York Sunline 2000 User manual

INSTALLATION
MANUAL - 50 Hz
CAUTION: READ ALL SAFETY GUIDES BEFORE YOU
BEGIN TO INSTALL YOUR UNIT.
SAVE THIS MANUAL
SUNLINE 2000™
SINGLE PACKAGE HEAT PUMP
MODEL: BQ 240
(50 Hz)
66396-YIM-C-1004
CONTENTS
GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . . . . . . .4
INSPECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
REFERENCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
RENEWAL PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
APPROVALS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
PRODUCT NOMENCLATURE . . . . . . . . . . . . . . . . . . . .5
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
START-UP (COOLING) . . . . . . . . . . . . . . . . . . . . . . . . .31
TROUBLESHOOTING. . . . . . . . . . . . . . . . . . . . . . . . . .31
MAINTENANCE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
See the following page for a complete Table of Contents.
NOTES, CAUTIONS AND WARNINGS
Installer should pay particular attention to the words:
NOTE, CAUTION, and WARNING. Notes are intended to
clarify or make the installation easier. Cautions are given
to prevent equipment damage. Warnings are given to
alert installer that personal injury and/or equipment dam-
age may result if installation procedure is not handled
properly.

66396-YIM-C-1004
2Unitary Products Group
TABLE OF CONTENTS
GENERAL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . . . . . . . . . 4
INSPECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
REFERENCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
RENEWAL PARTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
APPROVALS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
PRODUCT NOMENCLATURE. . . . . . . . . . . . . . . . . . . . . . .5
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
INSTALLATION SAFETY INFORMATION . . . . . . . . . 7
LIMITATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
LOCATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
RIGGING AND HANDLING. . . . . . . . . . . . . . . . . . . . .8
CLEARANCES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
DUCTWORK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
FIXED OUTDOOR AIR INTAKE DAMPER . . . . . . . . . 9
CONDENSATE DRAIN . . . . . . . . . . . . . . . . . . . . . . . . 9
COMPRESSORS . . . . . . . . . . . . . . . . . . . . . . . . . . .10
FILTERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
SERVICE ACCESS. . . . . . . . . . . . . . . . . . . . . . . . . .10
THERMOSTAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
POWER AND CONTROL WIRING . . . . . . . . . . . . . .12
OPTIONAL ELECTRIC HEAT. . . . . . . . . . . . . . . . . .12
OPTIONAL ECONOMIZER/MOTORIZED DAMPER
RAIN HOOD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
OPTIONAL POWER EXHAUST/BAROMETRIC
RELIEF DAMPER AND RAIN HOOD . . . . . . . . . . . . .13
OPTIONAL ECONOMIZER AND POWER EXHAUST
DAMPER SET POINT ADJUSTMENTS AND
INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
MINIMUM POSITION ADJUSTMENT . . . . . . . . . . . . .13
ENTHALPY SET POINT ADJUSTMENT. . . . . . . . . . .13
POWER EXHAUST DAMPER SETPOINT (WITH
OR WITHOUT POWER EXHAUST) . . . . . . . . . . . . . .13
INDOOR AIR QUALITY AQ. . . . . . . . . . . . . . . . . . . . .13
CFM, STATIC PRESSURE, AND POWER -
ALTITUDE AND TEMPERATURE CORRECTIONS. 21
PHASING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
CHECKING SUPPLY AIR CFM. . . . . . . . . . . . . . . . .25
AIR BALANCE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
OPERATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
SEQUENCE OF OPERATIONS OVERVIEW . . . . . .27
COOLING SEQUENCE OF OPERATION . . . . . . . . 27
CONTINUOUS BLOWER . . . . . . . . . . . . . . . . . . . . . . 27
INTERMITTENT BLOWER . . . . . . . . . . . . . . . . . . . . . 27
NO OUTDOOR AIR OPTIONS . . . . . . . . . . . . . . . . . . 27
ECONOMIZER WITH SINGLE ENTHALPY
SENSOR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
ECONOMIZER WITH DUAL ENTHALPY SENSORS. 28
ECONOMIZER WITH POWER EXHAUST. . . . . . . . . 28
MOTORIZED OUTDOOR AIR DAMPERS . . . . . . . . . 28
COOLING OPERATION ERRORS. . . . . . . . . . . . . . . 28
HIGH-PRESSURE LIMIT SWITCH. . . . . . . . . . . . . . . 28
LOW-PRESSURE LIMIT SWITCH . . . . . . . . . . . . . . . 28
FREEZESTAT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
LOW AMBIENT COOLING . . . . . . . . . . . . . . . . . . . . . 28
SAFETY CONTROLS. . . . . . . . . . . . . . . . . . . . . . . . 29
COMPRESSOR PROTECTION . . . . . . . . . . . . . . . . 29
FLASH CODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
RESET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
HEATING SEQUENCE OF OPERATIONS . . . . . . . 29
WITH ELECTRIC HEAT . . . . . . . . . . . . . . . . . . . . . . . 29
WITHOUT ELECTRIC HEAT . . . . . . . . . . . . . . . . . . . 29
HEATING OPERATION ERRORS . . . . . . . . . . . . . . 30
TEMPERATURE LIMIT. . . . . . . . . . . . . . . . . . . . . . . . 30
SAFETY CONTROLS. . . . . . . . . . . . . . . . . . . . . . . . 30
FLASH CODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
RESET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
HEAT ANTICIPATOR SETPOINTS . . . . . . . . . . . . . 31
START-UP (COOLING). . . . . . . . . . . . . . . . . . . . . . . . . . . 31
PRESTART CHECK LIST . . . . . . . . . . . . . . . . . . . . 31
OPERATING INSTRUCTIONS. . . . . . . . . . . . . . . . . 31
POST START CHECK LIST. . . . . . . . . . . . . . . . . . . 31
SHUT DOWN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
TROUBLESHOOTING. . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
COOLING TROUBLE SHOOTING GUIDE. . . . . . . . 31
UNIT FLASH CODES. . . . . . . . . . . . . . . . . . . . . . . . 35
MAINTENANCE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
NORMAL MAINTENANCE . . . . . . . . . . . . . . . . . . . . 36
FILTERS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
MOTORS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
BLOWER SHAFT BEARING . . . . . . . . . . . . . . . . . . 36
OUTDOOR COIL . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

