York Fitness experience cycle User manual

owner’s manual
yorktness.com
experience cycle
16/06/2008
experience

Congratulations on
purchasing a cycle from
York Fitness.
You have chosen a high quality, safe and
innovative piece of equipment as your
training partner and we are certain it
will keep you motivated on the way to
achieving your personal tness goals.
Please take the time to read this owner’s
manual as it will help you to get the
most out of your new cycle. For more
information visit www.yorktness.com
2

contents
safety information 04
customer support 05
assembly instructions 06
user instructions 09
- quick start
- console display and feedback
- button functions
- using workout programs
exercising with your cycle 10
cycle features explained 11
how to take care of your cycle 12
your warranty 13
exploded diagrams and parts list 14
3

PLEASE READ THIS INSTRUCTION MANUAL BEFORE YOU BEGIN ASSEMBLY. GREAT
CARE HAS BEEN TAKEN TO DESIGN THESE INSTRUCTIONS AND FOLLOWING THEM
WILL HELP YOU WITH QUICKER ASSEMBLY AND MINIMISE THE RISK OF INJURY
YOU ARE RESPONSIBLE FOR YOUR OWN SAFETY -
THIS LIST IS NOT EXHAUSTIVE.
•Always assemble and operate
the product on a level surface
•Always use the product on a level surface,
ensure that the product is stable before use.
• Always ensure that the equipment has adequate space
on each side and front (the back can be near to a wall).
• Ensure that the seat height is adjusted correctly - you
should be stable and balanced whilst on the saddle.
• Adjust the seat height to ensure that you have a good
downward pedal stroke without overstretching, don’t
compromise your balance.
• Try to ensure that your back is straight whilst exercising,
especially for long periods
•The safety level of this equipment can only be maintained
only if it is regularly examined for wear and tear.
•Replace defective components immediately, and/or
keep the equipment out of use until it is repaired.
•Use only the adjustment settings as described in the
instructions. Always use the correct adjustment pin/xing.
•Always check that any pins / xings are tight and
secure before use and / or after adjustment.
•Never leave any adjustment devices
projecting from the product.
•Always consult your doctor before
undertaking any exercise program.
•Always wear suitable clothing and footwear
e.g. tracksuit / shorts / training shoes
•Remove all personal jewellery before exercising.
•Ensure you warm-up well before using the
equipment as this will help to prevent muscle strain.
•After eating, allow 1-2 hours before exercising as
this will help to prevent muscle strain.
• Never overload the equipment – the maximum
user weight of this cycle is 100kg.
•Never use the equipment in any other manner other
than the ways explained in these instructions and/or
any wall-chart supplied.
•Injuries to health may result from incorrect or
excessive training.
•Parents and others in charge of children should be aware
of their responsibility, because the natural play instinct
and the fondness of experimenting of children can lead to
situations and behaviour for which the training equipment
is not intended
•If children are allowed to use the equipment,
their mental and physical development and above all
their temperament should be taken into account. They
should be controlled and instructed in the correct use
of the equipment.
•The equipment is under no circumstances
suitable as a children’s toy.
•Children should not be allowed on, or around
the equipment - especially when it is not in use.
•This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
Safety Standards
This cycle meets the requirements of the EU’s EMC and Low Voltage directives (where applicable),
ISO 20957 parts 1 and 5 and AS 4092-1993. Therefore the product carries the following marks:
4
It is important that you keep these instructions for future reference.
!
This product is not suitable for therapeutic purposes.
safety information

