➲ 40 Watt Mini Series Speaker
➲ 90° x 90° HF Driver
➲ 5-inch Woofer with Tweeter
➲ Cabinet Is Available In Either a White (C110W) or
Black (C110) Finish
➲85 to 19,000 Hz Frequency Response
➲
70-volt ‘Matching Transformer’
➲Binding Post and 1/4" Phone Connectors
➲Injection Molded, ABS Plastic Cabinet Construction
➲Two-year Unconditional Warranty*
*Warrany valid in Canada and the United States only
The Coliseum C110 is a high quality, weather resistant speaker which features specially treated drivers in a rugged
plastic enclosure. It is well-suited for many applications including commercial installations, home theaters, home
stereos, reference monitors and personal stage monitors. The C110 is a bass reflex enclosure with a tuned port
and a 5-inch woofer whose computer-optimized design gives improved bass performance over conventional 5-inch
woofer enclosures. With a power rating of 40 watts of continuous music power the C110 is accurate from 85Hz to
19kHz with an efficiency of 92dB.
The C110 features an internal 70-volt ‘matching transformer’ which allows multiple C110s to be connected
together without danger of overloading the power amplifier due to impedance drop. The user has a choice of three
sensitivity settings (10w, 20w, 30w or off) selected via a rotary switch located on the rear panel of the
speaker, allowing convenient adjustment of the relative volumes of multiple interconnected cabinets.
A wide variety of mounting options are available using the four integral screw-slots or the provided metal L-bracket
which allows it to be angled up, down or sideways depending on the mounting orientation. The C110 is available in
a low-reflectance black or white finish with a matching, perforated metal grille and can be painted to match its
surroundings.
Coliseum C110
Coliseum C110
Features:
Overview:
yorkville.com
5-inch Mini Series Speaker
5-inch Mini Series Speaker
C110 Specifications:
C110
2-Way, Tuned Port
Bass Reflex
40
70V Transformer / Passive 8Ω
92
85 - 19k
5"
Mylar
Screw Terminals
Injection Molded ABS Plastic
Black
White (C110W)
Rear Key Hole Mounts (4) /
L-Bracket
-
10W / 20W / 30W / 8R
5.5 x 6.26 x 8.9
14 x 15.9 x 22.6
3.8 / 1.7
Model
TYPE
SYSTEM
PROGRAMPOWER (watts)
IMPEDANCE (ohms)
SENSITIVITY (dB @ 1W/1m)
FREQ. RESP. (+/-3dB)
WOOFER
TWEETER
INPUTS
CABINET CONSTRUCTION
STANDARD COLOR
OPTIONAL COLOR
STANDARD HARDWARE
OPTIONAL HARDWARE
70V TRANSFORMER TAPS
DIMENSIONS (DxWxH inches)
DIMENSIONS (DxWxH cm)
WEIGHT (lbs / kg)
