YoloLIV YoloBox Ultra User manual

The Ultimate YoloBox Experience
Everything in One: Stream Beyond Limits
User Manual
www.yololiv.com
YoloBox Ultra

Making pro video accessible for everyone is the mission of YoloLiv.We value your feedback!
Email us your suggestions and let us know how you think we're doing and where you'd like to
see our products improve:[email protected]
Technical support
YoloLiv's products are backed by our professional support team.You can reach our team in
several ways:
· Email [e-mail]
· Directly contact us via Messenger by going to our Facebook Page"YoloLiv Technology"
· Join our Official YoloLiv Users Group on Facebook,where you can ask questions,get help or
share your tips and tricks
· Fill out a contact form or live chat on Messenger from here: www.yololiv.com/contact-us
Suggest a feature
Have a great idea for a new feature? Tell us about it via [email protected]
Issue Report
Gather as much information about your problem as you can before you contact us so we can
Thank you for choosing YoloLiv!
01

help you better, including:· A description of the issue (ideally with pictures or videos)
· A description of the issue (ideally with pictures or videos)
· A description of the issue (ideally with pictures or videos)
· Details about your video or audio source (product model, ports, resolution, etc.)
· Product serial number
· Your account email
· Firmware & software version
· As many details as possible (For example, for audio/video issues, what is the camera brand &
model, resolution/fps setting, internet connection,etc)
Please refer to this manual while using YoloBox Ultra to familiarize yourself with
this product:
When reading this manual, please carefully understand the technical parameters and
functional interfaces contained in the product, so that you can better Learn more about this
product. Please be sure to keep this manual safe so that you can refer to it again when
necessary.
02

The following precautions are intended to prevent injury to you and others. Before you start
using this product, be sure to understand and follow these precautions.
If there is any malfunction, problem or damage to this product, please contact YoloLiv Quick
Repair Center or the Dealer where you purchase this product .
To avoid fire, overheating, chemical leakage, explosion and electric shock,
please follow the following safety precautions:
· Do not use any batteries, power supplies, or accessories other than those specified in the
instructions. Do not use homemade batteries or modified batteries, and do not use if the
product is broken.
· Do not short-circuit, disassemble, or modify the battery. Do not heat or weld batteries. Do not
allow the battery to come into contact with fire or water. Do not expose the battery to strong
physical impact. Do not insert the positive and negative battery terminals in reverse.
· Do not charge the battery at a temperature beyond the allowable charging (operating)
temperature range. In addition, do not exceed the charging time indicated in the instruction
manual.
· Do not replace the battery without permission.
· Do not insert any metal objects into the heat dissipation holes, charging port or other
03
Warning: Follow these warnings to prevent death or serious injury.
01 / Safety Precautions

functional interfaces of the product.
· When discarding used batteries after maintenance, use adhesive tapes to insulate battery
electronic contacts. If it comes into contact with other metal objects or batteries, it may cause
a fire or explosion.
· If the battery overheat, emit smoke or smoke while charging the battery, unplug the battery
charger from the electrical outlet immediately to stop charging. Otherwise, fire, heat damage
or electric shock may result.
· If the battery leaks, changes color, deforms, emits smoke or fumes, disconnect the power
immediately and stop charging. Avoid burns during operation. If continued use, it may cause
fire, electric shock or scalding.
· Do not allow leakage from the battery to come into contact with eyes, skin, or clothing, as
this can cause blindness or skin damage. If the battery leak comes into contact with eyes, skin,
or clothing, immediately rinse the contact area with plenty of water (do not rub) and seek
medical attention immediately.
· Do not keep any power cable close to the heat source; otherwise, the power cable may be
deformed by heat or melt its insulation layer, which may cause fire or electric shock.
· Do not hold the product in the same position for a long time. Even if the product does not
feel too hot, prolonged contact with the same body part may cause skin redness or blistering
due to low temperature contact burns. A tripod is recommended when using the product in
very hot places, or for people with circulation problems or dull skin sensation.
· When products or accessories are not in use, be sure to keep the device turned off and
unplug the charging plug. This is to prevent electric shock, overheating, fire and corrosion.
04