Customer Support
Should you require any assistance regarding this product please gather the following information,
and then contact us using the details below:
1. Serial no. - this can be found on
the sticker below, located as indicated.
For future reference, please write down
your serial number in the space
provided below.
2. Original purchase date
3. Place of purchase
4. Information about the place
and conditions of use
5. Precise description of the issue/defect
Your Serial No. is:
Care & Maintenance
•
Always place the equipment in a dry environment.
•
Use a warm, damp cloth to keep the product clean.
•
No wet cleaning of electrical components, unplug before any care and maintenance
•
The safety level of the equipment can be maintained only if it is regularly examined for damage and wear. This
includes any ropes, pulleys, nuts, bolts, moving parts, bushes, chains, wheels, bearings & connection points etc
•
Ensure that you inspect the product regularly - at least once a week is recommended.
•
Ensure that all xings are tight before use.
•
Always replace damaged / worn components with original parts from the manufacturer.
Protect the environment by not disposing of this product with household waste.
Check your local authority for recycling advice and facilities (Europe only).
5
Contact Us
ENGLAND
York Barbell (UK) Ltd. York Way, Daventry, Northants, England NN11 4YB
Tel: [phone] Helpdesk Tel: [phone] Fax: [phone] email: helpdesk@yorktness.co.uk
AUSTRALIA
Unit 1, Lot 2, Swaham Road, Minto, N.S.W. 2566 Australia
Tel: [phone] Fax: [phone] email: service@yorktness.com.au
OTHER LOCATIONS
Please see website - www.yorktness.com

assembly instructions
6
If you suspect you may have some parts missing, please contact
us before going back to your retailer. Refer to the Customer
Support section on page 5 for contact details.
!
This cycle takes up
a oor space of 92cm by 55cm
and weighs 23kg
!
60mm
Carriage
bolt
small
Flat
washer
1. Before you start
1. Prepare your work area -
it is important you assemble
the product in a clean and
uncluttered space.
2. Work with a friend -
we recommend you have
someone assist you with
the assembly as some of the
components are quite heavy.
3. Open the carton -
checking any warnings on
the carton and make sure you
have it the right way up.
4. Unpack the carton
Make sure you have
the following parts:
Console x 1
Handle bar x 1
Seat post
x 1
Seat x 1
Fixings Tools and Consumables
Screwdriver and
allen key
Part
No.
21
Part
No.
32
Part
No.
18
Part
No.
14
Part
No.
4
Part
No.
52
Part
No.
47
Part
No.
3
Part
No.
2
Part
No.
60
Front post
x 1
x 8
x 4
x 4
x 4
Part
No.
51
Pedal set
x 1
Front stabilizer
x 1
Part
No.
5
Rear stabilizer
x 1
Nylock
nut
15mm
allen head
bolt
Part
No.
6
Hand
wheel
Part
No.
44 x 1
Part
No.
25 x 8
Spring
washer
Part
No.
49 x 4
Plastic
bolt cap
Handlebar
bracket
cover
Part
No.
43
T-bar
bolt x 1
x 1
Multi spanner
(10, 13, 14, 15mm)
spanner
(13, 15mm)
Part
No.
80
Part
No.
78
Part
No.
79

1
2
7
2. Attach the stabilisers
1. Attach the front and rear stabilisers with the nuts, bolts and washers as shown in the diagram
2. Be sure to t the parts in the same order as the diagram
FIXINGS:FIXINGS:
x 4
x 4
Part
No.
32
x 4
Part
No.
25
x 4
Part
No.
21
Part
No.
49
x 4
Check the bolts are fully tightened by making sure they penetrate
through the top of the nut
!
3. Attach the front post
1. Hook the tension cables together as shown (you may have to pull the outer tension cables rmly, to hook the
upper cable into the bracket of the lower cable)
2. Connect the computer cables as shown
3. Slide the front post tube over the front post mounting
4. Secure in place using the bolts and washers as shown - be sure to t them in the same order as the diagram
FIXINGS:FIXINGS:
x 4
Part
No.
14
x 4
Part
No.
21
x 4
Part
No.
25
Tension
cables
Computer
cables
4. Attach handlebars
1. Open the handlebar clamp bracket and place the handlebar inside
2. Close the clamp bracket and place the handlebar bracket cover over it
3. Secure in place using the T-bar bolt
Make sure T-bar bolts is
fastened tightly
!
49
25
32
21
18
49
25
32
21
18
25
14
21
14
14
21
Part
No.
18
32
21 49
25
32
21 49
25
25
21
25

