Yudor YUC-H6A6R User manual

1
INDOOR BOX IP CAMERA
V3.2.1R_1608
User Manual

2
This is a 1/2.8” Sony Starvis CMOS Sensor IP camera with a built-in web
server. The user can view real-time video via IE browser. It supports H.264,
and M-JPEG video compression which provides smooth and high video
quality. The video can be stored in the Micro SD card and playback
remotely.
With a user friendly interface, it is an easy-to-use IP camera for security
applications.
i. Warnings, Cautions and Copyright ........................................................3
ii. Product Specifications.............................................................................4
iii. Product Installation.................................................................................7
* Monitor Settings ...................................................................................7
* Hardware Installation .........................................................................8
* IP assignment.....................................................................................10
* Install ActiveX control…………….....................................................14
iv. Live Video.................................................................................................21
v. Camera Configuration ............................................................................24
* System ..............................................................................................24
* Network ............................................................................................30
* A / V Settings ...................................................................................43
* Event List ...........................................................................................53
vi. Network Configuration ….......................................................................65
vii. I / O Configuration .................................................................................67
viii. Factory Default ......................................................................................70
ix. Universal Password .................................................................................71
x. Package Contents ..................................................................................74
xi. SD Card Compatibility (Optional) .........................................................75
INDOOR BOX IP CAMERA

3
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS PRODUCT TO RAIN OR MISTURE.
DO NOT INSERT ANY METALLIC OBJECT THROUGH VENTILATION
GRILLS.
CAUTION
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION：TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
COPYRIGHT
THE TRADEMARKS MENTIONED IN THE MANUAL ARE LEGALLY
REGISTERED TO THEIR RESPECTIVE COMPANIES.
i. Warnings, Cautions and Copyright

4
Main Features:
High Frame Rate of 60 Frames Per Second (fps)
Scene Analytics Enhanced by Unique Features Such as Face
Detection
H.264 (High/Main/Baseline Profile)/ M-JPEG Video Codec
Supports WDR Enhancement in Extremely Bright and Dark
Environments
Support Intelligent Functions
3D+2D Digital Noise Reduction
Manually Day&Night Switch Time Control
Mechanism IR Cut Filter Available
Power over Ethernet Available
Video Output
SD Card Backup(option)
Support iPhone/iPad/Android
Triple Streaming
SDK for Software Integration
Free Bundle 36 ch Recording Software
Hardware
CPU
Multimedia SoC
RAM
256MB
Flash
512MB
Image sensor
1/2.8" SONY Starvis CMOS sensor IMX291
Sensitivity
Color: 0.001 Lux (AGC ON)
B / W: 0.0005 Lux (AGC ON)
ii. Product Specifications

5
Lens Type
Changeable, CS Mount
Support DC IRIS
Yes
ICR
Mechanism IR cut-filter
Audio
G.711(64K) and G.726(32K,24K) audio
compression
Input : Audio in or Mic built-in(Auto switch)
Output: 3.5mm phone jack, Support 2-way.
I/O
1 DI/ 1DO
RS-485
Yes
Video Output
Yes
Power over Ethernet
Yes
Power Consumption
DC 12V Max：3.96W
AC 24V Max：4.8W
PoE Max：4.75W
Operating Temperature
0°C ~ 45°C
Dimensions
65mm (W) x 58mm (H) x 132mm (L)
Weight
450g
Network
Ethernet
10/ 100 Base-T
Network Protocol
IPv6, IPv4, HTTP, HTTPS, SNMP, QoS/DSCP,
Access list, IEEE 802.1X, RTSP, TCP/ IP, UDP,
SMTP, FTP, PPPoE, DHCP, DDNS, NTP, UPnP,
3GPP, SAMBA, Bonjour
Wireless (Optional)
Wireless: 802.11b/g/n
Security: WEP,WPA-PSK,WPA2-PSK
System
Video Resolution
1920x1080@60fps, 1280x720@60fps,
640x480@60fps, 320x240@60fps,
176x144@60fps
Video Adjust
Brightness, Contrast, Hue, Saturation, Sharpness,
AGC, Night Mode, WDR, Flip, Mirror, Noise
reduction, Day & Night adjustable, White Balance
Triple Streaming
Yes

6
Image Snapshot
Yes
Full Screen Monitoring
Yes
Privacy Mask
Yes, 3 different areas
Compression Format
H.264/ M-JPEG
Video Bitrates Adjust
CBR, VBR
Motion Detection
Yes, 3 different areas
Triggered Action
Mail, FTP, Save to SD card, DO, SAMBA
Pre/ Post Alarm
Yes, configurable
Security
Password protection, IP address filtering, HTTPS
encrypted data transmission, 802.1X port-based
authentication for network protection
Firmware Upgrade
HTTP mode, can be upgraded remotely
Simultaneous
Connection
Up to 10
Micro SD card management
Recording Trigger
Motion Detection, IP check, Network break down
(wire only),Schedule, DI
Video Format
AVI, JPEG
Video Playback
Yes
Delete Files
Yes
Web browsing requirement
OS
Windows 7, 2000, XP, 2003, Microsoft IE 6.0 or
above, Chrome, Safari, Firefox
Mobile support
iOS 4.3 or above,Android 1.6 or above
Hardware Suggested
Intel Dual Core 2.53G,RAM: 1024MB, Graphic card:
128MB
*SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTIFICATION.

