INTRODUCTION
Thank you for purchasing the Yamaha TP100/120SD Electric Drum Pad. The TP100/120SD
are designed as trigger pads for use in an electric drum system. The pads utilize a newly
structure to deliver subtle and rich performance with realistic feel and rebound, and
quiet operation. To get the most out of your TP100/120SD, please read this Owner's Manual
thoroughly. Also, after reading this manual, keep it in a safe place for future reference.
■Handling Precautions
•Do not disassemble or alter the product. Doing so may result in damage or deterioration to the product.
• Do not step on or place heavy objects on the product. It may result in damage.
•Do not use or keep the product in places with extremely high temperature (places in direct sunlight,
close to a heater, in a closed car, etc.) or damp (bathroom, outside on a rainy day, etc.). It may result in
deformation, discoloration, damage or deterioration.
•To clean the product, please wipe with a soft cloth or a damp cloth that been wrung out thoroughly, If
the product is soiled, use a neutral detergent on a cloth then wipe with a damp cloth that has been
wrung out thoroughly to remove any remaining detergent. Do not use benzine, thinner or alcohol as it
may result in discoloration or deformation. Also pay close attention so as not to let the water and
detergent come into contact with the cushions used in the product, it may result in deterioration.
•Make sure you hold onto the plug, not the cable, when connecting or disconnecting the cable. Also,
never place any heavy or sharp objects on the cable. Applying excessive force to the cable may result
in damage to the cable such as cutting the wires, etc.
■Output Level Adjustment
The trigger level output on the TP100/120SD is adjustable. Rotate the knob to the right (look-
ing at the knob from above) increases trigger output level while rotating to the left decreases
output level. The pad's output level should be adjusted in regard to how hard you hit the pad
when playing, to adjust the pad's dynamic range, or to better match the pad with the type of
DTX Series Drum Trigger Module (DTXPRESS/DTX/DTXTREME) you are using.
Level Adjustment Knob
Adjusting the Voice Volume
To change the volume of the voice assigned to the TP100/120SD pad, use the
[VOICE] edit mode in the DTX Series Drum Trigger Module. Please refer to the
Owner's Manual that came with your module for more information.
■Replacing Worn Pads
•After extended use, parts such as the pad rubber, etc., that make up the playing sur-
face will wear out, or their quality will deteriorate (rubber rim cover, body, switch, jacks,
etc.). The life of these parts varies according to the circumstances under which the
TP100/120SD is used.
•Please ask the dealer from whom you purchased the device about replacing worm
parts.
NOTE: When using the TP100/120SD with a DTX Series Drum Trigger Module (DTXPRESS/DTX/
DTXTREME), enter the trigger module's trigger edit mode and set the [PAD GAIN] param-
eter so that a value of between 90-95% is registered on the display when the pad is struck
ff (fortissimo). Please refer to the Owner's Manual that came with your module for more
information.
If the output level is too high, the pad's dynamic range (the difference between loud and
soft tone) will be reduced and trouble such as double triggers (multiple triggers being pro-
duced by a single stroke) may occur.
Do not put excessive pres-
sure on the level adjustment
knob, it may result in damage.
TP100 TP120SD
■Inside This Package
Before setup, please make sure that all of the items listed below are present and ac-
counted for. If anything is missing, please contact the dealer from whom you purchased
the unit.
* To customers who purchased a pads set (DT2K10SP1,2, etc.), please refer to the
attached “Accessories List”sheet included with each pads set when confirming
package contents.
• Owner’s Manual (this sheet) x1
◆TP100
• TP100 (Main Unit, Clamp Bolt) x1
◆TP120SD
• TP120SD (Main Unit) x1
•Stereo Phone Cable
(Parallel Type*) x1
The connector has two
black rings. (The monaural
type connector has one
black ring.)
*The parallel type stereo phone
cable is designed with two lines
running in parallel carrying left and
right signals on their own indepen-
dently shielded lines.
