Yudor YUC-HiA6R User manual

1
OUTDOOR DOME IP CAMERA
V2.2.1R_1608
User Manual

2
This is a 1/2.8 " SONY Starvis CMOS sensor Outdoor IP camera with a
built-in web server. The user can view real-time video via IE browser. It
supports H.264, M-JPEG and MPEG4 video compression which provides
smooth and high video quality. The video can be stored in the Micro SD
card and playback remotely.
With a user friendly interface, it is an easy-to-use IP camera for security
applications.
i. Warnings, Cautions and Copyright ...........................................................3
ii. Product Specifications...............................................................................4
iii. Product Installation....................................................................................7
* Monitor Settings ........................................................................................7
* Hardware Installation ...............................................................................8
* IP assignment...........................................................................................12
* Install ActiveX control……………...........................................................16
iv. Live Video.................................................................................................23
v. Camera Configuration ............................................................................26
* System .....................................................................................................26
* Network ...................................................................................................31
* A/V Settings ............................................................................................54
* Event List ..................................................................................................63
vi. Network Configuration ….......................................................................74
vii. I/O Configuration ...................................................................................76
viii. Factory Default ......................................................................................80
ix. Universal Password .................................................................................81
x. Package Contents ..................................................................................84
xi. Micro SD Card Compatibility (Optional) ..............................................85
OUTDOOR DOME IP CAMERA

3
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS PRODUCT TO RAIN OR MISTURE.
DO NOT INSERT ANY METALLIC OBJECT THROUGH VENTILATION
GRILLS.
CAUTION
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION：TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
COPYRIGHT
THE TRADEMARKS MENTIONED IN THE MANUAL ARE LEGALLY
REGISTERED TO THEIR RESPECTIVE COMPANIES.
i. Warnings, Cautions and Copyright

4
Main Features:
Maximum Resolution of 1920 x 1080 Pixels with the SONY Starvis CMOS
Sensor
High Frame Rate of 60 Frames Per Second (fps)
Scene Analytics Enhanced by Unique Features Such as Face Detection
H.264 (High/Main/Baseline Profile)/ M-JPEG Video Codec
Supports WDR Enhancement in Extremely Bright and Dark Environments
Support Intelligent Functions
Superior low light performance
3D+2D Digital Noise Reduction
Day & Night Switch Time Control Manually
IR LED Built in 20M Available
Power over Ethernet Available
Video Output
H.264/ M-JPEG Compression
IK10
IP66
Micro SD Card Backup(option)
Support iPhone/iPad/Android
Triple Streaming
SDK for Software Integration
Free Bundle 36 ch Recording Software
Hardware
CPU
Multimedia SoC
RAM
256MB
Flash
512MB
Image sensor
1/2.8 " SONY Starvis CMOS sensor IMX291
Lens Type
Vari-focus Lens 2.8~12mm @ F1.4
ii. Product Specifications

5
Angle of View
35.25 ~ 101.52°(H)
20.37 ~ 53.13°(V)
Sensitivity
Color : 0.001 Lux (AGC ON)
B / W: 0.0005 Lux (AGC ON)
ICR
Mechanism IR cut Filter
I/O
1 DI/ 1 DO
Video output
Yes
Audio
G.711(64K) and G.726(32K,24K)
Input : External Mic in
Output: External Line out, Support 2-way
Power over Ethernet
Yes
Power consumption
DC 12V Max: 5.28W(IR On), 3.84W(IR Off)
PoE Max: 802.3af, 6.72W(IR On), 5.28W(IR Off)
Operating Temperature
-10°C ~ 50 ° C
Dimensions
137mm () x 102mm (H)
Weight
890 g
IR LEDs
LEDs
18 units
IR distance
20 Meters
Network
Ethernet
10/ 100 Base-T
Network Protocol
IPv6, IPv4, HTTP, HTTPS, SNMP, QoS/DSCP,
Access list, IEEE 802.1X, RTSP, TCP/ IP, UDP,
SMTP, FTP, PPPoE, DHCP, DDNS, NTP, UPnP,
3GPP, SAMBA, Bonjour
System
Video Resolution
1920x1080@60fps, 1280x720@60fps,
640x480@60fps, 320x240@60fps,
176x144@60fps
Video Adjust
Brightness, Contrast, Hue, Saturation,
Sharpness, AGC, Shutter Time, WDR, Flip,
Mirror, Day&Night adjustable, White Balance,
Denoise
Triple Streaming
Yes
Image snapshot
Yes

6
Full screen monitoring
Yes
Privacy Mask
Yes, 3 different areas
Compression format
H.264/ M-JPEG
Video bitrates adjust
CBR, VBR
Motion Detection
Yes, 3 different areas
Triggered action
Mail, FTP, Save to SD card, DO, Samba
Pre/ Post alarm
Yes, configurable
Security
Password protection, IP address filtering, HTTPS
encrypted data transmission, 802.1X port-based
authentication for network protection
Firmware upgrade
HTTP mode, can be upgraded remotely
Simultaneous connection
Up to 10
SD card management (option)
Recording trigger
Motion Detection, IP check, Network break down
(wire only), Schedule, DI
Video format
AVI, JPEG
Video playback
Yes
Delete files
Yes
Client System requirement
OS
Windows 7, 2000, XP, 2003, Microsoft IE 6.0 or
above, Chrome, Safari, Firefox
Mobile Support
iOS 4.3 or above, Android 1.6 or above.
Hardware Suggested
Intel Dual Core 2.8G,RAM: 4GB
*SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTIFICATION.

