YOKOGAWA JUXTA VJA7 Series User manual

Model VJA7
Distributor
(Multi-function)
(Isolated Single-output and
Isolated Dual-output Types)
IM 77J01A07-01E
5th Edition Aug. 2020
CAUTIONARY NOTES FOR SAFE USE OF THE
PRODUCT
This User’s Manual should be carefully read before installing and
operating the product. Please keep this User’s Manual for future
reference.
For more information of the safety precautions, please refer to the
“Precautions on the Use of the JUXTA Series (IM 77J01A00-91Z1)”.
The related manuals and general specications are shown in the
table below.
Doc. Name Doc. Number
Precautions on the Use of the JUXTA Series (User’s Manual)
IM 77J01A00-91Z1
Model VJA7 Distributor (User’s Manual) IM 77J01A07-01E
(This manual)
Model VJA7 Distributor (General Specifications) GS 77J01A07-01E
User’s manuals in the above table are essential parts of the
product; keep it in a safe place for future reference.
This manual is intended for the following personnel;
• Engineers responsible for installation, wiring, and maintenance
of the equipment.
• Personnel responsible for normal daily operation of the
equipment.
The following symbol is used on the product and in this manual to
ensure safe usage.
WARNING
Calls attention to actions or conditions that could
cause serious or fatal injury to the user, and indicates
precautions that should be taken to prevent such
occurrences.
CAUTION
Calls attention to actions or conditions that could
cause injury to the user or damage to the instrument
or property and indicates precautions that should be
taken to prevent such occurrences.
CHECKING PRODUCT SPECIFICATIONS
AND THE CONTENTS OF PACKING
(1) Model Number and Specication Check
Check that the model number and specications shown on the
nameplate attached on the side of the product are as ordered.
(2) Contents of the Packing
Check that the packing contains the following items:
• VJA7: 1 unit
Standard Accessories:
• Tag number label: 1 sheet
• User’s manual (IM 77J01A07-01E, this manual): 1 copy
• User’s manual (IM 77J01A00-91Z1): 1 copy
GENERAL
This distributor, which belongs to the JUXTA series of signal
conditioners, receives 4 to 20 mA DC signals from two-wire
transmitters while supplying power to transmitters and converting
the received signal to pairs of isolated current and voltage signals.
• Output-2 signal is selectable from a DC voltage signal, DC
current signal, communication function (RS-485), and alarm
output (two relay contacts). (Isolated Dual-output Type)
• Various parameters can be set and modied using a PC
(VJ77 (sold separately)) or Handy Terminal (JHT200 (sold
separately)) and the like.
MODEL AND SUFFIX CODES
Model Sux codes Description
VJA7 -0 x x -A xx0/x Distributor (Multi-function)
Fixed
code -0 Always -0
Output
conguration
11 output
22 outputs
Power supply 6100-240 V AC/DC*1
715-30 V DC*2
Input signal -A
4 to 20 mA DC
Transmitter power supply:
25.25 ± 0.25 V DC
Output-1 signal
A4 to 20 mA DC
61 to 5 V DC
Z(Custom order)*3
Output-2 signal
A4 to 20 mA DC
61 to 5 V DC
P
Communication function (RS485)
TAlarm output (2 relay contacts)
NNo output-2
Fixed code 0Always 0
Option
/SN
No socket (with socket if not specied)
/C0 HumiSeal coating*4
/FB Fuse bypass*4
*1: Operating range: 85 to 264V AC/DC
*2: Operating range: 12 to 36V DC
*3: DC voltage signal or DC current signal
*4: When option code /C0 or /FB is specied, the conformity to the safety
and EMC standards is excluded. CE marking is not applicable.
1. MOUNTING METHODS
CAUTION
●Plug/disconnect the main unit into/from the
socket vertically to the socket face. Otherwise the
terminals may bend and it may cause bad contact.
●The converter shall not tilt 5 degrees or more in
either direction when installed.
●When the converter is not connected to the socket,
it is necessary to protect the socket against ingress
of dust to the connector part.
●Keep this product in a conductive bag when
plugged out, during transport or storage.
User’s
Manual
1
Thank you for purchasing the JUXTA Signal Conditioner.
Please read through this manual before use for correct handling.
2-9-32, Naka-cho Musashino-shi, Tokyo 180-8750 Japan
http://www.yokogawa.com/ns/juxta/im/
You can download the latest manuals from the following website:

1.1 Wall Mounting
Loosen the main unit-xing screw of the distributor to disconnect
the main unit from the socket. Next, anchor the socket onto the
wall with screws. Then, plug the main unit into the socket and
secure the main unit with the main unit-xing screw.
29.5 or more
22±0.2
2-M4 or
2-ø
4.5 or more
Mounting Dimensions
Unit: mm
59±0.3
Main unit-fixing screw
Socket
Main unit
Threaded hole for
fixing the main unit
Mounting screws
1.2 DIN Rail Mounting
Locate the distributor so that the DIN rail ts into the upper part
of the DIN-rail groove at the rear of the socket, and fasten the
socket using the slide lock at the lower part of the socket.
DIN rail
DIN rail
(Rear of socket)
Slide lock
DIN rail
Fit into here
Push
1.3 Mounting Using a Multi-mounting Base
For mounting using a multi-mounting base, see the Instruction
Manual for VJCE (VJ Mounting Base).
1.4 Using Ducts
Wiring ducts should be installed at least 30 mm away from the top
or bottom of the main unit.
2. INSTALLATION AND ENVIRONMENTAL
CONDITIONS
• Avoid the following environments for installation locations:
Areas with vibrations, corrosive gases, dust, water, oil,
solvents, direct sunlight, radiation, a strong electric eld,
and/or a strong magnetic eld, direct radiant heat, wind,
temperature uctuation.
• If there is any risk of a surge being induced into the power line
and/or signal lines due to lightning or other factors, a dedicated
lightning arrester should be used as protection for both the
product and a eld-installed device.
• Use indoors at an altitude of 2000 m or less.
• Operating temperature/humidity range: −10 to 55°C (−10
to 45°C for side-by-side mounting*)/5 to 90%RH (no
condensation)
* If the previous model (style S3.xx earlier) is installed
together, the ambient temperature is 0 to 40°C.
• Continuous vibration: (at 5 to 9 Hz) Half amplitude of 3 mm or
less (at 9 to 150 Hz) 9.8m/s2 or less, 1 oct/min for 90 minutes
each in the three axis directions
• Impact: 98 m/s2 or less, 11 ms, 3 axes, 6 directions, 3 times
each
3. EXTERNAL WIRING
WARNING
●To avoid the risk of an electric shock, turn o the
power supply and use a tester or similar device to
ensure that no power is supplied to a cable to be
connected, before carrying out wiring work.
●Do not operate the product in the presence of
ammable or explosive gases or vapors. To do so is
highly dangerous.
●Use of the product ignoring the specications may
cause overheating or damage. Before turning on
the power, ensure the following:
• Power supply voltage and input signal value
applied to the product should meet the required
specications.
• The external wiring to the terminals and wiring to
ground are as specications.
Wiring should be connected to the terminals on the socket of
the product. The terminals for external connections are of M3
screws. Use crimp-on terminal lugs for connections to the
terminals.
• Recommended cables: A nominal cross-sectional area of
0.5 mm2 or thicker for signal cables, and that of 1.25 mm2 or
thicker for power cables.
Wiring Diagram
When internal
power is used
When external
power is used
Input signal
Analog output
Output-1 signal
Analog output
Output-2 signal
Alarm output
RS-485
communication
Power Supply
Transmitter Transmitter Transmitter
(NO)
(NO)
1011
3 2 1
4
56
789
1110 8
L+N–GND
+
–
+
–
5
2
6
5
2
9
7
ALM1
ALM2
COM 5
2
6
B+
A–
COM
1
3
PS+
–
+
–3
–
+
–
4
COM
When using as
an isolator
4
3
COM
+
–
CAUTION
●Do not use output-2 for the isolated single-output type.
●The power line and input/output signal lines should be
installed away from noise-generating sources. Other
wise accuracy cannot be guaranteed.
●Make sure to earth ground the ground terminal
through minimum resistance. The length and
thickness of the grounding cable should be as
short and thick as possible. Directly connect the
lead from the ground terminal (terminal no. 8) of
the product to the ground. Do not carry out daisy-
chained inter-ground terminal wiring.
●The product is sensitive to static electricity;
exercise care in operating it. Before you operate
the product, touch a nearby metal part to discharge
static electricity.
●The use of inductance (L) loads such as auxiliary
relays and solenoid valves causes malfunction or
relay failure; always insert a CR lter or diode for
spark-removal into the line in parallel with the load.
Recommended CR
• C: 0.5 to 1µF against contact current 1A
• R: 0.5 to 1Ω against contact voltage 1V
●If the ambient temperature is 50 °C or more, please
use the cable that the rated temperature is 70 °C or
more.
2IM 77J01A07-01E 5th Edition

4. DESCRIPTION OF FRONT PANEL AND
CONNECTION OF HANDY TERMINAL
4.1 Front Panel
The communications connector in the front panel is used for
setting up parameters through the Handy Terminal. The alarm-1
and alarm-2 LEDs light up if an alarm occurs (those LEDs are
provided only when the output-2 is specied for alarm output (the
output-2 sux code is T).)
Alarm indicator lamp
(for alarm 1)
Communication connector
Alarm indicator lamp
(for alarm 2)
4.2 Connector for Communication
Connect the modular jack-to-connector adapter to the connection
cable (with 5-pin connector) of the Handy Terminal and then
connect this adapter to the communications connector of the
distributor.
< How to connect with the setting tool>
JUXTA communication
cable with 5-pin
connector
Modular jack
conversion
adapter
Dedicated adapter
Dedicated cable
<How to connect with the setting tool>
JUXTA
VJ Series
PC with the
VJ77 installed
JHT200
Handy Terminal
• Use the VJ77 of version R2.02.01 or later.
• The modular jack conversion adapter does not come with the
JHT200 Handy Terminal. It is sold separately.
5. SETTING PARAMETERS
Set the parameters using a PC (VJ77 Parameter Setting Tool) or
the Handy Terminal. Refer to “7. LIST OF PARAMETERS” in this
manual and the User’s Manual for VJ77 PC-based Parameters
Setting Tool (IM 77J01J77-01E) or the User’s Manual for JHT200
Handy Terminal (IM 77J50H01-01EN).
5.1 Settings Related to Inputs and Outputs
5.1.1 Square Root Extraction
Select SQR in [D41: LINEARIZE]. To linearize the signal, set
[D41: LINEARIZE] to SQR. Not to linearize the signal, set
[D41: LINEARIZE] to OFF.
5.1.2 Low-cut Function
Set this parameter when an input signal is square-root
extracted for use. Set it in [D42: LOW CUT] numerically.
• Setting range: A range of 0 to 100% of input range
• Setting resolution: 0.1%
Input signal (X)
0
Low-cut point
Hysteresis
(Fixed to 0.2%)
Y=X
Output signal (Y)
5.1.3 Linearization
Set the breakpoint linearization in [D41: LINEARIZE].
Select “ON” to use the breakpoint linearization.
Select “OFF” not to use the breakpoint linearization.
Set the breakpoints data.
Set the input breakpoints data in [M01: X TABLE] to [M32: X
TABLE].
Set the number of breakpoints data in [M33: MAX POINT].
Set the output breakpoints data in [N01: Y TABLE] to [N32: Y
TABLE].
• Setting condition of breakpoints data
Maximum number of breakpoints: 32
Setting range: −6 to 106% (both input and output)
• Set a relationship between the input and output at % value
to the span.
• With 4 signicant digits; can be set to the second place of a
decimal point.
• For input: −6.00 % ≤ X0< X1< X2… Xn-1 < Xn ≤ 106.0%
• For output: −6.00 % ≤ Y0 to Yn ≤ 106.0%
5.1.4 Software Filter
Set the software lter in [D57: S/W FILTER].
OFF, LOW, MIDDLE, HIGH (default value: OFF)
When LOW, MIDDLE, or HIGH is selected, a rst-order lter
equivalent to 100 ms, 300 ms, or 1 s is inserted in the input.
5.1.5 Direction of Output Action
Analog output signals can be reversed. To reverse the signal
from output-1, set [D50: OUT1 DR] to REVERSE. For
output-2, set [D51: OUT2 DR] to REVERSE. To return the
output-1 signal to normal, set [D50: OUT1 DR] to DIRECT.
For output-2, set [D51: OUT2 DR] to DIRECT.
5.2 Settings Related to Communication
Function
Set the following parameters when output-2 is specied
for communication function. For more information on the
communication function, see the Instruction Manual for VJ Series
Communication Function (IM 77J1J11-01E).
5.2.1 Communication Protocol
Set the communication protocol by selecting from among PC-
LINK, PC-LINK WITH SUM, MODBUS ASCII, MODBUS RTU,
and LADDER in [F01: PROTOCOL].
5.2.2 Communication Address
Set the address number of the distributor numerically in a
range of 1 to 99 in [F02: ADDRESS].
5.2.3 Baud Rate
Set the baud rate by selecting from among 1200, 2400, 4800,
9600, 19200, and 38400 bps in [F03: BAUD RATE].
5.2.4 Parity
Select and set NONE, EVEN, or ODD in [F04: PARITY].
5.2.5 Data Length
Select and set 7 bits or 8 bits in [F05: DATA LEN].
5.2.6 Stop Bit
Select and set 1 bit or 2 bits in [F06: STOP BIT].
5.2.7 Input Decimal Point Position
Number of digits of decimal places (setting of D register
[D0003]) can be set.
Select and set among 0 to 5 digits in [F07: INPUT DEC PT].
3IM 77J01A07-01E 5th Edition

5.3 Settings Related to Alarm Output
Set the following parameters when output-2 is specied for alarm
output.
5.3.1 Alarm Setpoints
Set the alarm setpoints of alarm-1 and alarm-2 in [E03: SET
POINT1] and [E04: SET POINT2] numerically.
• Setting range: A range of 0 to 100% of input range
• Setting resolution: 0.1%
5.3.2 Direction of Alarm Action
Select the direction of alarm-1 action and that of alarm-2
action from among HIGH ALM (high-limit alarm) and LOW
ALM (low-limit alarm) and set each in [E05: ALM1 ACTION]
(direction of alarm-1 action) or [E06: ALM2 ACTION]
(direction of alarm-2 action).
• To activate alarm status when input signal ≥ alarm setpoint,
select HIGH ALM.
• To activate alarm status when input signal ≤ alarm setpoint,
select LOW ALM.
5.3.3 Hysteresis
Set alarm-1 and alarm-2 hysteresis, in [E09: HYSTERESIS1]
and [E10: HYSTERESIS2]. Hysteresis is a value added to the
alarm setpoint in order for an alarm status to be released (to
normal) after the alarm status has been activated. The alarm
status will be released in the following conditions, depending
on the direction of alarm action.
* When HIGH ALM (high-limit alarm) is set: Alarm is released
when input signal < (alarm setpoint - hysteresis).
* When LOW ALM (low-limit alarm) is set: Alarm is released
when input signal > (alarm setpoint + hysteresis).
• Setting range: A range of 0 to 100% of input range
• Setting resolution: 0.1%
5.3.4 Alarm ON Delay and Alarm OFF Delay
Set alarm-1 and alarm-2 ON delays in [E11: ON DELAY1] and
[E12: ON DELAY2] and then alarm-1 and alarm-2 OFF delays
in [E13: OFF DELAY1] and [E14: OFF DELAY2].
An alarm ON delay is a delay time from the establishment of
alarm condition to alarm output; an alarm OFF delay is a delay
time from the establishment of return-to-normal condition to
output.
• Setting range: 0 to 999 seconds
• Setting resolution: 1 second (Note that about 0.2 second
will be added to set time to prevent erroneous operation.)
For example, when an alarm ON delay is set to 1 second,
alarm output is generated if alarm status continues for
more than 1 second after the input value exceeds the
alarm setpoint. Further, when an alarm OFF delay is set
to 2 seconds, alarm output is released if normal condition
continues for more than 2 seconds after the input value has
returned to normal from the alarm status.
5.3.5 Direction of Relay Action
Set the direction of relay energizing in alarm-1 normal
condition and alarm-2 normal condition by selecting from
among NRM DE-ENERGIZED (de-energized under normal
condition) and NRM ENERGIZED (energized under normal
condition) in [E15: RL1 ACTION] and [E16: RL2 ACTION]
and set them.
6. DESCRIPTION OF ALARM ACTIONS
This chapter describes examples of alarm actions under the
following conditions.
Item Alarm 1 Alarm 2
Parameter Setpoint Parameter Setpoint
Direction of alarm
action
E05: ALM1 ACTION High-limit
alarm
E06: ALM2 ACTION Low-limit
alarm
Alarm setting E03: SET POINT1 80% E04 : SET POINT2 15%
Hysteresis E09: HYSTERESIS1 10% E10 : HYSTERESIS2 5%
Alarm ON delay E11: ON DELAY1 1 sec E12 : ON DELAY2 3 sec
Alarm OFF delay E13: OFF DELAY1 2 sec E14 : OFF DELAY2 4 sec
Description of
alarm actions
The alarm is output if the
condition where the input value
is 80% or more of high-limit
alarm continues for 1 second
or more.
After the alarm is output, when
the condition where the input
value is less than 70% of
high-limit alarm continues for
2 seconds or more, the status
returns to normal.
The alarm is output if the
condition where the input value
is 15% or less of low-limit
alarm continues for 3 seconds
or more.
After the alarm is output, when
the condition where the input
value is more than 20% of
low-limit alarm continues for
4 seconds or more, the status
returns to normal.
Figure 6.1
Alarm-1 action
Alarm-2 action
Normal Normal
Normal
Normal
Alarm
Alarm
[%]
0
20
15
40
60
80
100
1 s. 2 s.
3 s. 4 s.
Alarm-2 hysteresis (5%)
Alarm-1 hysteresis (10%)
Alarm-1 setpoint (80%)
Alarm-2 setpoint (15%)
Elapsed time s.
[1] [2]
[3] [4]
Alarm-1
ON delay
Alarm-2
ON delay
Alarm-2
OFF delay
Alarm-1
OFF delay
Alarm conditions established
Alarm conditions
established
Normal conditions
established
Normal conditions established
High-limit alarm ON
Low-limit alarm ON
High-limit alarm OFF
Low-limit alarm OFF
[1] Alarm status does not continue for more than 1 second after the
alarm conditions are established at alarm 1.
[2] Normal status does not continue for more than 2 seconds after
the normal conditions are established at alarm 1.
[3] Alarm status does not continue for more than 3 seconds after the
alarm conditions are established at alarm 2.
[4] Normal status does not continue for more than 4 seconds after
the normal conditions are established at alarm 2.
4IM 77J01A07-01E 5th Edition

7. LIST OF PARAMETERS
Parameter Display Item
MODEL Model
TAG NO Tag no.
SELF CHK Self-check result
A DISPLAY1 Display 1 *2
A01 INPUT1 Input value 1
A09 OUTPUT1 Output value 1
A10 OUTPUT2 Output value 2
A15 ALM1 STATUS Alarm-1 status
A16 ALM2 STATUS Alarm-2 status
A54 STATUS Status *1
A56 REV NO Rev. no.
A58 MENU REV MENU REV
A60 SELF CHK Self-check result
B DISPLAY2 Display 2 *2
B01 INPUT1 Input value 1
B09 OUTPUT1 Output value 1
B10 OUTPUT2 Output value 2
B15 ALM1 STATUS Alarm-1 status
B16 ALM2 STATUS Alarm-2 status
B60 SELF CHK Self-check result
D SET (I/O) Setting (I/O) *2
D01 TAG NO.1 Tag no. 1
D02 TAG NO.2 Tag no. 2
D03 COMMENT1 Comment 1
D04 COMMENT2 Comment 2
D32 OUT1 L_RNG Output-1 low range *3
D33 OUT1 H_RNG Output-1 high range *3
D34 OUT2 L_RNG Output-2 low range *3
D35 OUT2 H_RNG Output-2 high range *3
D41 LINEARIZE Linearize
D42 LOW CUT Low cut
D50 OUT1 DR Direction of output-1 action
D51 OUT2 DR Direction of output-1 action
D57 S/W FILTER Software lter
D59 NMRR Frequency setting *3
D60 SELF CHK Self-check result
E SET(ALM) Setting (alarm output) *2
E03 SET POINT1 Alarm-1 setting (%)
E04 SET POINT2 Alarm-2 setting (%)
E05 ALM1 ACTION Direction of alarm-1 action
E06 ALM2 ACTION Direction of alarm-2 action
E09 HYSTERESIS1 Alarm-1 hysteresis (%)
E10 HYSTERESIS2 Alarm-2 hysteresis (%)
E11 ON DELAY1 Alarm-1 ON delay setting
E12 ON DELAY2 Alarm-2 ON delay setting
E13 OFF DELAY1 Alarm-1 OFF delay setting
E14 OFF DELAY2 Alarm-2 OFF delay setting
E15 RL1 ACTION Direction of alarm-1 relay action
E16 RL2 ACTION Direction of alarm-1 relay action
E60 SELF CHK Self-check result
F SET(COM) Setting (communication) *2
F01 PROTOCOL Communication protocol
F02 ADDRESS Address
F03 BAUD RATE Baud rate
F04 PARITY Parity
F05 DATA LEN Data Length
F06 STOP BIT Stop bit
F07 INPUT DEC PT Decimal point position of input
F60 SELF CHK Self-check result
M X TABLE Input breakpoint table *2
M01 X TABLE Input breakpoints data
M02 X TABLE Input breakpoints data
⁞ ⁞ ⁞
M31 X TABLE Input breakpoints data
M32 X TABLE Input breakpoints data
M33 MAX POINT Number of breakpoints
M60 SELF CHK Self-check result
N Y TABLE Output breakpoint table *2
N01 Y TABLE Output breakpoints data
N02 Y TABLE Output breakpoints data
⁞ ⁞ ⁞
N31 Y TABLE Output breakpoints data
N32 Y TABLE Output breakpoints data
N60 SELF CHK Self-check result
P ADJUST Adjustment *2
P04 IN1 ZERO ADJ Zero adjustment of input-1
P05 IN1 SPAN ADJ Span adjustment of input-1
P30 OUT1ZERO ADJ Zero adjustment of output-1
P31 OUT1SPAN ADJ Span adjustment of output-1
P32 OUT2ZERO ADJ Zero adjustment of output-2
P33 OUT2SPAN ADJ Span adjustment of output-2
P60 SELF CHK Self-check result
Q TEST Test *2
Q04 OUT1 TEST Forced output (output 1)
Q05 OUT2 TEST Forced output (output 2)
Q10 ALM1 TEST Forced output (alarm 1)
Q11 ALM2 TEST Forced output (alarm 2)
Q60 SELF CHK Self-check result
*1 The Status is displayed for service personnel to see history
records.
*2 There are items not displayed depending on what output-2
is specied.
X TABLE/Y TABLE is displayed when D41:LINEARIZE=ON.
*3 The parameters are the items to be set at the factory.
8. MAINTENANCE
The product starts running immediately when the power is turned
on; however, it needs 10 to 15 minutes of warm-up before it
meets the specied performance.
For cleaning the instrument, use a soft and dry cloth.
8.1 Calibration Apparatus
• A voltage and current generator (YOKOGAWA GS200 or the
equivalent)
• A voltmeter (YOKOGAWA 7561 or the equivalent)
• A precision resistor of 250 Ω ± 0.01%, 1 W (for current output)
• Setting tool for adjustment (Refer to "4.2 Connector for
Communication" in this manual.)
8.2 Calibration Procedure
1. Connect the instruments as shown in gure below. First adjust
the output-1 signal and then the output-2 signal.