· Do not use this device in an environment with flammable gases to avoid explosion or fire. If
the shell of the device is broken and internal parts are exposed, do not touch the exposed
internal parts. Otherwise, there is zero chance of electric shock. Do not disassemble or modify
the equipment yourself. Internal high voltage parts can cause electric shock. Keep this device
out of the reach of children and infants (including when using it). Electrical cords can cause
accidental suffocation, electric shock, or injury. A stroke or injury may also occur if a child or
infant accidentally ingests product parts or accessories. If this happens, seek immediate
medical attention.
· Do not use or store the device in dusty or damp places to prevent short circuit. This is to
prevent fire, overheating, electric shock and burns.
· Before using this product on an airplane or in a hospital, please first verify that the product is
available for use in the location. The electromagnetic waves emitted by the product may
interfere with the operation of aircraft instrumentation or medical equipment in hospitals.
· To avoid fire or electric shock, follow the following safety precautions:
(1) Make sure the power plug is fully plugged in.
(2) Do not touch the power plug with wet hands.
(3) When unplugging, hold the power plug and do not pull the power cable.
(4) Do not scratch, cut, or over-bend the power cord, and do not place heavy objects on the
power cord.
(5) Do not bend or tie the power cord.
(6) Do not connect more than one power plug to one power outlet.
(7) Do not use power cables with damaged wires or damaged insulation.
05

· Periodically remove the power plug and clean the dust around the power socket with a dry
cloth. If the surrounding environment is dusty, wet or greasy, the dust on the electrical outlet
may become wet and cause a short circuit in the outlet, which can lead to a fire.
· Do not connect the product charging port directly to an electrical outlet or a cigarette lighter
outlet in your car. Batteries may leak, generate excessive heat, or explode, which can cause
fires, burns, or other injuries
· Adults are required to provide detailed instructions on how to use the product when it is
used by children and to supervise the use of the product by children. Improper use may result
in electric shock or other injury.
· Do not cover or wrap this product with cloth. Otherwise, it will cause deformation of the shell
or cause fire due to poor heat dissipation.
· Be careful not to get the product wet. If the product falls into the water or if water or metal
enters the product, unplug the power supply immediately or stay away from the product. This
is to prevent fires, explosions, electric shocks and burns.
· Do not use paint thinner, benzene or other organic solvents to clean this product, otherwise
it may cause fire or harm your health.
06

· Do not use or store this product in a hot place such as a car under the hot sun, as this
product may become hot and cause burning injures. Doing so may also cause the battery to
leak or explode, thereby reducing the performance of this product or shortening its life.
· After this product is installed on the tripod, do not carry it to move, otherwise it may cause
injury or accident. Please also confirm the tripod can firmly support the body of the product.
· Do not leave this product in a low temperature environment for a long time. The
temperature of this product will decrease and may cause injury when touched damages or
damages the screen.
· When using audio playback, do not change the sound recording Settings. Otherwise, the
monitoring sound of the headset may suddenly increase, which may damage your hearing.
07
Warning: Follow these warnings to prevent death or serious injury.

08
· This product is a precision instrument, do not drop it or expose it to physical impact.
· This product is not waterproof and cannot be used underwater.
· If there is water on the product, wipe it with a clean dry cloth. If there is dirt, dust or salt on
the product, wipe it with a clean, damp cloth that is wrung out.
· Using the product in an area with a lot of dirt or dust may cause a malfunction.
· It is recommended to clean the product immediately after use. If there is dirt, dust, water or
salt on the product, it may cause failure.
· If the product accidentally falls into water or is concerned that moisture, dirt, dust or salt
may enter the product, please consult the product customer service center immediately.
· When using products near objects with strong radio waves or placing products near such
objects, such as large antennas, strong magnetic fields may cause product misoperation or
destroy audio and video data.
· Do not place this product in a place where the temperature is too high, such as in a car in
direct sunlight. High temperatures may cause product failure.
· There are precision electronic circuits in the product, do not disassemble the product
yourself.
· If the product suddenly enters a warm room from a low temperature, it may cause
condensation on the surface of the product and its internal parts. To prevent condensation,
02 / Operation Precautions
Product maintenance：