5. Attach the console
1. Connect the computer wires together
2 Secure onto the bracket using screws
as shown - (screws are located in the
back of the console)
FIXINGS:FIXINGS:
x 2
Part
No.
73
8
6. Attach the seat and seat post
1. Attach the seat to the seat post as shown
- (nuts and washers are located on the
underside of the seat)
2. Slide the seat post into the seat post
mounting tube and secure in position
with the hand wheel
FIXINGS:FIXINGS:
x 3
Part
No.
22
x 3
Part
No.
32
7. Attach the pedals
1. Attach the straps to the pedals (the straps and
pedals are marked L and R, match each strap to
the corresponding pedal)
2. Attach the L pedal to the left crank arm - this
pedal will thread on anti-clockwise
3. Attach the R pedal to the right crank arm - this
pedal will thread on clockwise
Final Checks
Your cycle is now assembled. Please make the following nal checks before you use it for the rst time
•Make sure all screws / bolts are tightened
•Make sure you have positioned it on a at, level surface
73
32
22
32
22

user instructions
Quick Start
Console Display and Feedback
Button Functions
Pre – workout During workout
mode
up
down
reset
Scan
Automatically scrolls through the other
feedback modes, each being displayed
for 6 seconds
Time (TMR)
Time exercised this session; default
counts up from zero, but counts down if
a target has been set
Speed (SPD)
Current speed you are cycling at,
in km/h
Calories (CAL)
Approximate calories burned this
session (for comparison only, not to
be used for medical purposes); default
count up from zero, but counts down if
a target has been set
Distance (DST)
Distance travelled this session; default
counts up from zero, but counts down if
a target has been set
Screen Display
1. Simply start pedalling and away you go!
2. The values of time, distance and calories will start counting upwards
3. Adjust the resistance level with the large dial
select ‘target program’ switches between the feedback
modes as described above
set values in
‘target program’ mode
set values in
‘target program’ mode
reset current value
press and hold for 4
seconds for a total reset
Using Workout Programs
Manual Program
To use in the manual mode simply start
pedalling. The values of time, distance and
calories will start counting upwards. Adjust
the resistance level with the large dial.
Target Programs
You can choose to workout by setting a
target based on time, distance travelled
or calories burned. When you reach your
target the cycle will sound a short alarm.
Target time
1. Press‘mode’until ‘TMR’ is showing on
the display
2. Use the ‘up/down’buttons to set your
workout time
3. Start pedalling to begin your workout
Target distance
1. Press‘ mode’until ‘DST’ is showing on
the display
2. Use the ‘up/down’buttons to set your
workout time
3. Start pedalling to begin your workout
Target calories
1. Press‘mode’until ‘CAL’is showing on the
display
2. Use the ‘up/down‘ buttons to set your
target calories
3. Start pedalling to begin your workout
9

10
exercising with your cycle
Always consult your doctor
before undertaking a new
exercise regime
If you experience nausea, dizziness or other abnormal
symptoms during exercise, stop at once and consult
your doctor
!
Correct cycling form
•Sit on the cycle, with your feet on the pedals and inside the pedal
straps
•Ensure that the seat height is adjusted correctly - you should be
stable and balanced whilst on the saddle. The basic rule for getting
the seat height right is that as the pedal reaches its lowest point, the
leg is almost straight.
•Try to ensure that your back is straight whilst exercising, especially for
long periods.
How long should I exercise for?
That really depends on your current level of tness. If you’re just
starting out on a new exercise program, you should start gradually
and build up – do not try to do too much too quickly. 30 minutes,
3 times a week should be enough.
Don’t push yourself too hard - you should never feel exhausted
during or following exercise.
Heart Rate Training
To get the most out of your new piece of tness equipment and see
the best results from your training you should exercise at the right
level of eort, and that means listening to your heart! Working out
to a target heart rate means you can direct your workout to achieve
dierent goals:
Good health - For those wishing to improve quality of life and
general well being. Your sessions will need to be done at an
intensity of between 50-60% of your estimated maximum heart
rate, should last about 30 minutes and can be done on most days
of the week.
Weight loss – To see a signicant reduction in body fat, your
sessions must be a little more intense - between 60 and 70% of
your estimated maximum heart rate. These sessions can also be
performed on most days of the week for up to 30 minutes.
Improving Fitness levels –These sessions should be performed
at 70-80% of your estimated maximum heart rate and can also
involve bouts of interval training that would have your heart
rate peaking for short times near your maximum heart rate level.
These are intense sessions and will require at least a 48 hour rest
between sessions.
Calculating your target heart rate
First, you need to nd your estimated maximum heart rate using the
formula ‘220 minus your age in years’. So, if you are 35 years old your
estimated maximum heart rate is:
220 – 35 = 185 beats per minute (bpm)
Next, to calculate your target heart rate, simply multiply your
estimated maximum heart rate (185bpm) by the applicable
percentage. So, if your goal is better heath:
185 x 60% = 111bpm
NOTE: The important issue to remember with all estimated
calculations is that they are just estimates – if you don’t
feel comfortable exercising at your target then reduce it to
a level you are comfortable with.
!
Note: Heart rate training requires you to monitor your heart rate
throughout the workout. For this we recommend using a chest strap
(if your machine has a wireless receiver) or a heart rate monitor. For
more information please visit yorktness.com or get in touch using
the Contact Us details on page 5.
Starting and nishing your workout
Begin and end each workout with a Warm Up / Down session – a few minutes of stretching to help prevent strains, pulls and cramps

