Youmi Intelligent Technology C6T User manual

01 02
Best wear the wristband behind malleolus
ulnaris;
Adjust the size suitable for the size of
wrists via Adjustment Hole; Fasten wrist
strap buttons;
Sensor shall be close to skin avoiding
moving.
1.
2.
3.
When the device starts up, to touch function keys for a short time period can lighten
screen or switch over display;
The screen shall be turned off without operation and users can connect the mobile
1.
2.
phone APP to revise off-screen time;
Switch to the heart rate and blood pressure interfaces to be tested automatically and
leave the heart rate and blood pressure interfaces to stop tests.
3.
POWER ON/OFF
1.In the state of the wristband shutdown, the long touch function key over 3 seconds
can make the device vibrate.
2.When the wristband is in the boot state, it will switch to the shutdown interface. If the
touch function key is more than 3 seconds, it can enter the shutdown interface. After
the short touch is selected Off, it will touch the shutdown again.
OPERATION
WEARING METHOD
Malleolus ulnaris
PREPARATION
Make sure that the power is sufficient before turning on，
Use USB charging port to charge
First remove the wrist
band
Take out the fuselage
Plug into the USB
charging head to charge
For the first time, please take out the
bracelet and charge the device with the
corresponding charger. When charging, the
bracelet will start up automatically (charging
mode is shown in the figure below: remove
the bracelet body from the wristband and
plug the charging port into the standard USB
port to charge.)
Left Hand
Sensor

03 04
INSTALL THE WRISTBAND APP
Scan the following QR codes or enter into various large application markets to download
and install “ DayBand ”.
Device requirement: iOS8.0 and above; Android 4.4 and above to support bluetooth 4.0
iOS
DEVICE CONNECTION
When being used for the first time, it is necessary to connect APP to proofread. Open
the App click “Add a new device” to connect the wristband with mobile phones. After
successful connection, wristband will self-synchronize time, otherwise, the step
calculation and sleep data won't be accurate.
Open mobile phone APP
Click to set up icons
↓
My device (iOS)/ search
equipmen(Android)
↓
Pull down scanning equipment
↓
Click device attachment
Bluetooth connection: after successfully pairing, APP will automatically save the wristband
bluebooth address. When APP is opened, it will automatically search and connect with the
wristband.
Data Synchronism: manually pull down the synchronization data on the APP home page;
the bracelet can store off-line data for 7 days, the more data, the longer the synchronization
time is, and the longest time is about 2 minutes.
APP FUNCTIONS AND SETTING
Personal information and exercise goals
After entering into APP, please first set up
personal information.
Setting Personal setting
→
·
·
Head portrait, gender, age, height and weight
can be set up and personal information can
enhance accuracy of data.
Customize personal everyday exercise goals. A
reasonable exercise plan is helpful for promoting
body quality.
Google Play

05 06
In the motion interface, long press for three seconds to enter the specific motion
interface, which includes a number of movements. Click to switch. In the motion
interface, hold the button for three seconds to start the motion, hold the button for three
seconds to pause, and click to switch the motion mode.
Training interface
In the Blood pressure monitoring interface,During the measurement, please
wait for several tens of seconds for the data to appear
Blood pressure monitoring
MAIN FUNCTIONAL INTERFACE
Main interface
When the Bluetooth icon is , it means the wristband is not connected to the cell phone.
When the Bluetooth icon is , the connection is successful. When the wristband and
APP are paired for the first time, the wristband will synchronize the weather, time, date and
week of the mobile phone.
Long press 3 seconds to switch the main interface
· When the test, the icon will beat and the back heart rate of the hand ring LED lights will be lit;
· When testing, the sensor should stick to the skin to avoid the influence of external light on the accuracy of the test.
· To keep the test area clean, sweat or stains will affect the test results.
In the blood oxygen monitoring interface, please wait for dozens of seconds
for data display during measurement
Blood oxygen monitoring
Exercise Data
Display step count, wristband default step counting mode, the wristband is worn on
the wrist. When the user walks and arms swings, the wristband is recorded according
to the number of steps.
In the heart rate monitoring interface, During the measurement, please wait
for several tens of seconds for the data to appear
Heart rate monitoring
In theTemperature monitoring interface, During the measurement, please wait
for several tens of seconds for the data to appear
Temperature monitoring
When taking your temperature, wear it for more than 1 minute to be
more accurate In the message interface, long press three seconds to view the message, click page
flip, view the message to exit or long press three seconds to exit.
Message interface
In more features interface, long press three seconds to enter the lower menu interface
for more functions.
More functional interface
When connected, click on the "Find Phone" option and the phone will send a vibration
reminder or ringtone reminder.
Find phone interface
The interface is restored for three seconds, and the bracelet is restored to the factory
settings.
Restore setting interface

07 08
Screen ruler 0.96inch
245mm*16mm*11.5mm
Bluetooth4.0
90mAh
Bracelet+Instructions
Battery type Lithium Polymer
Charging time 1.5-2 hours
Wrist band ruler
Bluetooth
waterproof Ip67 waterproof
capacity
Packing
Please avoid strong impact, extreme heat and exposure to the wristbandt.
Please do not disassemble, repair or transform the machine on its own.
The use of the environment is 0 degrees ~45 degrees, and it is forbidden to throw it into
the fire so as not to cause an explosion.
Please wipe the water, the wristband can be used only for the charging operation with a
soft cloth, otherwise it will cause corrosion of charging contact point, charging fault.
Do not touch the chemical substances such as gasoline, clean solvent, propanol, alcohol
or insect repellent.
Please do not use this product in high pressure and high magnetic environment.
If you have sensitive skin skin or tighten the wristband, you may feel discomfort.
Please dry the sweat drips on the wrist in time. The strap has long contact with soap,
sweat, allergies or pollution ingredients, which may cause skin allergy itching.
If it is often used, it is recommended to clean the wristband every week. Wipe with wet
cloth and remove oil or dust with mild soap.
It is not appropriate to wear a hot bath with a wristband.
After swimming, please wipe the wristband in time so as to keep dry.
For promoting function, a promoting switch shall be switched on in AP P-end
Setting Center, mobile phone and wristband shall be kept to be connected
successfully and there will be vibrating reminders when there are messages.
PROMOTING FUNCTION
PARAMETER
MATTERS NEEDING ATTENTION
Long press more 3s, you can see the six digits Bluetooth address and the software
version
More interface
In the Shutdown interface, long press more than three seconds to shake the phone off.
Shutdown interface
Sitting
message
Calling Alarm clock
Call reminding : when the calls coming, the device will shake and the name or
number of the caller is displayed. (if the caller's name has been saved in the phone
address book, the name is displayed, otherwise the display number only)
SMS reminder: when a message arrives, the wristband will vibrate and display the
SMS and Sende.(if the sender saved in phone book, will display name, otherwise
display number only).
Alarm clock: You can set there alarm clocks in App, after setting, it will sync to
wristband. When Alarm clock start, the wristband will vibrate.
Sedentary reminder: if you don’t move over one hour, the wristband will vibrate to
remind You to stand up and move.

This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
Warning: changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment
RF warning for portable device:
The device has been evaluated to meet general RF exposure requirement. The device can be used in
portable exposure condition without restriction.
