York THGD18 THRU 60 Quick start guide

TECHNICAL GUIDE
SPLIT-SYSTEM
HEAT PUMPS
13 SEER – R-22
MODELS:
THGD18 THRU 60
(1.5 THRU 5 NOMINAL TONS, 1 PHASE)
Due to continuous product improvement, specifications
are subject to change without notice.
V
isit us on the web at www.york.com
A
dditional rating information can be found at
w
ww.ahridirectory.org
LISTED
ISO 9001
Certified Quality
Management System
365147-YTG-C-0608
FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE
DESCRIPTION
The heat pump condensing unit is the outdoor part of a versa-
tile system of heating and air conditioning. It is designed to be
custom-matched with one of UPG’s complete line of evapora-
tor sections, with each serving a specific function. Matching
Air Handlers are available for upflow, downflow, or horizontal
applications to provide a complete system. Electric Heaters
are available, if required. Add-on coils are available for use
with upflow, downflow, or horizontal furnaces and air han-
dlers.
WARRANTY
Single Phase Units:
5-year limited parts warranty.
5-year limited compressor warranty.
FEATURES
•QUALITY CONDENSER COILS - The coil is constructed
of copper tubing and enhanced aluminum fins for
increased efficiency and corrosion protection.
•PROTECTED COMPRESSOR - The compressor is inter-
nally protected against high pressure, temperature, and
externally by a factory installed high pressure switch. This
is accomplished by the simultaneous operation of high
pressure relief valve and a temperature sensor which pro-
tects the compressor if undesirable operating conditions
occur. A liquid line filter-drier further protects the compres-
sor.
•DURABLE FINISH - The cabinet is made of pre-painted
steel. The pre-treated galvanized steel provides a better
paint to steel bond, which resists corrosion and rust creep.
Special primer formulas and matted-textured finish insure
less fading when exposed to sunlight.
•LOWER INSTALLED COST - Installation time and costs
are reduced by easy power and control wiring connec-
tions. Available in sweat connect models only. The unit
contains enough refrigerant for matching indoor coils and
15 feet of interconnecting piping. The small base dimen-
sion means less space is required on the ground or roof.
•TOP DISCHARGE - The warm air from the top mounted
fan is blown up away from the structure and any landscap-
ing. This allows compact location on multi-unit applica-
tions.
•LOW OPERATING SOUND LEVEL - The upward air flow
carries the normal operating noise away from the living
area. The rigid top panel effectively isolates any motor
sound. Isolator mounted compressor and the rippled fins
of the condenser coil muffle the normal fan motor and
compressor operating sounds.
•LOW MAINTENANCE - Long life permanently lubricated
motor-bearings need no annual servicing.
•EASY SERVICE ACCESS - Fully exposed refrigerant con-
nections, and a single panel covering the electrical con-
trols make for easy servicing of the unit.
•SECURED SERVICE VALVES - Secured re-usable ser-
vice valves are provided on both the liquid and vapor
sweat connections for ease of evacuating and charging.
•U.L. and C.U.L. listed - approved for outdoor application.
Certified in accordance with the Unitary Small Equipment cer-
tification program, which is based on ARI Standard 210/240.

365147-YTG-C-0608
2Johnson Controls Unitary Products
All dimensions are in inches. They are subject to change
without notice. Certified dimensions will be provided upon
request.
.
Physical and Electrical Data
MODEL THGD18
S21S1 THGD24 S21S1 THGD30 S21S1 THGD36 S21S1 THGD42 S21S1 THGD48 S21S1 THGD60 S21S1
Unit Supply Voltage 208-230V, 1φ, 60Hz
Normal Voltage Range 1187 to 252
Minimum Circuit Ampacity 9.9 13.1 17.7 19.8 24.9 40.1 40.1
Max. Overcurrent Device Amps 215 20 30 30 40 50 60
Min. Overcurrent Device Amps 315 15 20 20 25 45 45
Compressor Type Recip Recip Recip Recip Recip Scroll Scroll
Compressor Amps Rated Load 7.6 9.9 13.1 14.6 18.7 30.9 30.9
Locked Rotor 36 54 61 78 78 115 150
Crankcase Heater Yes Yes Yes Yes Yes No No
Fan Motor Amps Rated Load 0.5 1.5 1.4 1.5 1.5 1.5 1.5
Fan Diameter Inches 24 24 24 24 24 24 24
Fan Motor Rated HP 1/15 1/10 1/4 1/4 1/4 1/4 1/4 Nominal RPM 850 825 1100 850 850 850 850
Nominal CFM 2050 2250 3700 3700 3600 3450 3600
Coil Face Area Sq. Ft. 15.72 18.34 20.96 23.58 23.58 24.00 27.00 RowsDeep1111122
Fin / Inches 22 22 22 22 22 22 22
Liquid Line Set OD (Field Installed) 3/8 3/8 3/8 3/8 3/8 3/8 3/8
Vapor Line Set OD (Field Installed) 3/4 3/4 3/4 7/8 7/8 7/8 1-1/8
Unit Charge (Lbs. - Oz.) 47 - 3 7 - 7 8 - 12 9 - 1 11 - 14 13 - 4 15 - 5
Charge Per Foot, Oz. 0.68 0.68 0.68 0.70 0.70 0.70 0.76
Operating Weight Lbs. 172 184 196 208 208 275 280
1.Rated in accordance with ARI Standard 110, utilization range “A”.
2.Dual element fuses or HACR circuit breaker. Maximum allowable overcurrent protection.
3.Dual element fuses or HACR circuit breaker. Minimum recommended overcurrent protection.
4.The Unit Charge is correct for the outdoor unit, matched indoor coil and 15 feet of refrigerant tubing. For tubing lengths other than 15
feet, add or subtract the amount of refrigerant, using the difference in length multiplied by the per foot value.
B
C
A
Unit
Model
Dimensions
(Inches) Refrigerant Connection Service Valve Size
A1
1. Including Fan Guard.
* Adapter fitting required for 1-1/8” line set.
B C Liquid Vapor
18 28 34 34
3/8”
3/4”
24 32 34 34
30 36 34 34
36 40 34 34 7/8”42 40 34 34
48 40 34 34
60 40 34 34 1-1/8”

365147-YTG-C-0608
Johnson Controls Unitary Products 3
Additional R-22 Charge / Orifice Size for Various Matched Systems
Outdoor Unit THGD18
S21S1 THGD24 S21S1 THGD30 S21S1 THGD36 S21S1 THGD42 S21S1 THGD48 S21S1 THGD60 S21S1
Required Orifice or TXV 11TVM2A1 1TVM2A1 1TVM2A1 1TVM2A1 1TVM2C1 1TVM2C1 1TVM2C1
Factory Charge, lbs-oz 7 - 3 7 - 7 8 - 12 9 - 1 11 - 14 13 - 4 15 - 5
Indoor Coil2,3 Additional Charge, Oz
FC/MC/PC/UC18A2A 0––––––
FC/MC/PC/UC18B2A 0––––––
FC/MC/PC/UC24A2A 00–––––
FC/MC/PC/UC24B2A 00–––––
FC/MC/PC/UC30A2A 00–––––
FC/MC/PC/UC30B2A 00–––––
FC/MC/PC/UC32A2A –50––––
FC/MC/PC/UC35B2A –50––––
FC/MC/PC/UC35C2A –50––––
FC/MC/PC/UC37A2A – – 0 0 – – –
FC/MC/PC/UC43C2C –––––––
FC/MC/PC/UC48C2C ––––0––
FC/MC/PC/UC48D2C ––––0––
FC/PC/UC60C2C ––––20–
FC/MC/PC/UC60D2C ––––20–
FC/PC62D2C –––––20
HC18A2A 0––––––
HC30A2A –0–––––
HC36B2A –50––––
HC60C2C ––––20–
HD24A2A –4–––––
HD36B2A ––0––––
HD60D2C ––––20–
MH30S2A –6–––––
AHP18B2A 0––––––
AHP24B2A 00–––––
AHP30B2A –50––––
AHP36C2A – – 0 0 – – –
AHP48D2C ––––20–
AHP60D2C ––––20–
AV24B2A 00–––––
AV36C2A ––00–––
AV48D2C ––––00–
AV60D2C ––––00–
FC/MC/PC/UC18A3X2A+0––––––
FC/MC/PC/UC18B3X2A+0––––––
FC/MC/PC/UC24A3X2A+02A+0–––––
FC/MC/PC/UC24B3X2A+02A+0–––––
FC/MC/PC/UC30A3X –2A+0–––––
FC/MC/PC/UC30B3X –2A+0–––––
FC/MC/PC/UC32A3X –2A+52A+0––––
FC/MC/PC/UC35B3X –2A+52A+0––––
FC/MC/PC/UC35C3X –2A+52A+0––––
FC/MC/PC/UC37A3X – – 2A + 0 2A + 0 – – –
FC/MC/PC/UC43B3X – – 2A + 0 2A + 0 – – –
FC/MC/PC/UC43C3X – – 2A + 0 2A + 0 – – –
FC/MC/PC/UC48C3X – – – 2A + 3 2C + 0 – –
FC/MC/PC/UC48D3X – – – 2A + 3 2C + 0 – –
FC/PC/UC60C3X – – – 2A + 5 2C + 2 2C + 0 –
FC/MC/PC/UC60D3X – – – 2A + 5 2C + 2 2C + 0 –
FC/PC62D3X –––––2C+22C+0
For Notes See Page 4.

365147-YTG-C-0608
4Johnson Controls Unitary Products
PROCEDURES:
1. Unit factory charge listed on the unit nameplate includes refrigerant for the condenser, the smallest evaporator and 15 feet of inter-
connecting line tubing.
2. Verify the TXV or orifice and additional charge required for specific evaporator coil in the system using the above table.
3. Additional charge for the amount of interconnecting line tubing greater than 15 feet at the rate specified in Physical and Electrical
Data Table.
4. Permanently mark the unit nameplate with the total system charge. Total System Charge = Base Charge (as shipped) + adder for
evaporator + adder for line set.
HC18A3X 2A+0––––––
HC30A3X –2A+0–––––
HC36B3X –2A+52A+0––––
HC42C3X – – 2A + 0 2A + 0 – – –
HC60C3X – – – 2A + 5 2C + 2 2C + 0 –
HD24A3X –2A+4–––––
HD36B3X ––2A+0––––
HD48C3X – – – 2A + 3 – – –
HD60D3X – – – 2A + 5 2C + 2 2C + 0 –
MH24S59 –2A+62A+0––––
MH30S65 –2A+62A+0––––
AHP18B3X 2A+0––––––
AHP24B3X 2A+02A+0–––––
AHP30B3X –2A+52A+0––––
AHP36C3X – – 2A + 0 2A + 0 – – –
AHP42C3X – – – 2A + 0 – – –
AHP48D3X ––––2C+22C+0–
AHP60D3X – – – 2A + 5 2C + 2 2C + 0 –
AV24B2A 2A+02A+0–––––
AV36C2A – – 2A + 0 2A + 0 – – –
AV48D2C – – – 2A + 0 2C + 0 2C + 0 –
AV60D2C ––––2C+02C+0–
F4FP024 0––––––
F4FP030 –0–––––
F4FP040 ––0––––
F5FP045 – – – 2A + 5 2 – –
F5FP048 – – – 2A + 3 0 – –
F5FP060 – – – 2A + 5 2 0 –
F4FV060 – – – 2A + 0 0 0 –
FOOTNOTES:
1.For applications requiring a TXV use 1TVM series kit.
2.Systems matched with furnace or air handlers not equipped with blower-off delays may require blower Time Delay Kit
2FD06700224.
3.PC coils cannot be used in downflow or horizontal applications. FC coils cannot be used in horizontal applications.
Additional R-22 Charge / Orifice Size for Various Matched Systems (Continued)
Outdoor Unit THGD18
S21S1 THGD24 S21S1 THGD30 S21S1 THGD36 S21S1 THGD42 S21S1 THGD48 S21S1 THGD60 S21S1
Required Orifice or TXV 11TVM2A1 1TVM2A1 1TVM2A1 1TVM2A1 1TVM2C1 1TVM2C1 1TVM2C1
Factory Charge, lbs-oz 7 - 3 7 - 7 8 - 12 9 - 1 11 - 14 13 - 4 15 - 5
Indoor Coil2,3 Additional Charge, Oz

