Yudo TW 600 User manual

HEAD OFFICE & FACTORY
169-4, Gujang-Ri, Paltan-Myun, Hwasung-City, Gyeonggi-Do, 445-915 Korea
Tel : + 82 31 350 2530 (Overseas Sales Team) Fax : + 82 31 354 7446
▶We reserve the right to change specifications without notice.
Ver. 1.5 MN TW 600 (11. Sep)
MODEL : TW 600
User Manual
TW 600
SEQUENCE INJECTION TIMER
www.yudo.com
English

User ManualUser Manual
Contents.
1. Uses ----------------------------------- 3
2. Power Supply -------------------------- 3
3. TW 600 parts name -------------------- 4
4. Function ------------------------------- 5
5. MODE Specification --------------------- 7
6. Sequence system application ----------- 9
7. Connector position and Assembly ------ 10
8. Sequence Timer connecting diagram ---- 11
Thank you for using YUDO product.
Please be noted of this manual to avoid problems
by any misuse, before you use YUDO product.
You can contact YUDO Headquarter or
regional sales office for technical advice.
TW 600
User Manual
TW 600
User Manual
SEQUENCE INJECTION TIMER
TW 600TW 600
SEQUENCE INJECTION TIMER
1 2

User ManualUser Manual User ManualUser Manual
220V 24V
Sig On Sig OFF
T
DELAY OPEN
DELAY OPEN
T1
MODE B
MODE A
1. Uses
2. Power Supply
TW 600TW 600 TW 600TW 600
3. TW 600 Parts name
Blank panel
YUDO Sequence Injection System is to provide a means of controlling the mould
filling sequence when Valve Gate Hot Runner System. The sequence
injection Timer enables the Valve Gates of a Hot-Runner System to
be individually controlled to provide the following benefits.
1) Removal or Positioning of Weld Line
Quality of the Molded part can be improved by removing or
re-positioning of weld lines on visual surfaces, or sections where a
weld line would cause a weakness.
2) Regulation of the Injection Quantity by Gate operation
Injection balance can be adjusted in Family mould application.
3) Improvement on Flash and short-shot
By Gate open control in an orderly manner, it can eliminate Flash
and short-shot problem.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
SEQUENCE INJECTION TIMER SEQUENCE INJECTION TIMER
3 4
Main Power Supply (Timer Case) AC(85~264VAC),50/60 Hz
Injection Signal Input Power DC 24V, AC 110V, AC 220V
Free Voltage
Solenoid Valve output voltage DC 24V, AC110V, AC220V
*AC Solenoid Valve output must be same with AC input power .
Operating temperature 0℃~ 50℃
PCB Structure
① Power board Power PCB
② Relay board Relay (Solenoid Valve on/off)
③ CPU board MPU, out signal Input/Output,
Display, Switch Signal input
④ Front board Solenoid Valve output display
(24V or 220V)
⑤ Mother board DC Main Power distribution and
Connector
DELAY The time until gate is started to be opened
after receiving injection signal.
Mode A, Mode B, Mode C operates in the
same way. ( Basic setting value : 3 sec. )
OPEN The time when gate is being opened.
Counting continues in mode A until injection
signal ends. Gate opens only during setting
time in Mode B and Mode C.
( Basic setting value : 3 sec. )
SIGNAL LED Lamp is turned on, as injection signal is input.
OUT LED Lamp is turned on, as Gate is open.
In manual mode, it operates in the same way.
MODE A LED Lamp is turned on when it is set as A type
( Refer to 5-page, Mode setting )
MODE B LED Lamp is turned on when it is set as B type
( Refer to 5-page, Mode setting )
MODE C LED Lamp is turned on when it is set as B type
( Refer to 5-page, Mode setting )
DELAY SET Key
A key to set gate opening time after injection signal.
("SAVE" is displayed 3 seconds after setting, and
then setting value is saved. If signal is turned on
before "save" display, it operates with the
changed value. If input power is turned off and
then turned on, setting value is not saved).
