Yoda VP306 User manual

1
VP306 / VP306P
SIP VoIP Phone
Quick Installation Guide
&
User Manual
January 31, 2007

2
Memory Dial
1st SIP Account
2nd SIP Account
3rd SIP Account
Do Not Disturb
Voice
Message
Speaker
Phone
MicroPhone
Quick Installation Guide
Step 1: VP306 Keypads & Backplane

3
LAN
NAT
Router
ADSL
Modem
PHONE IP: 192.168.123.1
WAN
PC IP: 192.168.123.150
INTERNE
Step 2: Broadband (ADSL/Cable Modem) Connections for VP306
1. Connect VP306 RJ45 WAN port to ADSL NAT Router as the following connection.
2. Connect VP306 RJ45 LAN port to Notebook PC LAN port using a Category 5 LAN cable.
3. Connect DC Power Adaptor. The LCD Panel will start showing Loading Program!
4. The LCD panel will show Date,Time and No service without SIP registration, or <phone number>
after successful SIP registration.
5. Pick up the phone, and the LCD panel will show IP Dialing.. 1.Please hang up.
6. Press Menu_4 _5 from the keypad to check the LAN IP address (default: 192.168.123.1) for
VP306.
7. The Menu key is used for menu/escape, the Up Down keys for arrow and the Enter key for
selection.
Figure A. ADSL Connections with NAT Router for VP306
Step 3: Configurations from Keypads
Keypad Settings for Password and SIP Account:
1. Press Menu_7_4, the LCD panel will show Password:
2. Press test (i.e. press 8two times_3three times_7five times_8two times_Enter) for password.
Note that you must enter the password first to access the other settings!!
3. Press Menu_5_Enter to configure First realm for SIP account.
Keypad Settings for IP Status:
1. IP Addresses for WAN and LAN Ports :Press Menu_4_5
2. WAN port Status :Press Menu_4_1_1
3. LAN port Status :Press Menu_4_2
Example: Network Settings for Fixed IP by Keypad (M=Menu; E=Enter)

4
For Network Settings, there are three choices for IP type in WAN Settings; Fixed IP, DHCP, and PPPoE.
For Fixed IP, the user must key in static fixed IP address, Subnet Mask, and Gateway IP with DNS
Server IP address.
1. Fixed IP:Press M_4_E_1_E_M_M_M to select Fixed IP and reboot.
2. Set IP Address:Press M_4_E_2_1 and enter 192*168*101*112 and E_M_M_M_M_M to reboot.
3. Set Subnet Mask:Press M_4_E_2_2 and enter 255*255*255*000 and E_M_M_M_M_M to
reboot.
4. Set Gateway IP:Press M_4_E_2_3 and enter 192*168*101*001 and E_M_M_M_M_M to reboot.
5. Set DNS Server IP address as the following page if necessary.
6. Power OFF and ON again.
Step 4: Configurations from PC Web Browser
1. Connect a notebook PC to the LAN port, and click IE to enter for Web configurations.
2. Press Menu_4_5 from keypad to get WAN and LAN IP addresses.
3. Given the IP address 192.168.123.1 for LAN port, enter http://192.168.123.1:9999 from IE Web
browser to display login page for Web configurations.
4. Login default username and password;
Username: root
Password: test
Click the “Login” button to enter for configurations.

5
5. The IE Web browser will show the following System Information page.
6. You need to set up the following web configurations: Phone, Network WAN/LAN Settings, SIP
Settings. Remember to submit, save and reboot for new configurations.
7. For WAN settings
DHCP:
This is for Dynamic IP address and is commonly selected for WAN IP address when NAT is selected.
Once selected, the IP address, Subnet mask, and Gateway IP will be automatically assigned.
Remember to click Submit button to get effective.
PPPoE:
This is for ADSL IP address when PPPoE protocol is used. Once selected, the user needs to enter
the PPPoE username and password, and the WAN port will get an IP automatically.

6
Bridge LAN mode:
The Bridge LAN mode can be selected when NAT is not needed. In this case, the WAN and LAN
port are transparent as Ethernet Bridge Hub. Note that the embedded NAT is enabled at default.
8. SIP Settings:You may configure up to 3 SIP registration accounts with the 3 realms in Service
Domain Settings.
Realm 1 (Default for 1st SIP registration account)
Active: ON
Display Name: 206
User Name: 206
Register Name: 206
Register Password: 1234
Proxy Server: 220.228.43.172:5070
Domain Server: 220.228.43.172:5070
Outbound Proxy:
Realm 2 & 3 (for 2nd & 3rd SIP registration accounts)
Active: ON
Display Name: 371
User Name: 371
Register Name: 371
Register Password: 1234567
Proxy Server: 210.72.128.106:5060
Domain Server: 210.72.128.106:5060
Outbound Proxy:

7

8
SIP Account Number Selections
With 3 SIP account registered numbers, the VP306 may receive all the incoming calls from the 3
SIP servers. Realm 1, 2, and 3 are used to configure the registered numbers for the 1st, 2nd,
and 3rd SIP servers, respectively. VP306 may register different phone numbers to different SIP
servers. You may press function key LINE-2 to select for the 2nd SIP server, and the LCD will
display the <phone number> for the SIP server registration. You may also press 2_*_Speaker
to select for the 2nd SIP server. In the same way, you may press LINE-3 (or 3_*_Speaker) to
select for the 3rd SIP server. The LINE-1 is used at default. Make sure all the Realm 1, 2 and 3
are all registered and the LED indicator REG will be ON.
9. The LCD will display the registered <phone number> after successful SIP registration to the 1st SIP
server at default.
Step 5: Making Point-To-Point SIP Calls
1. Select one of the three SIP servers. Pick up the phone, and you should hear a dial tone.
2. Press 123456# to call the party with the number 123456 registered in the SIP server. Note #is
used to send out the call immediately. In a moment, you should hear the ring back tone, and wait for
the called party to answer.
3. For more applications, please refer to the user manual for VoIP Applications Examples.
Note: 1) if you have difficulties in configuring VP306, please refer to the last chapter for trouble
shootings.
2) VP306P is the same as VP306 with additional Power over Ethernet feature. With power
supply over Ethernet cable from central Ethernet Switch, VP306 may work without
external power adapter.

9
VP306 / VP306P
SIP VoIP Telephone
User Manual
V2.1f

10
Table of Content
1. Introductions 11
2. Features 11
3. Standard Compliances 12
4. Packing Contents 12
5. LED Indicators 12
6. Installations & SIP Configurations 13
7. Default Reset by Using Keypads 13
8. Configurations by Web Browser 14
9. LCD Display with Keypads Settings 51
10. VoIP Application Examples 55
11. Trouble Shooting for Web Configurations 59

11
1. Introductions
The VP306 is an IP Telephone with SIP Protocols for Voice over IP (VoIP) applications. Connecting to
the Internet, the VP306 can make a VoIP call over the Internet. The VP306 provides one WAN port for
Internet ADSL connections, and one LAN port for Notebook PC. With an embedded NAT/DHCP
server, VP306 can be easily configured for different network diagrams by IE Web browser and
telephone keypads. VP306P is the same as VP306 with additional Power over Ethernet feature. With
power supply over Ethernet cable from central Ethernet Switch, VP306 may work without external
power adapter. It is very convenient for ITSP (Internet Telephony Service Providers) and SOHO users
to make VoIP calls with registrations to IP PBX.
Note that VP306 requires an IP address, a subnet mask, and its gateway Router IP address for its own
use to connect to Internet. These three are available from your Internet service provider. VP306
may enable PPPoE or DHCP features to automatically get an assigned dynamic IP from the ITSP.
Please refer to Section 8 Configurations by Web Browser for detailed information.
2. Features
Equipped with two RJ45 connectors VP306 is featuring as the following
ØTwo LED Indicators: REG for registration, VMS for voice mail
ØRJ45 x 2 for WAN and LAN ports
ØSupport Power over Ethernet feature (for VP306P only)
ØConfigurations by Web Browser and Telephone Keypads
ØEmbedded NAT/DHCP Server
ØPPPoE/DHCP Client for Dynamic IP plus NAT, DNS, and DDNS Clients
ØSupport STUN server for NAT Traversal
ØSupport registrations for up to 3 SIP Servers.
ØHot Line Mode
ØSupport SMS of VOIP ( SIP server need to support)
ØDial Plan Settings
ØSpeaker Phone, Voice Message (VMS) for incoming IP calls
ØCall Forward/Transfer/Waiting/Hold, and 3-Way Conference Call features
ØAuto Configurations by TFTP, HTTP, or FTP server
ØRemote Firmware Upgraded with HTTP or TFTP server by Web PC
ØDirect IP/URL Dial without SIP Proxy or Dial number via SIP server
ØTelephone features: Volume Adjustment, Phone book, Redial
ØFunction Keys: Speed Dial, 3 SIP Registration Lines, DND, VMS, and Pickup
ØOut-Band DTMF (RFC 2833) / In-Band DTMF / Send DTMF SIP Info

12
3. Standard Compliances
The VP306 VoIP Phone supports for the following standards
VoIP Protocol: IETF RFC3261 and RFC 2543 for SIP
SIP Authentication: IETF RFC2069 and RFC 2617 for MD5
Speech Codec: ITU-T G.711, G.723, G.729A/B, VAD and CNG
Echo Cancellation: ITU-T G.165/168
4. Packing Contents
Inside the package you should find:
(1) One VP306 SIP Phone
(2) One AC to DC Power Adaptor (9~12VDC/1A)
(3) One User Manual CD
Please check if the packing is damaged or any component is missing. If so, please contact your
distributor.
5.
LED Indicators
On the front panel of VP306, there are three LED indicators as the following
REG: “Green On” indicates successful registration at SIP server.
VMS: “Red Flashing” indicates there are voice messages for incoming VoIP call.
To hear the message you may press the Speaker Phone key then VMS function key.

