ysctech HD-A03001 User manual
HD Digital Video Microscope
HD-A03001
www.digital-usb-microscopes.com
www.digital-usb-microscopes.com
YSC Technologies
www.digital-usb-microscopes.com
www.digital-usb-microscopes.com
www.digital-usb-microscopes.com
YSC Technologies
www.digital-usb-microscopes.com
www.digital-usb-microscopes.com
www.digital-usb-microscopes.com
YSC Technologies
www.digital-usb-microscopes.com
Introductions:
This is a new design and exclusive digital video microscope. Its functions include camera
drawing, video display, graphic measurement, video recording, which is not only for
mobile phone repair but also jewelry welding and more precision welding works. 12-78X
magnification details will be display on 12 inch screen with 1080 HD resolution. Graphic
measurement function of this microscope will help you solve more problems.
The HD-A03001 is an intelligent digital microscope. Due to the many accessories it can be
used in many areas.Among other things, it is also useful in the following fields: industry,
life sciences, mineralogy, insect barn, botany, crime lab, education, etc. For its simplicity,
its use is easy to learn.
www.digital-usb-microscopes.com
www.digital-usb-microscopes.com
YSC Technologies
www.digital-usb-microscopes.com
Main Specifications:
Microscope:
Magnification: 12X-78X (ZOOM) on 12” HD Monitor.
Built in 0.35X Video Coupler; 0.5X for options.
Standard 1X Objective Lens; 0.75X and 1.5X options.
FOV: 23mm- 3mm standard.
Working Distance: 96mm standard.
Base Size: 260mm(X)*320mm(Y)
Height of the microscope: 480mm
Weight of the microscope: 5.5kgs
Camera:
2.0M HDMI, true color, no delay.
Max. Resolution: 1920*1080
Sensor: 1/2.86 inch SONY sensor
Pixel Size: 2.75*2.75μm
Frame Rate: 60fps@1920*1080
SNR: 65DB
LCD Display:
12 inch HD LCD display, 1080P, wide screen, multi angle adjustment.
Illumination:
High quality LED illumination, 144 LED bulbs.
Operation:
Wireless mouse or manual operation, image capture, U disk storage and
measurement.
Features:
Intelligent all-in-one digital microscopes
Supports high definition video/images, image freezing
Manual measurement with measuring data Excel output, graphic primitive Excel
output
oMeasurement features: Single and double reticle, four transverse and four
vertical lines
Image setting adjustments: white balance, gain, saturation, reflection elimination,
brightness, HDR depth of field, buttons and mouse dual control
External HDMI output available for connecting to larger HDMI LCD monitor
USB interface for U-disk/USB storage
www.digital-usb-microscopes.com
www.digital-usb-microscopes.com
YSC Technologies
www.digital-usb-microscopes.com
Quickly, Exactly, Simply
www.digital-usb-microscopes.com
www.digital-usb-microscopes.com
YSC Technologies
www.digital-usb-microscopes.com
Comfort, magnification and speed
With the HD-A03001 Digital Microscope, work is fast and easy, and the 12” HD resolution
monitor provides sharp, high-quality images.
The ergonomically tilting monitor makes the instrument comfortable and reduces neck
strain. The monitor image can be displayed on multiple screens simultaneously with HDMI
www.digital-usb-microscopes.com
www.digital-usb-microscopes.com
YSC Technologies
www.digital-usb-microscopes.com
splitter, so it's great for use in education as well. Manual focus and zoom enable quick
setting.
www.digital-usb-microscopes.com
www.digital-usb-microscopes.com
YSC Technologies
www.digital-usb-microscopes.com
Camera Specifications
Image spec
1920x1080x24Bit
Shoot Mode
Manual/line control
Resolution
60 fps@1920x1080
Storage Mode
U Disk
Optical Size
1/2”
Crosshairs
Superpose or cancel
Pixel Size
3.75x3.75um
Lens Mount
C Mount
Color Adjust
R.G.B adjust
individually
Working voltage
5V-12V
WB
One button/Manual
Camera Size
280x180x67mm
Displayer Size
11.6’’
280x180x16mm
Displayer
Resolution
1920*1080P
Exposure
Auto or Manual
Weight
450g
www.digital-usb-microscopes.com
www.digital-usb-microscopes.com
YSC Technologies
www.digital-usb-microscopes.com
Camera Operation Instructions
Preparation before using
①Select appropriate lens for camera
②Fix the camera to the holder and match the light source
③Turn on the power and make sure the monitor indicates that the power
light is on.
④Select language after booting. Simplified Chinese, Traditional Chinese and
English are optional (Simplified Chinese is defaulted).
Camera Settings
Select the camera settings in the auxiliary tool, set the camera's own
properties according to the natural light, the intensity of the light, the ratio of red,
green and blue, HDR is the suppression glare mode, and the left and right keys of
the function keys are reduced or Increase the control of light; SE edge
enhancement mode can improve the edge effect of the image by reducing or
increasing the sharpening of the edge under specific requirements. But it also
increases the noise of the image.
Button Function
Contrast
Manual
Working Temperature
0-70℃
Brightness
Contrast
Red adjust
Edge
enhancement
Green
adjust
Wide Dynamic
Blue adjust
www.digital-usb-microscopes.com
www.digital-usb-microscopes.com
YSC Technologies
www.digital-usb-microscopes.com
1）To adjust the image: Use mouse to click the slide block and set, or click the slide block
and then roll the mouse to get the set.
2）To add horizontal line and vertical line: Set the number of lines and press “ok” key, then
you will see the lines as you set. Put the mouse to any line, mouse arrowhead will change
to hand form then you can move this line to deserved position. Adjust the line slightly with
mouse roller.
Put the mouse to any line and press right key to adjust the line attribute, it will show
the set window to adjust the line color, thickness.
Each line is with its unique coordinate position, you can calculate and set the distance
between two lines.
Central cross curve set: Press this button and it will show the set window, you can
change the cross curve thickness and color.
Auto exposure set：Press this button and adjust the current brightness. Select the
lower left quarter block to get the auto exposure.
White balance set：Put a white paper or abject under the lens, press WB button,
camera will adjust RGB automatically under your lighting environment to make the color close to
white. Select the lower left quarter block to get the auto white balance.
Photo button：Press this button to save the image. It will save to the U disk(if available)
prior to camera internal storage.
This machine has one USB port only. Please capture the picture with the remote
control. Or an external USB extender to insert a USB flash drive to store images.
Photo reading：Press this button to browse the images.
Image comparison：Press this button and get the image that needs to be compared,
system will show this image into the right part of the screen, and show the real time
image on the left of screen. Use the mouse to adjust the position of 2 images and
compare.
Mirror image button: Mirror operate the image.
Image up and down adjust button：To adjust or switch the image from top to bottom.
Color and black/white convert: To select color or black/white mode for the image.
Freeze button: Current dynamic picture will be frozen by pressing this button, restore to
dynamic picture by pressing this button again.
Press this button will freeze the current dynamic picture, pressing it again will restore the
dynamic picture.
Electric frequency：Select the suitable electric frequency to avoid picture scroll.
Color Temperature：To choose the right color temperature.
Frame selection area: You can draw the area of interest by dragging with the mouse to
mark the key points.
www.digital-usb-microscopes.com
www.digital-usb-microscopes.com
YSC Technologies
www.digital-usb-microscopes.com
Product Size Chart：
Install Size Chart ：