365147-YTG-C-0608
Johnson Controls Unitary Products 5
COOLING CAPACITY - With Air Handler Coils
UNIT
MODEL
AIR HANDLER COIL
MODEL1
COOLING
MODEL W RATED
CFM NET MBH SEER EER
TOTAL SENS.
13 SEER HP WITH MA
THGD18S21S1 MA08B 17 FC/MC18B 600 18.0 12.9 13.00 11.00 MA08B 17 FC/MC24B 600 18.0 12.9 13.00 11.00
MA08B 17 FC/MC30B 600 18.0 12.9 13.00 11.00
THGD24S21S1 MA08B 17 FC/MC24B 800 23.0 16.8 13.00 11.00 MA08B 17 FC/MC30B 800 23.0 16.8 13.00 11.00
MA08B 17 FC/MC35B 800 23.0 16.8 13.00 11.00
THGD30S21S1 MA12B 17 FC/MC35B 1000 29.0 21.2 13.00 11.00
MA12B 17 FC/MC43B 1000 29.0 21.2 13.00 11.00
THGD36S21S1 MA12B 17 FC/MC43B 1200 35.0 25.6 13.00 11.00 MA14D 24 FC/MC48D 1200 35.0 25.6 13.00 11.00
MA14D 24 FC/MC60D 1200 35.0 25.6 13.00 11.00
THGD42S21S1
MA14D 24 FC/MC48D 1400 40.0 28.8 13.00 11.00
MA16C 21 FC/MC48C 1400 40.0 28.8 13.00 11.00
MA14D 24 FC/MC60D 1400 40.0 28.8 13.00 11.00
MA16C 21 FC60C 1400 40.0 28.8 13.00 11.00
THGD48S21S1 MA16C 21 FC60C 1600 45.0 33.2 13.00 11.00 MA20D 24 FC/MC60D 1600 45.0 33.2 13.00 11.00
MA20D 24 FC/MC62D 1600 45.0 33.2 13.00 11.00
THGD60S21S1 MA20D 24 FC/MC62D 1800 55.0 40.0 13.00 11.00
13 SEER HP WITH MV - VARIABLE SPEED
THGD18S21S1 MV12B 17 FC/MC18B 600 18.0 13.3 14.00 12.00 MV12B 17 FC/MC24B 600 18.0 13.4 14.00 12.00
MV12B 17 FC/MC30B 600 18.0 13.4 14.00 12.00
THGD24S21S1 MV12B 17 FC/MC24B 800 23.0 17.4 14.00 12.00 MV12B 17 FC/MC30B 800 23.0 17.4 14.00 12.00
MV12B 17 FC/MC35B 800 23.0 17.4 14.00 12.00
THGD30S21S1
MV12B 17 FC/MC35B 1000 29.0 21.8 14.00 12.00
MV16C 21 FC/MC35C 1000 29.0 22.0 14.00 12.00
MV12B 17 FC/MC43B 1000 29.0 21.8 14.00 12.00
MV16C 21 FC/MC43C 1000 29.0 22.0 14.00 12.00
THGD36S21S1
MV12B 17 FC/MC43B 1200 35.0 26.2 14.00 12.00
MV16C 21 FC/MC43C 1200 35.0 26.4 14.00 12.00
MV16C 21 FC/MC48C 1200 35.0 26.4 14.00 12.00
MV16C 21 FC60C 1200 35.0 26.4 14.00 12.00
MV12D 24 FC/MC48D 1200 35.0 26.4 14.00 12.00
MV12D 24 FC/MC60D 1200 35.0 26.4 14.00 12.00
THGD42S21S1
MV16C 21 FC/MC48C 1400 41.0 29.4 13.85 11.00
MV16C 21 FC/MC48C 1400 41.0 29.4 13.85 11.00
MV20D 24 FC/MC48D 1400 41.0 29.4 13.85 11.00
MV20D 24 FC/MC60D 1400 41.0 29.4 13.85 11.00
THGD48S21S1 MV16C 21 FC60C 1200 45.0 33.2 13.25 11.00 MV20D 24 FC/MC60D 1600 46.0 33.8 13.25 11.00
MV20D 24 FC/MC62D 1600 45.0 33.6 13.30 11.00
THGD60S21S1 MV20D 24 FC/MC62D 1800 55.0 40.5 13.50 11.00
For Notes See Page 6.

365147-YTG-C-0608
6Johnson Controls Unitary Products
— = Not applicable.
13 SEER HP WITH AV / SV / F*FV - VARIABLE SPEED
THGD18S21S1 AV24 17 – 565 18.0 13.4 14.00 12.00
THGD24S21S1 AV24 17 – 770 23.0 17.5 14.00 12.00
THGD30S21S1 AV36 21 – 1015 29.0 22.0 14.00 12.00
THGD36S21S1 AV36 21 – 1270 35.0 26.2 14.00 12.00
AV/SV48 24 – 1270 35.0 26.2 14.00 12.00
THGD42S21S1 AV/SV48 24 – 1415 41.0 29.4 13.85 11.00 AV/SV60 24 – 1410 41.0 29.4 13.85 11.00
F4FV060 24 – 1410 41.0 29.4 13.85 11.00
THGD48S21S1 AV/SV48 24 – 1610 46.0 33.8 13.25 11.00 AV/SV60 24 – 1655 46.0 33.6 13.25 11.00
F4FV060 24 – 1655 46.0 33.6 13.30 11.00
13 SEER HP WITH AHP / SHP / F*FP
THGD18S21S1 AHP18 17 – 650 18.0 12.9 13.00 11.00 AHP24 17 – 655 18.0 13.0 13.00 11.00
F4FP024 17 – 655 18.0 13.0 13.00 11.00
THGD24S21S1 AHP24 17 – 830 23.0 16.9 13.00 11.00 AHP30 17 – 795 23.0 16.8 13.00 11.00
F4FP030 17 – 795 23.0 16.8 13.00 11.00
THGD30S21S1 AHP30 17 – 1015 29.0 21.2 13.00 11.00 AHP36 21 – 1040 29.0 21.2 13.00 11.00
F4FP040 21 – 1040 29.0 21.2 13.00 11.00
THGD36S21S1
AHP36 21 – 1235 35.0 25.6 13.00 11.00
AHP42 21 – 1255 35.0 25.6 13.00 11.00
AHP/SHP60 24 – 1270 35.0 26.2 14.00 12.00
F4FP045 24 – 1200 35.0 25.6 13.00 11.00
F5FP048 24 – 1200 35.0 26.2 14.00 12.00
F5FP060 24 – 1200 35.0 26.2 14.00 12.00
THGD42S21S1
AHP/SHP48 24 – 1400 40.0 29.0 13.00 11.00
AHP/SHP60 24 – 1400 41.0 29.4 13.85 11.00
F4FP045 24 – 1400 40.0 29.0 13.00 11.00
F5FP048 24 – 1400 41.0 29.4 13.85 11.00
F5FP060 24 – 1400 41.0 29.4 13.85 11.00
THGD48S21S1 AHP/SHP48 24 – 1600 45.0 33.2 13.00 11.00 AHP/SHP60 24 – 1600 46.0 33.6 13.30 11.00
F5FP060 24 – 1600 46.0 33.6 13.30 11.00
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ARI Standards 210.
Cooling MBH based on 80°F entering air temperature, 50% RH, and rated air flow.
EER (Energy Efficiency Ratio) is the total cooling output in BTU’s at 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTU’s during a normal annual usage period for cooling divided by the total electric power
input in watt-hours during the same period.
1. MC coils available with a factory installed horizontal drain pan. See price pages for specific model number.
COOLING CAPACITY - With Air Handler Coils (Continued)
UNIT
MODEL
AIR HANDLER COIL
MODEL1
COOLING
MODEL W RATED
CFM NET MBH SEER EER
TOTAL SENS.

365147-YTG-C-0608
Johnson Controls Unitary Products 7
COOLING CAPACITY - Upflow, Downflow & Horizontal Furnaces and Coils
UNIT MODEL FURNACE** COIL
MODEL
COOLING
CFM RANGE
(Min.-max.) WRATED CFM NET MBH SEER1EER
TOTAL SENS.
THGD18S21S1
450 - 750 14,17 FC/MC/PC/UC18 600 18.0 12.9 13.00 11.00
450 - 750 14,17 FC/MC/PC/UC24 600 18.0 12.9 13.00 11.00
450 - 750 14,17 FC/MC/PC/UC30 600 18.0 12.9 13.00 11.00
450 - 750 14 HC18 600 18.0 12.9 13.00 11.00
THGD24S21S1
600 - 1000 14,17 FC/MC/PC/UC24 800 23.0 16.8 13.00 11.00
600 - 1000 14,17 FC/MC/PC/UC30 800 23.0 16.8 13.00 11.00
600 - 1000 14 FC/MC/PC/UC32 800 23.0 16.8 13.00 11.00
600 - 1000 17,21 FC/MC/PC/UC35 800 23.0 16.8 13.00 11.00
600 - 1000 14 HC30 800 23.0 16.8 13.00 11.00
600 - 1000 17 HC36 800 23.0 16.8 13.00 11.00
600 - 1000 – HD24 800 23.0 16.8 13.00 11.00
600 - 1000 19 MH24S 800 23.0 16.8 13.00 11.00
600 - 1000 19 MH30S 800 23.0 16.8 13.00 11.00
THGD30S21S1
800 - 1200 14 FC/MC/PC/UC32 1000 29.0 21.2 13.00 11.00
800 - 1200 17,21 FC/MC/PC/UC35 1000 29.0 21.2 13.00 11.00
800 - 1200 14 FC/MC/PC/UC37 1000 29.0 21.2 13.00 11.00
800 - 1200 17,21 FC/MC/PC/UC43 1000 29.0 21.2 13.00 11.00
800 - 1200 17 HC36 1000 29.0 21.2 13.00 11.00
800 - 1200 21 HC42 1000 29.0 21.2 13.00 11.00
800 - 1200 – HD36 1000 29.0 21.2 13.00 11.00
800 - 1200 19 MH24S 1000 29.0 21.2 13.00 11.00
800 - 1200 19 MH30S 1000 29.0 21.2 13.00 11.00
THGD36S21S1
1000 - 1400 14 FC/MC/PC/UC37 1200 35.0 25.6 13.00 11.00
1000 - 1400 17,21 FC/MC/PC/UC43 1200 35.0 25.6 13.00 11.00
1000 - 1400 21,24 FC/MC/PC/UC48 1200 35.0 25.6 13.00 11.00
1000 - 1400 21,24 FC/MC/PC/UC60 1200 35.0 25.6 13.00 11.00
1000 - 1400 21 HC42 1200 35.0 25.6 13.00 11.00
1000 - 1400 24 HC60 1200 35.0 25.6 13.00 11.00
1000 - 1400 – HD48 1200 35.0 25.6 13.00 11.00
1000 - 1400 – HD60 1200 35.0 25.6 13.00 11.00
THGD42S21S1
1200 - 1600 21,24 FC/MC/PC/UC48 1400 40.0 28.8 13.00 11.00
1200 - 1600 21,24 FC/MC/PC/UC60 1400 40.0 28.8 13.00 11.00
1200 - 1600 24 HC60 1400 40.0 28.8 13.00 11.00
1200 - 1600 – HD60 1400 40.0 28.8 13.00 11.00
THGD48S21S1
1400 - 1800 21,24 FC/MC/PC/UC60 1600 45.0 33.2 13.00 11.00
1400 - 1800 24 FC/MC62 1600 45.0 33.2 13.00 11.00
1400 - 1800 24 HC60 1600 45.0 33.2 13.00 11.00
1400 - 1800 – HD60 1600 45.0 33.2 13.00 11.00
THGD60S21S1 1600 - 2000 24 FC/MC62 1800 55.0 40.0 13.00 11.00
1. Requires a 2FD06700224 Blower Time Delay unless a standard furnace is equipped with one.
** Refer to Quick Selection Chart for specific furnace match-up.

