TF5/TF3/TF1/TF-RACK/NY64-D Firmware Update Guide 1
TF5/TF3/TF1/TF-RACK/NY64-D Firmware Update Guide
Thank you for choosing a Yamaha product.
This guide explains how to update the TF series (TF5, TF3, TF1 and TF-RACK) and the NY64-D firmware.
■Precautions (Please be sure to read this section first!)
・The user assumes full responsibility for the update.
・Please note that the device may be damaged if you fail to follow these instructions properly, or turn off
the device or operate any control/function while the update is in progress.
・If the update fails, and the device still does not operate correctly even after you execute the update once
again, please contact your Yamaha dealer.
・Yamaha Corporation owns exclusive copyrights for the TF series firmware, its update program, and the
update guide.
・It is prohibited to duplicate or modify the firmware, software or guides, in part or in their entirety, without
permission from the copyright owner.
・The screen shots in this guide are for use with this update procedure only and may be different from the
actual screen shots.
・The company names and product names in this document are the trademarks or registered trademarks of
their respective companies.

TF5/TF3/TF1/TF-RACK/NY64-D Firmware Update Guide 2
■Checking the version number
You can check the TF main firmware and the NY64-D firmware version numbers from the Version field in the
ABOUT screen of the SYSTEM SETUP screen (V2.5 and earlier)/SETUP screen (V3.0 and later).
■Preparing for the update
The following items are necessary for the update procedure.
●Formatted (FAT32) USB flash drive with 1GB free space
In the TF series, memory of 4GB or larger will be formatted in FAT32. For the formatting procedure,
refer to “TF5/ TF3/ TF1/TF-RACK Reference Manual.”
For formatting in a computer, refer to documentations supplied with the computer or its OS.
●The TF series firmware, and the NY64-D firmware
Download the latest firmware from the following URL.
http://www.yamahaproaudio.com/downloads/
When updating a NY64-D card installed to the TF series:
There are two options.
●Using a USB flash drive inserted to the TF series →page 3
The firmware of the TF series and the NY64-D are separate. You can update them individually, or
simultaneously.
●Using a computer (Dante Firmware Update Manager) → page 7
Dante Firmware Update Manager is required.

TF5/TF3/TF1/TF-RACK/NY64-D Firmware Update Guide 3
■
Updating the TF series/NY64-D firmware
Instructions for updating the TF series firmware and the NY64-D firmware are given below.
Both firmware files (compressed) must be downloaded, and must be expanded prior to updating. In addition,
be sure to disconnect all cables from the PRIMARY/SECONDARY connector of the NY64-D.
1. Connect the USB flash drive (formatted in FAT32) to the USB connector of your computer.
2. Copy the “TF_updater_v***.bin” (*** indicates the version number) in the folder extracted from the
downloaded zip file to the root directory of the USB flash drive.
3. If the NY64-D firmware update is required simultaneously, also copy the file
“FWUpdate_NY64-D_v******_sw***.dnt” in the folder extracted from the downloaded zip file to the root
directory of the USB flash drive.
Make sure that no other files, except those relevant to the TF series and NY64-D firmware, are copied to the
root directory.
4. Remove the USB flash drive when the files have been copied.
For more information on removing the USB flash drive, refer to the owner's manuals of your computer and USB flash
drive.
5. Turn off the power to the TF series.
At this time, be sure to disconnect all cables from the PRIMARY/SECONDARY connector of the NY64-D.
6. Connect the USB flash drive to the TF USB connector (right side), and then turn on the power to the TF
series.
An "Update firmware?" message will be displayed.
NOTE
- This display will not appear if the current version of the TF series and the version of the firmware update file are
the same.
- When only updating the NY64-D, this display will not appear, but the UPDATE window will appear after the splash
screen.

TF5/TF3/TF1/TF-RACK/NY64-D Firmware Update Guide 4
7. Touch the “Update” button to start loading the firmware.
CAUTION
：
DO NOT OPERATE ANY CONTROL OF THE CONSOLE (SWITCHES, KNOBS, FADERS, ETC.) WHILE UPDATING THE
FIRMWARE.
TF series firmware is transferred (lasting about two minutes).
After finishing the file transfer, the TF series reboots, and the splash screen is shown.
The UPDATE window appears.