66396-YIM-C-1004
Unitary Products Group 3
LIST OF FIGURES
Fig. # Pg. #
1 TYPICAL RIGGING. . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2 CENTER OF GRAVITY. . . . . . . . . . . . . . . . . . . . . . . . . 8
3 FIXED OUTDOOR AIR DAMPER. . . . . . . . . . . . . . . . . 9
4 RECOMMENDED DRAIN PIPING . . . . . . . . . . . . . . . 10
5 TYPICAL FIELD WIRING . . . . . . . . . . . . . . . . . . . . . . 11
6 ENTHALPY SETPOINT ADJUSTMENT . . . . . . . . . . . 14
7 HONEYWELL ECONOMIZER CONTROL W7212 . . . 15
8 FOUR AND SIX POINT LOADS . . . . . . . . . . . . . . . . . 15
9 CENTER OF GRAVITY. . . . . . . . . . . . . . . . . . . . . . . . 16
10 UNIT DIMENSIONS - 20 TON. . . . . . . . . . . . . . . . . . . 19
11 DETAIL “X” ACCY. SIDE SUPPLY & RETURN
AIR OPENINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
12 DETAIL “Y” UNIT WITH RAIN HOODS. . . . . . . . . . . . 20
13 ALTITUDE/TEMPERATURE CONVERSION
FACTOR (°C/METER) . . . . . . . . . . . . . . . . . . . . . . . . 22
14 ALTITUDE/TEMPERATURE CONVERSION
FACTOR (°F/FEET) . . . . . . . . . . . . . . . . . . . . . . . . . . 22
15 BELT ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . 25
16 PRESSURE DROP ACROSS A DRY
INDOOR COIL VS SUPPLY AIR CFM . . . . . . . . . . . . 26
LIST OF TABLES
Tbl. # Pg. #
1 UNIT APPLICATION DATA. . . . . . . . . . . . . . . . . . . . . . 7
2 CONTROL WIRE SIZES. . . . . . . . . . . . . . . . . . . . . . . 12
3 ELECTRIC HEAT APPLICATION DATA. . . . . . . . . . . 12
4 FOUR AND SIX POINT LOADS . . . . . . . . . . . . . . . . . 16
5 PHYSICAL DATA - BASIC UNIT. . . . . . . . . . . . . . . . . 17
6 OPERATING WEIGHTS (KG./LBS.). . . . . . . . . . . . . . 17
7 VOLTAGE LIMITATIONS . . . . . . . . . . . . . . . . . . . . . . 18
8 ELECTRICAL DATA -WITHOUT POWERED
CONVENIENCE OUTLET. . . . . . . . . . . . . . . . . . . . . . 18
9 ELECTRICAL DATA -WITH POWERED
CONVENIENCE OUTLET. . . . . . . . . . . . . . . . . . . . . . 18
10 ELECTRIC HEAT CORRECTION FACTORS. . . . . . . 18
11 MINIMUM CLEARANCES (MM/IN.) . . . . . . . . . . . . . . 19
12 UTILITIES ENTRY DATA (MM/IN.). . . . . . . . . . . . . . . 19
13 ALTITUDE CORRECTION FACTORS (°C/METER). . 21
14 ALTITUDE CORRECTION FACTORS (°F/FEET). . . . 21
15 BQ240 SUPPLY AIR WITH DOWNFLOW DUCT
APPLICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
16 STATIC RESISTANCES . . . . . . . . . . . . . . . . . . . . . . . 24
17 POWER EXHAUST PERFORMANCE . . . . . . . . . . . . 24
18 BLOWER MOTOR AND DRIVE DATA . . . . . . . . . . . . 24
19 LIMIT CONTROL SETTING . . . . . . . . . . . . . . . . . . . . 31
20 ELECTRIC HEAT ANTICIPATOR SETPOINTS . . . . . 31
21 UNIT CONTROL BOARD FLASH CODES . . . . . . . . . 36

66396-YIM-C-1004
4Unitary Products Group
GENERAL
York®Model BQ units are single package heat pumps
equipped with optional factory installed electric heat-
ers. These are designed for outdoor installation on a
rooftop or slab.
The units are completely assembled on rigid, perma-
nently attached base rails. All piping, refrigerant
charge, and electrical wiring is factory installed and
tested. The units require electric power, duct connec-
tions, and fixed outdoor air intake damper (units with-
out economizer or motorized damper option only) at
the point of installation.
The supplemental electric heaters have nickel-chrome
elements and utilize single point power connection.
These units are designed and manufactured under ISO
9002 Quality System Certification.
SAFETY CONSIDERATIONS
Due to system pressure, moving parts and electrical
components, installation and servicing of air condition-
ing equipment can be hazardous. Only qualified,
trained, service personnel should install, repair, main-
tain or service this equipment.
Observe all precautions in the literature, on labels and
tags accompanying the equipment whenever working
on air conditioning equipment. Be sure to follow all
other safety precautions that apply.
Wear safety glasses and work gloves, and follow all
safety codes. Use a quenching cloth and have a fire
extinguisher available for all brazing operations.
INSPECTION
As soon as a unit is received, it should be inspected for
possible damage during transit. If damage is evident,
the extent of the damage should be noted on the car-
rier's freight bill. A separate request for inspection by
the carrier's agent should be made in writing. Refer to
Form 50.15-NM for additional information.
REFERENCE
Additional information on the design, installation, oper-
ation and service of this equipment is available in the
following reference forms:
• 035-19856-000 - Barometric Relief Damper
Accessory
• 035-19854-000 - Economizer Damper
Accessory
RENEWAL PARTS
Refer to Renewal Parts Manual for complete listing of
replacement parts on this equipment. Part Number
035-19284-000.
APPROVALS
Design certified by CSA as follows:
• For use as a heat pump only with or without
optional electric heat.
• For outdoor installation only.
• For installation on combustible material.
Installer should pay particular attention to the words:
NOTE, CAUTION and WARNING. Notes are intended
to clarify or make the installation easier. Cautions are
given to prevent equipment damage. Warnings are
given to alert installer that personal injury and/or equip-
ment damage may result if installation procedure is not
handled properly.
This product must be installed in strict compli-
ance with the enclosed installation instructions
and any applicable local, state, and national
codes including, but not limited to, building,
electrical, and mechanical codes.
Improper installation may create a condition
where the operation of the product could cause
personal injury or property damage.

66396-YIM-C-1004
Unitary Products Group 5
PRODUCT NOMENCLATURE
20T Sunline 2000™ Heat Pump Model Number Nomenclature
B Q 240 C 00 A 7 A AA 1
Product Category
B = Heat Pump, Single Package
Product Generation
1 = First Generation
Product Identifier
Q= Standard Efficiency Heat Pump
Installation Options Additional Options
A = No Options Installed (See Next Page)
Voltage B = Option 1
7= 380/415-3-50 C = Option 2
D = Options 1 & 2
Nominal Cooling Capacity - MBH E = Option 3
F = Options 4 G = Options 1 & 3
240 = 20 Ton
H = Options 1 & 4 J = Options 1, 2 & 3 K = Options 1, 2, & 4
A= Std Motor/Drive L = Options 1,3 & 4 B = Std Mtr/Drive/Single Input Econo M = Options 1, 2, 3, & 4 C = Std Mtr/Drive/Single Input Econo/Power Exhaust N = Options 2 & 3 D = Std Mtr/Drive/Motorized Damper P = Options 2 & 4
Heat Type & Nominal Heat Capacity F = Std Mtr/Drive/4" Filters Q = Options 2, 3, & 4
C00 = Cooling Only. No field installed electric heat G = Std Mtr/Drive/4" Filters/Single Input Econ R = Options 3 & 4
H = Std Mtr/Drive/4" Filters/Single Input Econ/Power Exhaust S = Option 5 L = Std Mtr/Drive/BAS Ready Econ (No BAS Controller) w/2" Pleated Filters T = Options 1 & 5 M = Std Mtr/Drive/BAS Ready Econ (No BAS Controller)/Power Exhaust w/2" Pleated Filters U = Options 1, 3, & 5 N = Hi Static Drive V = Options 1, 4, & 5 P = Hi Static Drive/Single Input Econo W = Options 1, 3, 4, & 5
Electric Heat Options
Q = Hi Static Drive/Single Input Econo/Power Exhaust X = Options 3 & 5
E18 = 18 KW
R = Hi Static Drive/Motorized Damper Y = Options 4 & 5
E36 = 36 KW
T = Hi Static Drive/4" Filters Z = Options 3, 4, & 5
E54 = 54 KW
U = Hi Static Drive/4" Filters/Single Input Econ Options
E72 = 72 KW
V = Hi Static Drive/4" Filters/Single Input Econ/Power Exhaust 1 = Disconnect Y = Hi Static Drive/BAS Ready Econ (No BAS Controller) w/2" Pleated Filters 2 = Non-Pwr'd Conv Oultet Z = Hi Static Drive/BAS Ready Econ (No BAS Controller)/Power Exhaust w/2" Pleated Filters 3 = Smoke Detector S.A.
4 = Smoke Detector R.A. 5 = Pwr'd Conv. Outlet
Airflow
York Brand