7
* Monitor Settings
1. Right-Click on the desktop. Select Properties
2. Change color quality to highest (32bit).
iii. Product Installation

8
* Hardware Installation
1. Connector Instruction
Open the cover to find the cable connectors inside the Camera.
Connect the power adaptor first, then connect the IP Camera to PC or
network, and set up the network configurations according to the
network environment.

9
2. Vandal Dome Installation Tips
The Unused cable outlet hole must be closed, and the waterproof
connector on the used hole must be locked closely.
For keeping the IP, when using separate cables for Power and
Internet, please use silicon in the cable gland, around the cables,
just as shown in the following picture, indicated in yellow color.
3. Adjusting the 3-Axis bracket
Use the 3-Axis bracket to adjust the camera to appropriate angle.

10
4. Closing the dome cover
When you mount the camera housing on the ceiling or wall, please use
the screws with the black rubber o-rings. Without the o-ring, the water
may seep into the machine.
Make sure there are no cables around the screws, and slowly lock the
four corners at the same time, applying equal force in every corner. Do
not totally lock one screw at a time; otherwise the closing might not be
equal in all four screws.
Before you close the dome cover, make sure that the black rubber
band sticks to the inside of the cover completely. Crook or uneven
rubber band may cause the waterproof defective.
Lock tightly the screws on the dome cover to ensure there's no gap
between the lid and base.

11
5. PoE ( Power Over Ethernet)(Optional) 802.3af, 15.4W PoE Switch is
recommended
Power over Ethernet (PoE) is a technology that integrates power into a
standard LAN infrastructure. It enables power to be provided to a network
device, such as an IP phone or a network camera, using the same cable
as that used for network connection. It eliminates the need for power
outlets at the camera locations and enables easier application of
uninterruptible power supplies (UPS) to ensure 24 hours a day, 7 days a
week operation.

12
*IP assignment
1. Open the software IP Scanner to assign the IP address of the IP Camera.
Find this software in the Applications folder in the software CD attached
to the product’s package.
2. IP Scanner supports two languages: This manual is for English version.
3. There are 3 kinds of IP configuration.
a. Fixed IP (Public IP or Virtual IP)
b. DHCP (Dynamic IP)
c. Dial-up (PPPoE)
4. Execute the IP Scanner.
5. For Windows XP SP2 or above, a Windows Security Alert may pop up.
Choose the network type based on your surveillance environment, and
click on Unblock.

13
6. IP Scanner configuration:
7. IP Scanner will search for all the IP Cameras connected on the LAN. The
user can click Search Device to search again.
8. Click one of the IP Cameras listed on the left side. The network
configuration of this IP camera will be shown on the right side once you
highlight the device with your mouse. You can change the name of the IP
Camera to your preference (e.g.: Office, warehouse). Change the
parameters and click Submit, then click OK, it will apply the changes and
reboot the device.
9. Please make sure the subnet of the PC IP address and the IP Camera IP
address are the same.
The same Subnet:
IP Camera IP address: 192.168.1.200
PC IP address: 192.168.1.100

14
Different Subnets:
IP Camera IP address: 192.168.2.200
PC IP address: 192.168.1.100
To Change the PC IP address:
Control PanelNetwork ConnectionsLocal Area Connection
PropertiesInternet Protocol (TCP/IP) Properties
Make sure your IP Camera and PC are in the same Subnet. If not,
change the IP Camera subnet or the PC IP subnet accordingly below.
10. To quickly access remote monitoring, left-click the mouse twice on the
selected IP Camera listed under Device list of IP Scanner. A default
network browser of the camera control interface will open.

15
11. Enter admin for both Username and Password to gain access.

16
*Install ActiveX control
1. For users of IE 6.0 or above:
When viewing the camera video for the first time via IE, the browser will ask
you to install the ActiveX component.
Choose ‘Allow’,
Then choose ‘Install’.
Start installing the ActiveX component.
If the installation fails, please check the security settings in the IE
browser.
Go to Start-Up Menu on the lower left corner of the Windows,
select Control Panel then Double-click on
to access to Internet Properties settings.

17
Starting from Internet Properties, proceeding step Aand B:
A. Security Custom Level Security Settings Download
unsigned ActiveX controls Enable or Prompt (recommended).
B. Security Custom Level Security Settings Initialize and
script ActiveX controls not marked as safe Enable or Prompt
(recommended).
1
2
3
4

18
5
When popup the following dialogue box, click Yes.
2. You can choose another way:
Go to: IE→Tools → Internet Options… → Security Tab → Trusted sites → Add the
IP address and click OK.
In the site list you can key one single IP address or a LAN address. For example,
if you add 192.168.21.*, all the IP address under 21.* on the LAN will be regarded
as trusted sites.

19
2. To Non-IE Web Browser Users
If you use Firefox or Google chrome to access the IP camera but fails to watch
the live video, please follow the steps to install necessary tools:
(The following pictures are based on chrome.)
a. You may see the prompt message as the picture below. Click the link:
Firstly, please install Microsoft Visual C++ 2010 Redistributable Package
(x86).
The link will conduct you to the Microsoft official site where you can download
the tools. Please select the language and click download.

20
In the pop-up window, please tick the first and the third file as the picture below.
Click Next to download both Microsoft .NET Framework 4 Client Profile (Web
Installer) and Microsoft Visual C++ 2010 Redistributable Package (x64).
After finishing downloading, execute the two files respectively to install them.
The windows may ask you to reboot the PC when the installation is finished.
b. Then, click the second link Please click here to download the installation
program which does not support IE browser to download Setup ActiveX.
