YUAN High-Tech nT15AX10 User manual

Operation Manual
Operation Manual
nT15AX10
MULTI INPUT TO SDI/HDMI CONVERTER
SOLUTIONS FOR GROWTH n - TECH SOLUTIONS
nT

Content
Feature ................................................................................... 3
Front Panel ............................................................................... 4
Rear Panel ................................................................................ 4
Side Panel ................................................................................ 5
DipSwitch/LED Control ................................................................. 6
Installation ............................................................................. 12
Package Contents ..................................................................... 12
Specifications .......................................................................... 13
Firmware Upload ...................................................................... 15
Appendix Table A ..................................................................... 15
Update List ............................................................................. 18

Feature
 SDI Supports HD formats :
 720p50 & 60
 1080i50 & 60
 1080p24, 25, 30, 50 & 60
 SDI Support 525i & 625i SD D1 format
 Auto 3G/HD/SD-SDI detecon
 Can be split one 3G-SDI displays simultaneously.
 Frame rate conversion(1.000/1.001)
 External Dipswitch and Usb Configuraon
 Firmware is upgradable in the field using the integrated USB port
 The converter is Plug-and-Play
 Support DVI-D, DVI-A, Component, CVBS and S-Video Input0
 Support Embedded audio and stereo audio( L/R Audio )

Front Panel
NO Component Funcon
1 SDI Output Port From your SDI Display Device plug into this ports
2 HDMI output Port From your HDMI Display Device plug into this port
3 Input Port/ Audio
source LED
The LEDs are indicate Input Ports and Audio
Source
5 Dipswitch Control the Box ( Input Port/Audio/Output
Format)
6 Power Jack The Power adapter plug into here
Rear Panel
NO Component Funcon
1 Phone Jack From you Audio Device plug into this port
2 Component/CVBS/S-Video
Input Port
From your YPbPr/CVBS/S-Video Device plug
into this port
3 DVI-D/DVI-A Input Port From your DVI-D/DIV-A Device plug into this
port
1 3
1 5 2
2
3
4

Side Panel
NO Component Funcon
1 USB Port Upgrade firmware/Control Box From PC
1

DipSwitch/LED Control
NO Component Function
1 Input Source Five of kinds input source be support
( DVI-D/DV-A/YPbPr/CVBS/S-Video)
2 Audio Source Two of kinds Audio input source
(Embedded audio/L/R Audio)
3 Output format Control Box to switch Output Format.
 Input Source:
VPC-MX1 Box can choose one of three standard inputSource by DipSwitch.
Input Source Dipswitch Indicates
DVI-D(HDMI)
DVI-A(VGA)
YPbPr
CVBS
S-Video(YC)
USB Control
1 2 3

 Audio Source:
VPC-MX1 Box can be select audio source from L/R Audio.
Resoluon Dipswitch Indicates
Internal (Default)
L/R Audio
 Output Format:
VPC-MX1box can be select 16 of kinds output format.
Resoluon Dipswitch Indicates Resoluon
1920x1080p60 1920x1080i60
1920x1080p59 1920x1080i59
1920x1080p50 1920x1080i50
1920x1080p30 1280x720p60
1920x1080p29 1280x720p59
1920x1080p25 1280x720p50
1920x1080p24 720x480i59
1920x1080p23 720x576i50

 LED Indicate:
NO Component Function
1 Internal/L/R Audio The LED is indicate Audio Source
indicate
2 DVI-D(HDMI) The LED is indicate DVI-D Signal indicate
3 DVI-A(VGA) The LED is indicate DVI-A Signal indicate
4 YPbPr The LEDs is indicate YPbPr Signal
indicate
5 CVBS The LED is indicate CVBS Signal indicate
6 S-Video The LEDs is indicate S-Video Signal
indicate
1 6
2 3 4 5

1. DVI-D + L/R Audio:
DVI-D + L/R Audio
DVI-D DVI-A YPbPr Cvbs S-Video
Locked ● ○ ○ ○ ○
Un-locked ● ○ ○ ○ ○
MicroVision ●(Blinking) ○ ○ ○ ○
2. DVI-A+ L/R Audio:
DVI-A + L/R Audio
DVI-D DVI-A YPbPr Cvbs S-Video
Locked ○ ● ○ ○ ○
Un-locked ○ ● ○ ○ ○

3. YPbPr + L/R Audio:
YPbPr + L/R Audio
DVI-D DVI-A YPbPr Cvbs S-Video
Locked ○ ○ ● ○ ○
Un-locked ○ ○ ● ○ ○
4. Composite (CVBS) + L/R Audio:
Composite(CVBS) + L/R Audio
DVI-D DVI-A YPbPr Cvbs S-Video
Locked ○ ○ ○ ● ○
Un-locked ○ ○ ○ ● ○
MicroVision ○ ○ ○ ●(Blinking) ○