66396-YIM-C-1004
6Unitary Products Group
PRODUCT NOMENCLATURE - CONTINUED
AA = None BA = Hinged Filter Door & Tooless Access Panels
AB = Phase Monitor BB = Phase Monitor, Hinged Filter Door & Tooless Access Panels
AC = Coil Guard BC = Coil Guard, Hinged Filter Door & Tooless Access Panels
AD = Dirty Filter Switch BD = Dirty Filter Switch, Hinged Filter Door & Tooless Access Panels
AE = Phase Monitor & Coil Guard BE = Phase Monitor & Coil Guard, Hinged Filter Door & Tooless Access Panels
AF = Phase Monitor & Dirty Filter Switch BF = Phase Monitor & Dirty Filter Switch, Hinged Filter Door & Tooless Access Panels
AG = Coil Guard & Dirty Filter Switch BG = Coil Guard & Dirty Filter Switch, Hinged Filter Door & Tooless Access Panels
AH = Phase Monitor, Coil Guard, & Dirty Filter Switch BH = Phase Monitor, Coil Guard, & Dirty Filter Switch, Hinged Filter Door & Tooless Access Panels
CA = CPC Controller with Dirty Filter Switch & Air Proving Switch DA = CPC Controller with Dirty Filter Switch & Air Proving Switch, Hinged Filter Door & Tooless Access Panels
CB = CPC Controller, DFS, APS & Phase Monitor DB = CPC Controller, DFS, APS & Phase Monitor, Hinged Filter Door & Tooless Access Panels
CC = CPC Controller, DFS, APS & Coil Guard DC = CPC Controller, DFS, APS & Coil Guard, Hinged Filter Door & Tooless Access Panels
CD = CPC Controller, DFS, APS, Phase Monitor, & Coil Guard DD = CPC Controller, DFS, APS, Phase Monitor, & Coil Guard, Hinged Filter Door & Tooless Access Panels
CE = CPC Controller, DFS, APS & Technicoat Cond. Coil DE = CPC Controller, DFS, APS & Technicoat Cond. Coil, Hinged Filter Door & Tooless Access Panels
CF = CPC Controller, DFS, APS, Technicoat Cond. Coil, & Phase Monitor DF = CPC Controller, DFS, APS, Technicoat Cond. Coil, & Phase Monitor, Hinged Filter Door & Tooless Access Panels
CG = CPC Controller, DFS, APS, Technicoat Cond. Coil, & Coil Guard DG = CPC Controller, DFS, APS, Technicoat Cond. Coil, & Coil Guard, Hinged Filter Door & Tooless Access Panels
CH = CPC Controller, DFS, APS, Technicoat Cond. Coil, Phase Monitor, & Coil Guard DH = CPC Controller, DFS, APS, Technicoat Cond. Coil, Phase Monitor, & Coil Guard, Hinged Filter Door & Tooless Access Panels
CJ = CPC Controller, DFS, APS & Technicoat Evap. Coil DJ = CPC Controller, DFS, APS & Technicoat Evap. Coil, Hinged Filter Door & Tooless Access Panels
CK = CPC Controller, DFS, APS, Technicoat Evap. Coil, & Phase Monitor DK = CPC Controller, DFS, APS, Technicoat Evap. Coil, & Phase Monitor, Hinged Filter Door & Tooless Access Panels
CL = CPC Controller, DFS, APS, Technicoat Evap. Coil, & Coil Guard DL = CPC Controller, DFS, APS, Technicoat Evap. Coil, & Coil Guard, Hinged Filter Door & Tooless Access Panels
CM = CPC Controller, DFS, APS, Technicoat Evap. Coil, Phase Monitor, & Coil Guard DM = CPC Controller, DFS, APS, Technicoat Evap. Coil, Phase Monitor, & Coil Guard, Hinged Filter Door & Tooless Access Panels
CN = CPC Controller, DFS, APS & Technicoat Evap. & Cond Coils DN = CPC Controller, DFS, APS & Technicoat Evap. & Cond Coils, Hinged Filter Door & Tooless Access Panels
CP = CPC Controller, DFS, APS, Technicoat Evap. & Cond Coils, & Phase Monitor DP = CPC Controller, DFS, APS, Technicoat Evap. & Cond Coils, & Phase Monitor, Hinged Filter Door & Tooless Access Panels
CQ = CPC Controller, DFS, APS, Technicoat Evap. & Cond Coils, & Coil Guard DQ = CPC Controller, DFS, APS, Technicoat Evap. & Cond Coils, & Coil Guard, Hinged Filter Door & Tooless Access Panels
CR = CPC Controller, DFS, APS, Technicoat Evap. & Cond Coils, Phase Monitor, & Coil Guard DR = CPC Controller, DFS, APS, Technicoat Evap. & Cond Coils, Phase Monitor, & Coil Guard, Hinged Filter Door & Tooless Access Panels
JA = Johnson UNT Controller with Dirty Filter Switch & Air Proving Switch EA = Johnson UNT Controller with Dirty Filter Switch & Air Proving Switch, Hinged Filter Door & Tooless Access Panels
JB = Johnson UNT Controller, DFS, APS & Phase Monitor EB = Johnson UNT Controller, DFS, APS & Phase Monitor, Hinged Filter Door & Tooless Access Panels
JC = Johnson UNT Controller, DFS, APS & Coil Guard EC = Johnson UNT Controller, DFS, APS & Coil Guard, Hinged Filter Door & Tooless Access Panels
JD = Johnson UNT Controller, DFS, APS, Phase Monitor, & Coil Guard
JE = Johnson UNT Controller, DFS, APS & Technicoat Cond. Coil
JF = Johnson UNT Controller, DFS, APS, Technicoat Cond. Coil, & Phase Monitor
JG = Johnson UNT Controller, DFS, APS, Technicoat Cond. Coil, & Coil Guard EG = Johnson UNT Controller, DFS, APS, Technicoat Cond. Coil, & Coil Guard, Hinged Filter Door & Tooless Access Panels
JH = Johnson UNT Controller, DFS, APS, Technicoat Cond. Coil, Phase Monitor, & Coil Guard EH = Johnson UNT Controller, DFS, APS, Technicoat Cond. Coil, Phase Monitor, & Coil Guard, Hinged Filter Door & Tooless Access Panels
JJ = Johnson UNT Controller, DFS, APS & Technicoat Evap. Coil EJ = Johnson UNT Controller, DFS, APS & Technicoat Evap. Coil, Hinged Filter Door & Tooless Access Panels
JK = Johnson UNT Controller, DFS, APS, Technicoat Evap. Coil, & Phase Monitor EK = Johnson UNT Controller, DFS, APS, Technicoat Evap. Coil, & Phase Monitor, Hinged Filter Door & Tooless Access Panels
JL = Johnson UNT Controller, DFS, APS, Technicoat Evap. Coil, & Coil Guard EL = Johnson UNT Controller, DFS, APS, Technicoat Evap. Coil, & Coil Guard, Hinged Filter Door & Tooless Access Panels
JM = Johnson UNT Controller, DFS, APS, Technicoat Evap. Coil, Phase Monitor, & Coil Guard EM = Johnson UNT Controller, DFS, APS, Technicoat Evap. Coil, Phase Monitor, & Coil Guard, Hinged Filter Door & Tooless Access Panels
JN = Johnson UNT Controller, DFS, APS & Technicoat Evap. & Cond Coils EN = Johnson UNT Controller, DFS, APS & Technicoat Evap. & Cond Coils, Hinged Filter Door & Tooless Access Panels
JP = Johnson UNT Controller, DFS, APS, Technicoat Evap. & Cond Coils, & Phase Monitor EP = Johnson UNT Controller, DFS, APS, Technicoat Evap. & Cond Coils, & Phase Monitor, Hinged Filter Door & Tooless Access Panels
JQ = Johnson UNT Controller, DFS, APS, Technicoat Evap. & Cond Coils, & Coil Guard EQ = Johnson UNT Controller, DFS, APS, Technicoat Evap. & Cond Coils, & Coil Guard, Hinged Filter Door & Tooless Access Panels
JR = Johnson UNT Controller, DFS, APS, Technicoat Evap. & Cond Coils, Phase Monitor, & Coil Guard ER = Johnson UNT Controller, DFS, APS, Technicoat Evap. & Cond Coils, Phase Monitor, & Coil Guard, Hinged Filter Door & Tooless Access Panels
HA = Honeywell Excel 10 Controller with Dirty Filter Switch & Air Proving Switch GA = Honeywell Excel 10 Controller with Dirty Filter Switch & Air Proving Switch, Hinged Filter Door & Tooless Access Panels
HB = Honeywell Excel 10 Controller, DFS, APS & Phase Monitor GB = Honeywell Excel 10 Controller, DFS, APS & Phase Monitor, Hinged Filter Door & Tooless Access Panels
HC = Honeywell Excel 10 Controller, DFS, APS & Coil Guard GC = Honeywell Excel 10 Controller, DFS, APS & Coil Guard, Hinged Filter Door & Tooless Access Panels
HD = Honeywell Excel 10 Controller, DFS, APS, Phase Monitor, & Coil Guard GD = Honeywell Excel 10 Controller, DFS, APS, Phase Monitor, & Coil Guard, Hinged Filter Door & Tooless Access Panels
HE = Honeywell Excel 10 Controller, DFS, APS & Technicoat Cond. Coil GE = Honeywell Excel 10 Controller, DFS, APS & Technicoat Cond. Coil, Hinged Filter Door & Tooless Access Panels
HF = Honeywell Excel 10 Controller, DFS, APS, Technicoat Cond. Coil, & Phase Monitor GF = Honeywell Excel 10 Controller, DFS, APS, Technicoat Cond. Coil, & Phase Monitor, Hinged Filter Door & Tooless Access Panels
HG = Honeywell Excel 10 Controller, DFS, APS, Technicoat Cond. Coil, & Coil Guard GG = Honeywell Excel 10 Controller, DFS, APS, Technicoat Cond. Coil, & Coil Guard, Hinged Filter Door & Tooless Access Panels
HH = Honeywell Excel 10 Controller, DFS, APS, Technicoat Cond. Coil, Phase Monitor, & Coil Guard GH = Honeywell Excel 10 Controller, DFS, APS, Technicoat Cond. Coil, Phase Monitor, & Coil Guard, Hinged Filter Door & Tooless Access Panels
HJ = Honeywell Excel 10 Controller, DFS, APS & Technicoat Evap. Coil GJ = Honeywell Excel 10 Controller, DFS, APS & Technicoat Evap. Coil, Hinged Filter Door & Tooless Access Panels
HK = Honeywell Excel 10 Controller, DFS, APS, Technicoat Evap. Coil, & Phase Monitor GK = Honeywell Excel 10 Controller, DFS, APS, Technicoat Evap. Coil, & Phase Monitor, Hinged Filter Door & Tooless Access Panels
HL = Honeywell Excel 10 Controller, DFS, APS, Technicoat Evap. Coil, & Coil Guard GL = Honeywell Excel 10 Controller, DFS, APS, Technicoat Evap. Coil, & Coil Guard, Hinged Filter Door & Tooless Access Panels
HM = Honeywell Excel 10 Controller, DFS, APS, Technicoat Evap. Coil, Phase Monitor, & Coil Guard GM = Honeywell Excel 10 Controller, DFS, APS, Technicoat Evap. Coil, Phase Monitor, & Coil Guard, Hinged Filter Door & Tooless Access Panels
HN = Honeywell Excel 10 Controller, DFS, APS & Technicoat Evap. & Cond Coils GN = Honeywell Excel 10 Controller, DFS, APS & Technicoat Evap. & Cond Coils, Hinged Filter Door & Tooless Access Panels
HP = Honeywell Excel 10 Controller, DFS, APS, Technicoat Evap. & Cond Coils, & Phase Monitor GP = Honeywell Excel 10 Controller, DFS, APS, Technicoat Evap. & Cond Coils, & Phase Monitor, Hinged Filter Door & Tooless Access Panels
HQ = Honeywell Excel 10 Controller, DFS, APS, Technicoat Evap. & Cond Coils, & Coil Guard GQ = Honeywell Excel 10 Controller, DFS, APS, Technicoat Evap. & Cond Coils, & Coil Guard, Hinged Filter Door & Tooless Access Panels
HR = Honeywell Excel 10 Controller, DFS, APS, Technicoat Evap. & Cond Coils, Phase Monitor, & Coil Guard GR = Honeywell Excel 10 Controller, DFS, APS, Technicoat Evap. & Cond Coils, Phase Monitor, & Coil Guard, Hinged Filter Door & Tooless Access Panels
NA = Novar ETC-3 Controller with Dirty Filter Switch & Air Proving Switch PA = Novar ETC-3 Controller with Dirty Filter Switch & Air Proving Switch, Hinged Filter Door & Tooless Access Panels
NB = Novar ETC-3 Controller, DFS, APS & Phase Monitor PB = Novar ETC-3 Controller, DFS, APS & Phase Monitor, Hinged Filter Door & Tooless Access Panels
NC = Novar ETC-3 Controller, DFS, APS & Coil Guard PC = Novar ETC-3 Controller, DFS, APS & Coil Guard, Hinged Filter Door & Tooless Access Panels
ND = Novar ETC-3 Controller, DFS, APS, Phase Monitor, & Coil Guard PD = Novar ETC-3 Controller, DFS, APS, Phase Monitor, & Coil Guard, Hinged Filter Door & Tooless Access Panels
NE = Novar ETC-3 Controller, DFS, APS & Technicoat Cond. Coil PE = Novar ETC-3 Controller, DFS, APS & Technicoat Cond. Coil, Hinged Filter Door & Tooless Access Panels
NF = Novar ETC-3 Controller, DFS, APS, Technicoat Cond. Coil, & Phase Monitor PF = Novar ETC-3 Controller, DFS, APS, Technicoat Cond. Coil, & Phase Monitor, Hin
g
ed Filter Door & Tooless Acc
e
NG = Novar ETC-3 Controller, DFS, APS, Technicoat Cond. Coil, & Coil Guard PG = Novar ETC-3 Controller, DFS, APS, Technicoat Cond. Coil, & Coil Guard, Hinged Filter Door & Tooless Access Panels
NH = Novar ETC-3 Controller, DFS, APS, Technicoat Cond. Coil, Phase Monitor, & Coil Guard PH = Novar ETC-3 Controller, DFS, APS, Technicoat Cond. Coil, Phase Monitor, & Coil Guard, Hinged Filter Door & Tooless Access Panels
NJ = Novar ETC-3 Controller, DFS, APS & Technicoat Evap. Coil PJ = Novar ETC-3 Controller, DFS, APS & Technicoat Evap. Coil, Hinged Filter Door & Tooless Access Panels
NK = Novar ETC-3 Controller, DFS, APS, Technicoat Evap. Coil, & Phase Monitor PK = Novar ETC-3 Controller, DFS, APS, Technicoat Evap. Coil, & Phase Monitor, Hinged Filter Door & Tooless Access Panels
NL = Novar ETC-3 Controller, DFS, APS, Technicoat Evap. Coil, & Coil Guard PL = Novar ETC-3 Controller, DFS, APS, Technicoat Evap. Coil, & Coil Guard, Hinged Filter Door & Tooless Access Panels
NM = Novar ETC-3 Controller, DFS, APS, Technicoat Evap. Coil, Phase Monitor, & Coil Guard PM = Novar ETC-3 Controller, DFS, APS, Technicoat Evap. Coil, Phase Monitor, & Coil Guard, Hinged Filter Door & Tooless Access Panels
NN = Novar ETC-3 Controller, DFS, APS & Technicoat Evap. & Cond Coils PN = Novar ETC-3 Controller, DFS, APS & Technicoat Evap. & Cond Coils, Hinged Filter Door & Tooless Access Panels
NP = Novar ETC-3 Controller, DFS, APS, Technicoat Evap. & Cond Coils, & Phase Monitor PP = Novar ETC-3 Controller, DFS, APS, Technicoat Evap. & Cond Coils, & Phase Monitor, Hinged Filter Door & Tooless Access Panels
NQ = Novar ETC-3 Controller, DFS, APS, Technicoat Evap. & Cond Coils, & Coil Guard PQ = Novar ETC-3 Controller, DFS, APS, Technicoat Evap. & Cond Coils, & Coil Guard, Hinged Filter Door & Tooless Access Panels
NR = Novar ETC-3 Controller, DFS, APS, Technicoat Evap. & Cond Coils, Phase Monitor, & Coil Guard PR = Novar ETC-3 Controller, DFS, APS, Technicoat Evap. & Cond Coils, Phase Monitor, & Coil Guard, Hinged Filter Door & Tooless Access Panels
TA = Technicoat Condenser Coil UA = Technicoat Condenser Coil, Hinged Filter Door & Tooless Access Panels
TB = Technicoat Condenser Coil & Phase Monitor UB = Technicoat Condenser Coil & Phase Monitor, Hinged Filter Door & Tooless Access Panels
TC = Technicoat Condenser Coil & Coil Guard UC = Technicoat Condenser Coil & Coil Guard, Hinged Filter Door & Tooless Access Panels
TD = Technicoat Condenser Coil & Dirty Filter Switch UD = Technicoat Condenser Coil & Dirty Filter Switch, Hinged Filter Door & Tooless Access Panels
TE = Technicoat Condenser Coil, Phase Monitor, & Coil Guard UE = Technicoat Condenser Coil, Phase Monitor, & Coil Guard, Hinged Filter Door & Tooless Access Panels
TF = Technicoat Condenser Coil, Phase Monitor, & Dirty Filter Switch UF = Technicoat Condenser Coil, Phase Monitor, & Dirty Filter Switch, Hinged Filter Door & Tooless Access Panels
TG = Technicoat Condenser Coil, Coil Guard, & Dirty Filter Switch UG = Technicoat Condenser Coil, Coil Guard, & Dirty Filter Switch, Hinged Filter Door & Tooless Access Panels
TH = Technicoat Condenser Coil, Phase Monitor, Coil Guard, & Dirty Filter Switch UH = Technicoat Condenser Coil, Phase Monitor, Coil Guard, & Dirty Filter Switch, Hinged Filter Door & Tooless Access Panels
TJ = Technicoat Evaporator Coil UJ = Technicoat Evaporator Coil, Hinged Filter Door & Tooless Access Panels
TK = Technicoat Evaporator Coil & Phase Monitor UK = Technicoat Evaporator Coil & Phase Monitor, Hinged Filter Door & Tooless Access Panels
TL = Technicoat Evaporator Coil & Coil Guard UL = Technicoat Evaporator Coil & Coil Guard, Hinged Filter Door & Tooless Access Panels
TM = Technicoat Evaporator Coil & Dirty Filter Switch UM = Technicoat Evaporator Coil & Dirty Filter Switch, Hinged Filter Door & Tooless Access Panels
TN = Technicoat Evaporator Coil, Phase Monitor, & Coil Guard UN = Technicoat Evaporator Coil, Phase Monitor, & Coil Guard, Hinged Filter Door & Tooless Access Panels
TP = Technicoat Evaporator Coil, Phase Monitor, & Dirty Filter Switch UP = Technicoat Evaporator Coil, Phase Monitor, & Dirty Filter Switch, Hinged Filter Door & Tooless Access Panels
TQ = Technicoat Evaporator Coil, Coil Guard, & Dirty Filter Switch UQ = Technicoat Evaporator Coil, Coil Guard, & Dirty Filter Switch, Hinged Filter Door & Tooless Access Panels
TR = Technicoat Evaporator Coil, Phase Monitor, Coil Guard, & Dirty Filter Switch UR = Technicoat Evaporator Coil, Phase Monitor, Coil Guard, & Dirty Filter Switch, Hinged Filter Door & Tooless Access Panels
TS = Technicoat Evaporator & Condenser Coils US = Technicoat Evaporator & Condenser Coils, Hinged Filter Door & Tooless Access Panels
TT = Technicoat Evaporator & Condenser Coils & Phase Monitor UT = Technicoat Evaporator & Condenser Coils & Phase Monitor, Hinged Filter Door & Tooless Access Panels
TU = Technicoat Evaporator & Condenser Coils & Coil Guard UU = Technicoat Evaporator & Condenser Coils & Coil Guard, Hinged Filter Door & Tooless Access Panels
TV = Technicoat Evaporator & Condenser Coils & Dirty Filter Switch UV = Technicoat Evaporator & Condenser Coils & Dirty Filter Switch, Hinged Filter Door & Tooless Access Panels
TW = Technicoat Evaporator & Condenser Coils, Phase Monitor, & Coil Guard UW = Technicoat Evaporator & Condenser Coils, Phase Monitor, & Coil Guard, Hinged Filter Door & Tooless Access Panels
TX = Technicoat Evaporator & Condenser Coils, Phase Monitor, & Dirty Filter Switch UX = Technicoat Evaporator & Condenser Coils, Phase Monitor, & Dirty Filter Switch, Hinged Filter Door & Tooless Access Panels
TY = Technicoat Evaporator & Condenser Coils, Coil Guard, & Dirty Filter Switch UY = Technicoat Evaporator & Condenser Coils, Coil Guard, & Dirty Filter Switch, Hinged Filter Door & Tooless Access Panels
TZ = Technicoat Evaporator & Condenser Coils, Phase Monitor, Coil Guard, & Dirty Filter Switch UZ = Technicoat Evaporator & Condenser Coils, Phase Monitor, Coil Guard, & Dirty Filter Switch, Hinged Filter Door & Tooless Access Panels
EF = Johnson UNT Controller, DFS, APS, Technicoat Cond. Coil, & Phase Monitor, Hinged Filter Door & Tooless Access Panels
EE = Johnson UNT Controller, DFS, APS & Technicoat Cond. Coil, Hinged Filter Door & Tooless Access Panels
ED = Johnson UNT Controller, DFS, APS, Phase Monitor, & Coil Guard, Hinged Filter Door & Tooless Access Panels
20T Sunline 2000™ Heat Pump Model Number Nomenclature
Additional Options

