E-1
NS-125F
SPEAKER SYSTEM
Thank you for choosing a Yamaha speaker system.
Caution
■ Read the following before using these speakers:
• To assure the finest performance, please read
this manual carefully. Keep it in a safe place for
future reference.
• Install the speakers in a cool, dry, clean place
away from windows, heat sources, sources of
excessive vibration, dust, moisture and cold.
Avoid sources of humming (transformers,
motors). To prevent fire or electric shock, do
not expose the speakers to dripping or
splashing.
• To prevent the enclosure from warping or
discoloring, do not place the speakers where
they will be exposed to direct sunlight or
excessive humidity.
• Do not place the following objects on top of the
speakers:
1. Glass, china, etc.
If glass etc. falls by vibrations and breaks, it
may cause personal injury.
2. A burning candle etc.
If the candle falls by vibrations, it may
cause fire and personal injury.
3. A vessel with water in it
If the vessel falls by vibrations and water
spills, it may cause damage to the unit, and/
or you may get an electric shock.
• Do not place the speakers where foreign
objects such as water drips might fall. It might
cause a fire, damage to this unit, and/or
personal injury.
• Do not place the speakers where they are liable
to be knocked over or struck by falling objects.
Stable placement will also ensure better sound
performance.
• Secure placement or installation is the owner’s
responsibility. Yamaha shall not be liable for
any accident caused by improper placement or
installation of speakers.
• Any time you note distortion, reduce the
volume of your amplifier immediately. Make
sure the input power does not exceed the
specified maximum input power, otherwise the
speakers will be damaged.
• Do not attempt to clean the speakers with
chemical solvents as this might damage the
finish. Use a clean, dry cloth.
• Do not attempt to modify or fix the speakers.
Contact qualified Yamaha service personnel
when any service is needed. The cabinet
should never be opened for any reasons.
Note:
This speaker is magnetically shielded, but placing
them too close to a TV may impair the TV picture. If
this happens, move the speaker away from the TV.
Owner’s Manual
URG
0101NS-125F_en.fm Page 1 Thursday, September 2, 2004 5:25 PM

E-2
Precautions When
Positioning the Speakers
The speaker is constructed with the majority of
the weight located in its upper portion, and is thus
susceptible to falling over if proper care is not
taken to insure its stability. If the speaker falls
over, it may damage the speaker or be the cause of
injury (or even death) to persons and/or damage to
personal property.
■ For safe and proper use of the
speaker:
• Position the speaker in a location that is solid,
level, smooth, and low (with respect to the
floor).
• Do not push or apply pressure to the side of the
speaker when moving, or lean objects against
the side of the speaker.
• Do not sit on or set objects on top of the
speaker.
Vibrations or jolts associated with earthquakes
and other phenomena or activities may cause the
speaker to fall over. For safety reasons, using
commercially available products that increase
stability in the speaker is recommended (metal
fittings or chains, etc.).
Supplied Accessory
• Speaker cable (4 m)
Placing the Speakers
Place the speakers on a sturdy, vibration-free
surface.
■ Using as Normal Stereo Speakers
To get the best stereo performance, angle the
speakers inward so as to create a triangle, with the
listener at the apex.
■ Using as Front Speakers in a
Surround Sound System
Position the speakers both side of your TV. The
positioning of these speakers is important because
they provide a solid anchor for the sound image.
They should be positioned facing the listener at
about ear level, and equidistant from the TV.
✕ 1
Subwoofer
Surround L
Center
Surround R
NS-125F
0101NS-125F_en.fm Page 2 Thursday, September 2, 2004 5:25 PM

E-3
English
Connecting Your
Speakers
Always turn off your amplifier or receiver
before making any connections.
■ Preparing Your Speaker Cables
Carefully remove 10 mm (3/8 ”) of insulation
from both ends of your speaker cables and twist
the bare wires tightly, as shown.
■ Hookup
■ Using a Banana Plug
1. Remove the speaker terminal cover by
gently pulling it toward you.
2. Tighten the terminal knob.
3. Simply insert the banana plug into the
terminal.
Good No Good
10 mm
(3/8 ”)
SPEAKERS
A
B
LR
+
+– –
+
–
Loosen
Tighten
Amplifier or
receiver
Notes:
• Make sure that the bare wires are not touching each
other as this could damage the speaker and
amplifier.
• Connect one speaker to the left terminals of your
amplifier, and another speaker to the right
terminals, making sure not to reverse the polarity
(+, –). If one speaker is connected with reversed
polarity, the sound will be unnatural and lack bass.
1
3
2
Banana Plug
0101NS-125F_en.fm Page 3 Thursday, September 2, 2004 5:25 PM

Removing the front cover
The front cover, which is attached to each speaker
at six points, can be removed if desired. To
remove a cover, using both hands, gently pull the
top of the cover away from the speaker. When the
cover comes away, gently pull the bottom of the
cover away from the speaker. To reattach the
cover, line up the six holes on the cover with the
six pegs on the speaker, and gently push the cover
onto the speaker.
Specifications
Type.................2-way bass-reflex speaker system
magnetic shielding type
Drivers......2.2 cm (7/8 ”) balanced dome tweeter
8 cm (3.1 ”) cone woofer x2
Impedance ...................................................... 6 Ω
Frequency response.......................60 Hz–35 kHz
Nominal Input power ...................................40 W
Maximum input power...............................120 W
Sensitivity................................... 86 dB/2.83 V/m
Crossover frequency....................................6 kHz
Dimensions (with the stand)
(W ✕ H ✕ D)
.....236 (9.3 ”) ✕1050 (41.3 ”) ✕236 (9.3 ”) mm
Weight ........................................7.2 kg (15.9 lbs)
* Specifications are subject to change without
notice due to product improvements.
Note:
When removing the cover, be careful that you don’t
touch the drive units, and don’t exert excessive force
with any tools.
