YESOUL C1 User manual

PANTONE 193 C
PANTONE Black 6 C
此页为备注页，不用印刷
骑马钉整面展开 296*210mm
装订版单页尺寸 148*210mm
双面印刷
整面出血线 3mm
共18面
封面封底铜板纸 128g
内页铜板纸 80g

V2.0
Please read this important information
booklet carefully before you use the machine and save
it for further future reference.
CUSTOMER SUPPORT
MADE IN CHINA
North America [email protected]
YESOUL BIKE C1

WARRANTY
30-Day Money-Back
Guarantee for Any Reason
You may return your product within 30 days of purchases
to receive a FULL REFUND for any reason. But if the reason
for return isn't quality-related, the customer must pay for
the return shipping.
6-Month Warranty for
Quality-Related Issues
YESOUL warrants its products to be free from defects in
material and workmanship, under normal use, during the
warranty period. Within 6 months, YESOUL will provide a
replacement and cover any return shipping costs for
products that fail in normal use.
1IMPORTANT PRECAUTIONS P2
2P3STORAGE AND MAINTENANCE
3P4SPECIFICATIONS
4P5SETTING UP YOUR BIKE
5P17GETTING STARTED
6P21CONNECTING YOUR MOBILE DEVICES
7P29TROUBLE SHOOTING
8P32WARRANTY
Daily Maintenance
Monthly Maintenance
Packing List
Overview
Assembly
Before Doing Exercise
Saddle Adjustment
Handlebar Adjustment
Pedal Strap Adjustment
Resistance Adjustment
How to Connect Yesoul Sports APP
How to Connect Zwift APP
How to Connect Kinomap APP
[email protected] 32

FCC Caution:
Any Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate
the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1)This device may not cause harmful interference, and
(2)This device must accept any interference received, including
interference that may cause undesired operation.
Note:
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure
requirement.
The device can be used in portable exposure condition without
restriction.
IMPORTANT PRECAUTIONS
1. Consult a physician before beginning any exercise program. Inappropriate training
may result in serious accident or injury during exercise.
2. If you experience a shortness of breath, chest pains or a heavy feeling around your
sternum, suffer serious headaches, deep, raspy coughing fits, or feel dizzy or cannot
stand up straight, stop exercising and consult your physician.
3. The appliance is not intended for use by persons with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for
their safety.
4. To prevent injury, keep children under 14 and pets away from the exercise bike, keep a
close eye on children or pets when they close to the machine.
5. The maximum weight limits 265 pounds, do not use the bike if you are in excess of 265
pounds.
6. Set up and operate this exercise bike on a firm level surface.
7. This bike is for indoor use only. Do not store the bike outdoors, near water, or at high
humidity levels.
8. To prevent injury and ride comfortably, always check the seat and handlebars are
securely fastened and adjust their angles to your personal need.
9. Examine this machine for loose parts or signs of wear. Pay special attention to the seat,
pedals, and crank arms.
10. The resistance knob can be used as an emergency brake. Push straight down onthe
resistance knob to engage theemergency brake.
11. Keep hands, hair and loose clothingitems (likeshoelaces) away from the moving parts
during use.
12. Be especiallycareful when mountingordismounting the exercise bike, and always be
cautious when getting on and off.
13. Never ride the bike barefoot.
14. Metrics on the APP may be inaccurate. Values should be used for reference only.
To reduce risk of injury to persons, read carefully all precautions and
instructions before operating the bike. It is the owner's responsibility to
ensure that all users are aware of all warnings and precautions. Use
only as described. Improper use of this equipment may result in serious
injury or death. MEKBELT is not responsible for damage or injury caused
by inappropriate use.
[email protected] 2[email protected]
31

Q3. Exercise bike cannot connect to APP.
Perhaps the AA battery is out of energy, replace new batteries
and make sure the new batteries are correctly positioned.
Stop other devices from connecting to your bike, and try connecting
again.
In order to activate your bike, and to connect it to your mobile
devices, Bluetooth must be turned on on your mobile devices.
Riding your bike at least 5 seconds to pair with mobile devices.
STORAGE AND MAINTENANCE
DAILY
MAINTENANCE
01
MONTHLY
MAINTENANCE
02
1. Check pedals to make sure there is no grinding noise.
2. Inspect belt/chain for wear.
3. Inspect crank arm and drive sprocket, adjust as required.
4. Inspect and lube seat post.
5. Test and adjust belt tension.
1. Wiping the bike clean at the end of class or workout to prevent
rust from building up.
2. Never spray cleaner directly on the frame, and never use abrasive
or oil based cleaning products, as this can strip the paint from the
frame.
3. Never use wet cloth to clean the exercise bike.
[email protected] 30 [email protected]
3