66396-YIM-C-1004
Unitary Products Group 7
INSTALLATION
INSTALLATION SAFETY INFORMATION:
Read these instructions before continuing this appli-
ance installation. This is an outdoor combination heat-
ing and cooling unit. The installer must assure that
these instructions are made available to the consumer
and with instructions to retain them for future reference.
1. Install this furnace only in a location and position
as specified on Page 7 of these instructions.
2. This equipment is not to be used for temporary
heating of buildings or structures under construc-
tion.
LIMITATIONS
These units must be installed in accordance with the
following national and local safety codes:
In U.S.A.:
• National Electrical Code ANSI/NFPA No. 70.
• Local gas utility requirements.
In Canada:
• Current Canadian Electrical Code C22.1.
• Local plumbing and waste water codes.
• Other applicable local codes.
Refer to the Unit Application Data table and to the Elec-
tric Heat Application Data table.
If components are to be added to a unit to meet local
codes, they are to be installed at the dealer's and/or
the customer's expense.
Size of unit for proposed installation should be based
on heat loss/heat gain calculation made according to
the methods of the Air Conditioning Contractors of
America (ACCA).
This furnace is not to be used for temporary heating of
buildings or structures under construction.
LOCATION
Use the following guidelines to select a suitable loca-
tion for these units.
1. Unit is designed for outdoor installation only.
2. Condenser coils must have an unlimited supply of
air.
3. Where a choice of location is possible, position the
unit on either north or east side of building.
4. For ground level installation, use a level concrete
slab with a minimum thickness of 102 mm (4”). The
length and width should be at least 152 mm (6”)
greater than the unit base rails. Do not tie slab to
the building foundation.
5. Roof structures must be able to support the weight
of the unit and its options and/or accessories. Unit
must be installed on a solid level roof curb or
appropriate angle iron frame.
6. Maintain level tolerance to 13 mm (1/2”) maximum
across the entire length or width of the unit.
If a unit is to be installed on a roof curb or special frame
other than a York®roof curb, gasketing must be applied
to all surfaces that come in contact with the unit under-
side.
TABLE 1: UNIT APPLICATION DATA
UNIT MODEL NUMBER BQ240
Voltage Variation,
Min. / Max.1380/415-3-50 342/456
Supply Air m3/s (CFM), Min. / Max. 2.9 (6,000) / 4.7 (9,400)
Wet Bulb Temperature of Air on
Evaporator Coil, Min. / Max. °C
°F 14 / 22
57 / 72
Dry Bulb Temperature of Air on
Condenser Coil, Min. / Max. °C
°F -18 / 49
0 / 120
1. Utilization range “A” in accordance with ARI Standard 110.

