YARDART Williamsburg FT-133 User manual

F
T
-
133
Williamsburg Pineapple
Fountain
Two people are recommended for the installation ofthisfountain!
R
evised
July 21, 2017
PumpKitParts List
PK140 pump (1)
#7 stopper(1)
Approx.6”length of1/2”BlackNon-kinktubing (1)**
Approx.2”length of5/8”clearvinyltubing (1)**
Wedges(2)
Hose clamps(5)
*Hoseclamps maybe used asflow restrictors
**Black non-kink tubing and clear vinyltubing havebeen preassembled
-WINTERCARE-
Fountain bowls/tops and other fountain components, which collect water, should not be left outside in the winter since any component,
which fills with water and freezes may crack. Likewise, components such as pedestals, which remain in a basin, filled with water,
which then freezes, may also crack or crumble. Ideally, therefore, a fountain should always be stored indoors or in a dry protected
place such as a covered porch away from the elements. However, if a fountain must be left outside:
(1) Remove pump, rubber stoppers, drainpipes, finials, and other small components for storage indoors. Note that stoppers or
drainpipes are removed to allow drainage in the event water accumulates in any basin.
(2) Raise fountain base from ground with wood strips so that base will not freeze to the ground surface.
(3) Cover or wrap the fountain with burlap or other absorbent material (old blanket or towel) and then cover securely with
plastic, making sure that water will not accumulate in the basin or other fountain component and freeze;
(4) Check fountain periodically to insure that plastic is secure and water is not accumulating in any fountain component.
-GENERALFOUNTAINTIPS-
Install fountainsonalevel surface. You will need a properly grounded 110-volt (AC only) GFCI protected receptacle near the
fountain for your pump. All pumps are submersible and must be completely underwater to function properly. Test all pumps and
adjust to full output prior to assembly. It is not recommended that fountains be placed directly on grass or dirt. Position the channel
opening at the base of each fountain toward the electrical outlet to be used since the pump
cord will be threaded through this opening.
All of ourcaststone is proudly
FOUNTAININFORMATION:
Thisfountain holdsapproximately5gallonsof water.
Thisfountain usesasmallfountain cover.
(FTNCOV-SM)
Compatible with#7 Refill Device
(Aspecialstopper isrequiredtousethe refill kit for
thisfountain.)
TOOLSREQUIRED:
Bubble Level
PUMPINFORMATION:
OEMPF140 - 140GPH Pump
6FTcord length

F
T
-
133
Williamsburg Pineapple
Fountain
Two people are recommended for the installation ofthisfountain!
R
evised
July 21, 2017
Assemble your fountain on a level surface capable of holding a minimum of 315 pounds with an approximate 1 square foot footprint.
FT-132G (135 lbs)
12.75”W x 25.75”H
FT-132F (111 lbs)
30”W x 8.5”H
FT-133B (8 lbs)
9”W x 5.75”H
FT-133A (17 lbs)
7”W x 9.75”H
FT-133C (1 lb)
5”L x 1.25”W x 4”H
1. Place the base (FT-132G) into position where the fountain will be installed, ensuring
that it is level.
2. Center the large bowl (FT-132F) on the base (FT-132G)
3. Assemble the pump kit
a. Using a hose clamp, attach the 12” piece of 1/2” non-kink tubing to the
pump outlet.
b. Place a hose clamp over the 5/8” clear end of the tubing.
c. Place the stopper around the pump cord approximately 8” from the pump.
4. Feed the pump cord through the hole in the large bowl (FT-132F) and through the
base (FT-132G).
5. FIRMLY press the stopper into the hole evenly.
a. Note: Using the handle of a screwdriver or hammer works best to press the
stopper in place.
6. Place the pump cover (FT-133B) over the pump and in the center of the large bowl
(FT-132F).
7. Using the hose clamp, connect the 5/8” clear tubing to the copper pipe protruding
from the bottom of the finial (FT-133A).
8. Center the finial (FT-133A) on the pump cover (FT-133B).
9. Fit the pump cover door (FT-133C) into the pump cover (FT-133B).
10. Fill the fountain with water.