09
put the product in a sealed plastic bag first, and then take it out of the bag after the
temperature gradually rises.
· If the product appears dew, do not use, so as not to damage the product. If there is
condensation, do not turn on the device immediately to avoid device failure or battery fire or
explosion caused by short circuit. Wait until the condensation evaporates before using the
product.
· If the product is not used for a long time, please place the product in a dry and cool place
with good ventilation. During storage, please charge the product once in a while to confirm
the service life of the lithium battery and the normal operation of the product.
· Avoid storing products in chemical laboratories and other places where there are chemicals
that cause rust and corrosion.
· If you have not used the product for a long time, test all functions before use. If you have not
used the product for a while or if there is an important scenario to use (such as going abroad),
please have the after-sales technician assist you in checking the product or you check the
product yourself and make sure it works properly.
· If the product is reused for a long time, real-time display or audio and video data
transmission, the product may become hot, which is not a fault.
Liquid crystal display instructions：
· Although the LCD screen is manufactured with very high precision technology, its effective
pixels are as high as 99.99% or more, but 0.01% or less of the pixels may have bad spots, there

10
may be black, red or other color spots, bad spots are not faults. Bad spots do not affect your
output of video images.
· If the LCD screen is left on for a long time, there may be screen shadow phenomenon, which
is to see the residual image of the displayed image on the screen. However, this condition is
only temporary, and after a few days of not using the device, it will disappear.
· The LCD display may display slower at low temperatures and darker at high temperatures,
and it will return to normal at room temperature.
Memory card usage instructions：
To protect the memory card and recorded data from corruption, please note the following:
· Do not drop, bend or get wet the memory card. Do not apply excessive force to it, so that it is
subject to physical impact or vibration.
· Do not touch the electronic contacts of the memory card with your fingers or any metal
objects.
· Do not paste any stickers etc on the memory card.
· Do not store or use memory cards near anything with a strong magnetic field, such as
televisions, speakers, or magnets. Also avoid places that are prone to static electricity
· Do not expose the memory card to sunlight or close to heat sources.
· Do not store the memory card in the product card slot for a long time.
· Do not store memory cards in hot, dusty or humid environments.
· If it is a new memory card or a memory card that was previously formatted (initialized) with

Charger, battery instructions：
· This product can be used for chargers that meet the corresponding national or regional
standards and are compatible with PD3.0 fast charge protocol. (It is recommended to use a
charger with a power of 45W and above to charge, and the charger with a smaller power will
fail during the process of charging and using the product, which is caused by the smaller
power of the charger, not equipment failure or battery failure)
· Fully charging a fully drained battery at room temperature (23°C) takes about 4 hours and 30
minutes. The time required to charge the battery varies greatly depending on the ambient
temperature and the remaining battery power. And charging during use will make the
charging time longer.
· For safety reasons, charging at low temperatures (5°C - 10°C) takes longer (up to about 6
hours).
· The battery was not fully charged at the time of purchase.
· Charge the product battery before use.
· Charge the product the day before or on the same day you use it.
· Even during storage, a charged battery will gradually discharge and lose its charge.
· After charging, remove the charger from the power socket in time
· Chargers compatible with the protocol can also be used abroad. The charger input power
supply is compatible with 100 V AC to 240 V AC, 50/60 Hz power supply. If necessary, please
another device or computer, use this product to format that memory card.
11

install the plug charger available in the corresponding country or region. Do not install any
portable transformer to the charger, otherwise it will damage the charger.
· If the battery is quickly depleted after a full charge, the battery has reached the end of its
useful life. Contact the manufacturer or seller to purchase a new battery.
· After unplugging the charger, do not touch the plug for about 10 seconds.
12

