YARDART St. Aubin FT-218 User manual

Revised June 25, 2012
COMPONENTS AND PARTS LIST
FT-218 St. Aubin Wall Fountain
(2 pieces)
NOTE: Component drawings are not to scale
FT-165B
9”L x 5.5”W x 5.5”H
6 lbs
FT-218A
40”L x 22”W x 41”H
737 lbs
Pump Kit Parts List
PK300 (1)
#10 compression stopper (1)
Approx. 10” length of 5/8” Black non-kink tubing (1)
4mm Allen wrench (1)
Hose clamps (3) Note – Hose clamps can be used as
flow restrictor
Tools you will need
Level
4mm Allen wrench (included)
This fountain uses cover
FTNCOV-MED
Fountain holds approximately 25
gallons of water
uniquegardendecor.com
[phone]

Revised June 25, 2012
ASSEMBLY INSTRUCTIONS
1. Make sure you are assembling your fountain on a level surface that is capable of holding a minimum of 950
pounds within a 6 square foot area.
2. Place the basin (FT-218A) into position ensuring that it is level.
3. Feed the pump cord through the hole in the basin leaving enough cord length inside basin to work with the
pump.
4. See enclosed stopper assembly instructions and complete before continuing.
5. Place a hose clamp over one end of the 5/8” non kink tubing.
6. insert that end of the 5/8” non kink tubing onto the pump water outlet
7. Place another hose clamp onto the other end of the 5/8” non kink tubing.
a. Note – the third hose clamp may be placed on the tubing prior to installation as a flow restrictor if
necessary
8. Place the other end of the 5/8” non kink tubing onto the copper pipe extending out from the basin.
9. Tighten the hose clamps on the ends of the 5/8” non kink tubing.
10. Place the pump cover (FT-165B) over the pump.
11. Fill basin with approximately 25 gallons of water.
a. Note – do not allow pump to run dry as it will cause damage to the pump.
WINTER CARE AND GENERAL FOUNTAIN INSTRUCTIONS
-WINTER CARE-
Fountain bowls/tops and other fountain components, which collect water, should not be left outside in the winter since
any component, which fills with water and freezes may crack. Likewise components such as pedestals, which remain
in a basin, filled with water, which then freezes, may also crack or crumble. Ideally, therefore, a fountain should always
be stored indoors or in a dry protected place such as a covered porch away from the elements. However, if a fountain
must be left outside:
(1) Remove pump, rubber stoppers, drainpipes, finials, and other small components for storage indoors. Note
that stoppers or drainpipes are removed to allow drainage in the event water accumulates in any basin. Compression
stoppers may be left on the pump cord for easier assembly next season.
(2) Raise fountain base from ground with wood strips so that base will not freeze to the ground surface.
(3) Cover or wrap the fountain with burlap or other absorbent material (old blanket or towel) and then cover
securely with plastic, making sure that water will not accumulate in the basin or other fountain component and freeze;
(4) Check fountain periodically to insure that plastic is secure and water is not accumulating in any fountain
component.
-GENERAL FOUNTAIN TIPS -
Install fountains on a level surface. You will need a properly grounded 110-volt (AC only) GFCI protected receptacle
near the fountain for your pump. All pumps are submersible and must be completely underwater to function properly.
Test all pumps and adjust to full output prior to assembly. It is not recommended that fountains be placed directly on
grass or dirt. Position the channel opening at the base of each fountain toward the electrical outlet to be used since the
pump cord will be threaded through this opening
FT-218 St. Aubin Wall Fountain
(2 pieces)