cycle features explained
Adjusting the resistance
This cycle features a speed independent braking (resistance) system.
The resistance is controlled by a magnet, which is moved closer
or further away from the ywheel – the closer the magnet is to
the ywheel the higher the resistance. The magnet is controlled
manually, by twisting the dial. The resistance levels go from
1 = easy to 8 = hard
Adjusting the seat height
do not pull the seat out too far -
the maximum is indicated with a piece of tape
on the seat post
!
Adjusting the handlebars
The handlebars can be adjusted to match your individual equirements;
1. Loosen the T-bar bolt
2. Tilt the handlebars into your desired position
3. Tighten the T-bar bolt
Levelling your cycle
To help you level the cycle on uneven surface, 2 height adjusters are
included on the rear stabilisers. Simply twist these around to adjust
the height of the cycle
11
1. Unscrew the hand wheel
2. Adjust the seat up or down to your required height - to line it up
correctly, make sure the number and line is visible at the top of
the seat post mounting tube.
3. Re-screw the hand wheel - make sure it is screwed tightly
4. The basic rule for getting the seat height right is that as the pedal
reaches its lowest point, the leg is almost straight
Transporting your cycle
Your cycle has 2 transport wheels to help you move it around.
To engage the wheels, tilt the cycle towards you with the handlebars
and then using the handlebars push the cycle to your desired location
transport wheels

how to take care of your cycle
Storage
Keep the equipment in a dry place with as little temperature variation
as possible. Try to protect from dust and always unplug when not in
use (if applicable).
Cleaning
Use a warm, damp cloth to wipe the surfaces. Mild detergent may be
used if necessary.
Maintenance
Ensure you regularly check components for wear and make sure all
the nuts and bolts are tightened before each exercise session.
Troubleshooting
If you are still having problems with your equipment, please get in
touch with your local York distributor using the details found in the
Customer Support section on page 5.
Never remove the
protective casing.
!
If you have a problem with your equipment, before you do anything else please check that all
the cables have been connected correctly. Loose cables are very common and many problems
can be solved by making sure the cables are properly connected
!
12