03 / Memory card usage instructions
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
· This device may not cause harmful interference.
· This device must accept any interference received,including interference that may cause
undesired operation. The symbol for "ENVIRONMENT PROTECTION" is electrical products
should not be disposed of with household waste. Please recycle where facilities exist. Check
with your local authority or retailer for recycling advice.
FCC Caution:
Any changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate this equipment.
Note:
This equipment has been tested and found to comply with the limits for a Class B digital
device,pursuant to part 15 of the FCC Rules.These limits are designed to provide reasonable
protection against harmful interference in a residential installation.This equipment
generates,uses and can radi-ate radio frequency energy and,if not installed and used in
accordance with the instructions,may cause harmful interference to radio
communications.However,there is no guarantee that interference will not occur in a particular
installation.
13

If this equipment does cause harmful interference to radio or television reception,which can
be determined by turning the equipment off and on,the user is encouraged to try to correct
the interference by one or more of the following
Measures:
· Reorient or relocate the receiving antenna.
· Increase the separation between the equipment and receiver.
· Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
· Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference
(2) this device must accept any interference received
including interference that may cause undesired operation.
14

15
04 / About YoloBox Ultra
YoloBox Ultra is industry's YoloBox & Instream In One, live stream vertically or
horizontally to your favorite platforms.
Advantages:
· Up to 4 HDMI inputs
· Stronger CPU: 865 Qualcomm Snapdragon
· No Computer or OBS required
· All-In-One: Encoder, switcher, recorder, monitor all in one
· YoloBox & Instream in one: support horizontal and vertical streaming
· Touch screen control: Production at your fingertip, great ease to operate
Pro Features:
·
·
·
4K streaming:
Support streaming up to 4K, a huge leap forward for video quality.
ISO recordings:
Capture all the video inputs as well as the program video and save them separately. You can
also adjust the resolution, frame rate, and bitrate for each recording accordingly.
Cellular Bonding:
Combine up to 4 internet sources - 4G LTE cellular, WiFi, Ethernet and USB Dongle - into a
single faster, more reliable connection. Enjoy high-quality video experience without

·
·
·
·
·
·
·
interruptions.
Horizontal streaming:
Support streaming up to 3 destinations simultaneously like YouTube, Facebook, Twitch,
etc.Support streaming up to 4K, a huge leap forward for video quality.
Vertical streaming:
Support streaming up to 2 destinations simultaneously like Instagram, TikTok, etc.
Built-in Chroma Key:
Seamlessly add a different background of a design for your live productions with the magic
of Chroma Keying in a few taps.
Video Cropping:
Whether to remove some unwanted margin of video input, resize game capture, zoom video
conferencing, or create a close-up view, video cropping has all you need.
Instant Replay:
Jump back to any point in the game or a show with preset video duration and playback
video speed. Create highlight clips with the click of a button.
Web URL Overlay:
Incorporate professional-grade live graphics in minutes on any production. Control from
anywhere via your browser.
Auto Switching:
You can pick video sources, how long to stay on each one, and even prioritize the main
camera, we will automatically switch for you. Perfect for single-person multi-cam live
productions.
16

17
·
·
·
·
Wireless Phone Camera/Invite Guests:
Invite up to five guests to join your stream from anywhere. Create dynamic, collaborative live
streams with guests even though they cannot be on site.
Audio Mixing:
Built-in audio mixer with easy setup. Fine-tune each channel of audio individually to deliver
the best sound to your audiences.
Graphic Overlays:
Show off your brand, keep score, and always look professional with graphics support. Choose
from images, lower thirds, scoreboards, countdown timer overlays, titles, logos, social
overlays, and web URL overlays.
Multiple Multi-views:
Multiple video layouts to match your diverse streaming scenarios and help level up your
production with ease. Choose from PIP, Side by Side, Split View, News Layout, and Triple.

05 / What's In the Box
YoloBox Ultra
USB Charge Cable *2
Hotshoe Mount
YoloBox Ultra User Manual
SIM Card Eject Pin
18
