Getting Started with a ’blank’ desk
To erase all memories in the desk, and return it to its factory settings, hold the SCENE MEMORY [STORE] switch
while turning on the power, and choose the INITIALIZE option. (You don’t need to do this if you have just unpacked the
product from its box for the first time)!
To start from blank settings without erasing the memories, just recall SCENE 00. To do this, use the SCENE MEMORY
Up-Arrow/Down-Arrow switches to select Scene ‘00’ and then press [RECALL].
All the faders will then move down and all the mixing functions set to their default status.
Understanding the Rear Panel and Top Connectors
All the analog input connectors are at the back of the top panel. The analog outputs and digital I/O are found on the rear
panel. They include:
Rear Panel
Other connectors on the rear panel are for various control and sync functions. For example, the WORD CLOCK con-
nectors are for synchronizing with other digital audio devices, the MIDI ports are for communicating with other musi-
cal instruments (such as keyboards).
Monitor Out with Jacks, for connecting to
powered monitor speakers (or an amp for
powering passive speakers)
4 ‘OMNI’ analog outputs
with Jacks
ADAT optical 8-channel Digital Input and Output
(for multi-track recorder or computer sound card, for example).
USB 2.0 port for multi-track live
recording with DAW software and
Yamaha Studio Manager software.
Main Stereo Output with XLRs 1 option slot for expansion
2-Track Digital Out and In
(for Mini-Disc/DAT, for example)

01V96i Quick Start Guide
4/32
Top Panel
INPUT A/B connectors accept mic/line inputs with XLR and balanced TRS
phone jack respectively. If you plug cables to INPUT A and INPUT B of the
same number, only the signal from INPUT B is effective.
Unbalanced insert jacks for the 12
mic/line inputs
4 Line inputs with
balanced jacks

01V96i Quick Start Guide
5/32
Understanding the Front Panel
All the controls are on the front panel, laid out in logical areas:
✽The SELECTED CHANNEL area is a fundamental concept to understand. It shows important functions for one
channel at a time. Only one channel can be selected at any time. To select a channel (and see its settings in the
SELECTED CHANNEL area), just press the [SEL] button. Then press the[ SEL] button for another channel when
you are ready to move on.
Analog input gain and pad (+48V switches are on the rear panel,
and switch on phantom power for 4 channels at a time)
Faders, On, Solo, Sel buttons
for the channels
User Defined Keys (for
short-cuts)
Display control and Scene
Memory buttons
Level pots, On, Solo, Sel for
the Stereo input channels
Aux select and Fader Layer buttons
Display Access switches
(choose what to view on the LCD)
Monitor and
Headphone controls
EQ and Pan controls for the
selected channels ✽

01V96i Quick Start Guide
6/32
Controlling Channel Faders
There are 4 layers of faders on the 01V96i:
When you change layers, all the channel settings are remembered. You just change which channels you are looking at!
Each fader controls a different input to the 01V96i. This assignment is not fixed: it can be changed in the PATCH
menu.
Here is the default patch:
☞channels 1-16 control the 16 analog inputs on the top on the console;
☞channels 17-24 control ADAT inputs 1-8;
☞channels 25-32 control inputs 1-8 from the Slot;
☞stereo channels 1-4 control inputs from internal Effects 1-4.
Master Layer: Aux 1-8, Bus 1-8
Remote Layer for controlling other
functions / devices
Input channels 17-32
Input channels 1-16

01V96i Quick Start Guide
7/32
Changing INPUT PATCH
To assign different inputs to the input channels, such as Slot 1 inputs 9-16, follow these steps:
1. Press the [PATCH] DISPLAY
ACCESS key.
2. If necessary, press it repeatedly
until the IN PATCH page is dis-
played.
3. Press the [SEL] button for the
required channel (or move the cur-
sor on the screen to the required
channel number).
4. Press [ENTER] (by the data wheel
on the right side of the console).
This will open the PATCH SELECT
window.
5. Select the type of input from the
first list (AD in / Slot in / FX out
and so on).
6. Press [ENTER] and choose the
required item from the next col-
umn (CH# or FX unit for example).
7. Press [ENTER] and click YES on
the screen to complete the Patch
change.
1
3
2
4
5
67
PATCH SELECT window

01V96i Quick Start Guide
8/32
FADER MODE
There are nine FADER MODE keys to the left of the LCD.
[HOME] is the normal mode for the faders. Pressing the [HOME] key will show various METER pages on the LCD, so
input, output, and Effect channels can be metered.
The AUX 1-8 keys select one of the Aux Send levels to be edited by the faders, instead of the normal channel level. You can
also see the Aux Send levels on the LCD, represented either by rotary pots or by bar-graphs. Pre and Post Fade settings can
only be edited on the LCD, by using the cursor keys and the [ENTER] key. By pressing the [ENTER] key while the cursor
is over an Aux Send rotary pot, the Aux Send will be switched Off/On.
Pressing [HOME] again will always return the faders to show the channel fader level.