UP Key
A key to set up tim by pressing DEL or
OPEN SET Key simultaneously .
DOWN Key
A key to turn down time setting by pressing
DEL or OPEN SET key simultaneously.
Manual Output Key
A Key to open Gate manually.
It operates only when the key is being pressed.
OPEN SET Key
A key to set the time when gate is being opened.
This is used by pressing key or key simultaneously.
( Save function is the same as DEL SET key )
Main power switch
Unit take-out Bar
Unit fixing Bolt
Solenoid Valve output power supply display
The Voltage must be same as Solenoid Valve
input Voltage in mold. (AC 220V / DC 24V)
MODE operation Specification
11

User ManualUser Manual User ManualUser Manual
TW 600TW 600 TW 600TW 600
4. Fucntion
1) Main power input - operation
(1) Version and Segment ( from 0 ~ 9 ) counts up by 0.3 seconds
when Power Supply inputs.
(2) LED blinks successively.
(3) The final operation indication appears after a self-inspection.
2) Mode and time setting
(1) Press "Delay + Open" key simultaneously to make setting menu
change during operation.
①"SET" appears in Delay Segment.
②Time unit appears in Open Segment
(2) Press the manual output key to make MODE change.
(Mode A>B>C>A)
(3) Press ▲UP key to make Press Up key to make Time unit change
below decimal point. (0.01> 0.1> 1> 0.01)
(4) ▼Down key is to down the value.
(5) The value is saved if there is no response for 3 seconds.
(6) All Input & Output operation are not available during setting time.
3) Time setting
(1) Delay time setting.
①Press Delay key to make value change,
then use ▲UP and ▼DOWN key.
②To make the first Delay time setting in MODE C,
follow ①instruction during "A" kept in display.
③To make the second Delay time setting in MODE C,
follow ①instruction during "p" kept in display.
④Delay time setting is available all in MODE A, B, C.
⑤The value is saved, unless there is any response for 3 seconds.
⑥Manual operation can be done under Open key input during
the set time.
⑦Continual input is available under UP/DOWN key being pressed.
⑧If saved as 999 sec in 1 sec. setting, 99.9 sec. is displayed
in 0.1 sec. setting. ( 9.99 sec. is displayed in 0.01 sec. setting )
-The saved value is converted by multiple value )
1 Sec setting 0.1 Sec setting 0.01 Sec setting
Setting range 0 - 999 Sec 0 - 99.9 Sec 0 - 9.99 Sec
(2) Open time adjustment
①Press Open key to make value change,
then use ▲UP and ▼DOWN key.
②To make the first Open time setting in MODE C,
follow ①instruction during "A" kept in display.
③To make the second Open time setting in MODE C,
follow ①instruction during "p" kept in display.
④Open time setting is available only in MODE B, C.
(3) How to set Solenoid output Voltage
Disassemble TW600 blank panel under Power supply turn off.
After remove M4 x 5mm bolt, connect blank panel power B/D's
connector to jumper cable that needed(J8(DC24V Hydraulic),
J3(DC24V Pneumatic), J1(AC110V, AC220V)).
(Factory setting : AC220V)
* Output Voltage must be same with Solenoid Valve Input Voltage in mold.
( Unless, it causes malfunction in operation)
*Note : Sequence timer controller Unit card is interchangeable without regard
for Pneumatic or Hydraulic, but the Controller case has to be fit in
according to a type.