365147-YTG-C-0608
8Johnson Controls Unitary Products
COOLING CAPACITY - With Variable Speed Furnaces
UNIT MODEL VARIABLE SPEED
FURNACE MODEL COIL MODEL1WCOOLING
RATED
CFM Net MBH SEER EER
TOTAL SENS.
13 SEER HP WITH VARIABLE SPEED FURNACES2
THGD18S21S1
PV8*A12 FC/MC/PC/UC18A 14 600 18.0 13.4 14.00 12.00
PV9*A12 FC/MC/PC/UC18A 14 600 18.0 13.3 14.00 12.00
P(C,V)9*B12 FC/MC/PC/UC18B 17 600 18.0 13.4 14.00 12.00
PV8*A12 FC/MC/PC/UC24A 14 600 18.0 13.4 14.00 12.00
PV9*A12 FC/MC/PC/UC24A 14 600 18.0 13.3 14.00 12.00
P(C,V)9*B12 FC/MC/PC/UC24B 17 600 18.0 13.4 14.00 12.00
PV8*A12 FC/MC/PC/UC30A 14 600 18.0 13.4 14.00 12.00
PV9*A12 FC/MC/PC/UC30A 14 600 18.0 13.3 14.00 12.00
P(C,V)9*B12 FC/MC/PC/UC30B 17 600 18.0 13.4 14.00 12.00
PV8*A12 HC18 14 600 18.0 13.4 14.00 12.00
PV9*A12 HC18 14 600 18.0 13.3 14.00 12.00
THGD24S21S1
PV8*A12 FC/MC/PC/UC24A 14 800 23.0 17.3 14.00 12.00
PV9*A12 FC/MC/PC/UC24A 14 800 23.0 17.3 14.00 12.00
P(C,V)9*B12 FC/MC/PC/UC24B 17 800 23.0 17.3 14.00 12.00
PV8*A12 FC/MC/PC/UC30A 14 800 23.0 17.3 14.00 12.00
PV9*A12 FC/MC/PC/UC30A 14 800 23.0 17.3 14.00 12.00
P(C,V)9*B12 FC/MC/PC/UC30B 17 800 23.0 17.3 14.00 12.00
PV8*A12 FC/MC/PC/UC32A 14 800 23.0 17.3 14.00 12.00
PV9*A12 FC/MC/PC/UC32A 14 800 23.0 17.3 14.00 12.00
P(C,V)9*B12 FC/MC/PC/UC35B 17 800 23.0 17.3 14.00 12.00
PV8*A12 HC30 14 800 23.0 17.3 14.00 12.00
PV9*A12 HC30 14 800 23.0 17.3 14.00 12.00
P(C,V)9*B12 HC36 17 800 23.0 17.3 14.00 12.00
THGD30S21S1
PV8*A12 FC/MC/PC/UC32A 14 1000 29.0 21.6 14.00 12.00
PV9*A12 FC/MC/PC/UC32A 14 1000 29.0 21.6 14.00 12.00
PV8*B16 FC/MC/PC/UC35B 17 1000 29.0 22.0 14.00 12.00
PV8*C16 FC/MC/PC/UC35C 21 1000 29.0 22.0 14.00 12.00
PV8*C20 FC/MC/PC/UC35C 21 1120 29.0 21.6 14.00 12.00
P(C,V)9*B12 FC/MC/PC/UC35B 17 1000 29.0 21.6 14.00 12.00
P(C,V)9*C16 FC/MC/PC/UC35C 21 1010 29.0 21.8 14.00 12.00
PV8*A12 FC/MC/PC/UC37A 14 1000 29.0 21.6 14.00 12.00
PV9*A12 FC/MC/PC/UC37A 14 1000 29.0 21.6 14.00 12.00
PV8*B16 FC/MC/PC/UC43B 17 1000 29.0 22.0 14.00 12.00
PV8*C16 FC/MC/PC/UC43C 21 1000 29.0 22.0 14.00 12.00
PV8*C20 FC/MC/PC/UC43C 21 1120 29.0 21.6 14.00 12.00
P(C,V)9*B12 FC/MC/PC/UC43B 17 1000 29.0 21.6 14.00 12.00
P(C,V)9*C16 FC/MC/PC/UC43C 21 1010 29.0 21.8 14.00 12.00
PV8*B16 HC36 17 1000 29.0 22.0 14.00 12.00
P(C,V)9*B12 HC36 17 1000 29.0 21.6 14.00 12.00
PV8*C16 HC42 21 1000 29.0 22.0 14.00 12.00
PV8*C20 HC42 21 1120 29.0 21.6 14.00 12.00
P(C,V)9*C16 HC42 21 1010 29.0 21.8 14.00 12.00
For Notes See Page 9.

365147-YTG-C-0608
Johnson Controls Unitary Products 9
THGD36S21S1
PV8*A12 FC/MC/PC/UC37A 14 1200 35.0 26.0 13.55 11.00
PV9*A12 FC/MC/PC/UC37A 14 1200 35.0 25.8 13.25 11.00
PV8*B16 FC/MC/PC/UC43B 17 1200 35.0 26.2 14.00 12.00
PV8*C16 FC/MC/PC/UC43C 21 1200 35.0 26.2 14.00 12.00
PV8*C20 FC/MC/PC/UC43C 21 1200 35.0 26.0 13.85 12.00
P(C,V)9*B12 FC/MC/PC/UC43B 17 1200 35.0 26.0 13.70 12.00
P(C,V)9*C16 FC/MC/PC/UC43C 21 1175 35.0 26.2 14.00 12.00
P(C,V)9*C20 FC/MC/PC/UC43C 21 1200 35.0 26.2 14.00 12.00
PV8*C16 FC/MC/PC/UC48C 21 1200 35.0 26.4 14.00 12.00
PV8*C20 FC/MC/PC/UC48C 21 1200 35.0 26.0 13.90 12.00
P(C,V)9*C16 FC/MC/PC/UC48C 21 1175 35.0 26.2 14.00 12.00
P(C,V)9*C20 FC/MC/PC/UC48C 21 1200 35.0 26.2 14.00 12.00
P(C,V)9*D20 FC/MC/PC/UC48D 24 1200 35.0 26.2 14.00 12.00
PV8*C16 HC42 21 1200 35.0 26.2 14.00 12.00
PV8*C20 HC42 21 1200 35.0 26.0 13.90 12.00
P(C,V)9*C16 HC42 21 1175 35.0 26.2 14.00 12.00
P(C,V)9*C20 HC42 21 1200 35.0 26.2 14.00 12.00
THGD42S21S1
PV8*C16 FC/MC/PC/UC48C 21 1400 40.0 29.2 13.45 11.00
PV8*C20 FC/MC/PC/UC48C 21 1400 41.0 29.2 13.55 11.00
P(C,V)9*C16 FC/MC/PC/UC48C 21 1415 40.0 29.0 13.25 11.00
P(C,V)9*C20 FC/MC/PC/UC48C 21 1400 40.0 29.2 13.45 11.00
P(C,V)9*D20 FC/MC/PC/UC48D 24 1400 40.0 29.0 13.35 11.00
PV8*C16 FC/PC/UC60C 21 1400 41.0 29.2 13.45 11.00
PV8*C20 FC/PC/UC60C 21 1400 41.0 29.2 13.60 11.00
P(C,V)9*C16 FC/PC/UC60C 21 1415 40.0 29.0 13.25 11.00
P(C,V)9*C20 FC/PC/UC60C 21 1400 41.0 29.2 13.45 11.00
P(C,V)9*D20 FC/MC/PC/UC60D 24 1400 40.0 29.0 13.40 11.00
THGD48S21S1
PV8*C16 FC/PC/UC60C 21 1500 45.0 33.4 13.25 11.00
PV8*C20 FC/PC/UC60C 21 1610 45.0 33.4 13.25 11.00
P(C,V)9*C16 FC/PC/UC60C 21 1600 45.0 33.2 13.25 11.00
P(C,V)9*C20 FC/PC/UC60C 21 1600 45.0 33.4 13.25 11.00
P(C,V)9*D20 FC/MC/PC/UC60D 24 1600 45.0 33.4 13.25 11.00
PV8*C20 FC/MC62D 24 1610 45.0 33.4 13.25 11.00
P(C,V)9*C20 FC/MC62D 24 1600 45.0 33.4 13.25 11.00
P(C,V)9*D20 FC/MC62D 24 1600 45.0 33.4 13.25 11.00
THGD60S21S1 PV8*C20 FC/MC62D 24 1730 55.0 40.0 13.50 11.00 P(C,V)9*C20 FC/MC62D 24 1620 54.0 40.5 13.50 11.00
P(C,V)9*D20 FC/MC62D 24 1620 54.0 40.5 13.50 11.00
1. MC coils available with a factory installed horizontal drain pan. See price pages for specific model number.
2. Variable speed furnaces have B.O.D (Blower on Delay) standard.
COOLING CAPACITY - With Variable Speed Furnaces (Continued)
UNIT MODEL VARIABLE SPEED
FURNACE MODEL COIL MODEL1WCOOLING
RATED
CFM Net MBH SEER EER
TOTAL SENS.
13 SEER HP WITH VARIABLE SPEED FURNACES2

