs, déconnectez le câble d’alimentation et toute
antenne extérieure de la prise murale pendant un orage.
14 Ne tentez pas de modifier ni de réparer l’appareil. Consultez le service Yamaha compétent pour toute
réparation qui serait requise. Le coffret de l’appareil ne doit jamais être ouvert, quelle que soit la raison.
15 Si vous envisagez de ne pas vous servir de l’appareil pendant une longue période (par exemple, pendant
les vacances), débranchez la fiche du câble d’alimentation au niveau de la prise secteur.
16 Veuillez vous reporter à la section « Guide de dépannage » concernant les erreurs de fonctionnement
courantes avant d’en conclure que l’appareil est défectueux.
17 Avant de déplacer l’appareil, appuyez sur Apour placer l’appareil en veille puis débranchez la fiche du
câble d’alimentation au niveau de la prise secteur.
18 La condensation se forme lorsque la température ambiante change brusquement. En ce cas, débranchez
la fiche du câble d’alimentation et laissez l’appareil reposer.
19 La température de l’appareil peut augmenter en raison d’une utilisation prolongée. En ce cas, coupez
l’alimentation de l’appareil et laissez-le au repos pour qu’il refroidisse.
20 Installez cet appareil à proximité de la prise secteur et à un emplacement où la fiche du câble
d’alimentation est facilement accessible.
21 Une pression excessive du son par les écouteurs et le casque d’écoute peut entraîner la perte de l’ouïe.
ATTENTION : VEUILLEZ LIRE CE QUI SUIT AVANT D’UTILISER L’APPAREIL.
AVERTISSEMENT
POUR RÉDUIRE LES RISQUES D’INCENDIE OU DE DÉCHARGE ÉLECTRIQUE,
N’EXPOSEZ PAS CET APPAREIL À LA PLUIE OU À L’HUMIDITÉ.
Cet appareil n’est pas déconnecté du secteur tant qu’il reste branché à la prise de courant, même si
l’appareil en soi est éteint par la touche A. Il se trouve alors « en veille ». En mode veille,
l’appareil consomme une très faible quantité de courant.
L’utilisateur n’est pas autorisé à rétro-concevoir, décompiler, modifier, traduire ou désassembler le
logiciel utilisé dans cet appareil, aussi bien dans ses parties que dans sa totalité. En ce qui concerne les
utilisateurs en entreprise, les employés de l’entreprise proprement dite ainsi que ses partenaires
commerciaux doivent respecter les interdictions figurant dans cette clause. Si les termes de cette clause et
de ce contrat ne peuvent pas être respectés, l’utilisateur devra immédiatement cesser d’utiliser le logiciel.

INTRODUCTION
2 Fr
INTRODUCTION ................................................................... 2
Rôle de cet appareil........................................................................................2
Accessoires fournis........................................................................................2
DÉNOMINATION ET FONCTION DES ÉLÉMENTS DE L’APPAREIL .......... 3
Panneau avant................................................................................................3
Panneau arrière..............................................................................................4
RACCORDEMENTS................................................................ 5
Raccordement d’un lecteur de CD réseau ......................................................5
Raccordement des enceintes .........................................................................5
Raccordement d’un caisson de graves...........................................................6
Raccordement à la source d’alimentation.......................................................6
LECTURE ........................................................................... 7
Lecture d’une source......................................................................................7
ÉCOUTE DE LA MUSIQUE STOCKÉE SUR UN PC
(FONCTION USB DAC) (A-U670 uniquement) .............................. 8
RÉGLAGE DU SON SOUHAITÉ (A-U670 uniquement).......................10
ENCLENCHEMENT AVEC UN LECTEUR DE CD RÉSEAU ....................10
Mise sous/hors tension à l’aide de la télécommande ...................................10
Réglage du volume sonore à l’aide de la télécommande ..............................10
Activation/désactivation du son à l’aide de la télécommande .......................10
Sélection de l’entrée (A-U670 uniquement)..................................................10
GUIDE DE DÉPANNAGE .........................................................11
SPÉCIFICATIONS.................................................................13
uL’appareil est un amplificateur intégré qui reproduit des signaux stéréo analogiques
avec un son de haute qualité. Combiné à des enceintes, il peut reproduire de la musique
avec une qualité audio élevée.
uTREBLE (gamme des hautes fréquences), BASS (gamme des basses fréquences) et
BALANCE (balance gauche-droite) sont autant de réglages facilement accessibles à
partir des commandes du panneau avant.
uLa fonction USB DAC permet d’écouter la musique stockée sur un PC (+page 8).
(A-U670 uniquement)
uProfitez d’un son haute-fidélité particulièrement pur à l’aide de la fonction PURE
DIRECT (+page 10). (A-U670 uniquement)
uLes sons graves peuvent être accentués en raccordant un caisson de graves (+page 6).
Vérifiez que vous avez reçu tous les éléments suivants.
TABLE DES MATIÈRES INTRODUCTION
Rôle de cet appareil
Accessoires fournis
Câble de raccordement au système
Other manuals for A-670
1
This manual suits for next models
1
Table of contents
Languages:
Other Yamaha Amplifier manuals

Yamaha
Yamaha DSP-A1 User manual

Yamaha
Yamaha AX-490 User manual

Yamaha
Yamaha YST-A5 User manual

Yamaha
Yamaha CX-A5000 User manual

Yamaha
Yamaha PA2120 User manual

Yamaha
Yamaha CX-A5000 User manual

Yamaha
Yamaha PA24 User manual

Yamaha
Yamaha A-S2000 - Amplifier User manual

Yamaha
Yamaha SR-50 User manual

Yamaha
Yamaha T3n User manual

Yamaha
Yamaha DSP-AX2 User manual

Yamaha
Yamaha A-760 User manual

Yamaha
Yamaha XMV4140 User manual

Yamaha
Yamaha PC2602 User manual

Yamaha
Yamaha P4050 User manual

Yamaha
Yamaha PG1 User manual

Yamaha
Yamaha CA-610 User manual

Yamaha
Yamaha AV-55 User manual

Yamaha
Yamaha BBT 500H User manual

Yamaha
Yamaha A-520 User manual