66396-YIM-C-1004
8Unitary Products Group
RIGGING AND HANDLING
Exercise care when moving the unit. Do not remove
any packaging until the unit is near the place of installa-
tion. Rig the unit by attaching chain or cable slings to
the round lifting holes provided in the base rails.
Spreaders, whose length exceeds the largest dimen-
sion across the unit, MUST BE USED. Refer to
Figure 1.
Units may also be moved or lifted with a forklift, from
the side only, providing that an accessory skid is used.
LENGTH OF FORKS MUST BE A MINIMUM OF 2286
mm (90").
Refer to the Physical Data Table 5 for unit weights and
to the Figures 2 or 12 for approximate center of gravity. CLEARANCES
All units require certain clearances for proper operation
and service. Installer must make provisions for ade-
quate ventilation air. Refer to Unit Dimensions
Figure 10 and Minimum Clearances Table 11 for the
clearances required for combustible construction, ser-
vicing, and proper unit operation.
DUCTWORK
Ductwork should be designed and sized according to
the methods in Manual Q of the Air Conditioning Con-
tractors of America (ACCA).
A closed return duct system shall be used. This shall
not preclude use of economizers or outdoor fresh air
intake. The supply and return air duct connections at
the unit should be made with flexible joints to minimize
noise.
Before lifting a unit, make sure that all panels
are in place and that its weight is distributed
equally on all cables so it will lift evenly.
FIGURE 1 - TYPICAL RIGGING
C A U T I O N :
B E F O R E L I F T I N G U N I T ,
M A K E S U R E T H A T I T S
W I D T H I S D I S T R I B U T E D
E Q U A L L Y O N T H E C A B L E S
S O T H A T I T W I L L L I F T
E V E N L Y
L I F T I N G
H O L E S
SPREADER
BAR
FIGURE 2 - CENTER OF GRAVITY
Do not permit overhanging structures or shrubs
to obstruct outdoor air discharge outlet, com-
bustion air inlet or vent outlets.