01V96i Quick Start Guide
9/32
Using the SELECTED CHANNEL controls
When a channel is selected, some of its settings can be seen and controlled in the SELECTED CHANNEL area. The cur-
rently selected channel’s name and number is always shown in the top-left corner of the LCD screen.
✦EQUALIZER
When one of the EQ controls is moved, the LCD will show the EQ edit screen. There are 4 parametric bands. Select
which band to control with the HIGH, HIGH-MID, LOW-MID and LOW switches. Note that the LOW band can be a
Low Shelf or a HPF by changing the Q to the maximum or minimum position. In the same way, the HIGH band can
be a High Shelf or a LPF. There are 2 types of EQ (TYPE I or TYPE II), with slightly different sound characteristics.
The ATT function (seen in the LCD next to the EQ curve) is an attenuator, or digital trim, to adjust the channel level
pre-eq.
✦SELECTED CHANNEL area

01V96i Quick Start Guide
10/32
✦PAN
The PAN settings of the selected input channel can be edited here (output channels do not have Pan). 01V96i can also
perform surround panning. To select a SURROUND MODE, press the [PAN/ROUTING] Display Access Key so the
SURR MODE page is shown on the LCD. Then choose the SURROUND MODE: 3-1 or 5.1 or 6.1. This will then con-
vert some of the buses (1-8) into Surround Buses, and more displays will be added to the PAN menu for editing the
Surround Panning parameters.
In SURROUND MODE

01V96i Quick Start Guide
11/32
✦DYNAMICS
Each input channel has both a GATE and a COMP. The output channels only have a COMP. When the [DYNAMICS]
Display Access key is pressed, the LCD shows the relevant GATE or COMP screen. Gain Reduction meters and Key-In
source can also be viewed here. Usefully, the COMP can be positioned pre-eq, pre-fader (post-eq) or post-fader.
or

01V96i Quick Start Guide
12/32
✦ROUTING
In the [PAN/ROUTING] menu, the Selected Channel can be routed to any of the 8 Buses, to the Stereo Bus and to a
Direct Output. Move the cursor to the required bus number ([1-8], [S] for Stereo and [D] for Direct output) and press
[ENTER] to route the channel. The PAN indicators below each channel number in the LCD ensure that the PAN of
the channels will follow through to the Buses. This is particularly useful when using the Buses as stereo sub-groups
(like on a typical analog console).
Buses can be routed to Stereo (just like Sub-Groups on an analog console). To do this, press the [PAN/ROUTING]
button to view the BUS TO ST screen. Here Buses 1-8 can be routed, panned and mixed to the Stereo Bus. Use the cur-
sor keys, data wheel and [ENTER] switch to adjust the parameters.
Cursor
ENTER
Cursor Data wheel

01V96i Quick Start Guide
13/32
✦Ø / INSERT / DELAY
Press this DISPLAY ACCESS key to see Phase, Insert and delay information on the LCD. Phase reverse is only avail-
able for input channels. Insert and Delay are available for all channels except for the Stereo Inputs. Inserts need to be
patched, choosing which rear-panel connection (or internal Effect) to use for INSERT OUT and INSERT IN. The
INSERT POSITION can also be changed here.
Press the [Ø/INSERT/DELAY] key again to see Delay settings for each channel. The maximum possible delay time
varies with sample rate. At 44.1KHz, the maximum possible delay time is 984.1ms. Input channels have an FB.GAIN
(Feedback Gain) and MIX parameter to create a simple delay effect. The DELAY SCALE can be changed to see the
delay time in equivalent distance, number of samples, beats-per-minute or number of Frames (linked to MIDI
Machine Control Frame Rate).
After editing the delay time for one channel, double-click the [ENTER] key to copy this time to all the other channels.

01V96i Quick Start Guide
14/32
CHANNEL PAIR
If some Stereo input sources are used, such as a Synthesizer or CD player, it could be useful to pair the relevant input
channels together. There are two modes for pairing channels, as selected in the [PAIR/GROUP] menu.
Horizontal mode allows odd numbered channels to be paired with their adjacent even numbered channel.
Ver tical mode allows channels on the top fader layer (1-16) to be paired with the equivalent channel on the layer below
(17-32).
Output Buses and Auxes can also be paired, but only Horizontally.
When channels are paired, they share the same fader level, the same ON, EQ, Gate, Comp, Aux settings. Pan and Routing
parameters remain separate (though Pans can be linked separately).
To quickly pair channels without using the LCD screen, first 1hold down the
[SEL] button for the Left channel, then 2also hold down the [SEL] button for
the Right channel (or vice versa) for half a second. This only works in Hori-
zontal Pair Mode.
HORIZONTAL
VERTICAL
1 2

01V96i Quick Start Guide
15/32
FADER GROUPS
Fader Groups are useful for controlling many faders by just moving one fader. There are 8 Fader Groups available for
input channels and 4 Fader Groups for output channels.
Here is how to link faders together in a Group:
Now, when one fader in the Group is moved, all the others move by the same amount. If one fader in the Group needs to
be moved by itself, then hold that channel’s [SEL] button while pushing the fader (but not while the GROUP menu is dis-
played, or else the channel will be removed from the Group).
NOTE: Channels cannot be in more than one Fader Group at the same time.
1. Access the [PAIR/GROUP]
displays on the LCD.
2. Choose a Group (A to H for
inputs, Q to T for outputs)
using the Cursor keys (right of
the console, by the data wheel).
3. Press the [SEL] buttons for the
required channels to include
them in the Group.
3
12