TROUBLE SHOOTING
This part summarizes the most common problems you
could encounter with the stationary bike. If you are unable to solve
the problem with the information below, please feel free to contact
[email protected] for assistance.
Q1. The exercise bike make a grinding noise when ride it.
Some noise from the stationary bike is normal during operation due
to the movement of parts and friction.
Ensure the bike is sitting flat on the floor, try a different floor position
or adjust the screw feet if required.
Perhaps the pedal is loose or something wrong with the crank
connection. Remove pedals, and make sure there is no debris on
threads, and reinstall the pedals.
Loose fixings on pedals, seats and handlebars can cause ‘clicking’
and knocking noises. Tighten any loose bolts and screws on your bike
from top to bottom, ensure they are snug.
Q2. The seat is unstable.
There is a maximum value of the seat height adjustment. For safety
concerns, please make sure not to exceed the maximum height.
Perhaps bolts of your seat are loose, tighten bolts to make seat
stable.
SPECIFICATIONS
Product Name
YS-BC1
Resistance Mechanism
Connection Method Bluetooth
Magnetic Resistance
Battery Type 2 X1.5V AA Battery
Drive System
User Height Range
Maximum User Weight
Belt
4'11"-6'3"/150-190 cm
265 lb/120 kg
Model Number
Exercise Bike
Brand YESOUL
[email protected] 4[email protected]
29

Choose training
mode
Take "Free ride" as an example.
5PACKING LIST
Number Name Quantity Accessory
Drawing
Main Frame 1
1
1
2
1
1
1
Front Stabilizer
(With two screws)
Rear Stabilizer
(With two screws)
Pedals
(Left & Right)
Handlebars
Tablet Holder
Handlebar Post
1
2
3
4
5
6
7
SETTING UP YOUR BIKE
[email protected] 28 [email protected]
5

Click "YESOUL", then click "C1 Smart
Exercise Bike" and pedal your bike to
complete the pairing.
Enter the brand
and model
3
4
Number Name Quantity
3 x Washer 3
1
3
1
1
1
1
Cover
3 x Hexagon
Socket Head Screw
M6 x 30mm
1 x Hexagon
Socket Head Screw
M8 x 12mm
Bottle Holder
Seat
Seat Post
9
10
11
12
13
14
15
Accessory
Drawing
1
Tablet Holder Post
(with 2 screws)
8
[email protected] 6[email protected]
27

How to Connect Kinomap APP
Via bluetooth connection, Kinomap App helps record your workout data
on the bike, enabling a visible performance analysis and tracing of your riding.
Kinomap App provides multiple training modes
Create and Log in your
Kinomap account.
Creat your own profile, and choose the
second icon "Exercise Bike".
Download Kinomap from App Store/ Google Play.
Kinomap
1
2
Number Name Quantity
1
A
B
C
D
1
1
1
Hex Key with
Philips Screwdriver
Head(#6)
Hex Key(#5)
Hex Key(#4)
Wrench
For easy installation, some accessories have been
pre-installed on the body of the bike
Accessory
Drawing
[email protected] 26 [email protected]
7

Select your bike and click
"OK" to confirm.
After paired successfully, click
"LET'S GO" to start your training.
3
4
Overview
Handlebars
Handlebar
Adjustment Knob
Resistance
Adjustment Knob
Seat
Seat Slide
Adjustment Lever
Seat Height
Adjustment Knob
Rear Stabilizer
Cranks
Belt Guard Transport Wheels
Front Stabilizer
Flywheel
Pedals
Tablet Holder
Bottle Holder
Due to different batches production, the illustrations of some
accessories may slightly differ from actual items.
Please refer to the actual items.
[email protected] 8[email protected]
25

