Yeticool CX10 User manual

PORTABLE FRIDGE WITH COMPRESSOR
AND HEATING FUNCTION
USER MANUAL
CX10

DANGER!
Safety note: Non-observance can result in death or serious injury.
CAREFULLY!
Safety note: Failure to comply can result in injury.
ATTENTION!
Non-observance can lead to material damage or interference with the product.
TIP
Supplementary information on product handling.
1. Explanation of symbols.
Please read this manual carefully before starting the device. Keep these instructions. The manufacturer is not liable
for damages resulting from improper use or incorrect operation.
3.Description of operation and basic functions
• The device is used to cool or keep food warm.
• Thanks to high-class insulation and an efficient compressor, the cooling and heating process is extremely fast.
• The fridge can be DC (100-240V) or AC (12 / 24V).
• The device has multi-level protection of the vehicle battery against discharge and overvoltage protection to protect against sudden voltage surges in the electrical network.
• The control panel with a clear LCD screen enables intuitive control of the device.
• The fridge is equipped with a Bluetooth 5.0 transmitter. This allows you to control it using an application designed for mobile devices (Android / iOS).
• Built-in USB socket allows you to charge external devices such as a smartphone or tablet.
• Ergonomic handles, telescopic handle and wheels enable comfortable movement of the device.
• Possibility of connecting an external power supply battery, allowing the temperature inside the device to be maintained for up to 22 hours (5 ° C / 41 ° F at an ambient
temperature of 25 ° C / 77 ° F). Battery sold separately.
2. Safety information
• The device and / or its power cord may not be used if they show any signs of damage.
• The device should be connected to a power source that complies with the data included in the technical specification, only with the supplied power cords. 100-240V
power supply requires cable connection via the AC / DC adapter.
•The device must be disconnected from the mains after each use and before cleaning / maintenance. The battery should be turned off.
• If the device requires repair, contact the manufacturer's service. Contact details can be found at www.arkas.pl.
• Repairs may only be carried out by qualified persons. Self-repair can cause serious health or life hazards.
• The device should not be operated by children, persons with limited physical, sensory or mental capabilities and / or persons who do not have appropriate knowledge and
experience.
• The device should be stored out of the reach of children.
• Do not store caustic substances, containing solvents, which are known to be explosive or compressed flammable gases in the device.
• Foodstuffs should be stored in their original packaging or appropriate containers.
• Too low or too high temperature may adversely affect the stored food. The temperature inside the refrigerator should be adjusted to the temperature recommended by the
food manufacturer. Optimum storage temperature for fresh food: 0 ° C - + 4 ° C.
• This refrigeration appliance is not intended to be used as a built-in appliance.
• This refrigeration appliance is not suitable for the freezing of foodstuffs.
• The refrigeration appliance is intended for use in an ambient temperature ranging from 10 ° C to 32 ° C, or 16 ° C to 32 ° C, or 16 ° C to 38 ° C, or 16 ° C to 43 ° C. Detailed
information can be found in the "technical data" section of this manual.
• Protect the device against adverse weather conditions such as rain. The device is not waterproof.
• The device must be turned off or disconnected from the power source when the engine is switched off or the battery charging (12 / 24V) is switched on in motor vehicles.
Otherwise the battery may discharge.
• The device insulation contains cyclopentane. The device, which is not suitable for further operation, should be delivered to a specialized rendering plant.
• The manufacturer's warranty period - 24 months from the date of purchase.
• The minimum period for which spare parts necessary to repair are available is 7 or 10 years, depending on the type and purpose of the spare part, and is in line with
Commission Regulation (EU) 2019/2019. The list of spare parts and the ordering procedure are available on the websites of the manufacturer, importer or authorized
representative.
More information about the product can be found in the EU Product Database EPREL at https://eprel.ec.europa.eu. Information can be obtained by scanning the QR code
on the energy label or by entering the product model from the energy label in the EPREL search engine https://eprel.ec.europa.eu.

