YARDMAX YUT032 User manual

Save This Manual for Future Reference
Log lift table attachment
Operator’s Manual
FOR YOUR SAFETY
READ AND UNDERSTAND THE ENTIRE MANUAL BEFORE OPERATING MACHINE
Tame the Great Outdoors®
Model # YUT032 YUT040
Applicable
models YU3266 YU3666 YU4066
Length 29.5"
Width 19.9"
Weight 75.0 lbs

Introduction 1
Symbols 2
Contents Supplied 3
Assembly 4
Operation 9
Parts Diagram 10
Parts List 10
TABLE OF CONTENTS
INTRODUCTION
The log lift table attachment can be mounted on the log
splitter beam. Easily lift the log from the ground to a
position ush with the beam.
Carefully read through this entire operator's manual
before using your new unit. Pay attention to all
cautions and warnings.
DISCLAIMER
YARDMAX reserves the right to discontinue, change,
and improve its products at any time without notice
or obligation to the purchaser. The descriptions and
specications contained in this manual were in effect at
printing. Equipment described within this manual may be
optional. Some illustrations may not be applicable to your
unit.
CALIFORNIA PROPOSITION 65 WARNING:
CANCER AND REPRODUCTIVE HARM.
- WWW.P65WARNINGS.CA.GOV.
ENVIRONMENTAL
Recycle unwanted materials instead of disposing of
them as waste. All tools, hoses, and packaging should
be resorted, taken to the local recycling center and
disposed of in an environmentally safe way.
SUPPORT
Have questions about your YARDMAX equipment?
Call us at 847-327-0566 or 844-YARDMAX, email
us at [email protected], or contact us via your
favorite social media site.
1
|
Introduction

SYMBOLS
When the wedge is extended and not fully return back, do
not pull the control lever outwards, otherwise the log lift
table attachment may suddenly drop down, risks of falling
the log, damage and injury.
Wrong direction of the
log may cause roll and
fall when rise.
Vertical operating
position is prohibited
when the log lift table
attachment is attached.
Do not sit on the log lift
table.
Read and follow the lift
table assembly steps and
operating instructions in
owner's manual.
Always keep bystanders away at least 10 feet (3m) from this
machine. Only one person should operate the log splitter
and load the logs.
When the wedge or log lift table is moving, anybody
including operator is prohibited to stand in the restricted
zone.
Restricted Zone
Operator Zone
2
Log lift table attachment
»
Operator’s Manual
Symbols
|

1. Log lift table attachment-main table
2. Log lift table attachment-side table
3. Support Leg (left)
4. Support Leg (right)
5. Swing Arm
6. Slide-rail
7. Ejector Rod
8. Cable Fixing Plate
9. Log lift table handle
10. Rotating Shaft
11. Bending Plate
12. Connecting Plate
13. Short Bushing
14. Long Bushing
CONTENTS SUPPLIED
Your YARDMAX log lift table attachment contains the following:
Heavy lifting required. Some of the components in these assembly instructions are heavy and can't be lifted by one person
safely. Please plan to assemble this product when another person can be available to help.
M12 X 65 X 2 1
M6 X 20 X 2 2
M8 X 16 X 2 3
M10 X 20 X 4 4
M10 X 60 X 3
5
9.3 X 70 X 2
M8 X 20 X 1 6
25 X 20 X 8 X 2
7
φ 20 X 2
5 X 35 X 2
Handware Kit
1
2
4
3
5
11
6
7
12
14
10
13
9
8
15
15. Hardware Kit, Including:
3
|
Contents Supplied

ASSEMBLY
To assemble your log lift table attachment follow the below instructions.
Preparation
1. Remove the right log cradle before assembling the log lift table
attachment. ( See Figure 1a)
Figure 1a
M10x25(x4)
Log Cradle (Right)
13 mm
10 mm
16 mm
19 mm
2. Start the engine and operate the control handle to make the
wedge move forward 8''. (See Figure 1b)
3. Switchoff the engine. Makesure the wedgeisno longer moving.
Figure 1b
Split Control Handle
Wedge
1. Remove the two sets of hexagon recessed head screw M12x55
that x the guide slide plate with the wedge. (See Figure 2a)
2. Align the holes on the U-shaped plate at the front end of the
ejector rod with the holes on the wedge plate and guide slide
plate, then fasten them using M12X65 bolts and nuts. (See
Figure 2b)
M12 X 65 X 2 1
Figure 2a
Figure 2b
M12x65 (x2)
M12x55 (x2)
Ejector Rod
M12x65 (x2)
M12x55 (x2)
Ejector Rod
16 mm
13 mm
10 mm
18 mm
19 mm
24 mm
32 mm
13 mm
10 mm
16 mm
19 mm
13 mm
10 mm
16 mm
19 mm
6 mm
8 mm
5 mm
10 mm
Ejector Rod Assembly
4
Log lift table attachment
»
Operator’s Manual
Assembly
|