66396-YIM-C-1004
Unitary Products Group 9
The supply and return air duct systems should be
designed for the CFM and static requirements of the
job. They should NOT be sized to match the dimen-
sions of the duct connections on the unit.
Refer to Unit Dimensions Figure 10 for information
concerning side and bottom supply and return air duct
openings.
FIXED OUTDOOR AIR INTAKE DAMPER
This damper is shipped inside the return air compart-
ment. It is completely assembled and ready for installa-
tion. A damper baffle inside of the hood is adjustable to
provide variable amounts of outdoor air intake on units
that are not provided with an economizer or a motor-
ized damper option. Refer to the Fixed Outdoor
Damper Figure 3.
Gasketing and mounting screws are provided in a parts
bag attached to the hood assembly. Apply gasketing to
the three flange surfaces on the hood prior to installing
the hood. Extend gasketing 6 mm (1/4”) beyond the top
and bottom of the two side flanges to insure adequate
sealing.
Adjusting the damper to the desired air flow may be
done before mounting the hood into position or after
installation by removing the front hood panel or the
screen on the bottom of the hood. Damper baffle in
position 1 will allow approximately 10% outdoor air
flow, position 2 approximately 15% and, to allow
approximately 25%, remove the damper baffle.
On units with bottom return air application install the
damper assembly over the opening in the side return
air access panel. Remove and discard the opening
cover and the covering over the hood mounting holes
(used for shipping) before installing. Secure with the
screws provided.
On units with side return air applications, install the
damper assembly on the return air ductwork as close
to the unit as possible. Cut an opening 406 mm (16”)
high by 457 mm (18”) wide in the ductwork to accom-
modate the damper. Using the holes in the hood
flanges as a template, drill 3.6 mm (9/64”) dia. (#26
drill) holes into the ductwork and secure with the
screws provided.
CONDENSATE DRAIN
Plumbing must conform to local codes. Use a sealing
compound on male pipe threads. Install a condensate
drain line from the 25 mm (1”) NPT female connection
on the unit to an open drain.
NOTE: The condensate drain operates in a negative
pressure in the cabinet. The condensate drain
line MUST be trapped to provide proper drain-
age. See Figure 4.
When fastening ductwork to side duct flanges
on unit, insert screws through duct flanges
only. DO NOT insert screws through casing.
Outdoor ductwork must be insulated and
waterproofed. If outdoor air intake will not be required on
units with bottom return air applications, the
damper assembly should still be mounted on
the side return air access panel, per the
instructions above, to insure moisture is not
drawn into the unit during operation. The cov-
ering over the mounting holes only need be
removed. Do not remove the opening cover.
FIGURE 3 - FIXED OUTDOOR AIR DAMPER

66396-YIM-C-1004
10 Unitary Products Group
COMPRESSORS
Units are shipped with compressor mountings factory-
adjusted and ready for operation.
FILTERS
51 mm (2”) or 102 mm (4”) filters can be supplied with
each unit. Filters must always be installed ahead of the
evaporator coil and must be kept clean or replaced with
same size and type. Dirty filters will reduce the capacity
of the unit and will result in frosted coils or safety shut-
down. Minimum filter area and required sizes are
shown in Physical Data Table 5.
SERVICE ACCESS
The following removable panels provide access to all
serviceable components:
• Compressor compartment
• Electric Heat compartment
• Side Supply & Return Air compartments
(Two panels)
• Blower compartment (Three panels)
• Main control box
• Filter compartment
• Outdoor Air compartment (Two panels)
Refer to the Unit Dimensions Figure 10 for location of
these access panels.
FIGURE 4 - RECOMMENDED DRAIN PIPING
Do not loosen compressor mounting bolts.
Make sure that all screws and panel latches
are replaced and properly positioned on the
unit to maintain an airtight seal.

66396-YIM-C-1004
Unitary Products Group 11
FIGURE 5 - TYPICAL FIELD WIRING
W2
RC
RH
Y1
Y2
W1
G
C
X1
X3
X4
A1
A2
T
T
W2
Y1
Y2
W1
G
C
OCC
X
R
THERMOSTAT
1
TERMINALS UNIT CONTROL
BOARD
1
ElectronicprogrammableThermostat2ET0770010024(includessubbase).
2

TerminalsA1andA2providearelayoutput toclosetheoutdoor
economizerdamperswhenthethermostatswitchestotheset-backposition

.
24Volt
Transformer
2
TOREMOTESENSOR
2ET04701324IFUSED

O C C
W 1
W 2
Y 1
G
Y 2
X
R
S D
C
R E M O T E M I N P O S
W 1
W 2
Y 1
G
Y 2
C
U N I T C O N T R O L
B O A R D
T - S T A T
R H
R C
  







  
 
The thermostat must provide a “G” sig-
nal when there is a call for “W1.”The
unit control board will energize the
indoor blower when the compressors
are energized; however, if the thermo-
stat calls for “W2” during the anti-short-
cycle delay, the electric heat (when
installed) will be energized immediately
upon the call for “W2.”