your warranty
This product is supplied with a standard warranty as follows:
•Lifetime frame
•12 month other parts
•12 months labour
This product is warranted for use in a home, personal, family or household environment
Please Note: Warranty details may vary from one market area to another
Warranty Terms
York Barbell Ltd. warrants that the Product you have purchased from an authorised York reseller is free from defects in materials and
workmanship. The Warranty is valid subject to normal and reasonable use in the environment as described above, and correct assembly of
the product during the warranty period. The warranty period extends to the original purchaser only. It is not transferable to anyone who
subsequently purchases the Product from you.
The warranty excludes normal wear and tear on parts.
Your sales receipt, showing the date of purchase of the product, is your proof of the date of purchase.
This warranty becomes valid only if the Product is assembled / installed according to the instructions / directions included with the product.
This warranty does not extend to any product that has been damaged or rendered defective: (a) as a result of accident, misuse, abuse or lack
of reasonable care; (b) by the use of parts not manufactured by York Barbell or sold by York Barbell; (c) by modication of the product; (d) as a
result of service by anyone else other than York Barbell or an authorised York Barbell warranty service provider.
During the warranty period York Barbell will at no additional charge provide replacement part(s) or repair the product (at York Barbell’s option)
if it becomes defective, malfunctions or otherwise fails to conform with this warranty under normal, non-commercial, personal, family or
household use. In repairing the product, York Barbell may replace defective parts or at the option of York Barbell, use serviceable used parts
that are equivalent to new parts in performance. All exchanged parts and products replaced under this warranty will become the property of
York Barbell. York Barbell reserves the right to change manufacturers of any part to cover any existing warranty.
If the product must be returned, you must return the Product or defective part to York Barbell in its original container (or equivalent) with
Proof of Purchase. Any evidence of alteration, erasing or forgery of proof of purchase documents will be cause to void this warranty. You
must prepay any shipping charges and you are responsible for insuring any product or part that is returned. Should any product submitted
for warranty service be found to be ineligible, an estimate of repair cost will be furnished and the repair will be made if requested, upon
York Barbell’s receipt of payment or acceptable arrangement of payment. Under no circumstances will returns be accepted without return
authorisation by our Customer Service department.
To obtain warranty service you must provide the following information:
Name of Product, Product Code, Batch No, Date Purchased, and Nature of fault or part number required.
Neither dealer of this product nor any retail establishment selling this product has any authority to make any warranties or to promise
remedies in addition to, or inconsistent with, those stated above. This warranty does not aect your statutory rights.
Please note that warranty terms may vary from one market area to another
13

exploded diagram
14
1
31
31
38
39
65
10
11
30
35
38
24 9
23
37
29
23
35 26
1
8
32
22
26
40
36
45
34
68
72
67
70
71
68
72
69
66
63
12
13
50
62
48
19
15
27
75
33
17
32
8
16
28
41
74
7
29
74