365147-YTG-C-0608
10 Johnson Controls Unitary Products
HEATING PERFORMANCE - With Air Handler
UNIT
MODEL* AIR HANDLER COIL1
MODEL
ARI HEATING2
47°F17°FHSPF
MBH COP KW MBH COP KW STD
13 SEER HP WITH MA
THGD18S21S1 MA08B FC/MC18B 17.0 3.26 1.54 9.0 2.18 1.23 7.70 MA08B FC/MC24B 17.0 3.26 1.54 9.0 2.18 1.23 7.70
MA08B FC/MC30B 17.0 3.26 1.54 9.0 2.18 1.23 7.70
THGD24S21S1 MA08B FC/MC24B 23.0 3.72 1.82 12.0 2.44 1.47 7.70 MA08B FC/MC30B 23.0 3.72 1.82 12.0 2.44 1.47 7.70
MA08B FC/MC35B 23.0 3.72 1.82 12.0 2.44 1.47 7.70
THGD30S21S1 MA12B FC/MC35B 29.0 3.56 2.40 15.0 2.24 1.96 7.70
MA12B FC/MC43B 29.0 3.56 2.40 15.0 2.24 1.96 7.70
THGD36S21S1 MA12B FC/MC43B 34.0 3.58 2.78 21.0 2.52 2.39 8.50 MA14D FC/MC48D 34.0 3.58 2.78 21.0 2.52 2.39 8.50
MA14D FC/MC60D 34.0 3.58 2.78 21.0 2.52 2.39 8.50
THGD42S21S1
MA14D FC/MC48D 42.0 3.52 3.45 25.0 2.60 2.81 8.50
MA16C FC/MC48C 42.0 3.52 3.45 25.0 2.60 2.81 8.50
MA14D FC/MC60D 42.0 3.52 3.45 25.0 2.60 2.81 8.50
MA16C FC60C 42.0 3.52 3.45 25.0 2.60 2.81 8.50
THGD48S21S1 MA16C FC60C 48.0 3.40 4.13 37.0 2.76 3.97 7.70 MA20D FC/MC60D 48.0 3.40 4.13 37.0 2.76 3.97 7.70
MA20D FC/MC62D 48.0 3.40 4.13 37.0 2.76 3.97 7.70
THGD60S21S1 MA20D FC/MC62D 58.0 3.46 4.91 40.0 2.36 4.90 7.70
13 SEER HP WITH MV - VARIABLE SPEED
THGD18S21S1 MV12B FC/MC18B 17.0 3.44 1.43 9.0 2.30 1.10 8.00 MV12B FC/MC24B 17.0 3.46 1.41 9.0 2.30 1.10 8.00
MV12B FC/MC30B 17.0 3.46 1.41 9.0 2.30 1.10 8.00
THGD24S21S1 MV12B FC/MC24B 23.0 4.02 1.64 12.0 2.62 1.30 8.10 MV12B FC/MC30B 23.0 4.02 1.64 12.0 2.62 1.30 8.10
MV12B FC/MC35B 22.0 4.02 1.63 12.0 2.64 1.29 8.25
THGD30S21S1
MV12B FC/MC35B 29.0 3.76 2.22 14.0 2.36 1.78 7.95
MV16C FC/MC35C 28.0 3.76 2.21 14.0 2.36 1.77 7.95
MV12B FC/MC43B 29.0 3.74 2.24 14.0 2.36 1.78 7.95
MV16C FC/MC43C 28.0 3.78 2.20 14.0 2.36 1.77 7.95
THGD36S21S1
MV12B FC/MC43B 33.0 3.72 2.63 20.0 2.62 2.23 8.80
MV16C FC/MC43C 33.0 3.80 2.55 20.0 2.66 2.19 8.90
MV16C FC/MC48C 33.0 3.82 2.54 20.0 2.68 2.16 9.00
MV16C FC60C 33.0 3.82 2.54 20.0 2.68 2.16 9.00
MV12D FC/MC48D 33.0 3.82 2.54 20.0 2.68 2.16 9.00
MV12D FC/MC60D 33.0 3.78 2.55 20.0 2.66 2.18 8.90
THGD42S21S1
MV16C FC/MC48C 40.0 3.68 3.18 24.0 2.72 2.60 8.80
MV16C FC60C 40.0 3.68 3.18 24.0 2.72 2.60 8.80
MV20D FC/MC48D 40.0 3.70 3.20 24.0 2.74 2.58 8.85
MV20D FC/MC60D 40.0 3.70 3.20 24.0 2.74 2.58 8.85
THGD48S21S1 MV16C FC60C 47.5 3.44 4.04 37.2 2.78 2.92 7.80 MV20D FC/MC60D 48.0 3.48 3.99 37.0 2.82 3.84 8.00
MV20D FC/MC62D 47.5 3.50 3.98 37.0 2.82 3.84 8.10
THGD60S21S1 MV20D FC/MC62D 58.0 3.52 4.78 39.0 2.40 4.76 7.75
For Notes See Page 11.

365147-YTG-C-0608
Johnson Controls Unitary Products 11
CP equals MBH output divided by (total KW input x 3.412).
HSPF (Heating Seasonal Performance Factor) is the total heating output during a normal annual usage period for heating divided by
the total electric power input during the same period.
— = Not Applicable.
13 SEER HP WITH AV / SV / F*FV - VARIABLE SPEED
THGD18S21S1 AV24 – 17.0 3.46 1.40 9.0 2.32 1.08 8.00
THGD24S21S1 AV24 – 22.0 4.04 1.62 12.0 2.64 1.28 8.40
THGD30S21S1 AV36 – 28.0 3.80 2.18 14.0 2.38 1.76 8.00
THGD36S21S1 AV36 – 33.0 3.74 2.61 20.0 2.62 2.23 8.80
AV/SV48 – 33.0 3.74 2.61 20.0 2.62 2.23 8.80
THGD42S21S1 AV/SV48 – 40.0 3.68 3.18 24.0 2.74 2.58 8.85 AV/SV60 – 40.0 3.70 3.20 24.0 2.74 2.58 8.85
F4FV060 – 40.0 3.70 3.20 24.0 2.74 2.58 8.85
THGD48S21S1 AV/SV48 – 48.0 3.50 3.97 37.0 2.82 3.84 8.00 AV/SV60 – 48.0 3.48 3.99 37.0 2.82 3.84 8.00
F4FV060 – 48.0 3.48 3.99 37.0 2.82 3.84 8.00
13 SEER HP WITH AHP / SHP / F*FP
THGD18S21S1 AHP18 – 17.0 3.26 1.54 9.0 2.18 1.23 7.70 AHP24 – 17.0 3.28 1.52 9.0 2.18 1.22 7.70
F4FP024 – 17.0 3.26 1.54 9.0 2.18 1.23 7.70
THGD24S21S1 AHP24 – 23.0 3.74 1.80 12.0 2.46 1.45 7.70 AHP30 – 23.0 3.74 1.80 12.0 2.44 1.46 7.70
F4FP030 – 23.0 3.74 1.80 12.0 2.46 1.45 7.70
THGD30S21S1 AHP30 – 29.0 3.54 2.41 15.0 2.24 1.96 7.65 AHP36 – 29.0 3.54 2.41 15.0 2.24 1.96 7.65
F4FP040 – 29.0 3.54 2.41 15.0 2.24 1.96 7.65
THGD36S21S1
AHP36 – 34.0 3.58 2.78 21.0 2.52 2.39 8.50
AHP42 – 34.0 3.60 2.76 20.0 2.52 2.37 8.55
AHP/SHP60 – 33.0 3.74 2.61 20.0 2.62 2.23 8.80
F4FP045 – 34.0 3.58 2.78 21.0 2.52 2.39 8.50
F5FP048 – 33.0 3.74 2.61 20.0 2.62 2.23 8.80
F5FP060 – 33.0 3.74 2.61 20.0 2.62 2.23 8.80
THGD42S21S1
AHP/SHP48 – 42.0 3.56 3.41 25.0 2.64 2.75 8.60
AHP/SHP60 – 40.0 3.70 3.20 24.0 2.74 2.58 8.85
F4FP045 – 42.0 3.56 3.41 25.0 2.64 2.75 8.60
F5FP048 – 40.0 3.70 3.20 24.0 2.74 2.58 8.85
F5FP060 – 40.0 3.70 3.20 24.0 2.74 2.58 8.85
THGD48S21S1 AHP/SHP48 – 48.0 3.40 4.13 37.0 2.74 3.99 7.70 AHP/SHP60 – 48.0 3.48 3.99 37.0 2.80 3.87 8.00
F5FP060 – 48.0 3.48 3.99 37.0 2.80 3.87 8.00
1. Rated CFM same as for cooling.
2. Heating MBH based on ARI standards of 70° DB entering indoor air, 72% RH outdoor air with 25 feet of interconnecting piping and
no supplemental electric heat operation.
HEATING PERFORMANCE - With Air Handler (Continued)
UNIT
MODEL* AIR HANDLER COIL1
MODEL
ARI HEATING2
47°F17°FHSPF
MBH COP KW MBH COP KW STD

