YUAN High-Tech SDI2FIBER BOX User manual

SDI2FIBER
BOX
User Manual
Ver. 1.2

Content
Feature ..................................................................................3
Front Panel ...........................................................................4
Rear Panel .............................................................................4
Side Panel .............................................................................5
SFP Connector ........................................................................6
Button/LED Indicate ..............................................................7
Installation..........................................................................7
Package Contents ...................................................................8
Specifications ......................................................................9
Firmware Upload................................................................... 10
Update List ......................................................................... 12

Feature
SDI Supports HD formats :
720p50 & 60
1080i50 & 60
1080p24, 25, 30, 50 & 60
SDI Support 525i & 625i SD D1 format
Auto 3G/HD/SD-SDI detection
Cable equalization to ensure signal integrity.
Auto Reclocking at 270Mbps, 1.485Gbps, 2.97Gbps
Firmware is upgradable in the field using the integrated USB
port
The converter is Plug-and-Play
Long transmission capability up to 10Km
Pluggable fiber SFPdesign, LC connector

Front Panel
NO
Component
Function
1
Fiber Output
port
From your Fiber Cable plug into
this port
2
LEDs indicate
The LEDs is indicate Output Format
(SD/HD/3G)
3
Input Source
Select Input Source
4
SDI Output Port
Form your SDI Display Device plug
into this port
Rear Panel
NO
Component
Function
1
SDI Input port
From your SDI Source plug into
these ports
2
Power Jack
The Power adapter plug into here.
1
2
3
4
1
2

Side Panel
NO
Component
Function
1
Usb port
Upgrade firmware
1

SFP Connector
1. TX
XXX-XX-XXXX-T0
It is indicate the trasmitter SFP
2. RX
XXX-XX-XXXX-RO
It is indicate the Reciver SFP
3. SPF Installation Diagram:
TC1331T-10D

Button/LED Indicate
1. Input Source Select.
LED Indicate
Function
●
SDI Un-Locked
●
SDI Locked
2. Input Format LED Indicate
LED Indicate
Function
○○
NO SIGNAL
○●
SD
●○
HD
●●
3G
Installation
SDI2FIBER installation consists of the following:
1. Disconnect +12DC adaptor to converter.
2. Connect Video Source (SDI/Optic Fiber) to the SDI/Fiber
Connector.
3. Connect SDI Equipment or Fiber Cable to the BNCs
connector/LC connector
4. Connect the +12DC adaptor to the converter.

Package Contents
The SDI2FIBER package contains the following items:
User Manual x 1
+12 DC Adapter x 1
SDI2FIBER Converter x 1
SFP( TX and RX ) x 1

Specifications
DESCRIPTION
SDI Format
SD-SDI, HD-SDI & 3G-SDI
SDI Transition Rate
2.970Gb/s, 1.485Gb/s and 270Mb/s
Coaxial Cable Type
RG6/RG59(75Ω)
Cable Equalization
3G: 120m of RG6/ 100m of RG59
HD: 200m of RG6/ 140m of RG59
SD: 400m of RG6/ 280m of RG59
*1 RG6: CANARE L-5CFB Cable / RG59: Belden 9275
Cable
*2 Cable Length Performance: Depending on SDI
Signal and Cable Quality
Firmware Updates
Via Mini-USB
Input
1 x SDI
Output
1 x BNC [SDI]
1 x Fiber
BNC Connector
3G 75 Ω inter-locked socket
LC Connector
--
USB Connector
Mini-USB
Bottom
Input Source
Housing
SECC
Dimension
L:104mm x W:63.3mm xH:26mm
Power Source
Power Adapter: AC 100 ~ 240 V/DC (+6 ~ 15
V)
Operation
Temperature
0~50°C [32~114°F]
Storage Temperature
-20~+60°C

Firmware Upload
Firmware is upgradable in the field using the integrated USB
port
How to Firmware upgrade:
Step 1.
Open Upload Firmware Program tools.exe and connect box
to PC by USB Cable.
Step 2.
Plug and un-plug “DC adapter” to power on/off the
converter box (the connection check status will be changed
to “Connect”)

Step 3.
Plug and un-plug “DC adapter” again (the connection check
status will be changed to “Connected”) and Please click the
Open File button to select the firmware bin file.
Step 4.
Please click “Start’ Button to proceed with new firmware
programming. The PASS message will appear when the
procedures finished.
Step 5.
Close Upload Firmware Program tools

Update List
Data
Version
Command
2013.07.29
V1.0
1. Release