5. S-VIDEO + L/R Audio
Composite(CVBS) + L/R Audio
DVI-D DVI-A YPbPr Cvbs S-Video
Locked ○ ○ ○ ○ ●
Un-locked ○ ○ ○ ○ ●
MicroVision ○ ○ ○ ○ ●(Blinking)
6. Audio Select:
DVI-D + L/R Audio
Internal Audio ●
L/R Audio ●

Installation
MULTI2SDI-PRO installation consists of the following:
1. Disconnect +12DC adaptor to converter.
2. Connect Video Source to the Input Connector.
3. Connect Display Equipment to the output’s connector
4. Connect the +12DC adaptor to the converter.
Package Contents
The MULTI2SDI-PRO package contains the following items:
 User Manual x 1
 +12 DC Adapter x 1
 MULTI2SDI-PRO Converter x 1

Specifications
DESCRIPTION MULTI2SDI-PRO
SDI Format SD-SDI, HD-SDI & 3G-SDI
SDI Transion Rate 2.970Gb/s, 10485Gb/s and 270Mb/s
Audio Support
HDMI(DVI-D) : 8-Channel
L/R Audio :
a. only 2 channel and splier to 8 channel (HDMI/SDI
out)
b. Input impedance = 10K.
c. max input level(Vrms) = 10dBV (9V p-p), or 3.16
Vrms.
Re-Sample Clock Auto Resample audio clock to 48Khz
Coaxial Cable Type RG6/RG59(75Ω)
Cable Equalizaon
3G: 100m of RG6/ 86m of RG59
HD: 170m of RG6/ 120m of RG59
SD: 400m of RG6/ 280m of RG59
*1 RG6: CANARE L-5CFB Cable / RG59: Belden 9275 Cable
*2 Cable Length Performance: Depending on SDI Signal and
Cable Quality
Input Source HDMI/VGA/YPbPr/CVBS/S-Video
Output Source 2 X SDI + 1 x HDMI (the same me)
Input Format Support Appendix Table A
Output Format Support Appendix Table A
Firmware Updates Via Mini-USB
Output Connector 2 x BNC [SDI]
1 x HDMI
Input Connector
1 x BNC [SDI]
1 x DVI-I [DVI-D + DVI-A]
3 x BNC [YPbPr or YC + CVBS ]
1 x Phone Jack
BNC Connector 3G 75 Ω inter-locked socket
USB Connector Mini-USB
Dipswitch Output Format/Audio Source/Input Source
Housing SECC

Dimension L:153mm x W:63.3mm xH:26mm
Power Source Power Adapter: AC 100 ~ 240 V/DC (+9 ~ 15 V)
Operaon Temperature 0~50°C [32~114°F]
Storage Temperature -20~+60°C

Firmware Upload
Firmware is upgradable in the field using the integrated USB port
How to Firmware upgrade:
Step 1.
Open Upload Firmware Program tools.exe and connect box to PC by USB
Cable.
Step 2.
Plug and un-plug “DC adapter” to power on/off the converter box (the
connection check status will be changed to “Connect”)

Step 3.
Plug and un-plug “DC adapter” again (the connection check status will be
changed to “Connected”) and Please click the Open File button to select
the firmware bin file.
Step 4.
Please click “Start’ Button to proceed with new firmware programming.
The PASS message will appear when the procedures finished.
Step 5.
Close Upload Firmware Program tools

Appendix Table A
Support Input Format:
720x480i60 720x576i50 720x480 p60 720x576 p50
1280x720p60 1280x720p50 1920x1080i60 1920x1080i50
1920x1080p24 1920x1080p25 1920x1080p30 1920x1080p60
1920x1080p50
640x350p85 640x400p85 720x400p85 640x480p60
640x480p72 640x480p75 640x480p85 800x600p56
800x600p60 800x600p72 800x600p75 800x600p85
848x480p60 1024x768p50 1024x768p59 1024x768p60
1024x768p70 1024x768p75 1024x768p85 1152x864p70
1152x864p75 1280x768pRB 1280x768p60 1280x768p75
1280x768p85 1280x800p60 1280x800p75 1280x800p85
1280x960p60 1280x960p75 1280x960p85 1280x1024p60
1280x1024p75 1280x1024p85 1360x768p60 1366x768p50
1366x768p60 1400x1050p50 1400x1050p59 1400x1050p60
1400x1050p75 1440x900p60 1440x900p75 1440x900p85
1600x1200p50 1600x1200p59 1600x1200p60 1600x1200pRB
1680x1050pRB 1680x1050p60 1920x1200pRB 2048x1052p60
2048x1080p50 2048x1080p59 2048x1080p60
Support Output Format:
HDMI Mode
720x480 i60 720x480 i59.94 720x576 i50
1280x720 p60 1280x720 p59.94 1280x720 p50
1920x1080 i60 1920x1080 i59.94 1920x1080 i50
1920x1080 p60 1920x1080 p59.94 1920x1080 p50
1920x1080 p30 1920x1080 p29.97 1920x1080 p25
1920 x 1080 p24 1920 x 1080 p23.98

Update List
Data Version Command
2014.11.11 V1.0 1. Release
2016.08.22 V1.2 1. Change product picture.