How to Connect Zwift APP
Zwift is an app for cyclists, runners, and triathletes that makes
indoor training fun. Reach your fitness goals within virtual worlds designer
for riding alongside a global community.
Create and Log in your
Zwift account.
Select POWER SOURCE on the main
interface, and try riding your bike to pair.
Download Zwift from App Store/ Google Play.
Zwift
1
2
ASSEMBLY
Basic Assembly Tips
Place the bike on a solid, level and horizontal surface.
It is better to use a mat to avoid damage to the floor.
Allow a workout area of 24" (60cm) each side of the bike.
The assembly requires two people.
Please follow the instructions step by step, otherwise damage
may occur to the bike.
Attach Stabilizers to the Main
Frame of the Bike
1
Note: The foot screws are pre-installed and not in the ziplock bag, please remove
them with provided hex key (#6)(A) and set them safely aside.
Attach Front/ Rear Stabilizer②③ to frame with two washers and two hexagonal
screws and then tighten firmly by using provided hex key (#6)(A).
(#6)(A)
②
③
[email protected] 24 [email protected]
9

Make sure to turn on bluetooth on
your smartphone/tablet.
5
Ride your bike when pairing with
your smartphone/tablet.
6
Install Seat and
Seat Post
2
a. Insert Seat Post⑮into Main Frame①in the direction indicated by the arrow,
make sure the scale on the seat post coincides with the top surface of the
tube of bike frame, and then tighten by hand turning the handle cloclwise.
b. Place the Seat⑭onto the Seat Post⑮, and tighten clockwise with the provided
open-ended wrench (D).
⑭
⑮
(D)
Tight Loose
①
[email protected] 10 [email protected]
23

Take Free riding > Power training as an example.
Creat your
Own profile.
2
Connect bike to your smartphone/
tablet via Bluetooth.
3
Install Handlebar
Post to Main Frame
3
a. Turn handlebar adjustment lever counterclockwise to loose it, then insert
Handlebar Post⑦into the Main Frame①.
b. Hold the handlebar adjustment lever and move the Handlebar Post⑦upwards
or downwards to desired position.
c. Full tighten by hand turning the handlebar adjustment lever clockwise.
①
⑦
Loose
Tight
[email protected] 22 [email protected]
11

CONNECTING YOUR MOBILE
DEVICES
How to Connect Yesoul Sports APP
Via bluetooth connection, Yesoul Sports App helps record your workout data on the bike,
enabling a visible performance analysis and tracing of your riding. Yesoul Sports App offers a
variety of online courses that meet different training goals, bringing you professional and
scientifically effective fitnss guidance.
Create an
Account and Log in.
1
Download Yesoul Sports from App Store/ Google Play
or by scanning QR code.
Yesoul Sports
Install Handlebars to
Handlebar Post
4
a. Take one hexagon socket head screw M8x12⑫, three hexagon socket head screws
M6x30⑪and three Washers⑨out of the ziplock bag.
b. Align the holes on the Handlebar Post⑦with the holes on Handlebars⑤, and manually
rotate the hexagon socket head screw M8x12⑫into the hole as indicated (no need to
tighten at this time); Align the holes on the handle of the Tablet Holder Post⑧to the hole
on the Handlebars⑤, and secure using 3 hexagon screws and 3 washers to tighten them.
c. Use the hex key (#6)(A) to secure the hexagon socket head screw M8×12⑫, and then
tighten 3 hexagon socket head screws M6X30⑪with hex key (#5)(B).
d. Fasten the cover⑩on the handlebars⑤.
⑩
⑤
⑪
⑫
(#5)(B)
(#6)(A)
⑫
⑪
⑧
⑨
⑦
⑤
[email protected] 12 [email protected]
21

