Yazoo/Kees ZMBI48181 User manual

Operators manual Models:
Please read these instructions carefully and make
sure you understand them before using the machine.
MANUAL NO. 110872 REV. IR (09/13/04)
ZMBI48181
ZMKW48191
ZMKW52211
ZMKW52231
ZMKH52231
ZMKW61231

2
©2004 Yazoo/Kees Power Equipment. All right reserved.
Beatrice, NE. Printed U.S.A.

3
CONTENTS
INTRODUCTION .................................. 4
SYMBOLS & DECALS ......................... 6
SAFETY INSTRUCTIONS .................... 7
General use and saftey rules ...... 7-8
Driving on slopes ........................ 9
Children safety............................ 10
Maintenance safety ..................... 10-11
Transportation Safety ................. 12
ROPS Safety .............................. 13
Customer Responsibilities ......... 13
PRESENTATION ................................... 14
SETUP AND ADJUSTMENTS .............. 15
Setup .......................................... 15
ROPS assembly ........................ 15
Tires ........................................... 15
Control arm ................................ 16
Seat Installation .......................... 16
Engine oil .................................... 16
Cutting height ............................. 16
Mower deck leveling ................... 17
Throttle lever tension .................. 17
Park brake adj............................. 17
Motion control lever adj. .............. 18
OPERATING INSTRUCTIONS ............ 19
Roll bar and seat belt .................. 19
Starting and operation ................. 19
Controls ...................................... 19-20
MAINTENANCE .................................... 21
Engine oil .................................... 21
Mower blades ............................. 19
Safety interlock system .............. 21
Cutter housings .......................... 21
Hardware .................................... 22
Air filter........................................ 22
Hydraulic system ........................ 22
Deck belt .................................... 22
Pump belt ................................... 23
Lubrication .................................. 23
Tire pressure .............................. 23
Caster wheels ............................ 23
Fuel filter ..................................... 23
Winter storage ............................ 23
TORQUE SPECIFICATIONS ............... 24
MAINTENANCE SCHEDULE ............... 25
TROUBLE SHOOTING ........................ 26
WIRING DIAGRAMS ............................. 28

4
INTRODUCTION
Introduction
Congratulations
Thank you for purchasing a Yazoo/Kees ride-on mower. This machine is built for the greatest efficiency
and rapid mowing of large areas. Convenient controls and a hydrostatic transmission regulated by
steering levers also contribute to the machine’s performance.
This manual is a valuable document. Following the instructions (use, service, maintenance, etc.) can
considerably increase the life-span of your machine and even increase its resale value.
If you sell your machine, be sure to give the operator’s manual to the new owner.
The final chapter of this operator’s manual comprises a Service Journal. Ensure that service and
repair work is documented. A well kept service journal reduces service costs of the season-based
maintenance and affects the machine’s resale value. Take the operator’s manual along when the
machine is left at the service center for service.
General
In this operator’s manual, left and right, backward and forward are used in relation to the machine’s
normal driving direction.
Driving and Transport on Public Roads
Check applicable road traffic regulations before driving and transporting on public roads. If the machine
is transported, you should always use approved fastening equipment and ensure that the machine is
well anchored.
Operating
This machine is constructed only for mowing grass on lawns and other free and even ground without
obstacles such as stones, tree stubs, etc. The machine can also be used for other tasks when equipped
with special accessories provided by the manufacturer, for which the operating instructions are pro-
vided in conjunction with delivery. All other types of use are incorrect. The manufacturer’s directions
concerning operation, maintenance, and repairs must be carefully followed.
The machine must only be operated, maintained, and repaired by persons that are familiar with the
machine’s special characteristics and who are well versed in the safety instructions.
Accident prevention regulations, other general safety regulations, occupational safety rules, and traffic
regulations must be followed without fail.
Unauthorized modifications to the design of the machine may absolve the manufacturer from liability
for any resulting personal injury or property damage.