365147-YTG-C-0608
12 Johnson Controls Unitary Products
CP equals MBH output divided by (total KW input x 3.412).
HSPF (Heating Seasonal Performance Factor) is the total heating output during a normal annual usage period for heating divided by
the total electric power input during the same period.
— = Not Applicable.
HEATING PERFORMANCE - Upflow, Downflow, and Horizontal Furnaces and Coils
UNIT
MODEL* COIL1
MODEL
ARI HEATING2
47°F17°FHSPF
MBH COP KW MBH COP KW STD
THGD18S21S1
FC/MC/PC/UC18 17.0 3.26 1.54 9.0 2.18 1.23 7.70
FC/MC/PC/UC24 17.0 3.26 1.54 9.0 2.18 1.23 7.70
FC/MC/PC/UC30 17.0 3.26 1.54 9.0 2.18 1.23 7.70
HC18 17.0 3.26 1.54 9.0 2.18 1.23 7.70
THGD24S21S1
FC/MC/PC/UC24 23.0 3.72 1.82 12.0 2.44 1.47 7.70
FC/MC/PC/UC30 23.0 3.72 1.82 12.0 2.44 1.47 7.70
FC/MC/PC/UC32 23.0 3.72 1.82 12.0 2.44 1.47 7.70
FC/MC/PC/UC35 23.0 3.72 1.82 12.0 2.44 1.47 7.70
HC30 23.0 3.72 1.82 12.0 2.44 1.47 7.70
HC36 23.0 3.72 1.82 12.0 2.44 1.47 7.70
HD24 23.0 3.72 1.82 12.0 2.44 1.47 7.70
MH24S 23.0 3.72 1.82 12.0 2.44 1.47 7.70
MH30S 23.0 3.72 1.82 12.0 2.44 1.47 7.70
THGD30S21S1
FC/MC/PC/UC32 29.0 3.56 2.40 15.0 2.24 1.96 7.70
FC/MC/PC/UC35 29.0 3.56 2.40 15.0 2.24 1.96 7.70
FC/MC/PC/UC37 29.0 3.56 2.40 15.0 2.24 1.96 7.70
FC/MC/PC/UC43 29.0 3.56 2.40 15.0 2.24 1.96 7.70
HC36 29.0 3.56 2.40 15.0 2.24 1.96 7.70
HC42 29.0 3.56 2.40 15.0 2.24 1.96 7.70
HD36 29.0 3.56 2.40 15.0 2.24 1.96 7.70
MH24S 29.0 3.56 2.40 15.0 2.24 1.96 7.70
MH30S 29.0 3.56 2.40 15.0 2.24 1.96 7.70
THGD36S21S1
FC/MC/PC/UC37 34.0 3.58 2.78 21.0 2.52 2.39 8.50
FC/MC/PC/UC43 34.0 3.58 2.78 21.0 2.52 2.39 8.50
FC/MC/PC/UC48 34.0 3.58 2.78 21.0 2.52 2.39 8.50
FC/MC/PC/UC60 34.0 3.58 2.78 21.0 2.52 2.39 8.50
HC42 34.0 3.58 2.78 21.0 2.52 2.39 8.50
HC60 34.0 3.58 2.78 21.0 2.52 2.39 8.50
HD48 34.0 3.58 2.78 21.0 2.52 2.39 8.50
HD60 34.0 3.58 2.78 21.0 2.52 2.39 8.50
THGD42S21S1
FC/MC/PC/UC48 42.0 3.52 3.45 25.0 2.60 2.81 8.50
FC/MC/PC/UC60 42.0 3.52 3.45 25.0 2.60 2.81 8.50
HC60 42.0 3.52 3.45 25.0 2.60 2.81 8.50
HD60 42.0 3.52 3.45 25.0 2.60 2.81 8.50
THGD48S21S1
FC/MC/PC/UC60 48.0 3.40 4.13 37.0 2.76 3.97 7.70
FC/MC62 48.0 3.40 4.13 37.0 2.76 3.97 7.70
HC60 48.0 3.40 4.13 37.0 2.76 3.97 7.70
HD60 48.0 3.40 4.13 37.0 2.76 3.97 7.70
THGD60S21S1 FC/MC62 58.0 3.46 4.91 40.0 2.36 4.90 7.70
1. Rated CFM same as for cooling.
2. Heating MBH based on ARI standards of 70° DB entering indoor air, 72% RH outdoor air with 25 feet of interconnecting piping and
no supplemental electric heat operation.

365147-YTG-C-0608
Johnson Controls Unitary Products 13
HEATING CAPACITY - With Variable Speed Furnaces
UNIT
MODEL
VARIABLE
SPEED
FURNACE
COIL1
MODEL
ARI HEATING2
47°F17°FHSPF
MBH COP KW MBH COP KW STD
13 SEER HP WITH VARIABLE SPEED FURNACES3
THGD18S21S1
PV8*A12 FC/MC/PC/UC18A 17.0 3.46 1.41 9.0 2.32 1.09 8.00
PV9*A12 FC/MC/PC/UC18A 17.0 3.42 1.43 9.0 2.28 1.13 8.00
P(C,V)9*B12 FC/MC/PC/UC18B 17.0 3.46 1.41 9.0 2.30 1.10 8.00
PV8*A12 FC/MC/PC/UC24A 17.0 3.46 1.41 9.0 2.32 1.09 8.00
PV9*A12 FC/MC/PC/UC24A 17.0 3.42 1.43 9.0 2.28 1.13 8.00
P(C,V)9*B12 FC/MC/PC/UC24B 17.0 3.46 1.41 9.0 2.30 1.10 8.00
PV8*A12 FC/MC/PC/UC30A 17.0 3.46 1.41 9.0 2.32 1.09 8.00
PV9*A12 FC/MC/PC/UC30A 17.0 3.42 1.43 9.0 2.28 1.13 8.00
P(C,V)9*B12 FC/MC/PC/UC30B 17.0 3.46 1.41 9.0 2.30 1.10 8.00
PV8*A12 HC18 17.0 3.46 1.41 9.0 2.32 1.09 8.00
PV9*A12 HC18 17.0 3.42 1.43 9.0 2.28 1.13 8.00
THGD24S21S1
PV8*A12 FC/MC/PC/UC24A 23.0 3.94 1.68 12.0 2.58 1.34 8.00
PV9*A12 FC/MC/PC/UC24A 23.0 3.92 1.68 12.0 2.58 1.34 8.00
P(C,V)9*B12 FC/MC/PC/UC24B 23.0 3.94 1.68 12.0 2.58 1.34 8.00
PV8*A12 FC/MC/PC/UC30A 23.0 3.94 1.68 12.0 2.58 1.34 8.00
PV9*A12 FC/MC/PC/UC30A 23.0 3.94 1.68 12.0 2.58 1.34 8.00
P(C,V)9*B12 FC/MC/PC/UC30B 23.0 3.94 1.68 12.0 2.58 1.34 8.00
PV8*A12 FC/MC/PC/UC32A 23.0 3.94 1.68 12.0 2.58 1.34 8.00
PV9*A12 FC/MC/PC/UC32A 23.0 3.94 1.68 12.0 2.58 1.34 8.00
P(C,V)9*B12 FC/MC/PC/UC35B 23.0 3.96 1.67 12.0 2.58 1.34 8.00
PV8*A12 HC30 23.0 3.94 1.68 12.0 2.58 1.34 8.00
PV9*A12 HC30 23.0 3.94 1.68 12.0 2.58 1.34 8.00
P(C,V)9*B12 HC36 23.0 3.96 1.67 12.0 2.58 1.34 8.00
THGD30S21S1
PV8*A12 FC/MC/PC/UC32A 29.0 3.68 2.29 15.0 2.30 1.85 7.85
PV9*A12 FC/MC/PC/UC32A 29.0 3.66 2.30 15.0 2.30 1.85 7.80
PV8*B16 FC/MC/PC/UC35B 28.0 3.76 2.21 14.0 2.36 1.77 7.95
PV8*C16 FC/MC/PC/UC35C 28.0 3.78 2.20 14.0 2.36 1.77 7.95
PV8*C20 FC/MC/PC/UC35C 29.0 3.66 2.30 15.0 2.30 1.87 7.85
P(C,V)9*B12 FC/MC/PC/UC35B 29.0 3.70 2.26 14.0 2.32 1.83 7.85
P(C,V)9*C16 FC/MC/PC/UC35C 29.0 3.74 2.24 14.0 2.34 1.80 7.90
PV8*A12 FC/MC/PC/UC37A 29.0 3.66 2.30 15.0 2.30 1.85 7.80
PV9*A12 FC/MC/PC/UC37A 29.0 3.66 2.30 15.0 2.30 1.85 7.80
PV8*B16 FC/MC/PC/UC43B 28.0 3.76 2.21 14.0 2.36 1.77 7.95
PV8*C16 FC/MC/PC/UC43C 28.0 3.78 2.20 14.0 2.38 1.76 8.00
PV8*C20 FC/MC/PC/UC43C 29.0 3.68 2.29 15.0 2.30 1.85 7.85
P(C,V)9*B12 FC/MC/PC/UC43B 29.0 3.72 2.25 14.0 2.34 1.81 7.90
P(C,V)9*C16 FC/MC/PC/UC43C 29.0 3.74 2.24 14.0 2.34 1.80 7.90
PV8*B16 HC36 28.0 3.76 2.21 14.0 2.36 1.77 7.95
P(C,V)9*B12 HC36 29.0 3.70 2.26 14.0 2.32 1.83 7.85
PV8*C16 HC42 28.0 3.78 2.20 14.0 2.38 1.76 8.00
PV8*C20 HC42 29.0 3.68 2.29 15.0 2.32 1.84 7.85
P(C,V)9*C16 HC42 29.0 3.74 2.24 14.0 2.34 1.80 7.90
For Notes See Page 14.

365147-YTG-C-0608
14 Johnson Controls Unitary Products
CP equals MBH output divided by (total KW input x 3.412).
HSPF (Heating Seasonal Performance Factor) is the total heating output during a normal annual usage period for heating divided by
the total electric power input during the same period.
— = Not Applicable.
THGD36S21S1
PV8*A12 FC/MC/PC/UC37A 34.0 3.66 2.68 20.0 2.56 2.31 8.65
PV9*A12 FC/MC/PC/UC37A 34.0 3.60 2.76 20.0 2.54 2.35 8.55
PV8*B16 FC/MC/PC/UC43B 33.0 3.74 2.61 20.0 2.62 2.23 8.80
PV8*C16 FC/MC/PC/UC43C 33.0 3.76 2.60 20.0 2.64 2.21 8.85
PV8*C20 FC/MC/PC/UC43C 33.0 3.70 2.64 20.0 2.60 2.25 8.75
P(C,V)9*B12 FC/MC/PC/UC43B 34.0 3.68 2.67 20.0 2.58 2.29 8.70
P(C,V)9*C16 FC/MC/PC/UC43C 33.0 3.74 2.61 20.0 2.62 2.23 8.80
P(C,V)9*C20 FC/MC/PC/UC43C 33.0 3.74 2.61 20.0 2.62 2.23 8.80
PV8*C16 FC/MC/PC/UC48C 33.0 3.78 2.57 20.0 2.66 2.19 8.90
PV8*C20 FC/MC/PC/UC48C 33.0 3.72 2.63 20.0 2.60 2.25 8.75
P(C,V)9*C16 FC/MC/PC/UC48C 33.0 3.76 2.60 20.0 2.64 2.21 8.85
P(C,V)9*C20 FC/MC/PC/UC48C 33.0 3.76 2.60 20.0 2.64 2.21 8.85
P(C,V)9*D20 FC/MC/PC/UC48D 33.0 3.76 2.60 20.0 2.64 2.21 8.85
PV8*C16 HC42 33.0 3.76 2.58 20.0 2.64 2.21 8.85
PV8*C20 HC42 33.0 3.72 2.63 20.0 2.60 2.25 8.75
P(C,V)9*C16 HC42 33.0 3.74 2.61 20.0 2.62 2.23 8.80
P(C,V)9*C20 HC42 33.0 3.76 2.60 20.0 2.64 2.21 8.85
THGD42S21S1
PV8*C16 FC/MC/PC/UC48C 41.0 3.62 3.31 25.0 2.68 2.68 8.70
PV8*C20 FC/MC/PC/UC48C 41.0 3.64 3.30 24.0 2.70 2.64 8.75
P(C,V)9*C16 FC/MC/PC/UC48C 41.0 3.60 3.33 25.0 2.66 2.70 8.65
P(C,V)9*C20 FC/MC/PC/UC48C 41.0 3.62 3.31 25.0 2.68 2.68 8.70
P(C,V)9*D20 FC/MC/PC/UC48D 41.0 3.60 3.33 25.0 2.68 2.68 8.70
PV8*C16 FC/PC/UC60C 41.0 3.62 3.31 24.0 2.68 2.66 8.70
PV8*C20 FC/PC/UC60C 41.0 3.64 3.30 24.0 2.70 2.64 8.75
P(C,V)9*C16 FC/PC/UC60C 41.0 3.60 3.33 25.0 2.66 2.70 8.65
P(C,V)9*C20 FC/PC/UC60C 41.0 3.62 3.31 24.0 2.68 2.66 8.70
P(C,V)9*D20 FC/MC/PC/UC60D 41.0 3.62 3.31 25.0 2.68 2.68 8.70
THGD48S21S1
PV8*C16 FC/PC/UC60C 48.0 3.42 4.06 37.0 2.76 3.92 7.80
PV8*C20 FC/PC/UC60C 48.0 3.44 4.04 37.0 2.78 3.92 8.00
P(C,V)9*C16 FC/PC/UC60C 47.0 3.40 4.05 37.0 2.76 3.97 7.80
P(C,V)9*C20 FC/PC/UC60C 48.0 3.42 4.06 37.0 2.76 3.94 8.00
P(C,V)9*D20 FC/MC/PC/UC60D 48.0 3.44 4.04 37.0 2.78 3.92 8.00
PV8*C20 FC/MC62D 48.0 3.44 4.04 37.0 2.78 3.92 8.00
P(C,V)9*C20 FC/MC62D 48.0 3.42 4.06 37.0 2.76 3.94 8.00
P(C,V)9*D20 FC/MC62D 48.0 3.44 4.04 37.0 2.78 3.92 8.00
THGD60S21S1 PV8*C20 FC/MC62D 58.0 3.48 4.84 39.0 2.38 4.80 7.70 P(C,V)9*C20 FC/MC62D 57.0 3.48 4.79 38.0 2.38 4.73 7.70
P(C,V)9*D20 FC/MC62D 56.0 3.50 4.68 38.0 2.38 4.73 7.75
1. Rated CFM same as for cooling.
2. Heating MBH based on ARI standards of 70° DB entering indoor air, 72% RH outdoor air with 25 feet of interconnecting piping and
no supplemental electric heat operation.
3. Variable speed furnaces have B.O.D (Blower on Delay) standard.
HEATING CAPACITY - With Variable Speed Furnaces (Continued)
UNIT
MODEL
VARIABLE
SPEED
FURNACE
COIL1
MODEL
ARI HEATING2
47°F17°FHSPF
MBH COP KW MBH COP KW STD

