Yamaha RGX A2 User manual

SERVICE MANUAL
EG 011783 HAMAMATSU, JAPAN
Copyright (c) Yamaha Corporation. All rights reserved. PDF-K88 ’05.06
■CONTENTS
OVERALL ASSEMBLY ......................................................................2
ELECTRICAL PARTS ........................................................................4
CIRCUIT BOARD ..............................................................................4
CIRCUIT DIAGRAM ..........................................................................4
WIRING .............................................................................................5
SPECIFICATIONS .............................................................................5
WARNING: CHEMICAL CONTENT NOTICE!
The solder used in the production of this product contains LEAD. In addition,
other electrical/electronic and/or plastic (Where applicable) components
may also contain traces of chemicals found by the California Health and
Welfare Agency (and possibly other entities) to cause cancer and/or birth
defects or other reproductive harm.
DO NOT PLACE SOLDER, ELECTRICAL/ELECTRONIC OR PLASTIC
COMPONENTS IN YOUR MOUTH FOR ANY REASON WHAT SO EVER!
Avoid prolonged, unprotected contact between solder and your skin! When
soldering, do not inhale solder fumes or expose eyes to solder/flux vapor!
If you come in contact with solder or components located inside the
enclosure of this product, wash your hands before handling food.
ELECTRIC GUITAR
RGX A2

RGX A2
2
■OVERALL ASSEMBLY
Bridge Assembly Installation
Jack Installation
Flat Washer (QC887400)
A seal is attached
on the rear of the neck.
RGX A2
Tuning Machine Assembly
Volume/Pickup Switch Installation
E11
D01
E13
E03
E04 E02
E03
E04
E01
E12
E14
F18
F19
F20 F15
E11
F15
F10
E01 E02
E03
E01
E04
E03
E02
E04
E08
E15
A01
E16 E17
E18
D01
E06 E07
G01 G03 G04
G05 G07 G08 F06 F07
E24 E25
E19
E20 E21
F09
F11 F13
F01
F08 F10 F12
F15
F18 F19 F20
E19 F09
F11
E20
D01
E21
F13
F01
F08
F10
F12
E14
E13
E12
E11
E09
E10
E16E17
E18
A01d

RGX A2
3
REF NO.
PART NO.
DESCRIPTION REMARKS QTY RANK
OVERALL ASSEMBLY RGX-A2
*A01
AAX71450
Neck Assembly ACG
A01d
--
Seal (WF64920)
D01
--
Body
*E01
QC846100
Tuning Machine Assembly 4,5,6 string Satin Chrome 3
*E02
QC846200
Tuning Machine Assembly 1,2,3 string Satin Chrome 3
E03
--
Nut Satin Chrome with Tuning Machine Ass'y 6
E04
--
Washer Satin Chrome with Tuning Machine Ass'y 6
E06
QC683100
Rod Cover Black 03
E07
VE210700
Flat Head Wood Screw 2.4x16 MFC2BL Black 2 01
E08
QC692800
Nut 43mm UREA
E09
QC205200
Neck Joint Bush Black 4 04
E10
QC685200
Oval Head Wood Screw 4.5x40 MFC2BL Black 4 01
*E11
QC845000
Bridge Assembly
*E12
QC844200
Cap Screw 3x30 MFC2BL Black 3
*E13
QC844300
Spacer 3x6 3
E14
QC668600
Bushing Black 6 02
E15
--
Strings XL-120 1set (QC16510)
*E16
QC846300
Strap Button Satin Chrome 2
E17
QA132800
Oval Head Tapping Screw 3.5x25 MFCR33 Chrome 2 01
E18
VB793700
Spacer Felt Black 2 01
*E19
QC845900
Knob Assembly Aluminum 2
*E20
QC845400
Control Ring 2
*E21
QC845500
Ring 2
*E24
QC845600
Back Cover Black
E25
20454100
Oval Head Tapping Screw 2.4x16 MFC2BL Black 4 01
F01
--
Electrical Unit 1set (QC84580)
* F01a
QC884200
Circuit Board with LED
F01b
HS120071
Variable Resistor 15A 500K ohm VOLUME 03
* F01c
QC884300
Pickup Switch RSL25-1-4-3-15KC 4pole 3position Rotary Switch
F06
QC800100
Battery Box 05
F07
03706220
Round Head Wood Screw 2.1x10 MFC2BL Black 2
F08
--
Hexagonal Nut with Volume
F09
--
Hexagonal Nut with Pickup Switch
*F10
QC887400
Flat Washer
F11
--
Flat Washer with Pickup Switch
F12
ET800060
Toothed Lock Washer 2 01
F13
ET800150
Toothed Lock Washer 01
F14
03704270
Round Head Wood Screw 2.7x13 MFC2BL Black 2 01
F15
QA209900
Jack 07
F18
--
Hexagonal Nut with Jack
F19
--
Rubber Ring with Jack
F20
--
Toothed Lock Washer with Jack
*G01
QC844800
Pickup Assembly FRONT
G03
QC556200
Pan Head Tapping Screw 2.6x35 MFCR33 Chrome 2 01
G04
QC556400
Pickup Cushion 02
*G05
QC844800
Pickup Assembly REAR
G07
QC556200
Pan Head Tapping Screw 2.6x35 MFCR33 Chrome 2 01
G08
QC556400
Pickup Cushion 02
H01
QC354000
Accessory Unit G-1 1set 07
QC583200
Cord D 05
AA804050
Wrench #1.5 01
AA805430
Wrench #5 04
*
QC845000
Bridge Assembly
B01
--
Bridge Base Satin Chrome
B02
--
Bridge Saddle Satin Chrome 6
B03
--
Aluminum Pipe 3
B04
--
Cap Screw (Flat Head) 3x10 MFNI33 Nickel 3
B05
--
Cap Screw 2x10 MFC2BL Black 6
B06
--
Set Screw 3x6 MFC2BL Black 12
B07
--
Bridge Spring L=8 6
*: New Parts RANK: Japan only

