Yukon 62587 Assembly instructions

Visit our website at: http://www.harborfreight.com
Email our technical support at: [email protected]
62587
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual (or month and year of purchase if product has no number). Keep this manual and the
receipt in a safe and dry place for future reference. 22f
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright©2022 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.

Page 2 For technical questions, please call 1-888-866-5797. Item 62587
IMPORTANT SAFETY INFORMATION
Assembly Precautions
1. Assemble only according to these instructions.
Improper assembly can create hazards.
2. Wear ANSI-approved safety goggles and
heavy-duty work gloves during assembly.
3. Keep assembly area clean and well lit.
4. Keep bystanders out of the area during assembly.
5. Do not assemble when tired or when under the
influence of alcohol, drugs or medication.
6. Weight capacity and other product capabilities apply
to properly and completely assembled product only.
7. Assemble on a flat, level, hard and smooth surface
capable of safely supporting loaded Cart.
Use Precautions
TO PREVENT SERIOUS INJURY AND DEATH FROM TIPPING:
1. DO NOT SIT, STAND OR CLIMB ON THIS ITEM.
2. This product is not a toy nor a toy chest.
Do not allow children to play with or near this item.
3. Do not exceed weight capacities,
evenly distributed from bottom up.
Be aware of dynamic loading!
Sudden load movement may briefly create
excess load causing product failure.
4. Use only on a flat, level, hard and smooth surface
capable of safely supporting a fully loaded Cart.
Do not roll Cart over concrete seams
or other rough/uneven surfaces.
5. Do not lift using handle(s).
Do not lift while loaded.
6. Lock Swivel Casters after moving.
7. Do not mount on truck bed or
any other moving object.
8. Use as intended only.
9. Inspect before every use;
do not use if parts are loose or damaged.
10. Maintain product labels and nameplates.
These carry important safety information.
If unreadable or missing, contact
Harbor Freight Tools for a replacement.
SAVE THESE INSTRUCTIONS.
Specifications
Capacity 450 lb
Tray Depth 3-1/2"
Wheels 5" Rubber Casters
Dimensions 39" L x 24" W x 31-1/2" H

Page 3For technical questions, please call 1-888-866-5797.Item 62587
Assembly Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
Note: For additional information regarding the parts listed in the following pages, refer to the Assembly Diagram
near the end of this manual. 10mm, 14mm and 17mm sockets and/or wrenches are required for assembly.
Unwrap and separate all parts on a clear work area.
Attaching Posts to Bottom Tray
Lay the Bottom Tray (12) (the tray with four sets of four holes on the bottom) on the floor and attach the Posts
(15) to the outside corners of the tray using sixteen Bolts (2), Washers (5), Lock Washers (6), and Nuts (7).
Note: It is best to leave all nuts and bolts loose until assembly is finished, then tighten
all fasteners. This will make it easier to install and align all components.
Bottom Tray
(12)
Post (15)
Bolt (2) Washer (5)
Lock Washer
(6)
Nut (7)

Page 4 For technical questions, please call 1-888-866-5797. Item 62587
Attaching Top Tray
Attach Top Tray (4) to the other end of the legs using
twelve Bolts (2), Washers (5), Lock Washers (6), and
Nuts (7). (Four holes on one end of the top tray are
reserved for attaching the Handle in the next step.)
Top Tray (4)
Bolt (2)
Washer (5)
Post (15)
Lock Washer (6)
Nut (7)
Note: For ease of assembly,
set the Cart on its side and
work on two legs at a time.
Attaching Handle
Assemble the Handle Brackets (3) onto ends
of Handle (1) and attach Handle to end of
Posts (15) using the Bolts (2), Washers (5),
Lock Washers (6), and Nuts (7).
Bolt (2)
Washer (5)
Handle Bracket (3)
Post (15)
Lock Washer (6)
Nut (7)
Handle (1)

Page 5For technical questions, please call 1-888-866-5797.Item 62587
Attaching Casters
1. Decide on which end of the cart to mount the
pair of Rigid Casters (11) and pair of Swivel
Casters (14). For example, mounting the Fixed
Casters on the Handle end of the Cart will make
a push cart like those in a grocery store.
2. Attach each Fixed Caster to one end of the
Bottom Tray using four Bolts (8), Washers
(10), Lock Washers (9) and Nuts (13).
3. Attach each Swivel Caster to the remaining
end of the Bottom Tray using the remaining
Bolts (8), Lock Washers (9) and Nuts (13).
4. Make sure all fasteners are tight.
Bolt (8)
Rigid Caster (11)
Lock Washer (6)
Nut (7)
Bottom Tray (12)
Swivel Caster (14)
Washer (5)
Washer (5)

Page 6 For technical questions, please call 1-888-866-5797. Item 62587
Operation Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this document
including all text under subheadings therein before set up or use of this product.
1. Fill Cart evenly, from bottom to top.
Do not exceed weight capacities.
2. Close all Drawers and lock them.
3. Unlock Swivel Casters.
4. Roll Cart to a flat, level, hard and smooth
surface capable of safely supporting a fully
loaded Cart. Do not roll Cart over concrete
seams or other rough/uneven surfaces.
5. Lock Swivel Casters.
Maintenance and Servicing
Procedures not specifically explained in this manual must
be performed only by a qualified technician.
TO PREVENT SERIOUS INJURY FROM TOOL FAILURE:
Do not use damaged equipment. If any part becomes damaged,
have the problem corrected before further use.
1. PERIODICALLY, inspect the general
condition of the Cart. Check for:
• loose hardware,
• misalignment or binding of moving parts,
• caster swivel function and movement,
• cracked or broken parts,
• any other condition that may
affect its safe operation.
2. Wipe external surfaces of the Cart with clean cloth.

Page 7For technical questions, please call 1-888-866-5797.Item 62587
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS DOCUMENT AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Parts List and Assembly Diagram
Part Description Qty
1 Handle 1
2 Bolt 32
3 Handle Bracket 2
4Top Tray 1
5 Washer 32
6 Lock Washer 32
7 Nut 32
8 Bolt 16
Part Description Qty
9 Lock Washer 16
10 Washer 32
11 Rigid Caster 2
12 Bottom Tray 1
13 Nut 16
14 Swivel Caster 2
15 Post 4
4
5
6
7
8
9
10
11
12
13
1
23
14
15
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not available
individually as replacement parts. Specify UPC 193175485090 when ordering parts.

Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards,
and warrants to the original purchaser that this product is free from defects in materials and workmanship for the
period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly,
to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper
installation, normal wear and tear, or to lack of maintenance. We shall in no event be liable for death, injuries
to persons or property, or for incidental, contingent, special or consequential damages arising from the use of
our product. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation of exclusion may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with transportation charges
prepaid. Proof of purchase date and an explanation of the complaint must accompany the merchandise.
If our inspection verifies the defect, we will either repair or replace the product at our election or we may
elect to refund the purchase price if we cannot readily and quickly provide you with a replacement. We will
return repaired products at our expense, but if we determine there is no defect, or that the defect resulted
from causes not within the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
26677 Agoura Road • Calabasas, CA 91302 • 1-888-866-5797