Parts List
15
Ref. Qty Part no. Part Description Ref. Qty Part no. Part Description
1 1 YKA00108b2 Main Frame (C ) (665 x 184 x 488mm) 42 1 YKF20075w4 Chain Cover (C )[set L&R] (PU73338)
2 1 YKA00109b2 Front Post (C ) (Ø50.8 x 684mm) 43 1 YKF10221b3 T-Bar Bolt (M8 x 55mm)
3 1 YKA00110b2 Saddle Post (C ) (Ø38 x 36 x 600mm) 44 1 YKF10219b3 Hand Wheel - Male (M16 x 22mm)
4 1 YKP00163b2 Front Stabilizer & Wheel Mount (Ø50.8 x 450mm) 45 1 YKF50051b3 Jockey Wheel (Ø44 x T21.9mm)
5 1 YKP00164b2 Rear Stabilizer (C ) (Ø50.8 x 450mm) 46 1 YKF20137b3 Reducer Insert (Ø50 > Ø38mm x 166mm)
6 1 YKP00165c1 Handlebar (C ) (Ø22mm) 47 1 YKF20146b3 Handlebar Mount Bracket Cover (22.2mm Tube)
7 1 YKA00111c1 Jockey Wheel Bracket (T6mm) 48 1 YKF20180b3 Sensor Mount Bracket (43 x T1.5mm)
8 1 YKF50040c1 Magnet Shoe Assembly (T2mm) 49 4 YKF20183b4 Round Plastic Bolt Cap (13 x 13mm)
9 1 YKF50041b6 Flywheel (Ø260mm x 4KG) 50 1 YKF40051b1 Pulley Belt (400J-5)
10 1 YKF50042b6 Small Pulley Wheel (Ø37 x 60.9mm) 51 1 YKF30022b1 Saddle (A16)
11 1 YKF50043b6 Flywheel Axle (Ø10 x 126mm) 52 1 YKF50052b5 Pedal (Set [L&R])
12 1 YKF50044z1 Large Pulley Wheel (Ø230 x T21mm) 53 2 YKF20184b5 Round External End Cap (Ø56.5 x 40mm)
13 1 YKF50045c1 1 Piece Crank (6") 54 2 YKF20185b5 Round External Height Adjustable End Cap (Ø60mm)
14 4 YKF10062b6 Round Allen Head Bolt (M8 x 15mm [6mm Allen]) 55 2 YKF20186b5 Transport Wheel (Ø2" Tube)
15 1 YKF10186b6 Hex Head Bolt (M8 x 25mm) 56 2 YKF20187b5 Oval Crank Cover
16 1 YKF10187b6 Hex Head Bolt (M6 x 65mm) 57 2 YKF30023b1 Foam Handgrip
17 1 YKF10188b6 Hex Head Bolt (M8 x 52mm) 58 2 YKF20188b3 Round Internal Top Hat End Cap (OD30 x ID22.2 x 19mm)
18 4 YKF10189b6 Carriage Bolt (M8 x 60mm) 59 1 YKF40052b1 Tension Control & Cable (outer 420 + Inner 34mm)
19 1 YKF10190b6 Round Philips Head Self Tapping Screw (6 x 12mm) 60 1 YKF60099q25 Computer (C ) - (ST8318-61)
20 2 YKF10191b6 Round Philips Head Machine Screw (M5 x 15mm) 61 1 YKF60100b1 Computer Middle Cable (750mm Male-Female)
21 8 YKF10217b6 Flat Washer (ID-8 x OD-16 x T-1.2mm) 62 1 YKF60101b1 Computer Lower Cable (450mm Male-Sensor)
22 4 YKF10218b6 Flat Washer (ID-8 x OD-22 x T-1.5mm) 63 1 YKF50053b3 Magnet (sensor)
23 2 YKF10013b6 Flat Washer (ID-10 x OD-23mm) 64 4 YKF10201b6 Round Philips Head Self Tapping Screw (6 x 16mm)
24 1 YKF10215b6 Flat Washer (ID30 x OD34 x T0.8mm) 65 1 YKF50054b1 Bearing - One Way (FT-1735)
25 8 YKF10192b6 Spring Washer (ID-8mm) 66 1 YKF10202c1 Flat Washer (ID-24 x OD-38 x T-2.5mm)
26 2 YKF20027b3 Plastic Spacer (ID-M10 x OD-24 x T-0.3mm) 67 1 YKF50055c1 Ball Bearing Ring Nut (ID-15/16")
27 1 YKF20044b3 Plastic Spacer (ID-M6 x OD-19 x T-1.5mm) 68 2 YKF50056c1 Bearing Bowl (Ø51.4" x T3mm)
28 1 YKF10193b6 Hex Nut (M6) 69 1 YKF50057c1 Bearing Ring Nut (ID-7/8")
29 2 YKF10194c1 Hex Nut (3/8" x T3mm) 70 1 YKF50058c1 Flat Washer - Bearing (35mm)
30 1 YKF10195c1 Hex Nut (3/8" x T9mm) 71 1 YKF50079c1 Bearing Hex Nut (ID-7/8")
31 2 YKF10216b6 Hex Nut (3/8" x T-7mm) 72 2 YKF50080c1 Ball Bearing Set
32 9 YKF10061b6 Nyloc Nut (M8) 73 2 YKF10203b6 Round Philips Head Machine Screw (M5 x 10mm)
33 1 YKF10196b6 Nyloc Nut (M6) 74 1 YKF40053 Tension Cable Connector Cable (Outer 500 + Inner 42mm)
34 1 YKF10197b6 C Clip (C12) 75 1 YKF10204b6 Flat Washer (ID-6 x OD-15 x T-1.2mm)
35 2 YKF10198b6 C Clip (C10) 76 1 YKF10205b6 Flat Washer (ID-5 x OD-15 x T-1.2mm)
36 1 YKF50046 Bearing (6001) 77 1 YKF10206b6 Round Philips Head Machine Screw (M5 x 25mm)
37 1 YKF50047 Bearing (6000)
38 2 YKF50048 Bearing (6003) TOOLS
39 1 YKF50049 Bearing (6300) 78 1 YKF70007 Multi Spanner (10, 13, 14, 15mm)
40 1 YKF10199b6 Spring (Ø2.8 x 121mm) 79 1 YKF70008 Spanner (13 & 15mm)
41 1 YKF10200b6 Spring (Ø1.2 x 48mm) 80 1 YKF70009 Philips Screwdriver & Allen Key (6mm x 105mm)