SEQUENCE INJECTION TIMER SEQUENCE INJECTION TIMER
5 6
*AC 110V
or
AC 220V
(Hydraulic /
Pneumatic)
*DC 24V
(Hydraulic)
*DC 24V
(Pneumatic)
>
>

User ManualUser Manual User ManualUser Manual
TW 600TW 600 TW 600TW 600
SEQUENCE INJECTION TIMER SEQUENCE INJECTION TIMER
7 8
5. MODE Operation
t1 : Delay Time
T t1 t2
Gate Open
3 Sec 10 Sec
Signal On Signal Off
t1 : Delay Time / t2 : Open Time
T t1 t2
Gate Open
3 Sec 10 Sec
Signal On Signal Off
T t1 t2 t3 t4
Gate Open Gate Open
3 Sec 7 Sec 12 Sec 18 Sec 20 Sec
Signal On Signal Off
t1 : First Delay Time t2 : First Open Time
t3 : Second Delay Time t4 : Second Open Time
t1 : Delay Time / t2 : Open Time
T t1 t2
Gate Open
3 Sec 10 Sec 12 Sec
Signal On Signal Off
t1 : Delay Time / t2 : Open Time
T t1 t2
Gate Open
3 Sec 10 Sec 12 Sec
Signal On
Signal Off Signal Off
(Machine) (Timer)
YUDO Sequence Timer( TW 600 ) has 3 types of MODE.
The user can adjust Gate open/close/delay time for the optimal injection
application in a convenient way.
1) MODE A
Selection Mode A - After the injection signal has been received,
the gate remains closed during the DEL time. After the Del time
has elapsed, the gate Opens and remains open until the end of the
injection signal.
Ex1 ) Injection time : 10 seconds DEL Time ( T1) : 3 second setting
Operation : Gate opens 3 seconds after receiving the injection signal,
and remains open for 7 seconds, and then closes.
2) MODE B
Selecting Mode B - After the injection signal has been received,
the gate remains Closed during the Del time.
After the Del time has elapsed, the gate Opens for the Open time setting
After the Open time has elapsed, the gate closes and remains closed.
Ex1 ) Injection time : 10 seconds / DEL Time : 3 second setting
/ Open time : 4 second setting
Operation : Gate opens 3 seconds after receiving the injection signal,
and remains in the open condition for 4 seconds,
and then closes.
Ex2) Injection time : 10 seconds. / Del Time : 3 seconds
/ Open time : 9 seconds.
Operation : After 3 seconds delay, the Gate opens 7 seconds after
receiving the injection signal, and then closes.
*Note : The gate closes as soon as the injection signal ends,
regardless of Open time setting Value.
3) MODE C
In MODE C, Users can carry out MODE B operation twice successively.
Ex1 ) Injection time : 20 seconds.
The first Del. time : 3 seconds / The first Open time : 4 seconds
The second Del. Time : 5 seconds / The second Open time : 6 seconds
Operation : After 3 sec. delay, the Gate opens for 4 seconds.
Successively after 5 sec. close, the Gate opens for 6 seconds.
4) Injection signal extension function
Generally a valve Gate closes, when injection signal ends. But in some cases,
the valve Gate should be kept open even though the injection signal ends.
Users can actualize this operation by setting MODE B with (-) open time.
Then the Timer controller itself keeps the injection signal in an open condition.
This function is specially used for controlling Extension Nozzle in Stack-mold
which
needs to make a Gate close after HRS inner channel pressure becomes
reduced enough.
Ex1 ) injection time : 10 sec. / Delay time : 3 sec. / Open time : (-) 2 sec.
Operation : Gate opens 3 seconds after receiving the injection signal,
and still remains in the open condition for 2 seconds after
injection signal ends.

User ManualUser Manual User ManualUser Manual
TW 600TW 600 TW 600TW 600
Gate 1 Gate 2
Shot Short
Gate 1 Gate 2
Gate 2
Gate 3 Gate 5
Gate 1
Gate 4
7. Connector position and Assembly
1) Connector is installed to Solenoid Block Assembly in mold.
2) Connector Assembly
Connector Pin No
1, 2
3, 4
5, 6
7, 8
9, 10
11, 12
13, 14
15, 16
Sol Valve No
No. 1
No. 2
No. 3
No. 4
No. 5
No. 6
No. 7
No. 8
HAN 16A (250V 16A)
Mold : Male Insert
(09 20 016 2612 )
Cable : Female Insert
(09 20 016 2812 )
Connector 사양
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
6. Sequence system application
SEQUENCE INJECTION TIMER SEQUENCE INJECTION TIMER
9 10
Gate 1
Gate 3
Gate 2
Gate 4
Gate 5
1) MODE A application
(1) In case of short shot on product
Open Gate 1 first to enlarge filling area, then Open Gate 2 later to fill up well.