4. Contents of the package
• Portable fridge with compressor
• 12/24V power cord (length: 3.5m/11,4ft)
• AC/DC adapter with 100-240V power cord (EU/UK)
• User manual
5. Directions for use
• Before first use, remove the device from the packaging, clean the inside of the device with a damp cloth and wait 6 hours.
• During operation, the device should be located in a well-ventilated room, away from heat sources and direct sunlight.
• Ensure adequate space between the device and other equipment (≥200mm on the back of the device, ≥100mm on the sides of the
device).
• The device should be in a horizontal position during operation. The maximum angle of inclination of the device relative to the ground
should not be more than 5 °.
• Do not open the appliance door more often than necessary. This may change the temperature inside the device.
• If the device is used with the ignition off of a motor vehicle (when using a 12 / 24V power source), it switches itself off when the voltage
drops below the set battery protection value. The device will turn on again when the required voltage is obtained by charging the battery.
• When using an external battery, it is recommended to change the battery protection mode to low
Battery protection mode
Switch-off voltage with 12V supply
Restart voltage with 12V power supply
Switch-off voltage with 24V supply
Restart voltage with 24V supply
Low
(L)
9.6V
10.9V
21.3V
22.7V
Medium
(M)
10.1V
11.4V
22.3V
23.7V
High
(H)
11.1V
12.4V
24.3V
25.7V
6.Operating
Operating the device from control panel
The device automatically enters the standby mode after connecting the power source.
cooling
function
ON/OFF
button
heating
function
ON/OFF
button
Temperature
decrease
button
Temperature
increase
button
Current
temperature
inside
the device(°C)

The application Yeticool can be downloaded from the GooglePlay store (for Android devices) or AppStore (for iOS devices). For
the proper operation of the application, it is required to turn on the Bluetooth function and the location function on the external
device.
To connect to the application, launch it on an external device (smartphone / tablet), search for and select the fridge from the list of
available devices. The refrigeration appliance control panel will display "AP", which must be confirmed by pressing the button .
The device should be ready for receiving commands from the application.
Operating the device from control panel (cont.)
Operating the device from the application level (Android / iOS)
Button
Function
Holding it down will turn on / off the cooling function
Holding it down will turn on / off the heating function
In standby mode:
Holding both buttons simultaneously will enable the battery protection settings
Pressing + once changes the protection level to a higher one
Press - once changes the protection level to a lower level
In cooling mode:
The buttons are responsible for setting the temperature inside the device
Pressing + once increases the temperature
Pressing - once lowers the temperature
-03°C
L-Box -20°C
°C
COOL
H M L
MAX ECO
HOT
BAC K SENIO R S E T TING
50°C
L-Box -20°C
°C
COOL
H M L
MAX ECO
HOT
BAC K SENIO R S E T TING
Device on / off button
Current temperature
inside the chamber
Button for changing
the target temperature
inside the chamber
Settings change button
Return
to the previous screen
Battery protection
mode change slider (H / M / L)
Cooling/Heating
mode change buttons
Control panel lock
button on the device
Cooling mode
change slider (MAX / ECO)
Setting the minimum temperature
Setting the maximum temperature
Setting the compressor start delay after starting the device ( in minutes)
Chamber hysteresis setting - the compressor will start after exceeding the sum
of the set device temperature and hysteresis temperature
(example - cooling temperature set on the device: -20°C, hysteresis temperature:
+ 2°C, compressor restart temperature: -18°C)
Settings enabling leveling of differences between the actual temperature of the interior of
the device and the temperature set on the control panel (example - chamber cooling
temperature set on the device: 0°C, actual temperature inside the chamber: -5°C,
the temperature should be set to level the + 5°C differences)
Setting delaying / accelerating the compressor off after reaching the temperature
set on the control panel
Smart Car Fridge
Min Temperature
Max Temperature
Start Delay
Le Hysteresis
Le TC: T≥-6°C
Le TC: 12≤T˂-6°C
Le TC: T<-12°C
Le TC: Shutdown
ON
-20°C
20°C
0M
2°C
0°C
0°C
-4°C
0°C