5
INTRODUCTION
Good Service
Yazoo/Kees products are sold all over the world and only in specialized retail stores with complete
service. This ensures that you as a customer receive only the best support and service. Before the
product is delivered, the machine has, for example, been inspected and adjusted by your retailer, see
the certificate in the Service Journal in this operator’s manual.
When you need spare parts or support in service questions, warranty issues, etc., please consult the
following professional:
This Operator’s Manual belongs to the
machine with manufacturing number:
Engine Transmission
Manufacturing Number
The machine’s manufacturing number can be found on the printed decal affixed to the left side of the
frame under the seat.
•The machine’s type designation (I.D.).
•The manufacturer’s type number (Model).
•The machine’s serial number (Serial no.)
Please state the type designation and serial number when ordering spare parts.
The engine’s manufacturing number is stated on a decal. This is placed on the right side on the top
of the engine.
•The engine’s serial number (E/NO).
•The engine’s type designation (Code).
Please state these when ordering spare parts.
The hydraulic pump’s manufacturing number is stated on a barcode decal affixed to the left side of
the pump housing. The plate states:
•The pump’s type designation.
•The pump’s serial number.
The hydraulic motor’s manufacturing number is stated on a round metal plate. This is placed on the
gable inside the motor. The plate states:
•The hydraulic motor’s type designation and design version.
•The hydraulic motor’s serial number.

6
SYMBOLS AND DECALS
Symbols and Decals
These symbols are found on the machine and in the operator’s manual.
Study them carefully so that you know what they mean.
Used in this publication to notify the reader of a risk of personal injury, particularly if the reader
should neglect to follow instructions given in the manual.
IMPORTANT INFORMATION
Xxxxxxx xxxx xxxxxxxx xxx xxx
xxxx xxxxxx xx.
Used in this publication to notify the reader of a risk of material damage, particularly if the reader
should neglect to follow instructions given in the manual. Used also when there is a potential for
misuse or misassembly.
R
N
Reverse Neutral Fast Slow Fuel
Ignition
Stop Run Start Warning
Danger
Caution
Parking brake
Do not stand here
Warning! Rotating
blades, keep away from
the discharge deck Do not touch rotating parts
Battery acid is corrosive,
explosive, and flammable
Use on a slope no greater
than 10°.
No
passengers
Careful going
forward, watch
for other people.
Careful backing
up, watch for
other people.
WARNING!
Xxxxxxxxxx xxx xxxxx xxxxxxxx.
Xxxxxx xxxxx xxxxxxxxx
xxxxx xxxxx xxx x xxxxx.
Shut off engine
and remove key
before performing
any maintenace
or repair work.
Read
Operators
Manual.
Whole body
exposure to
thrown objects.
Severing of
fingers and toes.
Do not open
or remove
safety shields
while engine
is running.
Keep a safe
distance from
the machine.

7
SAFETY INSTRUCTIONS
Safety Instructions
These instructions are for your safety. Read them carefully.
WARNING!
This symbol means that important safety instructions need to be emphasized. It
concerns your safety.
General Use
•Read all instructions in this operator’s manual
and on the machine before starting it. Ensure
that you understand them and then abide by
them.
•Learn how to use the machine and its con-
trols safely and learn how to stop quickly. Also
learn to recognize the safety decals.
•Only allow the machine to be used by adults
who are familiar with its use.
•Make sure nobody else is in the vicinity of the
machine when you start the engine, engage
the drive, or run the machine.
•Make sure animals and people maintain a safe
distance from the machine.
•Stop the machine if someone enters the work
area.
•Clear the area of objects such as stones, toys,
steel wire, etc. that may become caught in
the blades and thrown out.
•Beware of the discharge deck and do not point
it at any one. Do not use the machine without
the discharge deck in place.
•Stop the engine and prevent it from starting
before you clean the discharge deck.
•Remember that the operator is responsible
for dangers or accidents.
•Never take passengers. The machine is only
intended for use by one person.
•Always look down and behind before and dur-
ing reversing maneuvers. Keep a look out for
both large and small obstacles.
•Slow down before turning.
•Shut down the blades when not mowing.
8011-512
Read the operator’s manual before starting the machine.
8011-513
Clear the area of objects before mowing.
8011-520
Never take passengers.