TF5/TF3/TF1/TF-RACK/NY64-D Firmware Update Guide 5
NOTE
- When a NY64-D is installed to the expansion slot, the NY64-D firmware update file in the USB flash drive will
necessarily open the UPDATE window regardless the version of the firmware update file.
- When updating the TF series firmware from V1.xx to V2.50 or later, the NY64-D firmware update requires updating
of the TF series firmware. (The NY64-D firmware update will be disabled even if the NY64-D firmware update file
exists in the USB flash drive.) Finish updating the TF series firmware first, and then perform from Step 5 again.
- When the UPDATE window appears, the update operation has already started, the operation has reached 100%
completion (Done), or a message prompting to reboot the TF series appears; these are all normal.
- During the update process, the display or the LED indicator may turn off. This is normal.
8. If you need to update the NY64-D, touch the “Update” button.
While this message is shown, do not operate any of the console controls.
NOTICE:
- Updating the NY64-D firmware via the TF series requires about 15 minutes.If you are in a hurry, we
recommend updating via a computer (Dante Firmware Update Manager; page 7)
- If the NY64-D firmware update has failed, refer to “If the NY64-D update failed” (page 9).
- When the Dante Device Lock function is enabled for the NY64-D, the Update button will be disabled. Make
sure to disable the Dante Device Lock via the Dante Controller in order to update.
9. When a message indicating completion of the update appears, remove the USB flash drive.
10. Reboot the TF series.

TF5/TF3/TF1/TF-RACK/NY64-D Firmware Update Guide 6
11. Confirm the updated version from the SYSTEM SETUP -> ABOUT window.
The firmware update is now complete.
NOTE
Some firmware versions have new default Presets for Scene or Library. To load the new Presets, the “Initialize All
Memories” operation is required. Refer to the “Initialize All Memories” screen of the “MAINTENANCE” screen in the
TF-series Reference Manual.

TF5/TF3/TF1/TF-RACK/NY64-D Firmware Update Guide 7
■
Updating the NY64-D firmware by computer
Described below are the procedures to update the NY64-D firmware with a computer (Dante Firmware Update
Manager).
Preparing for the update
Make sure you have the following items before starting the update procedure.
●A computer meeting the system requirements of the Dante Firmware Update Manager
●An Ethernet cable (CAT5e or higher recommended; straight-through or crossover.)
●Dante Firmware Update Manager (application)
The Dante Firmware Update Manager installer and User Guide are included in the compressed folder with the
NY64-D firmware. You can download the latest version from the Yamaha Pro Audio Website. For system
requirements, and detailed instructions, refer to the Dante Firmware Update Manager User Guide
“AUD-MAN-Firmware_Update_Manager-vX.Xen.pdf” (vX.X: version of the user guide).”
http://www.yamahaproaudio.com/
Update procedure sequence
Make sure to perform the update in the following sequence. If you plan to update multiple NY64-D cards,
repeat the procedure described in “Update” for each unit in sequence.
1. Install the Dante Firmware Update Manager
2. Make TCP/IP settings on computer
3. Update the NY64-D firmware
1. Install the Dante Firmware Update Manager
Follow step 4 (“Installing the Dante Firmware Update Manager”) of the Dante Firmware Update Manager User
Guide to install the application to your computer.
2. Make TCP/IP settings on computer
Set the TCP/IP setting of your computer to “Obtain an IP address automatically (Windows)” or ”Use DHCP
server (Mac).”
3. Update the NY64-D firmware
Described below are the procedures for updating the NY64-D firmware.
NOTE
For detailed instructions on the Dante Firmware Update Manager, refer to the Dante Firmware Update Manager User
Guide.
3-1. Turn the power of the TF series with NY64-D to on.

TF5/TF3/TF1/TF-RACK/NY64-D Firmware Update Guide 8
3-2. Connect the Dante [PRIMARY] connector of the NY64-D card to the Ethernet connector on the
computer using an Ethernet cable.
Be sure to directly connect the computer and the NY64-D, and do not connect any other Dante device to
the computer.
3-3. Execute the Dante Firmware Update Manager, and update the NY64-D firmware.
Follow step 5 (“Using the Dante Firmware Update Manager”) of the Dante Firmware Update Manager
User Guide to update.
Use the firmware update file “FWUpdate_NY64-D_vxxxxx_swyyy.dnt” (xxxxx, yyy: firmware version)
NOTICE:
Be sure to ensure compatibility of the update files with NY64-D. If update files other than NY64-D are
applied, the device will become inoperable. In general, do not check the [Override Device Matching]
option. If this option is left unchecked, only devices that support the file can be selected, ensuring that
updating the device with invalid or wrong files is prevented.
NOTE
If the update is not completed after 5 minutes, or an update failure indication appears, click X at the
upper right corner of the Dante Firmware Update Manager to exit the program without turning the TF
series power off, and restart the procedure from the step 3-3. If the update still fails, follow the
instructions stated in “If the NY64-D update failed” (page 9) to perform the recovery operation.
3-4. Restart the TF series.
The firmware update is now complete.

