Yolink YS7A01-UC Operation manual

Wireless
Communicaon Base
YS7A01-UC
Installaon & User Guide
Rev 1.0

Sincerely,
Queenie, Clair, James, Eric
Customer Support Team
Thank you for purchasing YoLink products and for entrusng us with your smart home needs!
Your 100% sasfacon is our goal. If you experience any problems with seng up your new
YoLink Wireless Communicaon Base, please give us a chance to assist you, before returning
your purchase.
We at Customer Support are here for you.If you need any assistance installing , seng up or
using a YoLink product or our app.
Find addional support and ways to reach us at:
www.yosmart.com/support-and-service
Or scan this QR code with your smartphone
Email us, 24/7 at:
[e-mail]
Call us, 9AM to 5PM Pacific Standard Time at:
[phone]
You may chat with us on Facebook (non-urgent maers):
www.facebook.com/YoLinkbyYoSmart

Contents
A.
B .
C .
D.
E .
F .
G.
H.
I .
J .
K .
In the Box ······· ····· · ·· · ··1······················ ····· ···················································· · ·
·Introducon ······························································································ 2
Set Up ····································································································· · 4· ·
Installaon ······························································· 6(With Detector Head) ·
Using the YoLink App ··················································7(With Detector Head)
About YoLink Control ················································14(With Detector Head)
Maintenance ······················································································· ····18·
Specificaons ····················································································· ·····20·
Troubleshoong ················································································· ·····21·
Warning ······························································································ ····22·
Customer Service & Warranty ······························································· ····23·
Revised: 07/29/2021
Copyright 2021 YoSmart Inc. All rights reserved©

1
A. In the Box
A. Wireless Communicaon Base
B. Quick Start Guide
B.
A.

B. Introducon
The YoLink Wireless Communicaon Base, works with a detector head (ANKA Smoke & CO Alarm,
model: AJ-939/AJ-933/AJ-938). Used in conjuncon with the Smoke & CO Alarm, it converts the
Smoke & CO Alarm into a smart alarm device. Add the Wireless Communicaon Base to the YoLink
app, you can monitor the real-me status of smoke and carbon monoxide in the detecon area, and
you can check the historical alarm record (including type, date and me) via the app. When smoke
or carbon monoxide is detected, it may be used as a trigger for custom automaons (for example,
turn off a gas valve when carbon monoxide is detected), as well as to iniate smartphone alerts and
noficaons based on your preferences.
2
Fixed Latches
Smoke & CO Alarm can
be inset by latches fixed
in the Wireless
Communicaon Base
SET Buon and
Status LED
Please refer to the
instrucons for the
ANKA Smoke & CO
A l a r m ( A J - 9 3 9 )
(packaged with the
detector)
Connect Pins
Connect the Wireless
Communicaon Base
with the Detector Head

The LED light indicates the current status of the wireless communicaon base:
3
Blinking Red Once, then Green Once
Device turned on
Fast Blinking Green
Establishing Connecon with YoLink System (YoLink Control)
Slow Blinking Green
Updang
Blinking Green
Connecng to Cloud
Blinking Red Once
Device is connected to the cloud and is funconing normally
Fast Red Every 30 Seconds Blinking
Baery is Low, Please Replace Your Wireless Communicaon Base
Fast Blinking Red
Removing Connecon to YoLink System (YoLink Control)
Blinking Red And Green Alternately
Restoring to Factory Defaults

C. Set Up
C-1. Set Up - First-Time YoLink Users (Exisng users proceed to C-2. Add Device, next page)
4
The YoLink Hub is required to
s e t u p y o u r W i r e l e s s
Communicaon Base. Please
set up your YoLink Hub first
(refer to YoLink Hub manual)
3
Power
Adapter
YoLink Hub
Log in to the YoLink app
2
Create a new account
if required
Download the YoLink app through
Apple App Store or Google Play
Store (Search in the store or use
the QR code on the right)
1
Apple iPhone or tablet that is iOS 9.0
or higher, or an Android phone or
tablet that is Android 4.4 or higher
YS1603-UC
User Guide
2. Ethernet patch cable (included) to
your network (router, switch, etc.),
recommended. Otherwise connect
your Hub to your home 2.4 GHz Wi-Fi
network (only when necessary).
Refer to the Hub set up manual for
more informaon:
1. Make sure your Hub is connected
to the internet (green LED indicator is
blinking, blue LED indicator is always
on)