8
SAFETY INSTRUCTIONS
•Be careful when rounding fixed objects, so that
the blades do not hit them. Never drive over
foreign objects.
•Only use the machine in daylight or in other
well-lit conditions. Keep the machine a safe
distance from holes or other irregularities in
the ground. Pay attention to other possible
risks.
•Never use the machine if you are tired, if you
have consumed alcohol, or if you are taking
other drugs or medication that can affect your
vision, judgement, or coordination.
•Beware of traffic when working near or cross-
ing a road.
•Never leave the machine unsupervised with
the engine running. Always shut down the
blades, pull back the parking brake, stop the
engine, and remove the ignition key before
leaving the machine.
•Never allow children or other persons not
trained in the use of the machine to use or
service it. Local laws may regulate the age of
the user.
Engine exhaust and certain vehicle
components contain or emit chemi-
cals considered to cause cancer,
birth defects, or other reproductive
system damage. The engine ex-
haust contains carbon monoxide,
which is colorless, poisonous gas.
Do not use the machine in en-
closed spaces.
WARNING!
WARNING!
When using the machine, approved personal protective equipment shall be used.
Personal protective equipment cannot eliminate the risk of injury but it will reduce
the degree of injury if an accident does happen. Ask your retailer for help in choosing
the right equipment.
•Make sure that you have first aid equipment
close at hand when using the machine.
•Never use the machine when barefoot. Always
wear protective shoes or boots, preferably with
steel toecaps.
•Always wear approved protective glasses or
a full visor when assembling or driving.
•Never wear loose clothing that can get caught
in moving parts.
8011-292
Personal protective equipment.
8011-518
Keep children away from the work area.

9
6003-004
Mow up and down, not side-to-side.
Driving on Slopes
SAFETY INSTRUCTIONS
Driving on slopes is one of the operations where
the risk is greatest that the driver will lose control
or the machine will tip over, which can result in
serious injury or death. All slopes require extra
caution. If you cannot reverse up a slope or if feel
unsure, do not mow the slope.
Do as follows:
•Remove obstacles such as stones, tree
branches, etc.
•Mow up and down, not side-to-side.
•Never drive the rider on terrain that slopes
more than 10°.
•Avoid starting or stopping on a slope, If the
tires begin to slip, shut down the blades and
drive slowly down the slope.
•Always drive evenly and slowly on slopes.
•Make no sudden changes in speed or direc-
tion.
•Avoid unnecessary turns on slopes, and if it
proves necessary, turn slowly and gradually
downward, if possible.
•Watch out for and avoid driving over furrows,
holes, and bumps. On uneven terrain, the
machine can tip more easily. Long grass can
hide obstacles.
•Drive slowly. Use small movements of the
steering controls.
•Be extra cautious with any additional equip-
ment, which can alter the machine’s stability.
•Do not mow near verges, ditches, or banks.
The machine can suddenly spin around if a
wheel goes over the edge of a drop or ditch,
or if an edge gives way.
•Do not mow wet grass. It is slippery, and the
tires can lose their grip, so that the machine
slides.
•Try not to stabilize the machine by putting a
foot on the ground.
•When cleaning the chassis, the machine may
never be driven near verges or ditches.
8011-519
Be extra cautious when driving on slopes.
•Avoid starting or stopping on a slope. If tires
lose traction, disengage the blades and pro-
ceed slowly straight down the slope.
•If machine stops while going uphill, disengage
blades and back down slowly.
•Do not turn on slopes unless necessary, and
then, turn slowly and gradually downhill, if pos-
sible.

10
SAFETY INSTRUCTIONS
Children:
•Serious accidents may occur if you fail to be
on guard for children in the vicinity of the ma-
chine. Children are often attracted to the ma-
chine and mowing work. Never assume that
children will stay put where you last saw them.
•Keep children away from the mowing area and
under close supervision by another adult.
•Keep an eye out and shut off the machine if
children enter the work area.
•Before and during a reversing maneuver, look
backward and downward for small children.
•Never allow a child to ride with you. They can
fall off and injure themselves seriously or pre-
vent risk-free maneuvering of the machine.
•Never allow children to operate the machine.
•Be particularly cautious near corners, bushes,
trees, or other objects that block your view.
WARNING!
The engine must not be started when the driver’s floor plate or any protective
plate for the mower deck’s drive belt is removed.
•Stop the engine. Prevent the engine from start-
ing by removing the ignition key before mak-
ing any adjustments or performing mainte-
nance.
•Never fill the fuel tank indoors.
•Fuel and fuel fumes are poisonous and ex-
tremely flammable. Be especially cautious
when handling fuel, as carelessness can re-
sult in personal injury or fire.
•Only store fuel in containers approved for the
purpose.
•Never remove the fuel tank cap and never fill
the fuel tank while the engine is running.
Maintenance:
8011-517
Never allow children to operate the machine.
8011-516
Never fill the fuel tank indoors.