(2) To inject products which have a big dimensional difference per cavity,
open G1 first to fill up the big size and then open G2 later to make
the balance. It can optimize the injection precision.
2) MODE B application
(1) To inject complicated products which have a big dimensional difference,
apply MODE 1 for Gate 1~4, and MODE B only for Gate 5. It is used to
fill up the very small sized dimension just before the injection ends.
3) MODE C application
(1) It is used to apply 'one and after' injection signal control.
Opening the gates first which could have fill-up Unbalance if Users
open the all gates at the same time, and then close the gates keeping
time with fill up. It is designed to avoid the excessive filling pressure.
Although this is also possible in MODE B operation, the function to
keep up the holding pressure in channel by opening the Gate (The Timer
controller itself keeps the injection signal in an open condition )
is possible only in MODE C. MODE C is a new type of output pattern
which is able to optimize the various sequence controls to match the
product feature and injection peculiarity.

User ManualUser Manual User ManualUser Manual
TW 600TW 600
M E M OM E M O
TW 600TW 600
8. Sequence Timer Connection
Signal
Solenoid Valve control
SEQUENCE INJECTION TIMER SEQUENCE INJECTION TIMER
11 12

Global NetworkGlobal Network
SEQUENCE INJECTION TIMER SEQUENCE INJECTION TIMER
13 14
PERU
KOREA
TAIWAN
THAILAND
INDIA
SOUTH AFRICA
IRAN
EGYPT
ISRAEL
SYRIA
TURKEY
PORTUGAL SPAIN
ITALY ROMANIA
POLAND
FINLAND
FRANCE
U.K
NETHERLANDS GERMANY
VIETNAM
CHINA
NEW ZEALAND
AUSTRALIA
INDONESIA
SINGAPORE
MALAYSIA
JAPAN
USA
BRAZIL
SLOVAKIA
CZECH
ARGENTINA
CHILE
COLOMBIA
MEXICO
RUSSIA
Headquarters
Plant
Subsidiary
Sales Office
Agency
BANGLADESH
PHILIPPINES
AMERICA & EUROPE & AFRICAASIA & OCEANIA
VIETNAM
HOA VAN HOA COMPANY LTD.
-Hanoi office
Tel : + 84 43 78 77 179
-Hochiminh office
Tel : + 84 938 36 23 77
JAPAN
YUDO JAPAN CO., LTD.
Tel : + 81 3 5714 4801
-Kyushu Office
Tel : + 81 92 473 4808
-Nagoya Office
Tel : + 81 52 745 0361
INDIA
YUDO HOT RUNNER INDIA PVT. LTD.
Tel : + 91 250 3200922
-Delhi Branch Office
Tel : +91 120 454 9076
-Pune Branch Office
Tel : +91 7798884634
-Chennai Branch Office
Tel : +91 8939625089
CHINA
YUDO TRADING CO., LTD.
Tel : + 86 769 8539 4466
YUDO
(HONG KONG) ENTERPRISE CO. LTD.
Tel : + 852 2344 5180
YUDO TIANJIN OFFICE
Tel : + 86 22 5839 9351
YUDO (SUZHOU) H.R.S. CO. LTD
Tel : + 86 512 6504 8882
YUDO (SHANGHAI) OFFICE
Tel : + 86 21 5138 6422
YUDO (NINGBO) OFFICE
Tel : + 86 574 8711 3033
YUDO (QINGDAO) TRADING CO. LTD.
Tel : + 86 532 8765 1698
YUDO (QINGDAO) TRADING CO., LTD
(WEIHAI) OFFICE
Tel : + 86 631 5672 582
YUDO (QINGDAO) TRADING CO., LTD
(DAILIAN) OFFICE
Tel : + 86 131 3002 3765
KUNSHAN YUDO-SUNS CO LTD.