365147-YTG-C-0608
Johnson Controls Unitary Products 15
ACCESSORIES
Refer to Price Manual for specific model numbers.
Start Assist Kit (2SA067*)
Blower Time Delay - Available to increase efficiency when
installed. Installs on indoor section and maintains blower for
approximately one minute after cooling thermostat has been
satisfied.
Hard Start Kits - Provides required starting torque for use
with Thermal Expansion Valve Kit.
Low Temperature Cutout (2LT06700224) - Prevents heat
pump operation below -10°F ambient temperature.
Compressor Blanket - Designed to further reduce the nor-
mal operating sound.
Add-on Fossil Fuel Control - Interface controls for use with
gas, oil furnaces and the heat pump system are available.
Thermal Expansion Valve Kit - 1TVM Series TXV kit used to
improve system performance.
Outdoor Thermostat (2TD06700124) - Provides additional
staging of supplemental electric heat.
Room Thermostats - A wide selection of matching thermo-
stats is available to provide features required for any installa-
tion.
2H/1C, manual changeover electronic non-programmable
thermostat.
3H/2C, non-programmable digital thermostat.
3H/2C, auto/manual changeover, electronic programmable,
7-day, hardwire thermostat.
* For the most current accessory information, refer to the
price book or consult factory.
SOUND POWER RATINGS
* Rated in accordance with ARI 270-95 Standards.
TYPICAL INSTALLATION
TYPICAL FIELD WIRING
UNIT MODEL (dBA)*
Cooling Heating
018 TBD TBD
024 TBD TBD
030 TBD TBD
036 TBD TBD
042 TBD TBD
048 TBD TBD
060 TBD TBD
THERMOSTAT
SEAL OPENING(S) WITH
PERMAGUM OR EQUIVALENT
TO INDOOR COIL
TO FURNACE OR
AIR HANDLER
TERMINAL BLOCK
NEC CLASS 2 WIRING
NEC CLASS 1 WIRING
ALL OUTDOOR WIRING
MUST BE WEATHERPROOF. CONTROL
ACCESS
PANEL
WEATHERPROOF
DISCONNECT
SWITCH
MINIMUM 24” SERVICE
ACCESS CLEARANCE
ON ONE SIDE
48” OVERHEAD
CLEARANCE
10” CLEARANCE
AROUND PERIMETER
NOTE:
ALL FIELD WIRING TO BE IN ACCORDANCE WITH ELECTRIC CODE (NEC) AND/OR LOCAL CODES
POWER WIRING
208/230-1-60
CONTACTOR
TERMINALS
COIL
GND.
LUG
CYRGW
YRGW
POWER WIRING
CONTROL WIRING
FACTORY WIRING
24 VOLT CONTROL WIRING
MINIMUM 18 GA. WIRE
(NEC CLASS 2)
FURNACE OR AIR HANDLER TERMINAL BLOCK
ROOM THERMOSTAT
CONDENSING UNIT
ALL OUTDOOR WIRING MUST BE WEATHERPROOF. USE COPPER CONDUCTORS ONLY.
TERMINAL W IS ONLY
REQUIRED ON SYSTEMS
WITH HEAT.
*
*

365147-YTG-C-0608
16 Johnson Controls Unitary Products
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COOLING PERFORMANCE DATA
CONDENSING UNIT MODEL NO. THGD18S21S1
INDOOR COIL MODEL NO. AHP18
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 450 600 750
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65 T.C. 16.6 18.5 18.3 20.4 22.0 18.9 20.1 19.8 22.0 24.0 21.2 21.7 21.3 23.6 25.9 S.C. 13.3 13.3 13.7 13.6 12.7 13.3 13.3 13.5 13.5 13.1 13.3 13.3 13.3 13.3 13.4
KW 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.2
75 T.C. 15.6 17.4 17.2 19.2 20.9 17.8 18.8 18.6 20.7 22.6 20.0 20.2 20.0 22.1 24.3 S.C. 13.3 13.3 13.3 13.3 12.0 13.3 13.3 13.3 13.3 12.7 13.3 13.3 13.3 13.3 13.3
KW 1.1 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.3
85 T.C. 14.6 16.3 16.2 18.1 19.7 16.7 17.5 17.4 19.3 21.2 18.9 18.7 18.6 20.6 22.7 S.C. 13.3 13.3 12.8 12.9 11.3 13.3 13.3 13.1 13.1 12.2 13.3 13.3 13.3 13.3 13.2
KW 1.2 1.2 1.2 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.4
95 T.C. 13.6 15.2 15.1 16.9 18.5 15.7 16.2 16.1 18.0 19.7 17.7 17.2 17.2 19.1 21.0 S.C. 13.3 13.3 12.4 12.5 10.7 13.3 13.3 12.8 12.9 11.8 13.3 13.3 13.3 13.3 13.0
KW 1.3 1.3 1.3 1.4 1.4 1.3 1.4 1.4 1.4 1.4 1.4 1.4 1.4 1.4 1.5
105 T.C. 12.9 14.1 14.0 15.7 17.3 14.8 15.2 14.9 16.7 18.3 16.6 16.2 15.8 17.6 19.4 S.C. 12.9 13.1 11.8 11.9 10.0 13.3 13.2 12.5 12.6 11.2 13.3 13.3 13.3 13.3 12.4
KW 1.4 1.4 1.4 1.4 1.5 1.4 1.4 1.4 1.5 1.5 1.5 1.5 1.5 1.5 1.6
115 T.C. 12.3 13.0 12.9 14.5 16.1 13.9 14.1 13.6 15.3 16.9 15.4 15.2 14.3 16.1 17.8 S.C. 12.3 13.0 11.2 11.3 9.3 13.3 13.1 12.2 12.3 10.5 13.3 13.3 13.3 13.3 11.7
KW 1.5 1.5 1.5 1.5 1.6 1.5 1.5 1.5 1.6 1.6 1.6 1.6 1.5 1.6 1.7
125 T.C. 11.7 12.0 11.9 13.3 14.8 13.0 13.1 12.4 14.0 15.5 14.2 14.2 12.9 14.6 16.2 S.C. 11.7 12.0 10.6 10.7 8.7 13.0 13.1 11.9 12.0 9.8 13.3 13.3 12.9 13.3 11.0
KW 1.5 1.6 1.6 1.6 1.7 1.6 1.6 1.6 1.7 1.7 1.7 1.7 1.6 1.7 1.8
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
– FC/MC/PC/UC18 1.00 1.00 1.00
– FC/MC/PC/UC24 1.00 1.00 1.00
– FC/MC/PC/UC30 1.00 1.00 1.00
– HC18 1.00 1.00 1.00
AHP24 – 1.00 1.00 1.00
AV24 – 1.00 1.03 0.91
F4FP024 – 1.00 1.00 1.00
MV12B FC/MC18B 1.00 1.03 0.91
MA08B FC/MC18B 1.00 1.00 1.00
MV12B FC/MC24B 1.00 1.03 0.91
MA08B FC/MC24B 1.00 1.00 1.00
MV12B FC/MC30B 1.00 1.03 0.91
MA08B FC/MC30B 1.00 1.00 1.00
Variable Speed
Furnace Coil T.C. S.C. KW
PV8*A12 FC/MC/PC18A 1.00 1.03 0.91
PV9*A12 FC/MC/PC18A 1.00 1.03 0.91
P(C,V)9*B12 FC/MC/PC18B 1.00 1.03 0.91
PV8*A12 FC/MC/PC24A 1.00 1.03 0.91
PV9*A12 FC/MC/PC24A 1.00 1.03 0.91
P(C,V)9*B12 FC/MC/PC24B 1.00 1.03 0.91
PV8*A12 FC/MC/PC30A 1.00 1.03 0.91
PV9*A12 FC/MC/PC30A 1.00 1.03 0.91
P(C,V)9*B12 FC/MC/PC30B 1.00 1.03 0.91
PV8*A12 HC18 1.00 1.03 0.91
PV9*A12 HC18 1.00 1.03 0.91