C-2. Add Device
5
Ta p “ ” b u  o n , t h e n s c a n Q R
C o d e o n t h e d e v i c e . Fo l l o w th e
ste p s t o a d d t h e d e v i c e
1
Press the SET buon once to turn
on the device. The Status LED will
blink red once, then green several
mes, indicang your device has
connected to the cloud and is
ready to use
2
1. You will need to press the SET buon once again if the device failed to connect to the cloud
2. Pressing the SET buon at any other me aer this inial process will result in the LED blinking
red once, only. This indicates the device is connected to the cloud and is funconing normally
3. If the red LED does NOT blink as noted this may indicate a problem with the relay. Please see the
troubleshoong secon and the contact secon for technical support
SET Buon

D. Installaon (With Detector Head)
6
1. Please refer to the installaon manual packaged with the detector head (ANKA Smoke & CO Alarm,
AJ-939) to complete the installaon of your Smoke & CO Alarm
2. Press down the ACTIVATE buon on the boom of Detector Head unl the buon be locked to
acvate the detector head first before you connect the detector head to the wireless communicaon
base
Detector Head
(ANKA, AJ-939)
Wireless
Communicaon
Base
ACTIVATE
Buon
Detector Head
(ANKA, AJ-939)

E. Using the YoLink App (With Detector Head)
E-1. Device page
7
Auto Self-Test Schedule
Schedule regular automatic detector head self-tests (weekly or monthly)
Connecon Status
of smoke & CO alarm and Hub
Current Baery Level of Communicaon Base
- Shown red if baery level is low
Details
- Tap to go to Details page(refer to page 8 & 9)
Baery Level of Detector Head: High or Low
- Shown red if baery level is low
Device History
Smoke alarm; CO alarm; extremely high temperature warning and self-test
history (self-test passed or failed), detector head failed, logged with date
and me
Real-me Status of Smoke & CO Alarm: Normal or smoke and (or)
CO alarm and (or) extremely high temperature warning or detector head
failed
Aer changing “Self-Checking ” sengs, press the device’s SET buon once, to sync the new sengs
to the device. Otherwise, the device will automacally update within 4 hours (maximum)

E-2. Details page-1
i. Real-me Status: Normal, Warning, Detector Head Failed
d. Add/Remove from favorites
a. Device Type
c. Choose a Room for device
e. Device History
Smoke alarm; CO alarm; extremely high temperature warning and self-test
history (self-test passed or detector head failed or failed to communicate
with the detector head), logged with date & me
b. Rename the Device
8
g. Alert interval
- Set re-noficaon interval aer an alert (smoke or CO detecon, extremely
high temperature warning). Default is 2 minutes
f. Alert sengs
- Enable or disable alerts
h. Device me
- Tap to sync with mobile
Aer changing “Alert Interval” sengs, press the device’s SET
buon once, to sync the new sengs to the device. Otherwise,
the device will automacally update within 4 hours (maximum)

E-2. Details page-2
9
l. Device SN (unique)
n. Connecon Signal Status of wireless communicaon base and Hub:
Strong; Good; Weak
p. Firmware Version
- ” indicates a new update is available“#### ready now (refer to page )17
k. Device EUI (unique)
j. Device Model
q. Remove Device From Current Account
- Tap to delete the device from your YoLink account
o. Current Baery Level
- Shown red if baery level is low
m. Temperature value
- Updates when:
1. SET buon pressed
2. On a device alert
3. Automacally within 4 hours maximum

E-3. Device Alarms
Device alarms with sounds and noficaons when both or either of the following condion is met
Smoke Detected
Temporal 3 Tone (Tone
3 mes, pause, repeat)
Carbon Monoxide Detected
Temporal 4 Tone (Tone
4 mes, pause, repeat)
10
P l e a s e r e fe r t o t h e i n s t r u c  o n s
fo r t h e A N K A S m o ke & C O A l a r m
( A J - 9 3 9 ) ( p a c k a g e d w i t h t h e
d e t e c t o r )

Device alerts with noficaons when either of the following condion is met
Extremely High
Temperature
Exceeding
135°F (57°C)
Detector Head
Failed
Detector Head
Baery is Low
Wireless
Communicaon
Base Baery is Low
You wil l nee d to rep lac e the wi rele ss
co m munica on b a se if bae r y is low, an d
you will need to re place the detector
head i f baery is low
11

E-4. Automaon (Set Up Rules For “If This Then Do That”)
Wireless Communicaon Base can be set as a trigger only, with three trigger opons: Smoke Alarm; CO
Alarm; Extremely High Temperature Alarm
a. Tap the “+” icon to add
an automaon
b. Add an automaon
b-1 Edit name
b-2 Edit trigger
b-3 Edit behavior (You must have at least one acon
device, or you cannot set a behavior)
b-4 Edit when (Set a me range for the automaon:
always or during specific days or mes)
b-5 Tap to save the sengs
1. Tap “ ” buon to enable or disable the
automaon
2. Swipe le to view the history logs and to edit or
delete the automaon
c. Click to edit the automaon
Swipe Le
12
a.
Go to the “Smart” screen, tap “Automaon”
b-1
b-2
b-3
b-5
b-4
c.