1. Install the cable xing plate, paying attention to keeping the
xing plate hole in line with the center of the upper spring pin.
(See Figure 3a)
M6 X 20 X 2 2
Figure 3a
Cable Fixing Plate
M6x20 (x2)
13 mm
10 mm
16 mm
19 mm
Cable Fixing Plate and Cable Assembly
2. Screw the straight end of the cable into the spring pin hole.
(See Figure 3b, illustration 1). Pass the cable between the
lower two adjusting nuts through the middle hole of the cable
xing plate. (See Figure 3b, illustration 2) By adjusting the
three adjusting nuts, make sure the cable between the upper
spring pin and the lower cable xing plate is just straightened.
(See Figure 3b, illustration 3)
Figure 3b
Cable
3
Adjusting Nuts M6 (x3)
1
2
Cable
16 mm
13 mm
10 mm
18 mm
19 mm
24 mm
32 mm
8 mm
1. Disassemble the original long control lever (See Figure 4,
illustration 1), assemble the shorter log lift table control
lever instead with the same hardware parts (See Figure 4,
illustration 2)
Figure 4
Handle and Cable Assembly
1
2
Log lift table handle ( Shorter)
Original Control Lever ( longer)
5
|
Assembly

1. Use a plier to pull down the spring pin and insert the slide-
rail through the xed guide rail until the two bolt holes on the
slide-rail are fully exposed. (See Figure 5a)
2. Insert the bending plate into the U-shaped narrow slot of the
slide-rail, align the two holes on the bending plate with the
two holes on the slide-rail, and then tighten them with M8x16
bolts. (See Figure 5b)
M8 X 16 X 2 3
Figure 5a
Figure 5b
Slide-rail
Fixed Guide Rail
Bolt Holes
Spring Pin
Bending Plate
M8x16 (x2)
Slide-rail
1
2
Slide-rail
Fixed Guide Rail
Bolt Holes
Spring Pin
Bending Plate
M8x16 (x2)
Slide-rail
1
2
6 mm
8 mm
5 mm
10 mm
Slide-rail Assembly Connecting Plate Assembly
Main Table & Side Table Assembly
1. Assemble the side table and the main table together to ensure
that the hole positions at the connection are aligned. (See
Figure 7a, illustration 1)
2. Use a D type pin to insert the right connection hole between
the main table and the side table. (See Figure 7b, illustration 2)
3. Align the front hole of the left support leg with the left
connecting hole between the main table and the side table,
and x them with a D type pin. At the same time, align the rear
hole of the left leg with the left hole at the bottom of the main
table and then fasten with M10x60 long bolts, washers and
nuts. (See Figure 7b, illustration 3)
Figure 7a
1. Assemble the connecting plate onto the tank, taking care to
ensure the correct bending direction of the plate. (See Figure
6)
M10 X 20 X 4 4
Figure 6
Connecting Plate
M10x20 (x4)
13 mm
10 mm
16 mm
19 mm
Main Table
Side Table
1
Left Support Leg
M10x60 (x1)
3
2
M10x60 (x2)
Right Support Leg
4
D type pin 9.3x70 (x2)
6
Log lift table attachment
»
Operator’s Manual
Assembly
|

4. Assemble the right support leg with the main table. Tighten
with bolts, washers and nuts. (See Figure 7b, illustration 4)
M10 X 60 X 3
5
9.3 X 70 X 2
Figure 7b
Main Table
Side Table
1
Left Support Leg
M10x60 (x1)
3
2
M10x60 (x2)
Right Support Leg
4
D type pin 9.3x70 (x2)
16 mm
13 mm
10 mm
18 mm
19 mm
24 mm
32 mm
17 mm
32 mm
1. Pass the rotating shaft through the connecting plate, right
support leg, long bushing, left support leg, and short bushing in
sequence, and nally, wrap it outside the beam pivot pin, then
x it on the connecting plate with M8x20 bolts and washers.
(See Figure 8)
Figure 8
M8 X 20 X 1 6
13 mm
10 mm
16 mm
19 mm
Log Lift Table Attachment Assembly
M8x20 (x1)
Rotating Shaft
Short Bushing Long Bushing
Connecting Plate
Rotating Shaft
Short Bushing
Beam Pivot Pin
1
2
3
4
5
6
7
7
7
|
Assembly