13
6. Installations & SIP Configurations
1. Connect VP306 RJ45 WAN port to NAT Router using a Category 5 LAN cable.
2. Connect RJ45 LAN port to Notebook PC using a Category 5 LAN cable.
3. Connect DC Power Adaptor. The LCD Panel will start displaying ”Loading Program”for about 5
seconds, and the LEDs will be ON and start initializations.
4. . The LCD panel will show Date,Time and No service without SIP registration, or <phone
number>after successful SIP registration.
5. Pick up the phone, and you will hear a dial tone and the LCD panel will show IP Dialing.. 1. If you
hear a busy tone, please check if the WAN port is connected and hang up.
6. Press Menu_7_4, and test (i.e. press 8two times_3three times_7five times_8two times_enter)
to enter password first. Press Menu_4_5 from keypad to read WAN and LAN IP addresses.
The default LAN IP address is 192.168.123.1.
7. Go to Chapter 8 and you may enter this IP address in IE Web browser for web configurations.
Configure and register VP306 into your SIP server. There are more details and examples for
VoIP application of SIP registrations in Chapter 10.
8. If VP306 has successfully registered in the SIP server, the LED REG will turn ON.
9.
Pick up the phone, and press 123456# to call the party with the number 123456 registered in the
SIP server. Note that #will dial out the number immediately. Dialing without #will not dial out until
the auto dial timer (default=5 seconds) elapsed. In a moment, you should hear a ring back tone,
and wait for answer.
7. Default Reset by Using Keypads
Press Menu / 7.Administrator / 3.Default setting / 1.Load default by using Menu and arrow keys
to reset back to factory defaults, and the LCD panel will show Set Default…. In 5 seconds, the LCD
will start showing Loading Program and System Initialized. The VP306 will reset to default and
restart.
Press Menu / 7.Administrator / 7.Restart to reboot VP306. In 5 seconds, the LCD will start showing
Loading Program and System Initialized.

14
8. Configurations by Web Browser
You may enter the IP address from PC Web browser to configure VP306. For example, enter
http://192.168.123.1:9999 from IE web browser to display login page as follows.
8.1. Please enter the default IP address http://192.168.123.1:9999 from PC Web browser.
The following Web page shall be displayed on PC. If you have difficulties accessing the Web
page from the PC Web browser, the subnet IP of PC might be different from 192.168.123.xxx.
In this case, please refer to Chapter 9 for trouble shooting.
8.2. Please enter the username and password into the blank field. The default settings are:
Username: root
Password: test
8.3. Click the “Login” button to enter the System information page for web configurations.
Whenever you change the setting in each Web page, remember to click the “Submit” button in the
page, and click the “Save” button to save into the non-volatile memory and click the “Reboot”
button to activate the new settings.

15
System Information
8.4. The system information shows firmware version, Codec, etc.
8.5. You may click the buttons, for example Phone Book, at the left hand side to configure the VP306.
Phone Book
Phone Book Settings
8.6. You may add/delete Name up to maximum 140 entries in Phone book list.
8.7. To add a phone name, you need to enter the position, the name, and the phone URL. When you
finished a new phone list, just click the “Add Phone” button.
8.8. To delete a phone name, please select the phone name then click “Delete Selected” button.
8.9. To delete all phone names, please click “Delete All” button.
8.10. After dialing a phone number, the VP306 will first match with the Name in the phone book. If
matched, VP306 will send out the corresponding URL instead. If not, the same dialed number will
be sent out.
Example 1: Name: 333, URL: 192.168.1.100
Press 333# on telephone, and the phone at 192.168.1.100 will start ringing.
Example 2: Name: 201, URL: 14081234567

16
Press 201# on telephone, and VP306 will call the registered number 14081234567.
Example 3: Name: 301, URL: 192.168.1.100:5062
Press 301# on telephone, and VP306 will call at 192.168.1.100 with port 5062.
Example 4: No Name 401 in phone book.
Press 401# on telephone, and VP306 will call the registered number 401.

17

18
Speed Dial Phone List
8.11. You can add/delete Speed Dial number up to maximum 10 entries in Speed Dial Phone List.
8.12. If you need to add a phone number into the Speed Dial list, you need to enter the position, the
name, and the URL. Click the “Add Phone” button to finish the setting.
8.13. To delete a phone number, please select the phone number you want to delete then click “Delete
Selected” button. If you want to delete all phone numbers, please click “Delete All” button.
Example 1: Press 2# from keypad to Speed Dial the phone number 2immediately.
Example 2: Press M2 function key will Speed Dial the phone number 2immediately.

19
Phone Setting
Call Forward
8.14. You can select the forward mode and enter the forward URL.
All Forward: All incoming call will forward to the URL you choose.
Busy Forward: The incoming call will forward to the URL when you are busy and on the phone.
No Answer Forward: The incoming call will forward to the URL when no answer.
8.15. You need to set the Time Out ring which will initiate No-Answer forwarding to the number you
choose. When you finished the setting, please click the “Submit” button.

20
SNTP
8.16. You can setup the primary and the second SNTP Server IP Addresses to get the date/time
information. You may also set the Time Zone, and how long need to synchronize again. When
you finished the setting, please click the “Submit” button.
