Yudor YUC-H7988M User manual

1/91
User Manual
Bullet
IP CAMERA

2/91
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
PRODUCT TO RAIN OR MISTURE.
DO NOT INSERT ANY METALLIC OBJECT THROUGH VENTILATION GRILLS.
CAUTION
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION：TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
COPYRIGHT
THE TRADEMARKS MENTIONED IN THE MANUAL ARE LEGALLY REGISTERED
TO THEIR RESPECTIVE COMPANIES.

3/91
Content
I. PREFACE ............................................................................................................4
II. PRODUCT SPECIFICATIONS.............................................................................4
III. PRODUCT INSTALLATION.................................................................................8
A. MONITOR SETTING ..................................................................................................................8
B. HARDWARE INSTALLATION ......................................................................................................9
C. IPASSIGNMENT .....................................................................................................................14
D. INSTALLACTIVEXCONTROL: ................................................................................................18
IV. LIVE VIDEO.......................................................................................................24
V. IP CAMERA CONFIGURATION ........................................................................28
A. SYSTEM .................................................................................................................................29
B. NETWORK..............................................................................................................................34
C. A/VSETTING.........................................................................................................................46
D. EVENT LIST ...........................................................................................................................53
VI. NETWORK CONFIGURATION..........................................................................63
VII. I/O CONFIGURATION .......................................................................................65
VIII. FACTORY DEFAULT.........................................................................................69
IX.UNIVERSAL PASSWORD.................................................................................70
X. PACKAGE CONTENTS.....................................................................................73
XI. MICRO SD CARD COMPATIBILITY..................................................................74
V1.1_20131030

4/91
I. Preface
This is a 1 / 3” Sony Exview, CCD sensor, Outdoor IP camera with a built-in web
server. The user can view real-time video via IE browser. It supports H.264 and
M-JPEG video compression which provides smooth and high video quality. The
video can be stored in the Micro SD card and playback remotely.
With a user friendly interface, it is an easy-to-use IP Camera designed for security
applications.
II.Product Specifications
5 Megapixel IR Bullet IP Camera
3D+2D Digital Noise Reduction
Support Digital Wide Dynamic Range
Power over Ethernet Available
IR LED Built in 25M Available
Smart Focus System for Remote Focus Adjustment
Mechanism IR Cut Filter Available
H.264/ M-JPEG/ MPEG4 Compression
Micro SD Card Backup(Optional)
Video Output
IP66
3-Axis Bracket Management
Support iPhone/iPad/Android
SDK for Software Integration
Free Bundle 36 Ch Recording Software

5/91
Specifications
*SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTIFICATION.
Hardware
CPU
Multimedia SoC
RAM
512MB
Flash
16MB
Image Sensor
1/3.2” Megapixel CMOS Sensor
Sensitivity
Color: 0.5 Lux (AGC ON)
B / W: 0.1 Lux (AGC ON)
Lens Type
2.8-12mm 4.2X Bulid-in Zoom Lens @ F1.4
ViewAngle
34.72°~ 75.59°(H)
26.18°~ 55.24°(V)
ICR
Mechanism IR cut Filter
LED
Built-in 35 IR LED
IR Distance 25M
I/O
1 DI/ 1 DO
Video Output
Yes
Audio
G.711(64K) and G.726(32K,24K) audio
compression
Input : 3.5mm phone jack
Output: 3.5mm phone jack, Support 2-way.
Power over Ethernet
Yes
Power Consumption
DC 12V Max: 6 W(IR ON); 3.84 W(IR OFF)
PoE Max: 802.3af, 7.2 W (IR ON); 5.28 W(IR
OFF)
Operation
Temperature
-10 ℃~ 50℃
Dimensions
83mm () x 180mm (H)
Weight
1350g

6/91
Network
Ethernet
10/ 100 Base-T
Network Protocol
IPv6, IPv4, HTTP, HTTPS, SNMP, QoS/DSCP,
Access list, IEEE 802.1X, RTSP, TCP/ IP, UDP,
SMTP, FTP, PPPoE, DHCP, DDNS, NTP, UPnP,
3GPP, SAMBA, Bonjour
Wireless (Optional)
Wireless
802.11b/g/n
Security
WEP,WPA-PSK,WPA2-PSK
Power Consumption
DC 12V Max: 6.72 W(IR ON); 4.44 W(IR OFF)
System
Video Resolution
2592x1944@15fps, 2048x1536@15fps,
1920x1080@30fps, 1280x720@30fps,
640x480@30fps, 320x240@30fps,
176x144@30fps
Video Adjust
Brightness, Contrast, Hue, Saturation,
Sharpness, Shutter Speed Adjustable, AGC,
Sense-Up, D-WDR, Flip, Mirror, Noise
Reduction, Day&Night Adjustable, White
Balance
Triple Streaming
Yes
Image Snapshot
Yes
Full Screen Monitoring
Yes
Privacy Mask
Yes, 3 different areas
Compression Format
H.264/ M-JPEG/ MPEG4(3GPP only)
Video Bitrates Adjust
CBR, CVBR
Motion Detection
Yes, 3 different areas
Triggered Action
Mail, FTP, Save to SD card, DO, Samba
Pre/ Post Alarm
Yes, configurable
Security
Password protection, IP address filtering,
HTTPS encrypted data transmission, 802.1X
port-based authentication for network protection
Firmware Upgrade
HTTP mode, can be upgraded remotely

7/91
Simultaneous
Connection
Up to 10
SD Card Management (Optional)
Recording Trigger
Motion Detection, IP check, Network break down
(wire only), Schedule, DI
Video Format
AVI, JPEG
Video Playback
Yes
Delete Files
Yes
Client System Requirement
OS
Windows 7, 2000, XP, 2003, Microsoft IE 6.0 or
above, Chrome, Safari, Firefox
Mobile Support
iOS 4.3 or above,Android 1.6 or above.
Hardware Suggested
Intel Dual Core 2.8G,RAM: 4GB

8/91
III. Product Installation
A. Monitor Setting
i. Right-Click on the desktop. Select “ Properties”
ii. Change color quality to highest (32bit).