Pedal Strap Adjustment
Pedals with straps ensure secure footing to the exercise bike, to ensure a healthy
foot position, the front half of your foot should be placed on the pedal with strap
tightened over the top of your foot. Be careful not to strap too tight or too loose, too
tight may cut off circulation to your feet while riding, while your feet may slip out of
the pedals and cause injury if it is too loose.
Resistance Adjustment
To increase the resistance and workload, turn the resistance adjustment knob clockwise.
To reduce the resistance, turn the Resistance Adjustment Knob counter-clockwise.
The range of movement of the Resistance Adjustment Knob is 0% to slightly past the
100% level of resistance (locked Flywheel). Do not turn the Resistance Adjustment Knob
past the range of movement. If turned past the range of movement, damage
to the machine may occur.
Note: The Resistance Adjustment Knob can be used as an emergency brake. Push
straight down on the resistance knob to engage the emergency brake.
Install the
Tablet Holder
5
Note: The tablet holder screws are pre-installed and not in the ziplock bag.
Please remove with provided hex key (#4)(C) and set them safely aside.
a. Take the hex key (#4)(C) out of the ziplock bag.
b. Remove the tablet holder screws with provided hex key (#4)(C)
c. Attach the Tablet Holder⑥to the Handlebars⑤and finger tighten the screws,
and then secure with provided hex key (#4)(C).
⑥
(#4)(C)
⑤
[email protected] 20 [email protected]
13

Handlebar Adjustment
The position of the handlebars is determined by your riding style and desired comfort.
A higher handlebar position is more forgiving than lower position. A position that is too
low will lead to discomfort in the low back and put unnecessary tension into the neck
and shoulders.
Recommendation:
The handlebars should be within a few inches higher than the saddle for fitness beginners.
While the handlebars can be slightly lower than the saddle for experienced exercisers.
Loosen and pull the Handlebar Adjustment Knob to adjust the handlebars to your
desired height.
Note: Check the height of your handlebars. When your hands are resting on grips,
your spine should be in a neutral position, meaning no arch or curve.
Install Pedals to
the Exercise Bike.
6
Note:
1. Begin by identifying the right and left pedals. Look for “L” and “R” marking on Pedals④.
2. For easy installation, set the resistance to maximum value before installing the Pedals④.
a. Thread right side pedal into right crank by hand turning the pedal axle towards the
front of the bike (Clockwise) with your left hand, and full tighten them with the provided
wrench (D).
b. Thread left side pedal into left crank by hand turning the pedal axle towards the front
of the bike (Counterclockwise) with your right hand, and full tighten them with the
provided wrench (D).
Note: We will not recommend for anyone with a bike to ride backward. Pedaling
backward may loosen the pedals and result in damage or injury.
(D)
④
④
R
L
[email protected] 14 [email protected]
19

Saddle Distance Adjustment
The position of the saddle forward and backward is determined in part by your
height, but your flexibility and riding approach will also impact the position. As you
riding on the bike, make sure that your front knee should be right down to the middle
of the pedal.
Loosen and pull the Seat Slide Adjustment Lever to adjust the seat to your preferred
distance.
Install the
Bottle Holder
7
Note: The bottle holder screws and washers are pre-installed and not in the ziplock
bag. Please remove them with provided hex key (#6)(A) and set them safely aside.
a. Remove the bottle holder screws with the hex key (#6)(A).
b. Align the holes on Bottle Holder⑬with the holes on Main Frame①, secure using 2
washers and 2 bottle holder screws with the provided hex key (#6)(A) to tighten
them.
(#6)(A)
⑬①
[email protected] 18 [email protected]
15

Activate and
Replace Battery
8
1. To activate the battery
The battery is attached a battery insulating pull tab, it will protect battery and
circuitry during shipping and handling. The insulator should be pulled out to activate
the battery before you would like to connect to your mobile devices.
Remove the battery cover, position 2 x AA battery in place of the old one, make sure
new batteries are correctly positioned.
Re-install the battery cover.
2. To replace battery
GETTING STARTED
Before Doing Exercise
Consult a physician before you start an exercise program, and stop exercising if
you experience a shortness of breath, serious headaches, or feel dizzy. Contact
your doctor before you use the machine again.
Use the values collected by Apps for reference purpose only.
Wear rubber-soled athletic shoes, and wear appropriate clothes for exercise that
allow you to move freely.
Saddle Adjustment
Saddle Height Adjustment
Suitable seat placement encourages exercise efficiency and comfort, while reducing
the risk of injury.
The top of the seat should be in line with your hip joint. Place your thumb on top of
your hip joint and make sure your palm lies flat on top of the bike seat.
Loosen and pull the Seat Height Adjustment Knob to adjust the seat to your desired
height.
Hip joint
[email protected] 16 [email protected]
17

FCC Warning
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