1. The front hole of the swing arm is xed to the short shaft on
the side of the left leg with bushing, washer and cotter pin. and
the rear hole of the swing arm is xed on the short shaft on
the inside of the bending plate. The inner side is xed with a
bushing, a washer and a cotter pin. (See Figure 9)
1. Loosen the lock nut, adjust the table angle adjustment bolt
backward to increase the length of the ejector rod, and the
table tilts upward; On the contrary, adjust the table angle
adjustment bolt forward to shorten the length of the ejector
rod, and the table will tilt down. When the height of the table
and beam is aligned, lock the nut tightly. (See Figure 10)
25 X 20 X 8 X 2
7
φ 20 X 2
5 X 35 X 2
Figure 9
Swing Arm
Bushing 25 X 20 X 8 (x2)
Washer φ20 (x2)
Pin5 X 35 (x2)
Swing Arm
Swing Arm
Bushing 25 X 20 X 8 (x2)
Washer φ20 (x2)
Pin5 X 35 (x2)
Swing Arm
Log Lift Table Attachment height AdjustmentSwing Arm Assembly
Figure 10
(x1)
LockNut M10
(x1)Table Angle Adjustment Bolt M10x40
(x1)
LockNut M10
16 mm
13 mm
10 mm
18 mm
19 mm
24 mm
32 mm
8
Log lift table attachment
»
Operator’s Manual
Assembly
|

OPERATION
1. When the log lift table attachment is ush with the beam, pull
the control lever of the control valve outward while pushing it
forward. then the wedge moves forward, and at the same time,
the log lift table attachment will go downward. When it lands,
release the control lever. (See Figure11a)
3. Give the control lever a backward thrust, wait until the wedge
starts to move, release the control lever, and then the log lift
table attachment starts to rise. (See Figure 11b)
When the wedge is extended and not fully return
back, it is prohibited to pull the control lever
outwards, otherwise the lift log attachment may
suddenly drop, causing unexpected risks such as
falling logo and so on. (See Figure 12)
Figure 11a
Figure 11b
Figure 12
Wedge Log Lift Attachment
Handle Grip
Handle Grip
Wedge Log Lift Attachment
Wedge Log Lift Attachment
Handle Grip
Handle Grip
Wedge Log Lift Attachment
2. Make sure wedge and log lift table stop moving, load the log
on the table.
4. Move the log from log table to the beam.
5. Push the control lever forward, the wedge will go forward to
split the log. Give the control lever a backward thrust, then
release the lever, the wedge will go back to the start position.
6. Repeat the operate from Step 1-5 to complete the log lifting
and splitting again.
9
|
Operation

Parts Pragram & Parts List
|
PARTS DIAGRAM
No. Description Qty
1# Ejector Rod 1
2# U-shaped Plate 1
3# Round Head Bolt M10x40 1
4# Nut M10 1
5# Flat Washer 6 4
6# Spring Washer 6 4
7# Bolt M6X20 4
8# Bolt M12X65 2
9# Nut M12 2
10# Cable Fixing Plate 1
11# Cable 1
12# Round head Nut M6 1
13# Nut M6 1
14# Handle Grip 1
15# Spring 1
16# Handle 1
17# Hexagon Socket Set Screw M6x10 1
18# Circlips 20 1
19# Slide-rail 1
20# Hex Socket Head Cap Screw M8x16 2
No. Description Qty
21# Bending Plate 1
22# Connecting Plate 1
23# Bolt M10x20 4
24# Spring Washer 10 10
25# Washer 10 4
26# Log Lift Table Attachment-side Table 1
27# D type Pin 9.3x70 2
28# Log Lift Table Attachment-main Table 1
29# Bolt M10X60 3
30# Nut M10 3
31# Support Leg-left 1
32# Support Leg-right 1
33# Rotating Shaft 1
34# Long Bushing 1
35# Short Bushing 1
36# Bolt M8x20 1
37# Spring Washer 8 3
38# Flat Washer 8 1
39# Swing Arm 1
40# Bushing 25x20x8 2
41# Flat Washer 20 2
42# Cotter Pin 5x35 2
PARTS LIST
31# 30#
2#
8#
9#
39#
1#
21#
10#
11# 14# 15# 17#
16# 18#
19#
20# 4# 3#
28# 27#
26#
32#
36#38# 37#
33#
23#
34#
35#
25#
24#
5#
42#
13#
41#40#
6#
7#
22#
12#
29#
10
Log lift table attachment
»
Operator’s Manual

847-327-0566 or 844-YARDMAX | [email protected]
yardmax.com
Tame the Great Outdoors®