TF5/TF3/TF1/TF-RACK/NY64-D Firmware Update Guide 9
■
If the NY64-D update failed
The NY64-D may become unusable due to data corruption if the Dante device is powered-off during a
firmware update. To recover from such a state, the NY64-D will enter "failsafe mode."
If the NY64-D could boot in the failsafe mode, you can recover it to send a recovery image from the Dante
Firmware Update Manager.
If the NY64-D could not boot in the failsafe mode, you will need to recover the system by a different
procedure; see “Updating the NY64-D firmware by computer” via the Dante Firmware Update Manager.
Confirming the NY64-D firmware corruption
If the NY64-D firmware is corrupt, the Dante version is displayed as “0.0.0.0 0.0.0.0 0.0.0” in the ABOUT
screen of the TF series.
When the NY64-D is booted in the failsafe mode, the NY64-D in failsafe mode is shown as “AUD-xxxxxx” with
red text in the network grid view of Dante Controller. In this case, follow the procedure “Recovery of the
NY64-D (in the failsafe mode)” (page 10) to recover the system.

TF5/TF3/TF1/TF-RACK/NY64-D Firmware Update Guide 10
When the NY64-D could not be booted in the failsafe mode, it is shown as a fixed Device Name like
“Y000-Yamaha-NY64-D-xxxxxx” with red text in the network grid view of Dante Controller. In this case, follow
the procedure “Recovery of the NY64-D (without the failsafe mode)” (page 11) to recover the system.
■
Recovery of the NY64-D (in the failsafe mode)
Described below are the procedures to recover the NY64-D in the failsafe mode.
1. Turn off the power to the TF series console to which the NY64-D is installed.
2. Separate the NY64-D from the Dante network.
3. Connect the Dante [PRIMARY] connector of the NY64-D to the Ethernet connector on the computer using
an Ethernet cable.
In some cases, an error may occur during recovery if you are going through a network switch. Connect the
computer with the NY64-D in a one-to-one connection.
4. Turn on the power to the TF series console having the NY64-D.
5. Disable all but one of the network interfaces on your computer.
You should also disable the wireless LAN.
6. Execute the Dante Firmware Update Manager to use failsafe recovery.
For more detailed instructions, refer to step 9 (“Using the failsafe recovery”) of the Dante Firmware Update
Manager User Guide.
7. Exit the Dante Firmware Update Manager, and wait for two minutes before turning off the power to the
TF series with NY64-D.
After recovery, restarting the NY64-D takes a while. If you power-off the TF series before restart is completed,
the data of the NY64-D will be corrupted, and you will have to perform the recovery once again. Start the

TF5/TF3/TF1/TF-RACK/NY64-D Firmware Update Guide 11
Dante Controller, and if the device name is shown in black, it is safe to turn off the power.
8. Update the NY64-D firmware.
After recovery, the NY64-D firmware will need to be updated to the latest version. To do this, follow the
instructions on page 7.
The recovery is now complete.
■
Recovery of the NY64-D (without the failsafe mode)
Described below are the procedures to recover the NY64-D which could not be booted in the failsafe mode.
1. Turn off the power to the TF series console to which the NY64-D is installed.
2. Separate the NY64-D from the Dante network.
3. Connect the Dante [PRIMARY] connector of the NY64-D to the Ethernet connector on the computer using
an Ethernet cable.
In some cases, an error may occur during recovery if you are going through a network switch. Connect the
computer with the NY64-D in a one-to-one connection.
4. Turn on the power to the TF series console having the NY64-D.
5. Disable all but one of the network interfaces on your computer.
You should also disable the wireless LAN.
6. Execute the Dante Firmware Update Manager to use failsafe recovery.
In this recovery procedure, make sure that “Override Device Matching” is checked.
For more detailed instructions, refer to step 9 (“Using the failsafe recovery”) of the Dante Firmware Update
Manager User Guide.
The recovery is now complete.

TF5/TF3/TF1/TF-RACK/NY64-D Firmware Update Guide 12
Manual Development Department
© 2015 Yamaha Corporation
Published 1/2017 YJ-D0