01V96i Quick Start Guide
16/32
MUTE GROUPS
Mute Groups are useful for switching On/Off many channels by just pressing one switch. There are 8 Mute Groups avail-
able for input channels and 4 Mute Groups for output channels. To assign channels to a Mute Group, follow the same 3
steps as made for a Fader Group, but while viewing the MUTE GROUP screens (Groups I to P are for Inputs, Groups U to
X are for Outputs).
Once a Mute Group is made, when the [ON] button for one channel is pressed, all the other channels in the same Group
are also switched On/Off.
CHANNEL VIEW
The [VIEW] Display Access Menu provides some useful displays, showing all the important parameters for the selected
channel. The PARAMETER page shows EQ, Comp, Gate, Insert, Delay, Pair information, while the FADER page shows
Pan, Aux, Bus Routing, Group status. There is also a LIBRARY page where channel data can be stored and recalled.

01V96i Quick Start Guide
17/32
EFFECTS
There are 4 Multi-Effect Units inside 01V96i. They can be viewed on the LCD by pressing the [EFFECT] Display Access
key, and then pressing one of the buttons [F1]-[F4] below the LCD.
✦EDITING AN EFFECT
The Effect parameters can be edited using the data wheel and cursor keys to the right of the console.
To change the type of effect (from Reverb to Rev-X for example), follow the LIBRARY link shown on the left side of
the LCD to see the FX LIBRARY. Then scroll through the list with the data wheel, and press [ENTER] with the cursor
over the RECALL button on the left of the screen.

01V96i Quick Start Guide
18/32
✦USING AN EFFECT
Before an effect can be used properly, it needs to be
patched. The default patch (factory setting) has Aux 1-4
patched to the inputs of FX1-4 respectively. The stereo out-
puts of FX1-4 are patched to stereo input channels 1-4
respectively. This is convenient, but can be changed if nec-
essary. For example, an effect could be inserted in just one
channel using the INSERT OUT and IN patch. To change
the FX patching, go to the EFFECT page in the [PATCH]
display menu.
✦ROUTING AUDIO THROUGH AN EFFECT
1. First, audio needs to be routed into the effect. If the default patch is used, first turn up Aux 1 send level for the
required channel: Select Aux1 fader mode, and push up the fader to the required level.
2. Check that the Aux 1 Master fader is up to 0dB (that is its default position): select Master Layer and adjust the
Aux1 fader position if necessary.
3. Already audio should be seen on the level meters of Effect 1. You can see the meters on the top-right corner of
the FX EDIT screen.
4. Then turn up ST IN 1 to start hearing the effect’s output in the Stereo bus: select the top layer for the ST IN
channels, and turn up ST IN1 encoder. The level can be viewed in the top-right corner of the LCD.
12
3
4

01V96i Quick Start Guide
19/32
SCENE MEMORY
There are 99 SCENE MEMORIES available in 01V96i. Each Scene stores all the mixing
parameters, including all input channel, output channel and Effects parameter data.
The SCENE MEMORY list can be seen by pressing the [SCENE] Display Access key.
✦RECALL SAFE
In this screen, choose which parameters will not be changed
when recalling a Scene. When the Global Recall Safe box is
checked (at the top of the screen), the chosen parameters will
be safe in all Scenes. Otherwise, these settings will only apply
to the current Scene (once it is stored).
✦SCENE FADE
Normally when a Scene is recalled, the Faders move instantly
to their stored position. Using the Fade Time function, the
faders can be programmed to move slowly, taking up to 30
seconds to complete their movement. Checking the Global
Fade Time box will give the same Fade Time to every Scene.
After setting the Fade Time for one channel, double-click the
[ENTER] button to copy the time to all Input or Output
Channels.
When a SCENE is stored, a
name can be entered.
The PATCH LINK feature
can be useful if different
Scenes need different Patch
settings. Patch information is
not stored in the scenes, but is
stored in the INPUT PATCH
and OUTPUT PATCH librar-
ies (accessed from the
[PATCH] Display Access
key). Then the Patch libraries
can be linked to the Scenes so
they are recalled at the same
time as the scene.
If a SCENE is PROTECTED,
it cannot be overwritten
when [STORE] is pressed.
This avoids erasing some-
thing by mistake.

01V96i Quick Start Guide
20/32
✦SCENE COPY / PASTE
If some settings need to be copied from one Scene to some others, the PATSE SRC and PASTE DST LCD screens can
be used.
In the PASTE SRC screen, choose which parameters of which
channels should be copied.
In the PASTE DST screen, choose which Scene Memories
should be updated. The maximum number is 10 Scenes for
each operation.
To move a Scene to a different position in the Library, use the
SORT screen in the [SCENE] menu:
