Yolink Garage Door Sensor 2 User manual

SET
Garage Door Sensor 2
User Guide
YS7706-UC

Contents
Product Required·····························································2
Introduction············································· ··················· ··1
Features······································································2
Set Up Garage Door Sensor 2··············································3
YoLink Control ·····························································16
Maintaining the Garage Door Sensor 2································19
Using YoLink App with Garage Door Sensor 2························12
Specifications···························································· ·· 21
Installation··························· · ····································· · ··8
Troubleshooting·························································· ·· 22
Customer Service and Warranty · 3································· ······2

1
YoLink Garage Door Sensor 2 can detect opening and closing of your Garage Door and send
alert or trigger action.
LED light can show you the current status. See the explanation below:s
Introduction
SET BUTTON
Red once
Alert.
Blinking Green
Connecting to cloud.
Fast Blinking Green
Paring with other devices (YoLink Control).
Fast Blinking Red
Unparing with other devices (YoLink Control).
Blinking Red and Green
Factory resetting.
Slow Blinking Green
Updating.
SET

2
Features
Check Status Anywhere - Monitor the real-time state of garage door via YoLink App.
Open Alert - Remind you while the door is open for a set up time.
Long Range - Up to 1,000 feet between Hub and device.
Battery Status - Update surplus of battery power and send low battery alert.
YoLink Control - Trigger an action of certain YoLink devices without internet.
Automation - Set up rules for “if this then do that” function via YoLink App.
IFTTT - Set up rules for “if this then that” function via IFTTT App.
Product Required
A YoLink Hub.
The smartphone or tablet able to run iOS 9.0 or higher; Android 4.4 or higher.

3
Set Up Garage Door Sensor 2
Follow the steps below to set up your Garage Door Sensor 2 via YoLink App.
Step 1: Set up YoLink App
Get the YoLink App from the Apple App Store or Google Play.
YoLink

4
If you don’t have a YoLink account, tap Sign up for an account and follow the steps
to sign up an account.
Open the App. Use your YoLink account to log in.
Step 2: Log in or sign up with YoLink account

5
Step 3: Add Garage Door Sensor 2 to YoLink App
b. Room - Choose a room for your Garage Door Sensor 2.
a. Name - Name your Garage Door Sensor 2.
You can customize the name, set the room, add to/remove from favourite.
Tap the “ ” in YoLink App. Scan the QR Code on the device.
c. Favourite - Click “ ” icon to add/remove from Favourite.
Tap the “Bind Device” to add the device to your YoLink account.
Pair with a controller.
Note
For better user experience, we suggest you to pair your YoLink Garage Door Sensor 2
with a YoLink Finger or a YoLink Garage Door Controller. After pairing you will get
real-time battery status of your Garage Door Sensor 2, signal Intensity between
YoLink Finger or Garage Door Sensor 2 and YoLink Hub, and the real-time status of
your garage door.
If you skip the pairing when adding the device, you can set the pairing on the Detail screen
of YoLink Finger.

6
a
b
c
SET

YoLink
SET
Cloud
DATA
(Internet)
DATA
(Internet)
DATA
(YoLink)
7
Step 4: Set up the connection
Follow the Installation to install the device first.
Press the SET button once on the device, a green blinking light will be shown and the
device is ready to use.
Note
Please note: YoLink Hub is required to set up Garage Door Sensor 2. Please set up your
YoLink Hub first.

8
Installation
Find an area at the top left in the inside garage door, clean the installation area.
Remove the protective layer of the double-side tape;
Keep the longer side of the Garage Door Sensor 2 parallel to the floor, stick the finger
to the clean area, press it for at least 5 seconds.
Remove the protective layer
2
Clean the installation area
1
TOP
PANEL

9
Stick and Press for 5 seconds at least
3
TOP
PANEL
SET
SET

10
Re-install the batteries and close the battery cover.
You can also mount the Garage Door Sensor 2 to the wall with screws.
Keep the longer side of the Garage Door Sensor 2 parallel to the floor, mount Garage
Door Sensor 2 to the top left of inside garage door using screws (not included).
Remove the battery cover and take out batteries.
Remove the battery cover
and take out batteries
1
SET
Mount the Garage Door Sensor 2
2
TOP
PANEL
SET
SET

11
Re-install the batteries and
close the battery cover
3
TOP
PANEL
SET

12
Using YoLink App with Garage Door Sensor 2
Tap the “Garage Door” in App to go to its controls.
Display the real-time battery status of your Garage Door Sensor 2, signal Intensity between
Garage Door Sensor 2 and YoLink Hub and the real-time status of your garage door.
Control

13
Details
a. Name - Name your Garage Door Sensor 2.
b. Room - Choose a room for your garage door device.
You can customize the name, set the room, set the alert and open alert, add to/ remove from
favourite, check device history.
d. History - Check the history log for the garage door.
c. Favourite - Click Add/Remove the device from Favourite.
g. Delete - Current device will be removed from your account.
f. Open Alert - Set a time which you will able to receive an alert once your door has been open
for that long.
e. Alert - Enable or disable alert for Garage Door Sensor 2.

14
Tap the icon for each of the setting you want to personalize.
Tap “ ” icon at the top-right corner.the
Tap the “Garage Door Sensor 2” in App to go to its controls.
g
a
b
c
d
e
f

15
Automation allows you to set up “if this then do that” rules so the devices can act automatically.
Automation
Tap “Smart” to switch to Smart screen and tap
“Automation”.
To set an Automation, you will need to set a
trigger time, local weather condition, or choose
a device with certain stage as a triggered
condition. Then, select the response devices or
Scenes.
Tap “ ” to create an automation.
Slide right or left the relative button to enable
or disable the Automation.
Note

YoLink Control
YoLink Control is our unique “device to device” control technology. Under YoLink Control,
the devices can be controlled without internet or Hub.
You will need to set it up physically.
Devices which send out command is called controller(Master). Devices which receive
command and act accordingly is called responder(Receiver).
Find a garage door sensor 2 as controller(Master).
Hold the set button for 5-10 seconds, the light
will flash green quickly.
After pairing is done, the light will stop flashing.
Find an action device as responder(Receiver).
Hold the set button for 5-10 seconds, the device
will enter pairing mode.
Whe n the doo r is detected to be opene d, the
res pond er w ill be turned o n as well.
Pairing
16
SET BUTTON
SET

17
Find the controller(Master) garage door sensor 2.
Hold the set button for 10-15 seconds, the light
will flash red quickly.
The above two devices will unpair by themselves
and the light stops flashing.
Find the responder(Receiver) action device.
Hold the set button for 10-15 seconds, the
device will enter unpairing mode.
When the garage door sensor 2 is detected to
be opened, the responder will no longer turn on.
Unpairing
Responder List
YS6602-UC YoLink Plug
YS6604-UC YoLink Plug Mini
YS5705-UC In-wall Switch
YS6801-UC Smart Power Strip
Continuously ..updating
YS6802-UC Smart Switch
YS6704-UC In-wall Outlet
SET BUTTON
SET

18
Diagram
UNPAIRED
TURN OFFTURN OFF
PAIRED
OPENED
TURN ONTURN OFF
CLOSED OPENEDCLOSED
SET SET