9/91
B. Hardware Installation
1. Connector Instruction
The Cable and connectors are as below. Connect power adaptor first, then
connect the IP Camera to PC or network, and set up the network
configurations according to the network environment.

10/91
2. 3-Axis Bracket
Use the 3-Axis bracket to adjust the camera to appropriate angle, then turn and
tighten the screw to fix it.
3. Adjust ZOOM and FOCUS
Adjust the “ZOOM” first and then “FOCUS” as following picture to complete
the adjustment.

11/91
4. Wireless Antenna (Optional)
Screw the Wireless Antenna into the IP Camera as shown in the following
procedures.
a. Plug the Antenna into the connector while holding the Antenna bar.
b. Turn the lock nut to the right until it is totally locked. Do not bend or try to
straight the antenna bar.

12/91
5. PoE (Power Over Ethernet)(Optional) 802.3af, 15.4W PoE Switch is recommended
Power over Ethernet (PoE) is a technology that integrates power into a standard
LAN infrastructure. It enables power to be provided to a network device,
such as an IP phone or a network camera, using the same cable as that
used for network connection. It eliminates the need for power outlets at the
camera locations and enables easier application of uninterruptible power
supplies (UPS) to ensure 24 hours a day, 7 days a week operation.

13/91
C. IP Assignment
i. Use the software, “IP Scanner” to assign the IP address of IP CAMERA.
The software is in the attached software CD.
ii. IP Scanner supports only language:
a. IP Scanner.exe：English version
iii. There are 3 kinds of IP configuration.
a. Fixed IP (Public IP or Virtual IP)
b. DHCP (Dynamic IP)
c. Dial-up (PPPoE)
iv. Execute IP Scanner
v. For Windows XP SP2 user, it may popup the following message box.
Please click “Unblock”.

14/91
vi. IP Scanner configuration:
vii. IP Scanner will search all IP Cameras connected on LAN. The user can
click “Search Device” to search again.
viii. Click one of the IP Camera listed on the left side. The network
configuration of this IP camera will show on the right side. You may
change the “name” of the IP Camera to your preference (e.g.: Office,
warehouse). Change the parameter and click “Submit” then click “OK”. It
will apply the change and reboot the Device.

15/91
ix. Please make sure the subnet of PC IP address and IP CAM IP address
are the same.
The same Subnet:
IP CAM IP address: 192.168.1.200
PC IP address: 192.168.1.100
Different Subnets:
IP CAM IP address: 192.168.2.200
PC IP address: 192.168.1.100
To Change the PC IP address:
Control PanelNetwork ConnectionsLocal Area Connection
PropertiesInternet Protocol (TCP/IP) Properties
Make sure your IP Camera and PC have the same Subnet. If not, change the
IP Camera subnet or PC IP subnet accordingly.

16/91
x. A quick way to access remote monitoring is to left-click the mouse twice
on a selected IP Camera listed on “Device list” of the IP Scanner. An IE
browser will be opened.
xi. Then, please key-in the default “user name: admin” and “password:
admin”.

17/91
D.Install ActiveX control:
1. For users of IE 6.0 or above:
When viewing the camera video for the first time via IE, the browser will ask you to
install the ActiveX component.
Choose ‘Allow’,
Then choose ‘Install’.
Start installing the ActiveX component.
If the installation fails, please check the security settings in the IE browser.
Go to Start-Up Menu on the lower left corner of the Windows, select Control
Panel then Double-click on to access to
Internet Properties settings.

18/91
Starting from Internet Properties, proceeding step Aand B:
A. Security Custom Level Security Settings Download unsigned
ActiveX controls Enable or Prompt (recommended).
B. Security Custom Level Security Settings Initialize and script
ActiveX controls not marked as safe Enable or Prompt
(recommended).
1
2
3
4

19/91
5
When pops up the following dialogue box, click “Yes”.
2. You can choose another way:
Go to: IE→Tools → Internet Options… → Security Tab → Trusted sites → Add the
IP address and click OK.
In the site list you can key one single IP address or a LAN address. For example,
if you add 192.168.21.*, all the IP address under 21.* on the LAN will be
regarded as trusted sites.

20/91
2. Use Non-IE Web Browser
If you use Firefox or Google chrome to access the IP camera but fail to watch
the live video, please follow the steps to install necessary tools:
(The following pictures are based on chrome.)
a. You may see the prompt message as the picture below. First, click the link:
"Firstly, please install Microsoft Visual C++ 2010 Redistributable Package
(x86)."
(i) The link conducts you to the Microsoft official site where you can download
the tools. Please select the language and click "download".
(ii) In the