66396-YIM-C-1004
12 Unitary Products Group
THERMOSTAT
The room thermostat should be located on an inside
wall approximately 1422 mm (56”) above the floor
where it will not be subject to drafts, sun exposure or
heat from electrical fixtures or appliances. Follow man-
ufacturer's instructions enclosed with thermostat for
general installation procedure. A minimum of seven
color-coded insulated wires 1.0 mm2(#18 AWG)
should be used to connect thermostat to unit.
POWER AND CONTROL WIRING
Field wiring to the unit must conform to provisions of
the National Electrical Code, ANSI / NFPA No. 70 (in
U.S.A.), current Canadian Electrical Code C22.1 (in
Canada) and/or local ordinances. The unit must be
electrically grounded in accordance with NEC and CEC
(as specified above) and/or local codes. Voltage toler-
ances, which must be maintained at the compressor
terminals, during starting and running conditions, are
indicated on the unit Rating Plate and the Unit Applica-
tion Data table.
The internal wiring harness furnished with this unit is
an integral part of a CSA design certified unit. Field
alteration to comply with electrical codes should not be
required.
A fused disconnect switch should be field provided for
the unit. The switch must be separate from all other cir-
cuits. Wire entry at knockout openings require conduit
fittings to comply with NEC (in U.S.A.), CEC (in Can-
ada) and/or local codes. Refer to the Unit Dimensions
Figure 10 and Utilities Entry Data Table 12 for installa-
tion location. If any of the wire supplied with the unit
must be replaced, replacement wire must be of the
type shown on the wiring diagram and the same mini-
mum gauge as the replaced wire.
Electrical line must be sized properly to carry the load.
Use copper conductors only. Each unit must be wired
with a separate branch circuit fed directly from the
meter panel and properly fused.
Refer to the Typical Field Wiring Figure 5 and to the
appropriate unit wiring diagram for control circuit and
power wiring information.
OPTIONAL ELECTRIC HEAT
The factory-installed heaters are wired for single point
power supply. Power supply need only be brought into
the single point terminal block and thermostat wiring to
the low voltage terminal strip located in the upper por-
tion of the unit control box.
These CSA approved heaters are located within the
central compartment of the unit with the heater ele-
ments extending into the supply air chamber. Refer to
Figure 10 for access panel location.
Fuses are supplied, where required, by the factory.
Some KW sizes require fuses and others do not. Refer
to Table 3 for minimum CFM limitations and to Tables
7, 8 and 9 for electrical data.
When connecting electrical power and control
wiring to the unit, waterproof type connectors
MUST BE USED so that water or moisture
cannot be drawn into the unit during normal
operation. The above waterproofing conditions
will also apply when installing a field-supplied
disconnect switch.
TABLE 2: CONTROL WIRE SIZES
Wire Size Maximum Length1
1. From the unit to the thermostat and back to the unit.
18 AWG 45.72 meters (150 Feet)
TABLE 3: ELECTRIC HEAT APPLICATION DATA
NOMINAL
HEATER SIZE
(KW)
VOLTAGE
3-PHASE,
50 HZ
MINIMUM m3/s (CFM) UNIT SIZE
20 TON
18
380/415 2.9 (6000)
36
54
72

66396-YIM-C-1004
Unitary Products Group 13
OPTIONAL ECONOMIZER/MOTORIZED DAMPER RAIN
HOOD
The instruction for the optional economizer/motorized
damper rain hood can be found in form 035-19854-
000. Use these instructions when field assembling an
economizer rain hood onto a unit. The outdoor and
return air dampers, the damper actuator, the damper
linkage, the outdoor and return air divider baffles, and
all the control sensors are factory mounted as part of
the "Factory installed" economizer option.
OPTIONAL POWER EXHAUST/BAROMETRIC RELIEF
DAMPER AND RAIN HOOD
The instructions for the power exhaust/barometric relief
damper and rain hood can be found in form 035-
19856-000. The exhaust fan, all supporting brackets,
angles, and the wiring are factory installed as part of
the power exhaust option.
All of the components, including the dampers, hard-
ware, and mounting instructions are shipped in a single
package external from the unit. The hood must be field
assembled and installed.
Power exhaust is not available as a field installed
accessory.
OPTIONAL ECONOMIZER AND POWER EXHAUST
DAMPER SET POINT ADJUSTMENTS AND INFORMA-
TION
Remove the economizer access panel from the unit.
Loosen but do not remove the two panel latches.
Locate the economizer control module, where the fol-
lowing adjustments will be made.
Check that the damper blades move smoothly without
binding; carefully turn the Minimum Position Adjusting
screw (found on the damper control module) fully
clockwise and then set the thermostat indoor fan switch
to the on position and then off, or energize and de-
energize terminals "R" to "G".
MINIMUM POSITION ADJUSTMENT
With thermostat set to indoor fan on position, or
terminals "R" to "G" energized, turn the Minimum
Position Adjusting screw (located on the damper
control module) counterclockwise until the desired
minimum damper position has been attained.
ENTHALPY SET POINT ADJUSTMENT
The enthalpy set point may now be set by selecting the
desired setpoint shown in the Enthalpy Setpoint Adjust-
ment Figure 6. Adjust as follows:
• For a single enthalpy operation carefully turn the
set point adjusting screw (found on the damper
control module) to the "A", "B", "C" or "D" setting
corresponding to the lettered curve of the Enthalpy
Setpoint Adjustment Figure 6.
• For a dual enthalpy operation, carefully turn the set
point adjusting screw fully clockwise past the "D"
setting.
POWER EXHAUST DAMPER SETPOINT (WITH OR WITH-
OUT POWER EXHAUST)
• With no power exhaust option, adjust the Exhaust
Air Adjustment Screw fully clockwise. This will
allow 2nd stage cooling to operate.
• With power exhaust option, each building pressur-
ization requirement will be different. The point at
which the power exhaust comes on is determined
by the economizer damper position (Percent
Open). The Exhaust Air Adjustment Screw should
be set at the Percent Open of the economizer
damper at which the power exhaust is needed. It
can be set from 0 to 100% damper open.
INDOOR AIR QUALITY AQ
Indoor Air quality (indoor sensor input): Terminal AQ
accepts a +2 to +10 Vdc signal with respect to the
(AQ1) terminal. When the signal is below it's setpoint,
the actuator is allowed to modulate normally in
accordance with the enthalpy and mixed air sensor
inputs. When the AQ signal exceeds it's setpoint
setting and there is no call for free cooling, the actuator
is proportionately modulated from the 2 to 10 Vdc
signal, with 2 Vdc corresponding to full closed and 10
Vdc corresponding to full open. When there is no call
for free cooling, the damper position is limited by the
IAQ Max damper position setting. When the signal
exceeds it's setpoint (Demand Control Ventilation
Setpoint) setting and there is a call for free cooling, the
actuator modulates from the minimum position to the
full open position based on the highest call from either
the mixed air sensor input or the AQ voltage input.
• Optional CO2Space Sensor Kit Part #
2AQ04700324
• Optional CO2Unit Sensor Kit Part # 2AQ04700424
Replace the economizer access panel.
Extreme care must be exercised in turning all
setpoint, maximum, and minimum damper
positioning adjustment screws to prevent twist-
ing them off.

66396-YIM-C-1004
14 Unitary Products Group
FIGURE 6 - ENTHALPY SETPOINT ADJUSTMENT

66396-YIM-C-1004
Unitary Products Group 15
FIGURE 7 - HONEYWELL ECONOMIZER CONTROL W7212
N1 N
P1 P
EXH
Set
EXH
Min
Pos
IAQ
Max
IAQ
IAQ
Min
Free
Cool
T
T1
AQ1 AQ
SO+ SO
SR+ SR
A
BC
D
TR TR1
24
Vac
HOT
24
Vac
COM
EF EF1
2
34
5
1
+
Exhaust Air
Adjustment
Screw
Exhaust Air LED
Damper Min.
Position
Screw
Indoor Air Quality
Max. Adjustment
Screw
Indoor Air Quality
LED
Indoor Air Quality
Min. Adjustment
Screw
Free Cooling LED
Economizer Enthalpy
Set Point Adjustment
Screw
FIGURE 8 - FOUR AND SIX POINT LOADS
A
B
C
D
FRONT
A
E
D
B
F
C
FRONT

66396-YIM-C-1004
16 Unitary Products Group
TABLE 4: FOUR AND SIX POINT LOADS
UNIT 4 - POINT LOADS (Kg. / Lbs)
TOTAL ABCD
240 1084/2390 233/514 244/538 310/684 297/654
NOTE: These weights are with economizer and 36 kW electric heat.
UNIT 6 - POINT LOADS (Kg. / Lbs)
TOTAL ABCDEF
240 1084/2390 156/343 163/359 185/407 207/456 198/436 176/389
NOTE: These weights are with economizer and 36 kW electric heat.
FIGURE 9 - CENTER OF GRAVITY