365147-YTG-C-0608
Johnson Controls Unitary Products 17
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COOLING PERFORMANCE DATA
CONDENSING UNIT MODEL NO. THGD24S21S1
INDOOR COIL MODEL NO. AHP24
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 600 800 1000
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65 T.C. 20.3 23.5 23.6 26.0 28.3 22.8 24.8 24.6 27.1 29.2 25.3 26.1 25.7 28.3 30.2 S.C. 17.2 17.2 17.7 17.6 15.6 17.2 17.2 17.5 17.4 16.6 17.2 17.2 17.2 17.2 17.7
KW 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5
75 T.C. 19.9 22.3 22.3 24.7 26.8 22.1 23.5 23.3 25.8 27.7 24.2 24.6 24.3 26.8 28.6 S.C. 17.2 17.2 17.2 17.2 14.9 17.2 17.2 17.2 17.2 15.9 17.2 17.2 17.2 17.2 16.9
KW 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6
85 T.C. 19.5 21.1 21.0 23.5 25.4 21.3 22.2 22.0 24.4 26.2 23.2 23.2 22.9 25.3 27.1 S.C. 17.2 17.2 16.8 16.9 14.3 17.2 17.2 17.0 17.1 15.2 17.2 17.2 17.2 17.2 16.1
KW 1.7 1.7 1.7 1.7 1.8 1.7 1.7 1.7 1.8 1.8 1.7 1.7 1.7 1.8 1.8
95 T.C. 19.0 20.0 19.8 22.2 23.9 20.6 20.8 20.6 23.0 24.7 22.1 21.7 21.5 23.8 25.5 S.C. 17.2 17.2 16.4 16.6 13.6 17.2 17.2 16.8 16.9 14.4 17.2 17.2 17.2 17.2 15.3
KW 1.8 1.8 1.8 1.8 1.9 1.8 1.8 1.8 1.9 1.9 1.9 1.8 1.8 1.9 2.0
105 T.C. 17.9 18.6 18.4 20.6 22.3 19.3 19.5 19.0 21.3 22.9 20.7 20.4 19.7 22.0 23.5 S.C. 17.2 17.2 15.7 15.8 12.8 17.2 17.2 16.5 16.5 13.7 17.2 17.2 17.2 17.2 14.5
KW 1.9 1.9 1.9 2.0 2.1 2.0 2.0 1.9 2.0 2.1 2.0 2.0 2.0 2.1 2.1
115 T.C. 16.8 17.1 16.9 18.9 20.7 18.1 18.2 17.5 19.6 21.1 19.3 19.2 18.0 20.3 21.5 S.C. 16.8 17.1 15.0 15.1 12.1 17.2 17.2 16.1 16.2 12.9 17.2 17.2 17.2 17.2 13.8
KW 2.0 2.0 2.0 2.1 2.2 2.1 2.1 2.1 2.2 2.3 2.2 2.2 2.1 2.2 2.3
125 T.C. 15.7 15.7 15.5 17.3 19.2 16.8 16.8 15.9 17.9 19.4 17.9 17.9 16.3 18.5 19.6 S.C. 15.7 15.7 14.3 14.4 11.3 16.8 16.8 15.8 15.8 12.2 17.2 17.2 16.3 17.2 13.0
KW 2.2 2.1 2.1 2.3 2.4 2.3 2.2 2.2 2.3 2.5 2.3 2.3 2.2 2.4 2.5
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
– FC/MC/PC/UC24 1.00 1.00 1.00
– FC/MC/PC/UC30 1.00 1.00 1.00
– FC/MC/PC/UC32 1.00 1.00 1.00
– FC/MC/PC/UC35 1.00 1.00 1.00
– HC30 1.00 1.00 1.00
– HC36 1.00 1.00 1.00
– HD24 1.00 1.00 1.00
– MH24S 1.00 1.00 1.00
– MH30S 1.00 1.00 1.00
AHP30 – 1.00 1.00 1.00
AV24 – 1.02 1.03 0.93
F4FP030 – 1.00 1.00 1.00
MV12B FC/MC24B 1.01 1.02 0.92
MA08B FC/MC24B 1.00 1.00 1.00
MV12B FC/MC30B 1.01 1.02 0.92
MA08B FC/MC30B 1.00 1.00 1.00
MV12B FC/MC35B 1.02 1.02 0.93
MA08B FC/MC35B 1.00 1.00 1.00
Variable Speed
Furnace Coil T.C. S.C. KW
PV8*A12 FC/MC/PC24A 1.01 1.02 0.92
PV9*A12 FC/MC/PC24A 1.01 1.02 0.92
P(C,V)9*B12 FC/MC/PC24B 1.01 1.02 0.92
PV8*A12 FC/MC/PC30A 1.01 1.02 0.92
PV9*A12 FC/MC/PC30A 1.01 1.02 0.92
P(C,V)9*B12 FC/MC/PC30B 1.01 1.02 0.92
PV8*A12 FC/MC/PC32A 1.01 1.02 0.92
PV9*A12 FC/MC/PC32A 1.01 1.02 0.92
P(C,V)9*B12 FC/MC/PC35B 1.01 1.02 0.92
PV8*A12 HC30 1.01 1.02 0.92
PV9*A12 HC30 1.01 1.02 0.92
P(C,V)9*B12 HC36 1.01 1.02 0.92

365147-YTG-C-0608
18 Johnson Controls Unitary Products
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COOLING PERFORMANCE DATA
CONDENSING UNIT MODEL NO. THGD30S21S1
INDOOR COIL MODEL NO. AHP30
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 800 1000 1200
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65 T.C. 25.7 27.6 26.2 29.0 32.9 27.1 30.3 28.1 31.3 32.9 28.5 32.9 30.0 33.5 33.0 S.C. 24.2 24.2 20.1 20.5 20.0 24.2 24.2 21.8 22.4 20.2 24.2 24.2 23.5 24.4 20.3
KW 1.5 1.6 1.5 1.6 1.7 1.6 1.6 1.6 1.6 1.7 1.6 1.7 1.6 1.7 1.7
75 T.C. 25.2 27.4 26.0 29.2 31.2 26.4 29.1 27.3 30.3 31.8 27.6 30.8 28.5 31.5 32.4 S.C. 24.2 24.2 20.3 21.1 18.9 24.2 24.2 21.6 22.1 19.3 24.2 24.2 22.9 23.1 19.6
KW 1.7 1.7 1.7 1.8 1.8 1.7 1.8 1.7 1.8 1.8 1.7 1.8 1.8 1.8 1.8
85 T.C. 24.7 27.3 25.9 29.4 29.6 25.7 28.0 26.5 29.4 30.7 26.7 28.7 27.1 29.4 31.9 S.C. 24.2 24.2 20.6 21.6 17.8 24.2 24.2 21.4 21.7 18.4 24.2 24.2 22.2 21.8 18.9
KW 1.9 1.9 1.9 2.0 2.0 1.9 1.9 1.9 2.0 2.0 1.9 1.9 1.9 2.0 2.0
95 T.C. 24.2 27.1 25.7 29.7 27.9 25.0 26.9 25.7 28.5 29.6 25.8 26.6 25.6 27.4 31.4 S.C. 24.2 24.2 20.8 22.2 16.7 24.2 24.2 21.2 21.3 17.5 24.2 24.2 21.6 20.5 18.2
KW 2.0 2.1 2.1 2.1 2.1 2.1 2.1 2.1 2.1 2.1 2.1 2.1 2.1 2.1 2.2
105 T.C. 23.4 25.3 24.5 27.9 26.9 24.2 25.6 24.6 27.2 28.2 25.0 25.9 24.7 26.6 29.4 S.C. 23.4 24.1 20.6 21.5 16.1 24.2 24.1 21.5 21.6 16.7 24.2 24.2 22.4 21.7 17.3
KW 2.2 2.2 2.2 2.3 2.3 2.2 2.3 2.2 2.3 2.3 2.2 2.3 2.3 2.3 2.3
115 T.C. 22.6 23.4 23.2 26.1 26.0 23.4 24.3 23.5 25.9 26.7 24.3 25.2 23.9 25.8 27.4 S.C. 22.6 23.4 20.3 20.7 15.5 23.4 24.1 21.8 21.8 15.9 24.2 24.2 23.3 22.9 16.3
KW 2.3 2.4 2.4 2.5 2.4 2.4 2.4 2.4 2.5 2.5 2.4 2.4 2.4 2.5 2.5
125 T.C. 21.8 21.6 22.0 24.3 25.0 22.6 23.0 22.5 24.7 25.2 23.5 24.4 23.0 25.0 25.4 S.C. 21.8 21.6 20.0 20.0 14.9 22.6 23.0 22.1 22.1 15.1 23.5 24.2 23.0 24.2 15.3
KW 2.5 2.5 2.5 2.6 2.6 2.5 2.6 2.5 2.6 2.6 2.6 2.6 2.6 2.6 2.7
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
– FC/MC/PC/UC32 1.00 1.00 1.00
– FC/MC/PC/UC35 1.00 1.00 1.00
– FC/MC/PC/UC37 1.00 1.00 1.00
– FC/MC/PC/UC43 1.00 1.00 1.00
– HC36 1.00 1.00 1.00
– HC42 1.00 1.00 1.00
– HD36 1.00 1.00 1.00
– MH24S 1.00 1.00 1.00
– MH30S 1.00 1.00 1.00
AHP36 – 1.00 1.00 1.00
AV36 – 1.02 1.03 0.93
F4FP040 – 1.00 1.00 1.00
MV12B FC/MC35B 1.02 1.02 0.93
MV16C FC/MC35C 1.02 1.03 0.93
MA12B FC/MC35B 1.00 1.00 1.00
MV12B FC/MC43B 1.02 1.02 0.93
MV16C FC/MC43C 1.02 1.03 0.93
MA12B FC/MC43B 1.00 1.00 1.00
Variable Speed
Furnace Coil T.C. S.C. KW
PV8*A12 FC/MC/PC32A 1.01 1.01 0.92
PV9*A12 FC/MC/PC32A 1.01 1.01 0.92
PV8*B16 FC/MC/PC35B 1.02 1.03 0.93
PV8*C16 FC/MC/PC35C 1.02 1.03 0.93
PV8*C20 FC/MC/PC35C 1.01 1.01 0.92
P(C,V)9*B12 FC/MC/PC35B 1.02 1.01 0.93
P(C,V)9*C16 FC/MC/PC35C 1.02 1.02 0.93
PV8*A12 FC/MC/PC38A 1.01 1.01 0.92
PV9*A12 FC/MC/PC38A 1.01 1.01 0.92
PV8*B16 FC/MC/PC43B 1.02 1.03 0.93
PV8*C16 FC/MC/PC43C 1.02 1.03 0.93
PV8*C20 FC/MC/PC43C 1.01 1.01 0.92
P(C,V)9*B12 FC/MC/PC43B 1.02 1.01 0.93
P(C,V)9*C16 FC/MC/PC43C 1.02 1.02 0.93
PV8*B16 HC36 1.02 1.03 0.93
P(C,V)9*B12 HC36 1.02 1.01 0.93
PV8*C16 HC42 1.02 1.03 0.93
PV8*C20 HC42 1.01 1.01 0.92
P(C,V)9*C16 HC42 1.02 1.02 0.93