Tel : + 86 512 5791 0286
BANGLADESH
YUDO (BD) PVT. LTD.
Tel : + 88 02 9014 632
e-mail: [email protected]
TAIWAN
YUDO CO., LTD. (TAIWAN BRANCH)
Tel : + 886 2 2205 6677
SINGAPORE
YUDO WANCO PTE. LTD.
Tel : + 65 6264 1166
PHILIPPINES
YUDO WANCO PHILIPPINES INC
Tel : + 63 949 307 1950
THAILAND
YUDO WANCO (THAILAND) CO., LTD.
Tel : +66 2 174 7236~40
MALAYSIA
MAWANCO SDN BHD. KL office
Tel : + 60 3 8945 2127
MAWANCO SDN BHD. JB office
Tel : + 60 7 8635 704
INDONESIA
PT.YUDO INDONESIA
Tel : + 62 21 29083283
PT GAYA STEEL
Tel : + 62 21 89832277
AUSTRALIA
STM AUSTRALIA PTY. LTD.
Tel : + 61 3 9805 9510
NEW ZEALAND
STM SALES LTD.
Tel : + 64 9 8206454
SYRIA
SAWAS TRADING GROUP
Tel : + 963 21 2254756
ISRAEL
ASI-AFASPEM ISRAEL LTD.
Tel : + 972 4 6802770
IRAN
YUDO IRAN
Tel : + 98 21 22066506~7
U.S.A.
YUDO INC. (Head Office)
Tel : + 1 614 873 1300
-Western Territory (Sales Office)
Tel : + 1 805 480 4922
-Central Territory (Sales Office)
Tel : + 1 630 529 7487
-Mid-Western Territory (Sales Office)
Tel : + 1 440 834 0167
-Southern Region & Peta Business (Sales Office)
Tel : + 1 214 774 4556
U.K.
YUDO (UK) LTD.
Tel : + 44 1989 763423
CZECH
YUDO CZ
Tel : + 420 724 358 612
RUSSIA
OOO YUDIX
Tel : +7 495 723 5221
PORTUGAL
YUDO EU SA.
Tel : + 351 244 570 390
FRANCE
YUDO FRANCE
Tel : + 33 2 3277 4200
SPAIN
YUDO IBERICA S.L.
Tel : + 34 93 715 81 22
ROMANIA
ROMOULD YUDO ROMANIA
Tel : + 40 213 272 115
TURKEY
YUDO TURKEY
Tel : + 90 212 320 95 63
ITALY
YUDO ITALY SH
Tel : + 39 2 99 551 78
e-mail: [email protected]
PERU
TOTALMATRIX S.A.C.
Tel : + 51 1 447 1652
CHILE
TOTALMATRIX E.I.R.L
Tel : + 56 2 671 8439
MEXICO
YUDO MEXICO S.A de C.V.
Tel : + 52 1 442 285 7120
ARGENTINA
Modular Mold Normalizados S.A.
Tel : + 54 11 4756 7272
EGYPT
C&C CORPORATION
Tel : + 20 2 2516 7926
REPUBLIC OF SOUTH AFRICA
HESTICO PTY. LTD.
Tel : + 27 11 786 5228
GERMANY
YUDO GERMANY GmbH.
Tel : + 49 711 707 30370
NETHERLANDS
YUDO BENELUX
Tel : + 31 (0)13 5705252
SLOVAKIA
YUDO SLOVAKIA s.r.o.
Tel : + 421 335 333 363
POLAND
EUROTECH HOLDING Sp. z o.o.
Tel : + 48 22 843 05 79
FINLAND
YUDO Nordic Oy
Tel : + 358 3 616 1847
BRAZIL
SOLUTION BASE
Tel : + 55 47 3435 0022
PAULO ENGENHARIA LTDA.
Tel : + 55 11 3392 5775
Table of contents
Other Yudo Timer manuals