66396-YIM-C-1004
Unitary Products Group 17
TABLE 5: PHYSICAL DATA - BASIC UNIT
MODEL BQ240
SUPPLY AIR
BLOWER CENTRIFUGAL BLOWER (Dia. x Wd. mm.)
(Dia. x Wd. in.) 457 x 381 18 x 15
FAN MOTOR (KW/HP) 5.6/7.5
INDOOR COIL
ROWS DEEP 4
FINS PER INCH 13
FACE AREA (Sq. M./Sq. Ft.) 1.92 x 20.5
OUTDOOR
FAN
(Two Per Unit)
PROPELLER DIA. (mm/in.) (Each) 762/30
FAN MOTOR (KW/HP) (Each) .8/1.25
NOM. M3/S/CFM TOTAL (Each) 3.4/7200
OUTDOOR COIL
ROWS DEEP 3
FINS PER INCH 15
FACE AREA (Sq. M./Sq. Ft.) 4.02/43.3
COMPRESSOR
(Qty. Per Unit) 10 TON TANDEM 2
AIR
FILTERS
QUANTITY PER UNIT (406 X 508 X 51 mm) / (16" X 20" X 2") 4
QUANTITY PER UNIT (406 X 635 X 51 mm) / (16" X 25" X 2") 4
TOTAL FACE AREA (sq. ft.) 20.0
CHARGE REFRIGERANT 22 SYSTEM NO. 1 (Kg./Lbs.) 10.88/24.0
SYSTEM NO. 2 (Kg./Lbs.) 11.3/25.0
TABLE 6: OPERATING WEIGHTS (KG./LBS.)
MODEL BQ240
Basic Unit BQ (Heat Pump) 998/2200
Options
Economizer 73/160
Economizer with Power Exhaust 111/245
Motorized Damper 68/150
Electric Heater
18 KW 11/25
36 KW 14/30
54 KW 16/35
72 KW 18/40
Accessories
Roof Curb 79/185
Barometric Damper 20/45
Wood Skid 91/220

66396-YIM-C-1004
18 Unitary Products Group
Note 1: Maximum HACR breaker of the same amp size is acceptable.
Note 2: Only 18kW of the 36 or 54kW, or only 36kW of the 72kW electric heat can be simultaneously energized with the mechanical
heating. The full heater kW operates only if both compressors are locked out.
Note 1: Maximum HACR breaker of the same amp size is acceptable.
Note 2: Only 18kW of the 36 or 54kW, or only 36kW of the 72kW electric heat can be simultaneously energized with the mechanical
heating. The full heater kW operates only if both compressors are locked out.
TABLE 7: VOLTAGE LIMITATIONS
POWER SUPPLY VOLTAGE
MIN. MAX.
380/415-3-50 342 456
TABLE 8: ELECTRICAL DATA -WITHOUT POWERED CONVENIENCE OUTLET
MODEL
TONNAGE VOLTAGE
COMPRESSORS OD FAN
MOTORS
FLA EACH
ID
BLOWER
MOTOR
FLA
CONV
OUTLET
AMPS
HEATER OPTION MIN.
CIRCUIT
AMPACITY
(AMPS)
MAX.
FUSE/
BRKR1
SIZE
(AMPS)
RLA
EACH LRA EACH MODEL KW2STAGES AMPS
BQ240
380 9.6 66 2.1 11.7 0.0
- 0.0 - - 57.2 60
E18 11.3 1 17.1 78.7 80
E36 22.6 2 34.3 78.7 80
E54 33.8 2 51.4 78.8 80
E72 45.1 2 68.6 100.3 110
415 9.6 66 2.1 11.7 0.0
- 0.0 - - 57.2 60
E18 13.5 1 18.7 80.7 90
E36 26.9 2 37.4 80.7 90
E54 40.4 2 56.2 84.9 90
E72 53.8 2 74.9 104.0 110
TABLE 9: ELECTRICAL DATA -WITH POWERED CONVENIENCE OUTLET
MODEL
TONNAGE VOLTAGE
COMPRESSORS OD FAN
MOTORS
FLA EACH
ID
BLOWER
MOTOR
FLA
CONV
OUTLET
AMPS
HEATER OPTION MIN.
CIRCUIT
AMPACITY
(AMPS)
MAX.
FUSE/
BRKR1
SIZE
(AMPS)
RLA
EACH LRA EACH MODEL KW2STAGES AMPS
BQ240
380 9.6 66 2.1 11.7 6.3
- 0.0 - - 63.5 70
E18 11.3 1 17.1 85.0 90
E36 22.6 2 34.3 85.0 90
E54 33.8 2 51.4 86.7 90
E72 45.1 2 68.6 108.2 110
415 9.6 66 2.1 11.7 6.3
- 0.0 - - 63.5 70
E18 13.5 1 18.7 87.0 90
E36 26.9 2 37.4 87.0 90
E54 40.4 2 56.2 92.8 100
E72 53.8 2 74.9 110.3 125
TABLE 10: ELECTRIC HEAT CORRECTION FACTORS
NOMINAL VOLTAGE VOLTAGE KW CAP. MULTIPLIER
380 380 0.627
415 415 0.75

66396-YIM-C-1004
Unitary Products Group 19
NOTE: Units and ductwork are approved for zero clearance to
combustible materials when equipped with electric heat-
ers.
NOTE: All entry holes should be field sealed to prevent rain
water entry into building.
FIGURE 10 - UNIT DIMENSIONS - 20 TON
All dimensions are in millimeters and
inches. They are subject to change with-
out notice. Certified dimensions will be
provided upon request.
TABLE 11: MINIMUM CLEARANCES (MM/IN.)
LOCATION CLEARANCE
Front 914 mm/36”
Back 610 mm/24” (Less Economizer)
1245 mm/49” (With Economizer
Left Side (Filter Access) 610 mm/24” (Less Economizer)
914 mm/36” (With Economizer)
Right Side (Cond. Coil) 914 mm/36”
Below Unit1
1. Units (applicable in U.S.A. only) may be installed on
combustible floors made from wood or class A, B or C
roof covering material.
0 mm/0”
Above Unit2
2. Units must be installed outdoors. Overhanging struc-
tures or shrubs should not obstruct outdoor air dis-
charge outlet.
1829 mm/72” With 914 mm/36”
Maximum Horizontal Overhang
For Condenser Air Discharge)
TABLE 12: UTILITIES ENTRY DATA (MM/IN.)
HOLE OPENING SIZE (DIA.) USED FOR
A28.6 mm/1-1/8” KO Control Wiring Front
19.1 mm/3/4” NPS (Fem.) Bottom
B92.1 mm/3-5/8” KO Power Wiring Front
76.2 mm/3” NPS (Fem.) Bottom

66396-YIM-C-1004
20 Unitary Products Group
DUCT COVERS - Units are shipped with the bottom
duct openings covered. An accessory flange kit is available for con-
necting side ducts.
For bottom duct applications:
1. Remove the side panels from the supply and return
air compartments to gain access to the bottom
supply and return air duct covers.
2. Remove and discard the bottom duct covers. (Duct
openings are closed with sheet metal covers except
when the unit includes a power exhaust option. The
covering consists of a heavy black paper composition.)
3. Replace the side supply and return air compartment
panels.
For side duct applications;
1. Replace the side panels on the supply and return air
compartments with the accessory flange kit panels.
2. Connect ductwork to the duct flanges on the rear of
the unit.
OUTDOOR AIR PANEL SIZE
20 TON UNITS 32-1/2" X 43"
FIGURE 11 - DETAIL “X” ACCY. SIDE SUPPLY & RETURN AIR OPENINGS
FIGURE 12 - DETAIL “Y” UNIT WITH RAIN HOODS