Shield
LR
Parallel type
(2 independently shielded lines)

■Part Names
◆ TP100
◆ TP120SD
■Setting Up
[TP100]
After setting up your rack system (Yamaha RS150,
etc.) or a standard tom stand (Yamaha WS series,
etc.), attach the TP100/120SD as shown in the dia-
gram below.Insert the tom holder (hexagonal bar)
on your rack or tom stand into the pad, and firmly
tighten the clamp bolt to secure.
[TP120SD]
Before setup, please prepare a snare stand (Yamaha
SS652, etc.), and set the TP120SD onto the stand
as you would an acoustic snare drum.
Output Jack Clamp Bolt
A Rim
B Rim
Pad
Pad Controller Knob Level Adjustment Knob
*Aand B rim switches are
embedded in the rim sec-
tions between indentations.
Output Jack
B Rim
A Rim Pad
Pad Controller Knob Level Adjustment Knob
Make sure that the pad is securely attached to the
rack or stand. If the clamp bolt, etc., is not tightened
securely, the pad can slip or drop off causing injury.
Also, if the rack or stand is placed on an unstable sur-
face, etc., the rack or stand can fall over resulting in
injury.
●： A single voice can be assigned to, and produced
by the pad section.
○： Independent voices can be assigned to and pro-
duced by the pad and rim sections (A rim and B
rim sections share the same voice) (Dual Zone).
◎： Independent voices can be assigned to and pro-
duced by the pad section, A rim section, and B rim
section (3 Zone).
△： Independent voices can be assigned to and pro-
duced by the pad and B rim sections. (A rim sec-
tion is inactive) (Dual Zone)
* ： Pad control functions described below are active
with INPUTs 1-5 on the DTXTREME s.
Module Input Number TP100/120SD
DTXTREME s1-5 ◎*
6-8 ◎
9/10-15/16 ●
DTXPRESS 1△
DTXPRESS 2,6,7 ◎
3-5,8 ○
9/10 ●
DTXTREME 1-5 △
6-8 ○
9/10-15/16 ●
DTXPRESS 1 △
2-8 ○
9/10 ●
DTX 1-8 ○
9/10,11/12 ●
● Pad Control Functions
The pad controller on the TP100/120S can be used with INPUTs 1-5 on the DTXTREME s.
The pad controller lets you adjust a variety of parameters (pitch control, snappy ON/OFF, etc.)
by rotating the pad controller knob. (Please refer to the Owner's Manual that came with your
DTXTREME s for more information.)
Output Jack
Insert
■Connections
Using the supplied stereo phone cable(Parallel Type), connect the pad's output jack to the
input jack (SNARE, TOM1, etc.) on the DTX Series Drum Trigger Module (DTXPRESS/DTX/
DTXTREME). Insert the L-shaped connector into the output jack on the TP100/120SD.
The manner in which the TP100/120SD will function corresponds to
the INPUT numbers on the DTX Series Drum Trigger Module shown
in the chart below.
コントローラーつまみ
Pad Controller Knob
*Always use the supplied stereo phone cable (parallel type) when connecting the TP100/120SD to the
module. Voices assigned to the rim switch or pad control functions can not be used when using a monaural
cable. Also, using any stereo phone cable other than the supplied parallel type cable may result in im-
proper function of the pad controller functions.
■Troubleshooting
If the following trouble occurs when the TP100/120SD is used, please check the follow-
ing points before asking your dealer for assistance.
●The rim section does not produce sound when struck.
What to checkProblem
Is the TP100/120SD connected to
the correct INPUT number on the
DTX Series Drum Trigger Module
using the supplied parallel type
stereo phone cable?
Too high of a the level adjustment setting causes the drum
module to produce multiple sounds because the large signal
produced by the high settings sustains for too long of a time.
Refer to the "Output Level Adjustment" section described
above to properly set the pad's output level.
Printed in Indonesia
WF75980
Also, please refer to the Owner's Manual that came with your DTX Series Drum Trigger Module
(DTXTREME/DTX/DTXPRESS) for more information regarding the problems described above and any
other problems that you may be experiencing.
If a solution can not be found to the problem after consulting the manuals, please contact the dealer from
whom you purchased the product.
