YORKVILLE COLISEUM C120P User manual

➲ 125 Watt Active Mini Series Speaker
➲ 90° x 90° HF Driver
➲ 5-inch Woofer with Mylar Tweeter
➲ Volume, Bass and Treble Controls
➲65 to 19,000 Hz Frequency Response
➲1 x 1/4-inch TRS Balanced / 1 x 1/8-inch Stereo Inputs
➲Injection Molded, ABS Plastic Cabinet Construction
➲Two-year Unconditional Warranty*
*Warrany valid in Canada and the United States only
The Coliseum C120P is the most compact active loudspeaker Yorkville Sound has to offer. This
compact speaker is ideally suited for many applications including commercial installations, satellite
extension speaker, home theatre, home stereo, reference monitor or personal stage monitor. The bass
reflex enclosure with a tuned port and a 5-inch woofer that provides improved bass performance over
conventional 5-inch woofer enclosures. Removing the press-fit grille gives access to the eyeball tweeter
that can be swivelled to suit various listening positions.
The C120P will deliver 125 watts of continuous music with a frequency response of 75Hz to over 19kHz.
Its amplifier section has easy to access volume, bass and treble controls, TRS balanced 1/4-inch inputs;
1/8-inch TRS stereo inputs are mounted on the rear panel. An innovative 1/8-inch TRS stereo link
output is provided for true stereo operation when using two C120P’s.
The C120P is shipped with a mounting U-bracket and all the necessary hardware for installation applications.
Coliseum C120P
Coliseum C120P
Features:
Overview:
yorkville.com
5-inch Active Mini Series Speaker
5-inch Active Mini Series Speaker
C120P Specifications:
Model C120P
SYSTEM TYPE 2-Way
ACTIVE OR PASSIVE Active
PROGRAM POWER (Watts) 125
BIAMPABLE No
MAX SPL (dB) 101
FREQUENCY RESPONSE (Hz +/- 3db) 65 - 19000
DRIVER CONFIGURATION Tweeter, 5 inch
HF DRIVER(S) Aimable Mylar Tweeter
HF DISPERSION (°H x °V) 90 x 90
LF DRIVER(S) 5 inch
INPUTS - 1/4" JACKS 1 (1 x 1/8inch)
MIXER CONTROLS Level, Treble, Bass, Mono/Stereo Select
FLYING HARDWARE U-Bracket, 2 Rear Key Hole Mounts
INCLUDED HARDWARE U-Bracket
ENCLOSURE MATERIALS Injection Molded, ABS Plastic
GRILLE Perforated Steel
COVERING / FINISH Low Reflective Black
DIMENSIONS (DWH xbackW, inches) 6.5 x 6.75 x 10.25 x 6
DIMENSIONS (DWH xbackW, cm) 16.5 x 17 x 26 x 16
WEIGHT (lbs/kg) 8.5 / 3.9