7
* Monitor Settings
1. Right-Click on the desktop. Select Properties
2. Change color quality to highest (32bit).
iii. Product Installation

8
* Hardware Installation
1. Connector Instruction
Plug in the DC adapter power, or use the 2P terminal block to
connect with AC power, or use POE. Connect the IP Camera to
your PC or network, and set up the network configurations
according to the network environment.
With 3G Dongle
Without 3G Dongle

9
2. PoE ( Power Over Ethernet)(Optional) 802.3af, 15.4W PoE Switch is
recommended
Power over Ethernet (PoE) is a technology that integrates power
into a standard LAN infrastructure. It enables power to be
provided to a network device, such as an IP phone or a network
camera, using the same cable as that used for network
connection. It eliminates the need for power outlets at the camera
locations and enables easier application of uninterruptible power
supplies (UPS) to ensure 24 hours a day, 7 days a week
operation.

10
*IP assignment
1. Open the software IP Scanner to assign the IP address of the IP Camera.
Find this software in the Applications folder in the software CD attached
to the product’s package.
2. IP Scanner supports two languages: This manual is for English version.
3. There are 3 kinds of IP configuration.
a. Fixed IP (Public IP or Virtual IP)
b. DHCP (Dynamic IP)
c. Dial-up (PPPoE)
4. Execute IP Scanner.
5. For Windows XP SP2 or above, a Windows Security Alert may pop up.
Choose the network type based on your surveillance environment, and
click on Unblock.

11
6. IP Scanner configuration:
7. IP Scanner will search for all the IP Cameras connected on the LAN. The
user can click Search Device to search again.
8. Click one of the IP Cameras listed on the left side. The network
configuration of this IP camera will be shown on the right side once you
highlight the device with your mouse. You can change the name of the IP
Camera to your preference (e.g.: Office, warehouse). Change the
parameters and click Submit, then click OK, it will apply the changes and
reboot the device.
9. Please make sure the subnet of the PC IP address and the IP Camera IP
address are the same.
The same Subnet:
IP Camera IP address: 192.168.1.200
PC IP address: 192.168.1.100

12
Different Subnets:
IP Camera IP address: 192.168.2.200
PC IP address: 192.168.1.100
To Change the PC IP address:
Control PanelNetwork ConnectionsLocal Area Connection
PropertiesInternet Protocol (TCP/IP) Properties
Make sure your IP Camera and PC are in the same Subnet. If not,
change the IP Camera subnet or the PC IP subnet accordingly below.
10. To quickly access remote monitoring, left-click the mouse twice on the
selected IP Camera listed under Device list of IP Scanner. A default
network browser of the camera control interface will open.

13
11. Enter admin for both Username and Password to gain access.

14
*Install ActiveX control
1. For users of IE 6.0 or above:
When viewing the camera video for the first time via IE, the browser will ask
you to install the ActiveX component.
Choose ‘Allow’,
Then choose ‘Install’.
Start installing the ActiveX component.
If the installation fails, please check the security settings in the IE
browser.
Go to Start-Up Menu on the lower left corner of the Windows,
select Control Panel then Double-click on
to access to Internet Properties settings.

15
Starting from Internet Properties, proceeding step Aand B:
A. Security Custom Level Security Settings Download
unsigned ActiveX controls Enable or Prompt (recommended).
B. Security Custom Level Security Settings Initialize and
script ActiveX controls not marked as safe Enable or Prompt
(recommended).
1
2
3
4

16
5
When popup the following dialogue box, click Yes.
2. You can choose another way:
Go to: IE→Tools → Internet Options… → Security Tab → Trusted sites → Add the
IP address and click OK.
In the site list you can key one single IP address or a LAN address. For example,
if you add 192.168.21.*, all the IP address under 21.* on the LAN will be regarded
as trusted sites.

17
2. To Non-IE Web Browser Users
If you use Firefox or Google chrome to access the IP camera but fails to watch
the live video, please follow the steps to install necessary tools:
(The following pictures are based on chrome.)
a. You may see the prompt message as the picture below. Click the link:
Firstly, please install Microsoft Visual C++ 2010 Redistributable Package
(x86).
The link will conduct you to the Microsoft official site where you can download
the tools. Please select the language and click download.

18
In the pop-up window, please tick the first and the third file as the picture below.
Click Next to download both Microsoft .NET Framework 4 Client Profile (Web
Installer) and Microsoft Visual C++ 2010 Redistributable Package (x64).
After finishing downloading, execute the two files respectively to install them.
The windows may ask you to reboot the PC when the installation is finished.
b. Then, click the second link Please click here to download the installation
program which does not support IE browser to download Setup ActiveX.

19
After finishing downloading, execute the files to install ActiveX. Then restart the
browser.
c. If you execute the steps above but still cannot see live video normally, please
try the following solution:
Search for the file np_hoem_x.dll in your system disk. For Windows XP users,
please go to Start → Search → Search for All files and folders and key-in
np_hoem_x.dll. For Windows 7 users, please use the search bar on the
top-right of the Windows Explorer.
Delete all the files named np_hoem_x.dll. They're the ActiveX control tools
installed in your computer, but the old version of ActiveX might not be
compatible with the new version of the browser. Therefore, they need to be
deleted in order to install the latest ActiveX control.

20
Start your web browser, and repeat the step 2-b: Download the installation
program which does not support IE browser to download and install
ActiveX.