Power Supply
Output-1 signal
R: For current output using 250 Ω
precision resistor
Voltage and
current
generator
Voltage and
current
generator
Output-2 signal
1011
3 2 1
4
56
789
1110 8
L+N–GND
3
4
+
–
Without SINK current
Input signal
DMM
DMM
DMM
DMM
2
5
R
+
–
1
3
+
–
With SINK current 2
5
Alarm-1 output
Alarm-2 output
ALM1
(NO)
COM
+
–
6
5
ALM2
(NO)
COM
+
–
7
9
R
+
–
2. Produce input signals equivalent to 0, 25, 50, 75, and 100% of
the input span (or those equivalent to 0, 6.25, 25, 56.25, and
100% of the input span if square root extraction is set) from
the voltage and current generator to the distributor.
3. Then, check that the distributor’s output signal shows voltages
corresponding to 0, 25, 50, 75, and 100% of the input span
within the rated accuracy range.
For alarm output, check the relay action by the alarm indicator
lamp or resistance of output terminals.
• When adjusting the output signal, use the VJ77 parameter
setting tool.
For adjustment using a setting tool, refer to the User’s Manual for
setting tool and “7. LIST OF PARAMETERS” in this manual.
User’s Manual for VJ77 [Document No.: IM 77J01J77-01E]
5IM 77J01A07-01E 5th Edition

9. SAFETY AND EMC STANDARDS
The following will be acquired.
Safety:
IEC/EN 61010-1 compliance (CE)
IEC/EN 61010-2-030 compliance (CE)
CAN/CSA-C22.2 No.61010-1 (CSA)
CAN/CSA-C22.2 No.61010-2-030 (CSA)
UL61010-1 (CSA NRTL/C)
UL61010-2-030 (CSA NRTL/C)
Overvoltage category: II
Pollution degree: 2
Measurement category: O (other)
Rated power supply voltage: 15-30 V DC (±10%) 3.6 W or
100-240V AC/DC (±10%)
50/60 Hz 3.6 W 8.8 VA
Rated voltage (Input signal) : 10 V DC
Rated voltage (Analog output signal): −10 to +10 V DC,
0 to 20 mA DC
Rated voltage (Alarm output signal) : 30 V DC 1A
Rated voltage (Communication output signal) : 5 V DC
Rated transient overvoltage: 1500 V (*)
* This is a reference safety standard value for the
measurement Category O. This value is not necessarily
a guarantee of instrument performance.
CAUTION
This instrument is for Measurement Category O
(other). Do not use it for measurements in locations
falling under Measurement Categories II, III, and IV.
Internal Wiring
Outlet
Entrance
Cable
III T
O
II
IV
Measurement
category
Description Remarks
O (other) For measurements
performed on circuits not
directly connected to MAINS.
II CAT.II For measurements
performed on circuits directly
connected to the low-voltage
installation.
Appliances,
portable
equipments,
etc.
III CAT.III For measurements
performed in the building
installation.
Distribution
board, circuit
breaker, etc.
IV CAT.IV For measurements
performed at the source of
the low-voltage installation.
Overhead
wire, cable
systems, etc.
EMC standards:
•CE:
EN 61326-1 Class A, Table 2
EN 61326-2-3
* The instrument continues to operate at a measurement
accuracy of within ±20% of the range during testing.
EN 55011 Class A, Group 1
EN 61000-3-2
EN 61000-3-3
•RCM:
EN 55011 Class A, Group 1
•KC:
Electromagnetic wave interference prevention standard,
electromagnetic wave protection standard
CAUTION
Caution to comply with EMC standards: When
operating this instrument by external power supply,
use an independent power unit conforming to the
respective standards. Be sure to use the lightning
arrester to comply EMC standards.
Note: When option code /C0 or /FB is specied, the conformity to
the safety and EMC standards is excluded.
10. ENVIRONMENT STANDARD
RoHS Directive: EN 50581
(However, when option code /C0 or /FB is specied, CE mark-
ing is not applicable because the product does not comply
with the Safety and EMC standards.)
11. TRANSPORT AND STORAGE CONDITIONS
• Temperature: -25 to 70°C
• Temperature change rate: 20°C per hour or less
• Humidity: 5 to 95%RH (no condensation)
CAUTION
Keep this product in a conductive bag when plugged
out, during transport or storage.
6IM 77J01A07-01E 5th Edition
Table of contents