■Specifications
* Improvements may result in a change in the specifications and/or design of the product without notice.
Dimensions
Weight
Sensor Type
Output Jack
297(W) x 313(D) x 74(H) 349(W) x 364(D) x 69(H)
(Control knob and clamp bolt not included.) (Control knob not included.)
2.2kg 2.5kg
Tr igger Sensor (piezo-electric) x1/rim switch (dual zone) x1
Standard Stereo Phone Jack
Clamp Bolt
Insert
Tom Holder
Snare Stand
TP100
TP120SD
Never hit the controller
knob or apply excess force
as it may result in damage
or malfunction.
TP100 TP120SD
●The pad control function does not work
What to check
Problem
Is the TP100/120SD connected to
the proper INPUT number on the
module (DTXTREME s) using
the supplied parallel type stereo
phone cable?
The Pad control function can only be used with INPUTs 1-5
on a DTXTREME s. (Refer to the [Connections] section
above.)
The Pad control function is not available when a monaural
phone cable is used.
*Using any stereo phone cable other than the supplied parallel
type stereo phone cable can result in improper function of the
pad control function.
Are module (DTXTREME s) set-
tings correct?
Refer to the Owner's Manual that came with your DTXTREME s,
and make sure settings are correct.
What to checkProblem
Is the level adjustment on the
TP100/120SD set too high?
Refer to the [Connections] section described above and make
sure the TP100/120SD is connected to the proper INPUT num-
ber.
When a monaural phone cable is used, the voice assigned to
the rim section is not produced.
●Hitting the pad once produces multiple sounds (Double trigger)
●No Sound, Volume is Low
What to check
Problem
Is the Level Adjustment knob on
the TP100/120SD set too low?
Is the TP100/120SD properly con-
nected to the DTX Series Drum
Trigger Module's input jack using
the supplied parallel type stereo
phone cable?
Is the module properly con-
nected to a pair of headphones
or an external audio device such
as an amplifier, speaker, etc.?
Are module settings correct?
If the Level Adjustment Screw is set too low, the single pro-
duced by the pad will be too low to produce sufficient volume
from the drum trigger module’s tone generator even though
the pad is struck.
Refer to the previous [Connections] section and make sure
that all connections are proper.
Check the connections between the external device and the
position of the power switch and volume level.
Check the volume setting of the voice assigned to the INPUT
number to which the TP100/120SD is connected (refer to the
previous "Adjusting the Voice Volume" section), or make sure
the headphones volume level is not set too low, etc.
● TP100 Tom pad (10 inch) with rod clamp ●TP120SD Snare Pad (12 inch)
SPECIAL MESSAGE SECTION
NOTICE: Service charges incurred due to a lack of knowledge relathing to how a function or effect works (when the unit is operating
as designed) are not covered by the manufacturer’s warranty, and are therefore the owners responsibility. Please study this manual
carefuly and consult your dealer before requesting service.
ENVIRONMENTAL ISSUES: Yamaha strives to produce products that are both user safe and environmentally friendly. We sincerely
believe that our products and the production methods used to produce them, meet these goals. In keeping with both the letter and the
spirit of the law, we want you to be aware of the following:
Warning: Do not attempt to disassemble.
Disposal Notice: Should this product become damaged beyond repair, or for some reason its useful life is considered to be at an end,
please observe all local, state, and federal regulations that relate to the disposal of products that contain lead, plastics, etc. If your
dealer is unable to assist you, please contact Yamaha directly.
NAME PLATE LOCATIOIN: The name plate is located on the bottom of the product. The model number, serial number are located on
this plate.
Yo u should record the model number, serial number, and the date of purchase in the spaces provided below and retain this manual as
a permanent record of your purchase.
Model : TP100 Serial No. Model : TP120SD Serial No.
Purchase Date
PLEASE KEEP THIS MANUAL
*If you are using the DTXTREME s, the module’s pad type setting
should be set to [TP-1/Snr] or [TP-1/Tom]. On other drum modules, the
setting should be set to tom pad. (Please refer to the Owner’s Manual
that came with your module for more information.)