E-5. Voice Assistants (Under Developing, Not Support Now)
Go to Sengs > Voice Assistants for the applicable voice assistant integraon guide
Tap “ ” in the upper le corner to go to My Profile
C o n n e c t Yo L i n k w it h t h ir d - p a r t y v o i c e a s si s t a nt s t o m o n i t o r t h e s t a t u s o f y o u r d e v i c es
t h r o ug h v o i c e c o mm a n d s
YoLink Wireless Communicaon Base is integrated with Google
Assistant, and is also integrated with IFTTT.com (works as a trigger
device using IFTTT)
13

F. About YoLink Control (With Detector Head)
YoLink Control is our unique device-to-device control technology. Using YoLink Control, YoLink
devices can be controlled without the Hub or an internet connecon. (Use of YoLink Control is
oponal; you can use the Automaon feature in the app OR use YoLink Control, but YoLink
Control offers the benefit of operaon without the Hub or internet connecon.)
One device controls another, directly. A device that sends out commands is called the controller. A
device that receives the commands is called the responder. Examples of a controller are a Door
Sensor or Wireless Communicaon Base, while examples of a responder are another Gas/Water
Valve Controller or a Siren Alarm
The YoLink Wireless Communicaon Base can only work as the controller in YoLink Control
F-1. Pairing
To configure your YoLink Wireless
Communicaon Base as a controller,
press and hold the SET buon for
5-10 seconds unl the LED quickly
blinks green, then, release the buon
1
SET Buon
(5-10 seconds)
14

To c o n fi g u re a Va l v e G a s / Wa t e r
Controller as the responder, ensure
the Valve has Gas/Water Controller
already been bound to the YoLink
app. Using the app, CLOSE the valve
(ve rif y th e va lve is sho w n to be
Closed on the app, or press the Close
buon if it is shown as Open) (FOR
GAS VALVE CONTROL). Press and hold
the SET buon for 5-10 seconds unl
the LED quickly blinks , then, green
release the buon
2
Refer to the Gas/Water Valve Controller
manual for more informaon:
YS4909-UC
Gas/Water Valve
Controller
b. SET Buon
(5-10 seconds)
a. Close the valve
Upon pairing, the LED will
stop blinking (this may
happen aer only blinking
two or three mes)
3
1. If you want to op e n the G a s/Water Val ve C ont rolle r when t h e smoke & CO alarm ac  vate s (FOR
WATER VALVE CONTROL O N LY), open th e Ga s / Water Valve Contro l l er first , a n d let it e nter p airing
mode
2. For the same YoLink Wireless Communicaon Base and Gas/Water Valve Controller, you can only
choose to either open or close the Gas/Water Valve Controller when the smoke & CO alarm acvates
15

When the smoke & CO alarm
ac  vate s ( S MO KE A L AR M/
CO ALARM/ EXTREMELY HIGH
TEMPERATURE ALARM), the
Yo L i n k G a s / W a t e r Va l v e
C o n t r o l l e r w i l l n o w
immediately close the valve.
The valve will remain closed
unl opened via the app or
usin g th e SE T bu o n ; th e
restoral of the smoke & co
alarm to normal (no smoke
/ C O / e x t r e m e l y h i g h
temperature detected) does
not open the valve
More advanced sequences,
controlling mulple outputs
(e.g. open valve and acvate
siren) are available via the
YoLink app
Operaon
ClosedOpened
Gas Pipe
Smoke Detected Carbon Monoxide
Detected
Extremely High
Temperature
Exceeding
135°F (57°C)
16

F-2. Unpairing
At t h e W i re l e s s C o m m u n i c a  o n
B a s e ( co n t ro l l er ) , pr e ss a nd h ol d
t h e S ET bu  o n f o r 1 0- 1 5 se c o n d s
u n  l t h e L E D q u i c k ly b li n k s g r e e n ,
t h e n r e d , t h e n , r e l ea s e t h e b u  o n
1
At the Gas/Water Valve Controller
(responder, either open or closed),
press and hold the SET buon for
10-15 seconds, unl the LED quickly
blinks green, then red, then, release
the buon
2
Upon un-pairing, either the Wireless
C o m m u n i c a o n B a s e L E D o r th e
Gas/Water Valve Controller LED will
stop blinking
3
SET Buon
(10-15 seconds)
The Gas/Water Valve Controller will
no longer respond when the smoke &
CO alarm acvates
4
SET Buon
(10-15 seconds)
17