365147-YTG-C-0608
Johnson Controls Unitary Products 19
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COOLING PERFORMANCE DATA
CONDENSING UNIT MODEL NO. THGD36S21S1
INDOOR COIL MODEL NO. AHP36
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 1000 1200 1400
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65 T.C. 35.0 37.8 37.5 41.8 46.7 37.1 39.1 38.7 43.0 47.4 39.1 40.4 39.9 44.2 48.1 S.C. 33.9 31.5 26.9 26.8 22.0 36.0 34.7 29.4 29.0 23.8 38.1 37.9 31.8 31.3 25.5
KW 1.9 1.9 1.9 1.9 1.9 1.9 1.9 1.9 1.9 1.9 1.9 1.9 1.9 1.9 1.9
75 T.C. 33.5 35.8 35.6 39.6 44.3 35.4 37.0 36.8 40.7 45.2 37.4 38.2 37.9 41.8 46.0 S.C. 32.4 30.5 26.0 26.0 21.2 34.4 33.5 28.4 28.2 22.9 36.4 36.5 30.8 30.5 24.6
KW 2.1 2.1 2.1 2.1 2.1 2.1 2.1 2.1 2.1 2.1 2.1 2.1 2.1 2.1 2.2
85 T.C. 32.0 33.8 33.8 37.4 41.9 33.8 34.9 34.9 38.4 42.9 35.6 36.0 36.0 39.4 43.8 S.C. 31.0 29.5 25.1 25.1 20.3 32.8 32.3 27.5 27.4 22.0 34.7 35.1 29.8 29.8 23.7
KW 2.3 2.3 2.3 2.3 2.4 2.3 2.3 2.3 2.3 2.4 2.3 2.3 2.3 2.3 2.4
95 T.C. 30.5 31.8 31.9 35.1 39.6 32.1 32.8 33.0 36.1 40.6 33.8 33.8 34.1 37.0 41.7 S.C. 29.5 28.4 24.3 24.2 19.5 31.2 31.1 26.6 26.6 21.2 33.0 33.7 28.8 29.0 22.8
KW 2.4 2.5 2.5 2.5 2.6 2.5 2.5 2.5 2.5 2.6 2.5 2.5 2.5 2.5 2.6
105 T.C. 29.0 29.9 29.8 32.9 36.9 30.5 30.8 30.8 33.7 37.8 31.9 31.7 31.7 34.5 38.7 S.C. 28.1 27.5 23.4 23.3 18.6 29.6 29.7 25.7 25.7 20.2 31.2 31.9 28.0 28.0 21.8
KW 2.7 2.7 2.7 2.7 2.8 2.7 2.7 2.7 2.7 2.8 2.7 2.7 2.7 2.8 2.8
115 T.C. 27.7 28.0 27.9 30.7 34.2 28.9 28.9 28.6 31.3 35.0 30.1 29.8 29.3 32.0 35.8 S.C. 26.8 26.6 22.6 22.4 17.7 28.1 28.4 24.9 24.7 19.2 29.4 30.2 27.1 27.0 20.8
KW 2.9 2.9 2.8 2.9 3.0 2.9 2.9 2.9 3.0 3.0 3.0 2.9 2.9 3.0 3.1
125 T.C. 26.3 26.1 25.9 28.5 31.6 27.3 27.0 26.4 29.0 32.3 28.3 27.8 27.0 29.5 32.9 S.C. 25.5 25.7 21.8 21.5 16.8 26.6 27.1 24.0 23.8 18.3 27.6 28.4 26.3 26.0 19.8
KW 3.1 3.1 3.0 3.1 3.2 3.1 3.1 3.1 3.2 3.3 3.2 3.2 3.1 3.2 3.3
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
– FC/MC/PC/UC37 1.00 1.00 1.00
– FC/MC/PC/UC43 1.00 1.00 1.00
– FC/MC/PC/UC48 1.00 1.00 1.00
– FC/MC/PC/UC60 1.00 1.00 1.00
– HC42 1.00 1.00 1.00
– HC60 1.00 1.00 1.00
– HD48 1.00 1.00 1.00
– HD60 1.00 1.00 1.00
AHP42 – 1.00 1.00 1.00
AHP/SHP60 – 1.01 1.02 0.92
AV36 – 1.01 1.02 0.92
AV/SV48 – 1.01 1.02 0.92
F4FP045 – 1.00 1.00 1.00
F4FV060 – 1.01 1.02 0.92
F5FP048 – 1.01 1.02 0.92
F5FP060 – 1.01 1.02 0.92
MV16C FC/MC43C 1.02 1.03 0.93
MA12B FC/MC43B 1.00 1.00 1.00
MV12B FC/MC43B 1.01 1.02 0.92
MV16C FC/MC48C 1.02 1.03 0.93
MV16C FC60C 1.02 1.03 0.93
MV12D FC/MC48D 1.02 1.03 0.93
MV12D FC/MC60D 1.02 1.03 0.93
MA14D FC/MC48D 1.00 1.00 1.00
MA14D FC/MC60D 1.00 1.00 1.00
MV12D FC/MC48D 1.01 1.03 0.92
Variable Speed
Furnace Coil T.C. S.C. KW
PV8*A12 FC/MC/PC38A 1.01 1.01 1.00
PV9*A12 FC/MC/PC38A 1.00 1.00 1.00
PV8*B16 FC/MC/PC43B 1.01 1.02 0.92
PV8*C16 FC/MC/PC43C 1.01 1.02 0.92
PV8*C20 FC/MC/PC43C 1.01 1.01 0.92
P(C,V)9*B12 FC/MC/PC43B 1.01 1.01 0.92
P(C,V)9*C16 FC/MC/PC43C 1.01 1.02 0.92
P(C,V)9*C20 FC/MC/PC43C 1.01 1.02 0.92
PV8*C16 FC/MC/PC48C 1.02 1.03 0.93
PV8*C20 FC/MC/PC48C 1.01 1.01 0.92
P(C,V)9*C16 FC/MC/PC48C 1.01 1.02 0.92
P(C,V)9*C20 FC/MC/PC48C 1.01 1.02 0.92
P(C,V)9*D20 FC/MC/PC48D 1.01 1.02 0.92
PV8*C16 HC42 1.02 1.02 0.93
PV8*C20 HC42 1.01 1.01 0.92
P(C,V)9*C16 HC42 1.01 1.02 0.92
P(C,V)9*C20 HC42 1.01 1.02 0.92

365147-YTG-C-0608
20 Johnson Controls Unitary Products
Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree below the listed temperature.
COOLING PERFORMANCE DATA
CONDENSING UNIT MODEL NO. THGD42S21S1
INDOOR COIL MODEL NO. AHP42
CONDENSING
ENTERING AIR
TEMPERATURE
IDCFM 1200 1400 1600
ID DB (°F) 80 80 75 80 80 80 80 75 80 80 80 80 75 80 80
ID WB (°F) 57 62 62 67 72 57 62 62 67 72 57 62 62 67 72
65 T.C. 38.3 43.6 41.6 46.5 49.4 40.5 44.8 42.8 47.6 50.2 42.7 46.1 44.0 48.7 50.9 S.C. 38.3 36.8 30.3 31.3 24.1 40.5 39.8 32.7 33.6 25.5 42.7 42.9 35.1 35.8 27.0
KW 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.4 2.5 2.4 2.4 2.4 2.4 2.5
75 T.C. 37.0 41.4 39.7 44.3 47.0 39.0 42.8 40.8 45.3 47.4 41.0 44.3 41.9 46.3 47.9 S.C. 37.0 35.8 29.5 30.3 23.7 39.0 38.7 31.9 32.6 25.2 41.0 41.5 34.3 34.9 26.7
KW 2.6 2.6 2.6 2.6 2.7 2.6 2.6 2.6 2.7 2.7 2.6 2.6 2.6 2.7 2.7
85 T.C. 35.6 39.3 37.9 42.1 44.6 37.4 40.9 38.8 43.1 44.7 39.3 42.4 39.7 44.0 44.8 S.C. 35.6 34.8 28.8 29.3 23.4 37.4 37.5 31.1 31.6 24.9 39.3 40.1 33.4 34.0 26.5
KW 2.8 2.8 2.8 2.9 2.9 2.8 2.9 2.8 2.9 2.9 2.9 2.9 2.8 2.9 3.0
95 T.C. 34.2 37.2 36.0 40.0 42.2 35.9 38.9 36.8 41.0 42.0 37.6 40.5 37.6 41.6 41.8 S.C. 34.2 33.8 28.0 28.3 23.0 35.9 36.3 30.3 30.8 24.6 37.6 38.8 32.6 33.0 26.3
KW 3.0 3.1 3.0 3.1 3.2 3.1 3.1 3.0 3.1 3.2 3.1 3.1 3.1 3.2 3.2
105 T.C. 32.4 35.2 33.6 37.3 39.4 34.2 36.8 34.3 38.0 39.4 36.1 38.4 35.1 38.7 39.4 S.C. 32.4 32.2 26.7 27.1 21.7 34.2 34.3 28.9 29.4 23.3 35.8 36.4 31.2 31.6 24.9
KW 3.3 3.3 3.2 3.3 3.4 3.3 3.3 3.3 3.4 3.5 3.4 3.4 3.3 3.4 3.5
115 T.C. 30.6 33.2 31.2 34.7 36.7 32.6 34.7 32.0 35.4 36.9 34.6 36.3 32.7 36.0 37.1 S.C. 30.6 30.6 25.5 26.0 20.5 32.3 32.3 27.6 28.1 22.0 33.7 34.0 29.8 30.2 23.6
KW 3.5 3.5 3.5 3.6 3.7 3.5 3.6 3.5 3.6 3.7 3.6 3.6 3.5 3.6 3.7
125 T.C. 28.8 31.2 28.8 32.1 33.9 31.0 32.7 29.6 32.7 34.3 33.1 34.2 30.3 33.3 34.7 S.C. 28.8 29.1 24.3 24.8 19.2 30.3 30.4 26.3 26.8 20.7 31.7 31.7 28.4 28.9 22.2
KW 3.7 3.7 3.7 3.8 4.0 3.8 3.8 3.7 3.8 4.0 3.8 3.8 3.7 3.9 4.0
NOTE: ALL CAPACITIES INCLUDE INDOOR FAN HEAT AT 1250 BTUH/1000 CFM.
Air Handler Coil T.C. S.C. KW
– FC/MC/PC/UC60 1.00 1.00 1.00
– HC60 1.00 1.00 1.00
– HD60 1.00 1.00 1.00
AHP/SHP48 – 1.00 1.00 1.00
AHP/SHP60 – 1.01 1.02 1.00
AV/SV48 – 1.01 1.02 1.00
AV/SV60 – 1.01 1.02 1.00
F4FV060 – 1.01 1.02 1.00
F5FP045 – 1.00 1.00 1.00
F5FP048 – 1.01 1.02 1.00
F5FP060 – 1.01 1.02 1.00
MV16C FC/MC48C 1.01 1.02 1.00
MV16C FC/MC60C 1.01 1.02 1.00
MV20D FC/MC48D 1.01 1.02 1.00
MA14D FC/MC48D 1.00 1.00 1.00
MA16C FC/MC48C 1.00 1.00 1.00
MV20D FC/MC60D 1.01 1.02 1.00
MA14D FC/MC60D 1.00 1.00 1.00
MA16C FC60C 1.00 1.00 1.00
Variable Speed
Furnace Coil T.C. S.C. KW
PV8*C16 FC/MC/PC48C 0.98 1.01 0.98
PV8*C20 FC/MC/PC48C 1.01 1.01 1.00
P(C,V)9*C16 FC/MC/PC48C 1.00 1.00 1.00
P(C,V)9*C20 FC/MC/PC48C 0.98 1.01 0.98
P(C,V)9*D20 FC/MC/PC48D 0.98 1.00 0.98
PV8*C16 FC/PC60C 1.01 1.01 1.00
PV8*C20 FC/PC60C 1.01 1.01 1.00
P(C,V)9*C16 FC/PC60C 1.00 1.00 1.00
P(C,V)9*C20 FC/PC60C 1.01 1.01 1.00
P(C,V)9*D20 FC/MC/PC60D 0.98 1.00 0.98