RGX A2
4
■ELECTRICAL PARTS
■CIRCUIT BOARD
REF NO.
PART NO.
DESCRIPTION REMARKS QTY RANK
*
QC884200
Circuit Board (QC88470)
*
QC884200
Circuit Board (QC88470)
* LD01
QC884500
LED T670TGKT
* LD02
QC884600
LED T670TBKT
R01
RD357100
Carbon Resistor (Chip) 10K 1/16W J 01
R02
RD356270
Carbon Resistor (Chip) 2.7K 1/16W J 01
*: New Parts RANK: Japan only
EPA-QC88420
Unit: mm
24
Hole
36
Green Blue Black
■CIRCUIT DIAGRAM

RGX A2
5
■WIRING
■SPECIFICATIONS
●STANDARD SPECIFICATIONS
Scale Length..................................... 648 mm
Body-Neck Construction.................. Bolt On
Length............................................... 953.7 mm
Width................................................ 325.5 mm
Net Weight ....................................... 2.5 kg
●COLOR
Head
WH............................................... White
Neck
ACG............................................. Aircraft Gray
Body
WH/ACG ..................................... White/Aircraft Gray
●BODY
Material ............................................ Agathis/Falcata
Body Depth ...................................... 44.5 mm
●FINGERBOARD
Material ............................................ Rosewood
Fingerboard Width ........................... 0-F 43.0 mm, 12-F 52.4 mm
●NECK
Material ............................................ Maple
Neck Thickness ................................ 1-F 20.0 mm, 12-F 23.0 mm
●PARTS
Hardware .......................................... Satin Chrome Plated
Nut.................................................... Urea
Bridge............................................... Fixed type (Satin Chrome)
Strings............................................... D’addario (XL-120)
●CONTROLS
Volume ............................................. A 500 KΩx 1
Pickup Switch................................... 4pole 3position Rotary Switch
●PICKUPS
Front/Rear .........................................Humbucking
Magnet
Front/Rear ....................................Alnico
Electrical Unit
Battery Box
FRONT PICKUP REAR PICKUP
Screw the lug terminal in
cavity for the front pickup.
Screw the lug terminal in
cavity for the rear pickup.
to bridge ground
OUTPUT
JACK
Red Red
Red
Black
Black
Black
Green+Bare Wire
Green+Bare Wire
White