7.Cleaning and maintenance
• Przed każdym czyszczeniem należy wyłączyć urządzenie oraz odłączyć je od zasilania zewnętrznego.
• Urządzenia nie wolno czyścić pod bieżącą wodą.
• Do czyszczenia nie należy używać agresywnych środków czyszczących.
• Urządzenie należy czyścić z zewnątrz i od wewnątrz wilgotną ściereczką z pominięciem panelu sterowania, sekcji zasilania oraz
otworów wentylacyjnych.
8. Troubleshooting the most common faults
Foodstuffs have been frozen:
• Change the cooling temperature to higher, the set temperature is too low.
The device makes a sound of flowing liquid:
• This sound is normal.
Droplets of liquid appear around the fridge door:
• Liquid droplets appear due to the temperature difference between the device and its surroundings, and are normal.
When starting the device, the compressor makes a loud noise:
• It is normal for the compressor to work loudly at start-up.
The device does not work:
• Check that the device is correctly connected to the power source.
• Check whether the power supply is functional.
• Check if the fuse has blown.
The device displays the F1 code:
• Code informing about 12 / 24V supply voltage drop. Change the protection setting to lower from (high) to (medium)
or from (medium) to (low).
The device displays the F2 code:
• Code informing about fan overload. Switch the device off and on again after 30 minutes.
The device displays the F3 code:
• Code informing about activation of protection against too frequent compressor operation. Switch the device off and on again after 30
minutes.
The device displays the F4 code:
• Code informing about compressor overload. Switch the device off and on again after 30 minutes.
The device displays the F5 code:
• Code informing about compressor module overheating. Switch the device off and on again after 30 minutes.
The device displays the code F6:
• Code informing about the inability to read parameters by the device controller. Restart the device. If the problem persists, please
contact your dealer.
The device displays the code F7 or F8:
• Code informing about temperature sensor error. Please contact the seller.
410mm(16")
310mm(12,2")
203mm(8")
154mm(6")
356mm(14")
284mm(11")

9. Technical data
MANUFACTURER'S DECLARATION
Arkas Sp. z o.o. declares that the CX10 Portable Refrigerator complies with the European Parliament and Council Directives 2009/125 / EC and 2014/53 / EU of
April 16, 2014. on the harmonization of the laws of the Member States concerning the making available on the market of radio equipment and repealing Directive
1999/5 / EC. The full text of the EU declaration of conformity is published at www.arkas.pl
The crossed out wheeled bin symbol means that this product should not be disposed of with other household waste. Waste electrical and electronic equipment
should be sent for recycling and recycling with environmental protection regulations in force in a given country regarding waste management. Selective waste
collection contributes to reducing their potential negative impact on human health and the resulting environment from the presence in the equipment of
dangerous substances, mixtures and components.
Manufacturer:
ARKAS Sp. z o.o.
ul. Kuziennicza 4,
59-400 Jawor, Poland
www.arkas.pl
www.yeticool.com
97/JAP/20
Instructions for use
in other languages
are available at
www.yeticool.com
Model number:
Supply voltage:
Rated current:
Number of cooling chambers:
Temperature range:
Average energy consumption:
Usable capacity:
Climate class:
Ambient temperature:
Noise level:
Communication Type:
Dimensions (W x H x D) in mm:
Net weight:
CX10
12/24V DC
100-240V AC, 50/60Hz
12V/5A
24V/2.5A
100V/1.2A
240V/0.5A
1
cooling function: from +20°C to -20°C (from 68°F to -4°F)
heating function: up to +50°C (up to 122°F)
45-60W (depending on the ambient temperature)
10 liters/2,20gal
N, T, SN, ST
from +10°C to +43°C (from 50°F to 109°F)
38dB
Bluetooth 5.0 (working range - up to 10m/32,8ft)
410 x 284 x 356 (inches: 16" x 11" x 14")
8,0kg(17,6Ibs)
Manufacturer:
Foshan Great Power Co,.Ltd
Commercial registration number:
91440606663372921C
Adress:
3/F Block, 16th, Street#3, Fengxin
Road, Fengxing Industrial Zone, Shunde
District, Foshan City, Guangdong
Province, Chiny
Model identifier:
GRT90-145600
Input voltage:
100-240V
Input AC frequency:
50/60Hz
Output voltage:
14,5V
Output current:
6,0A
Output power:
87W
Average active efficiency:
90%
Efficiency at low load (10%):
89%
No-load power consumption:
0.19W
POWER SUPPLY SPECIFICATION
